578
Camper infor mation
Center of gravity locationThe figures given in the illustration indicate the recommended center
of gravity zone. Recommended location for
cargo center of gravity for
cargo weight rating
Rear end of truck bed
*: Truck-campers cannot be used with the X-Runner since it is not
designed for them.
This information has been prepared in accordance with regula-
tion issued by the National Highway Traffic Safety Administration
of the U.S. Department of Transportation. It provides the purchas-
ers and/or prospective purchasers of Toyota vehicles with infor-
mation on truck-camper loading. Your Toyota dealer will help
answer any questions you may have as you read this informa-
tion.
Regular Cab models 49.9 in. (1267 mm) 36.1 in. (917 mm)
Access Cab models Except X-Runner
X-Runner
*
49.9 in. (1267 mm) — 36.1 in. (917 mm)
—
Double Cab models With short deck
With long deck 45.6 in. (1157 mm)
35.9 in. (911 mm) 31.8 in. (807 mm)
27.8 in. (706 mm)
579
7
For owners
Cargo weight rating and proper matchingWhen the truck is used to carry a slide-in camper, the total cargo load
of the truck consists of the manufacturer’s camper weight figure, the
weight of installed additional camper equipment not included in the
manufacturer’s camper weight figu re, the weight of camper cargo,
and the weight of passengers in the camper.
The total cargo load should not exceed the truck’s cargo weight rating
and the camper’s center of gravity should fall within the truck’s rec-
ommended center of gravity zone when installed.
Camper center of gravity
Recommended center of grav-
ity location zone
■ Cargo weight rating
Regular Cab models
3 people, 2TR-FE engine, 2WD: 700 lb. (317 kg)
2 people, 2TR-FE engine, 4WD: 1000 lb. (453 kg)
3 people, 2TR-FE engine, 4WD: 850 lb. (385 kg)
CAUTION
■Loading precaution
If a load is too far back, it can cause dangerous handling. If it is too far
forward, the front axle may be overloaded.
