seat adjustment TOYOTA TACOMA 2018 Owners Manual (in English)

Pictorial indexSearch by illustration
1For safety
and securityMake sure to read through them
2Instrument
clusterHow to read the gauges and meters, the variety of
warning lights and indicators, etc.
3
Operation of
each
componentOpening and closing the doors and windows,
adjustment before driving, etc.
4DrivingOperations and advices which are necessary for
driving
5MultimediaOperating the multimedia system
6Interior featuresUsage of the interior features, etc.
7Maintenance
and careCaring for your vehicle and maintenance
procedures
8When trouble
arisesWhat to do in case of malfunction or emergency
9Vehicle
specificationsVehicle specifications, customizable features, etc.
10For ownersReporting safety defects for U.S. owners, and seat
belt and SRS airbag instructions for Canadian
owners
IndexSearch by symptom
Search alphabetically

271-1. For safe use
1
For safety and security
WARNING
Observe the following precautions.
Failure to do so may result in death or serious injury.
●Do not adjust the position of the driver’s seat while driving.
Doing so could cause the driver to lose control of the vehicle.
● Do not place a cushion between the driver or passenger and the seatback.
A cushion may prevent correct posture from being achieved, and reduce
the effectiveness of the seat belt and head restraint.
● Do not place anything under the front seats.
Objects placed under the front seats may become jammed in the s eat
tracks and stop the seat from locking in place. This may lead t o an acci-
dent and the adjustment mechanism may also be damaged.
● Always observe the legal speed limit when driving on public roads.
● When driving over long distances, take regular breaks before yo u start to
feel tired.
Also, if you feel tired or sleepy while driving, do not force y ourself to con-
tinue driving and take a break immediately.

1313-3. Adjusting the seats
3
Operation of each component
Front seats
When the occupant’s back
presses against the seatback
during a rear-end collision, the
head restraint moves slightly for-
ward to help reduce the risk of
whiplash on the seat occupant.
Adjustment procedure
Seat position adjustment lever
Seatback angle adjustment
lever Seat lumbar support adjust-
ment knob
Active head restraints
1
2
3

1323-3. Adjusting the seats
■Active head restraints
Even small forces applied to the seatback may cause the head re straint to
move. Pushing up a locked head restraint forcibly may show the head
restraint inner structure. These do not indicate problems.
WARNING
■ When adjusting the seat position
● Take care when adjusting the seat position to ensure that other passen-
gers are not injured by the moving seat.
● Do not put your hands under the seat or near the moving parts t o avoid
injury.
Fingers or hands may become jammed in the seat mechanism.
■ Seat adjustment
● To reduce the risk of sliding under the lap belt during a collision, do not
recline the seat more than necessary.
If the seat is too reclined, the lap belt may slide past the hi ps and apply
restraint forces directly to the abdomen, or your neck may cont act the
shoulder belt, increasing the risk of death or serious injury in the event of
an accident.
Adjustments should not be made while driving as the seat may un expect-
edly move and cause the driver to lose control of the vehicle.
● After adjusting the seat, make sure that the seat is locked in position.
■ When adjusting the seat positions
Make sure to leave enough space around the feet so they do not get stuck.
Inner
structure
During
rear-end
collision

1363-3. Adjusting the seats
Head restraints
Vertical adjustmentUp
Pull the head restraints up.
Down
Push the head restraint down while
pressing the lock release button.
Access Cab models
Folding the head restraints
To u s e
Lift up the head restraint until it
locks.
To f o l d
Pull the head restraint lock release
lever to fold the head restraint.
Head restraints are provided for all seats.
Front seats
Lock release button
1
2
Rear seats
1
2

1373-3. Adjusting the seats
3
Operation of each component
Double Cab models
Folding the head restrains (outer head restraints)
To u s e
Lift up and push down the head
restraint to the lowest lock position.
To f o l d
Pull the head restraint up while
pressing the lock release buttons.
Vertical adjustment (c enter head restraint)
Up
Pull the head restraints up.
Down
Push the head restraint down while
pressing the lock release button.
Lock release button
1
2
Lock release button
N
O

686Alphabetical index
Engine switch (ignition switch)............. 193, 196
Engine switch light
(ignition switch light) ............ 441
Event data recorder (EDR) ........ 10
Flat tire...................................... 594
Floor mats .................................. 24
Fluid Automatic transmission......... 631
Brake .................................... 632
Power steering ...................... 632
Washer ................................. 518
Fog lights ................................. 220 Replacing light bulbs............. 549
Switch ................................... 220
Wattage ................................ 634
Four-wheel drive system ........ 299
Front passenger occupant
classification system .............. 45
Front personal lights ............... 442
Front seats ............................... 131
Adjustment ............................ 131
Cleaning................................ 494
Correct driving posture ........... 26
Head restraints ..................... 136
Seat heaters ......................... 439
Front side marker lights Light switch ........................... 211
Replacing light bulbs............. 547
Wattage ................................ 634
Front turn signal lights Replacing light bulbs............. 548
Turn signal lever ................... 209
Wattage ................................ 634 Fuel ........................................... 626
Capacity................................ 626
Fuel gauge.............................. 90
Fuel pump shut off system ... 565
Information............................ 635
Refueling .............................. 224
Type...................................... 626
Warning light......................... 567
Warning message................. 577
Fuel consumption
Average fuel consumption ................. 95, 101
Current fuel
consumption ................. 95, 101
Fuel filler door ......................... 226
Fuel pump shut off system..... 565
Fuses ........................................ 540
Garage door opener ................ 478
Gas station information .......... 696
Gauges ....................................... 90
Glove box ................................. 445
Grocery bag hooks.................. 460
F
G

