RS3200 PLUS
SECURITY SYSTEM DESIGNED FOR
USE WITH YOUR VEHICLE’S REMOTE
KEYLESS ENTRY SYSTEM
Owner's Guide
04-16-12
090002-3413A700
Page 2 of 12
Page 1 TOYOTA — RS3200 PLUS Security System
TABLE OF CONTENTS
To better understand the features and functions of this security system, \
please read this
Owner’s Guide completely prior to use.
DESCRIPTION PAGE
INTRODUCTION 2
BRIEF DESCRIPTION–RS3200 PLUS FEATURES 3, 4
OPERATION
ARMING THE RS3200 PLUS 5
DISARMING THE RS3200 PLUS 6
AUTOMATIC REARMING 7
ARMING SUSPENSION 7
ALARM INFORMATION
ALARM TRIGGERS 8
ALARM DESCRIPTIONS 9
STOPPING AN ALARM 9
GLASS BREAKAGE SENSOR INFORMATION
GLASS BREAKAGE SENSOR CHECK PROCEDURE 10
WARNING and CAUTION INFORMATION 11
Page 3 of 12
TOYOTA — RS3200 PLUS Security System Page 2
INTRODUCTION
Congratulations on your choice of the RS3200 PLUS add-on security system\
to
protect your vehicle! To get the most from the system, we strongly recommend that
you read this Owner’s Guide completely to learn all of its features and functions.
The RS3200 PLUS provides security through point-of-entry monitoring, gla\
ss
breakage detection and ignition switch monitoring. While ARMED, the system
will be TRIGGERED and sound an ALARM when a door, trunk or hatch is forcibly
unlocked or opened, or when a window is tapped on or broken. During the \
ALARM,
the vehicle’s horn sounds and the headlights, tail lights and front marker or turn
signal lights flash. Also, the vehicle’s starter is disabled, preventing engine start. In
addition to the comprehensive protection, the RS3200 PLUS works in conju\
nction
with your vehicle’s remote keyless entry system, enabling you to ARM and DISARM
the security system at the same time the doors are remotely locked and u\
nlocked. In
vehicles equipped with a buzzer, it will chirp when the system is REMOTE ARMED
and DISARMED.
An important note about your system:
Throughout this guide, there are references to the STATUS MONITOR for this
system. Illustrated below, this panel holds the LED indicator (for the system’s
operating status) and the GLASS BREAKAGE SENSOR’S microphone. In veh\
icles
equipped with an engine immobilizer system, there is a LED already insta\
lled, so the
RS3200 PLUS utilizes the vehicle’s engine immobilizer system LED instead and a
microphone mounted in a separate location. If your vehicle falls into th\
is category,
remember to look at that LED when the information refers to the STATUS MONITOR.
If you do not know where the LED is located, refer to your vehicle’s owner’s guide for
specific information.
123123123
Your engine immobilizer system led may look
different than the one illustrated here
Page 4 of 12
Page 3 TOYOTA — RS3200 PLUS Security System
BRIEF DESCRIPTION–RS3200 PLUS FEATURES
FEATURESFUNCTIONS
REMOTE ARMING /
DISARMING The RS3200 PLUS will ARM 30 seconds after the lock but
-
ton on the remote keyless entry system’s remote control is
pressed, and DISARM when the unlock button is pressed. If
your vehicle is equipped with a buzzer that chirps when the
lock and unlock buttons on the remote controls are pressed,
the buzzer will also chirp when the system is REMOTE ARMED
and DISARMED.
AUTOMATIC
REARMING The RS3200 PLUS will automatically REARM at the same time
the vehicle’s remote keyless entry system relocks the vehicle’s
doors, if no door is opened within 30 seconds after REMOTE
DISARMING.
KEY ARMING /
DISARMING The RS3200 PLUS will ARM 30 seconds after you close the
trunk (if open) and lock the vehicle’s doors with the key, and will
DISARM when you unlock a door with the key.
ARMED MODE
SUSPENSION** While ARMED, the trunk may be opened with the key (or trunk
release button on your remote control, if so equipped) without
TRIGGERING an ALARM. Once the open trunk is closed, the
system ARMS again.
MANUAL ARMING When you lock the vehicle with the central lock switch (while
a door is open), the RS3200 PLUS will ARM 30 seconds after
you close all the doors and the trunk (if open).
IGNITION KEY
DISARMING The RS3200 PLUS may be DISARMED by inserting the key
into the ignition switch and turning it to “ON.”
POINT-OF-ENTRY
PROTECTION Forcibly unlocking or opening a door or trunk while the RS3200
PLUS is ARMED will TRIGGER an ALARM immediately.
GLASS
BREAKAGE
SENSOR The RS3200 PLUS utilizes a microphone (usually mounted in
the STATUS MONITOR) to sense the noise from tapping on
window glass, or glass breaking, and TRIGGER the system
to sound an ALARM. It is fine tuned to “listen” for this type of
noise, and ignore other sounds.
WARN AWAY
ALARM When the GLASS BREAKAGE SENSOR’S microphone picks
up tapping or breaking of window glass, it TRIGGERS a WARN
AWAY ALARM; the headlights and tail and marker or turn signal
lights flash, and the horn sounds for 20 seconds, but the starter
is not disabled. If there is another detection of glass tapping or
breaking, or if a door is opened or unlocked without a key, the
regular ALARM is TRIGGERED.
** Starting from 2002 M.Y., Arming Suspension Mode by using the key to unlock the
trunk is not applicable to Camry, Solara, and Corolla.
Page 5 of 12
TOYOTA — RS3200 PLUS Security System Page 4
BRIEF DESCRIPTION–RS3200 PLUS FEATURES
FEATURESFUNCTIONS
IGNITION
SWITCH
MONITORING While ARMED, the RS3200 PLUS monitors the ignition switch. If
an attempt is made to start the vehicle without a key, an ALARM
is TRIGGERED.
STARTER
DISABLE When an ALARM is TRIGGERED, the system disables the ve-
hicle’s starter and prevents engine start until the system is reset
(DISARMED).
FORCED LOCK
DURING ALARM During an ALARM, the system will lock the doors if one is un
-
locked, and will continue to do so for the duration of the ALARM.
TRIGGER
MEMORY* The user is notified that an ALARM occurred. Upon DISARMING
the system after an ALARM was TRIGGERED, the vehicle’s tail
and marker lights will be turned on for 2 seconds.
EXTERIOR
LIGHT
ACTIVATION The RS3200 PLUS flashes the vehicle’s tail and marker or turn
signal lights during REMOTE ARMING and REMOTE DISARM-
ING, and during an ALARM. Also, during an ALARM the head
-
lights flash.
BUZZER
ACTIVATION If your vehicle is equipped with a buzzer that chirps when the lock
and unlock buttons on the remote keyless entry system’s remote
controls are pressed, the buzzer will also chirp when the system
is REMOTE ARMED and DISARMED.
HORN
ACTIVATION During an ALARM, the RS3200 PLUS activates the vehicle’s
horn.
POWER LOSS
MEMORY If power to the RS3200 PLUS is disrupted while it is ARMED, an
ALARM is TRIGGERED once power is restored.
STATUS
MONITOR This panel houses the GLASS BREAKAGE SENSOR micro
-
phone and the flashing LED that indicates the operating status
of the security system. (Some vehicle applications utilize the
vehicle’s engine immobilizer system LED and a separate micro -
phone, instead.)
* TRIGGER MEMORY is not available for Corolla / Matrix.
Page 6 of 12
Page 5 TOYOTA — RS3200 PLUS Security System
OPERATION
ARMING THE RS3200 PLUS
The system may be ARMED in several ways. Do one of the following: Lock the doors with your key:
Remove the key from the ignition switch. Exit the vehicle, and
close all the doors.* Close the trunk or hatch, if necessary.* Insert
the key into the door key switch and turn it toward the front of the
vehicle: The STATUS MONITOR’S LED turns on for 30 seconds,
then starts flashing.** The system is now ARMED.