690Alphabetical index
OpenerHood ..................................... 505
Outside rear view mirrors ....... 145
Adjusting and folding ............ 145
Blind spot monitor ................. 291
Outside rear view mirror defoggers ......... 428, 435
Outside temperature display ...................................... 90
Overhead console ................... 446
Overheating.............................. 617
Parking assist sensors
(intuitive parking assist) ....... 275
Parking brake ........................... 210
Operation .............................. 210
Parking brake engaged warning buzzer ................... 567
Parking brake engaged warning message ............... 580
Parking lights ........................... 211
Light switch ........................... 211
Replacing light bulbs..... 548, 553
Wattage ................................ 634
PCS (Pre-Collision System) .......... 235 Pre-collision brake assist ...... 236
Pre-collision braking ............. 236
Pre-collision warning............. 236
Warning light ......................... 568
Personal lights ......................... 442 Wattage ................................ 634
Power back window ................ 151
Power mode switch ................. 203 Power outlets ................... 464, 465
Power steering fluid ................ 514
Power windows ....................... 147
Jam protection function ........ 148
Operation .............................. 147
Power back window switch ................................. 151
Window lock switch .............. 147
Pre-Collision System (PCS).... 235
Radar cruise control (dynamic radar cruise control) ............. 257
Radiator .................................... 513
Radio
*...................................... 355
Rear differential
lock system ........................... 305
Rear seat Adjustment precautions ........ 135
Child seats/child restraint
system installation . ............... 55
Cleaning ............................... 494
Folding down ........................ 133
Head restraints ..................... 136
Raising the bottom
cushion ............................... 133
Rear side marker lights........... 211 Light switch ........................... 211
Replacing light bulbs ............ 551
Wattage ................................ 634
Rear step bumper .................... 122
Rear turn signal lights ............ 209
Replacing light bulbs ............ 551
Turn signal lever ................... 209
Wattage ................................ 634
Rear view mirror Inside rear view mirror .......... 142
Outside rear view mirrors ..... 145
Rear view monitor system ...... 281
P
R

691Alphabetical index
Refueling .................................. 224Capacity ................................ 626
Fuel types ............................. 626
Opening the fuel tank cap ..... 226
Replacing Electronic key battery ........... 537
Fuses .................................... 540
Light bulbs ............................ 543
Tires ...................................... 594
Wireless remote control battery ................................ 537
Reporting safety defects for U.S. owners ...................... 660
Resetting the remainder light or message indicating
maintenance is required ....... 498
Seat belt reminder light........... 567
Seat belts.................................... 28 Adjusting the seat belt ............ 29
Automatic Locking Retractor (ALR) .................... 30
Child restra int system
installation ............................ 55
Cleaning and maintaining the seat belt ........................ 495
Emergency Locking
Retractor (ELR) .................... 30
How to wear your seat belt ..... 28
How your child should wear the seat belt .......................... 30
Pregnant women, proper seat belt use ......................... 31
Reminder light and buzzer .... 567
Seat belt extender................... 30
Seat belt pretensioners ........... 29
SRS warning light ................. 566 Seat heaters ............................. 439
Seating capacity ...................... 174
Seats, Front.............................. 131
Adjustment............................ 131
Adjustment precautions ........ 132
Cleaning ............................... 494
Head restraints ..................... 136
Properly sitting in the seat ...... 26
Seat heaters ......................... 439
Seats, Rear ............................... 133
Adjustment precautions ........ 135
Child seats/child restraint system installation . ............... 55
Cleaning ............................... 494
Folding down ........................ 133
Head restraints ..................... 136
Raising the bottom cushion ............................... 133
Sensor
Automatic headlight system .......... ...................... 213
Automatic High Beam ........... 215
Camera sensor ..................... 230
Inside rear view mirror .......... 144
Intuitive parking assist .......... 275
LDA
(Lane Departure Alert) ....... 249
Radar sensor ........................ 230
Shift lever ......................... 201, 207 Automatic transmission ........ 201
If the shift lever cannot be shifted from P .... 205
Manual transmission............. 207
S mode ................................. 204
Shift lock system ..................... 205
Side airbags ............................... 35
S
*: For vehicles with Entune Audio Plus or Entune Premium Audio, refer to
the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”