Lock the doors from inside the vehicle:
Remove the key from the ignition switch. Open the driver’s or
front passenger’s door. Push the central lock switch. Exit the
vehicle, and close all the doors.* Close the trunk or hatch, if
necessary.* Then: The STATUS MONITOR’S LED turns on for 30 seconds,
then starts flashing.** The system is now ARMED.
Lock the doors with the remote control:
Remove the key from the ignition switch. Exit the vehicle, and
close all the doors.* Close the trunk or hatch, if necessary.* Press
the lock button on the remote control. Simultaneously: The doors lock.
The vehicle’s tail and marker or turn signal lights flash once.
The vehicle’s buzzer chirps once.Δ
The STATUS MONITOR’S LED turns on for 30 seconds,
then starts flashing.** The system is now ARMED.
* The system will not ARM while any of the doors, trunk or hatch is open.
Δ If your vehicle is equipped with a buzzer.
** For some vehicles the LED flashes during and after the 30 seconds (pre-arming).
123
123
123
123
123
Turn toward the front of the vehicle.
Press and releasethe lock button.
Push the lock
switch while the
door is open.
Lights for 30 seconds
(pre-arming) then startsflashing** (System Armed)123
The tail and marker or turn signal
lights flash once when the system is
remote armed.
123
All doors lock when
the system is remote
armed.
123
Page 7 of 12
TOYOTA — RS3200 PLUS Security System Page 6
OPERATION
DISARMING THE RS3200 PLUS
The system may be DISARMED in several ways. Do one of the following:
Unlock the doors with your key:
Insert the key into the door key switch and turn it toward the rear
of the vehicle:
The STATUS MONITOR’S LED stops flashing.*
The system is now DISARMED.*
In the case of Highlander, Sienna, and 4Runner, you may also
disarm the system using the key in the back door; all doors will
unlock at the same time.
Unlock the doors with the remote control:
Press the unlock button on the remote control. Simultaneously:
The driver’s door unlocks.
The vehicle’s tail and marker or turn signal lights flash twice.
The vehicle’s buzzer chirps twice.Δ
The STATUS MONITOR’S LED stops flashing.*
The system is now DISARMED.*
Press the unlock button again within 3 seconds after unlocking
the driver’s door to unlock the remaining doors.
Use the ignition switch:
Insert the key into the ignition switch, then turn it to ON:
The STATUS MONITOR’S LED stops flashing.
The system is now DISARMED.
This method of disarming is rarely used. You must be inside the
vehicle while the system is armed in order to do it.
NOTE: If your vehicle’s tail and marker or turn signal lights turn on for 2 seconds when the system is DISARMED, the TRIGGER MEMORY was activated; something
TRIGGERED an ALARM while you were away from the vehicle. This feature is
not available for Corolla / Matrix.
* Please note, if the system utilizes your vehicle’s engine immobilizer system LED instead of the STATUS MONITOR, the LED will continue to flash.
Δ If your vehicle is equipped with a buzzer.
123
123
123
123
123
Turn toward the rear of the vehicle.
Turn the key to “on”
to disarm the system
Push the unlock Button.
The driver’s door un-
locks when the system
is remote disarmed The tail and marker or turn signal
lights flash twice when the system
is remote disarmed
Stops
flashing
when the system is
disarmed
123123123
Page 8 of 12
Page 7 TOYOTA — RS3200 PLUS Security System
OPERATION
AUTOMATIC REARMING
When you unlock the doors using the remote control, the RS3200 PLUS is D\
ISARMED
at the same time. However, if you do not open a door or the trunk within 30 seconds,
the keyless entry system will relock the doors and the RS3200 PLUS will \
REARM 30
seconds later.
How the RS3200 PLUS automatically REARMS:
ARMING SUSPENSION** The ARMED state of the RS3200 PLUS can be suspended temporarily by using the\
key to unlock and open the trunk. If your remote control is so equipped,\
you may also
suspend the ARMED state using the trunk release button to open the trunk. When
the ARMING is suspended, the STATUS MONITOR’S LED will turn off until the
trunk is closed again. ** Starting from 2002 M.Y., Arming
Suspension Mode by using the key
to unlock the trunk is not applicable
to Camry, Solara, and Corolla.
* For some vehicles the LED
flashes during and after the 30
seconds (pre-arming).
0
15
30
45
The doors are unlocked by
pressing the
unlock button
on the remote control... When no door,
trunk or hatch is opened... For more than
30 seconds... The keyless entry
system automati- cally relocks the doors, then the
RS3200 plus auto -
matically rearms. The led will
light up for
30 seconds
(pre-arm), then
flash* when the
system is armed
123
Turns off whenThe
armed
state is
suspended
Opening the trunk
suspends the armed state of the security system
123
123
123
0
15
30
45
Page 9 of 12
TOYOTA — RS3200 PLUS Security System Page 8
ALARM INFORMATION
ALARM TRIGGERS
While the system is ARMED, an ALARM will be TRIGGERED when any of the following
occurs:
Forcibly opening a door, or the trunk or hatch without a key
Pulling the trunk release lever inside the vehicle will also
TRIGGER an ALARM.
Manually unlocking a door
Manually operating an inside lock button will TRIGGER an
ALARM.
Note: Because this action will TRIGGER an ALARM, it is important that you do not ARM the system while
someone is in the vehicle.
Pressing the Start Button
If the start button is pressed while the vehicle is ARMED, an
ALARM will be TRIGGERED.
“Hot wiring” the vehicle
The RS3200 PLUS can detect the absence of the ignition key if
the ignition circuit is shorted in attempt to start the vehicle.
Tapping on or breaking the glass
The noise from tapping on, or breaking of glass TRIGGERS a
WARN AWAY ALARM first, then a regular ALARM. See the de-
scription of how the GLASS BREAKAGE SENSOR TRIGGERS
ALARMS on page 9.
Power restoration
If power to the system is interrupted while it is ARMED, an
ALARM will be TRIGGERED immediately when power is
restored.
ENGINE
START STOP
Page 10 of 12
Page 9 TOYOTA — RS3200 PLUS Security System
ALARM INFORMATION
ALARM DESCRIPTIONS
Regular ALARM
When an ALARM is triggered in any way other than initial detection by the GLASS \
BREAKAGE SENSOR, the following occur:
The horn sounds repeatedly for 60 seconds.
The headlights flash repeatedly for 60 seconds.
The tail and marker or turn signal lights flash repeatedly for 60 seconds.
The starter is disabled (no engine start) until the system is DISARMED\
.
The door lock will be relocked if someone reaches in and unlocks the ins\
ide
lock button.
After 60 seconds of ALARM, the system will REARM and continue to protect
the vehicle.
WARN-AWAY ALARM
Upon initial detection of noise from tapping on, or breaking glass, the GLASS BREAK-
AGE SENSOR TRIGGERS a WARN AWAY ALARM: The horn sounds repeatedly for 20 seconds.
The headlights flash repeatedly for 20 seconds.
The tail and marker or turn signal lights flash repeatedly for 20 seconds.
If the GLASS BREAKAGE SENSOR detects noise again, or if a door or trunk \
is
opened while the system is still ARMED, the regular ALARM (described above) is
activated.
STOPPING AN ALARM Simply DISARM the system using the remote control or key as described on\
page 6.
The horn
sounds for
20 seconds Tail or turn signal
lights flash for 20
seconds
123
Headlights flash for 20 secondsMarker or turn
signal lights flash for 20 seconds
The horn
sounds for 60 secondThe starter is
disabled until the
system is disarmed
Marker or turn
signal lights flash for 60 seconds Tail or turn
signal lights flash for 60 seconds
123
Head lights flash for 60 seconds
123
123
