TOYOTA tC 2006 Owners Manual (in English)

123
OPERATION OF INSTRUMENTS AND
CONTROLS
Other equipment
Clock124
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . .
Outside temperature display 124
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio remote controls (steering switches) 124
. . . . . . . . . . . . . . . . . . . . .
AUX jack 125
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . .
Cigarette lighter 125
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . .
Power outlet 125
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . .
Glove box 126
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . .
Auxiliary box 126
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . .
Rear console box 127
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . .
Cup holders 127
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . .
Tie–down hooks 128
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . .
Grocery bag hooks 128
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . .
Luggage storage box 129
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . .
Luggage cover 129
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . .
Floor mat 130
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . .
Side mudguard 131
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . .
SECTION 1– 9

124
Clock
The digital clock indicates the time with
the ignition off. To reset the time, the
ignition key must be in the “ON” position.
To reset the hour: Push the “H” button.
To reset the minutes: Push the “M” button.
If the electrical power source has been
disconnected from the clock, the time dis-
play will automatically be set to 1:00.
When the key is in the “ON” position,
push the “OUTSIDE TEMP” button to
change the display from clock to outside
temperature display. (See “Outside temper-
ature display” in this page.)
19T002
The key must be in the “ON” position.
To change the display from clock to out-
side temperature display, push the “OUT-
SIDE TEMP” button. The display changes
between clock and outside temperature
display alternately each time you push the
switch. (See “Clock” in this page.)
The displayed temperature ranges from
–30C (–22 F) up to 50 C (122 F).
When you return the key to the “ACC”
position, the display returns to clock
mode.
If there is a problem with the connection
to the outside air temperature sensor,
“– –” will appear on the display. Contact
your Scion dealer.
19T025
Steering switches are installed on the left
side of the steering wheel.
You can use these switches to operate
the audio volume control, radio, CD player
and so on.
For more detailed information, see the
separate “SCION Audio System Owner ’s
Manual”.
CAUTION
Operate the switches with due care
while you are driving to avoid acci-
dents.
Outside temperature display Audio remote controls
(steering switches)

125
19T026
An AUX jack is installed in the rear
console box.
By inserting a mini jack into the AUX
jack, you can listen to music from a por-
table audio device through the vehicle’s
speaker system.
For more detailed information, see the
separate “SCION Audio System Owner ’s
Manual”.
Cigarette lighter
To use the cigarette lighter, press it in.
After it finishes heating up, it automati-
cally pops out ready for use.
If the engine is not running, the key must
be in the “ACC” position.
Do not hold the cigarette lighter pressed
in.
Use a genuine cigarette lighter or equiva-
lent for replacement.
19T027
The power outlet located in the lower
box contained in the rear console box
is designed for power supply for car
accessories.
The ignition switch must be in the “ACC”
or “ON” position for the power outlet to be
used.
AUX jackPower outlet

126
NOTICE
To prevent the fuse from being
blown, do not use the electricity
over the total vehicle capacity of
12V/120W.
 To prevent the battery from being
discharged, do not use the power
outlet longer than necessary when
the engine is not running.
 Close the power outlet lid when the
power outlet is not in use. Inserting
anything other than an appropriate
plug that fits the outlet, or allowing
any liquid to get into the outlet may
cause electrical failure or short cir-
cuits.
Glo ve bo x
19T024
To use the glove box, do this.
To open: Pull the lever.
To lock: Insert the master key and turn it
clockwise.
CAUTION
To reduce the chance of injury in
case of an accident or a sudden stop,
always keep the glove box door
closed while driving.
Auxiliary box
To use the auxiliary box, open it as
shown in the illustrations.
CAUTION
To reduce the chance of injury in
case of an accident or a sudden
stop, always keep the auxiliary box
closed while driving.
Do not use the auxiliary box as an
ashtray.

127
19T019
UPPER TRAY
To use the upper tray, raise the console
box lid without touching the lock re-
lease lever.
19T020
CONSOLE BOX
To use the rear console box, pull up
the lock release lever while raising the
rear console box lid.
CAUTION
To reduce the chance of injury in
case of an accident or a sudden stop,
always keep the console box closed
while driving.
Cup holders
Front
Rear
Rear console box

128
The cup holder is designed for holding
cups or drink–cans securely in its
holes.
CAUTION
Do not place anything else other than
cups or drink–cans in the cup holder,
as such items may be thrown about
and possibly injure people in the ve-
hicle during sudden braking or in an
accident.19T021
To secure your luggage, use the tie–
down hooks as shown above.
See “—Stowage precautions” on page 157
for precautions when loading luggage.
CAUTION
To avoid personal injury, keep the tie–
down hooks retracted when not in
use.
19T010
On quarter trims on both sides
19T011a
Both sides of luggage compartment
Tie–down hooksGrocery bag hooks

129
These hooks are designed to hang
things like grocery bags.
NOTICE
To prevent damage to the hook, do
not hang any object heavier than 4 kg
(8.8 lb.) on it.
19T012
UNLOCK UNLOCK
LOCK LOCK
To open the luggage storage box, turn
the knobs to the “UNLOCK” position
and open the lid. To close the luggage
storage box, lower the lid and turn the
knobs to the “LOCK” position.
CAUTION
To reduce the chance of injury in
case of an accident or a sudden stop,
always keep the luggage storage box
closed and locked while driving.
19T016
Luggage storage box Luggage cover

130
To use the luggage cover:1. Hook the back of the luggage cover.
2. Attach the front hooks of the lug- gage cover to the head restraint.
If the luggage cover cannot be hooked,
recline the rear seats a little.
CAUTION
Do not place anything on the luggage
cover. Such items may be thrown
about and possibly injure people in
the vehicle during sudden braking or
a collision.
19T017
To remove the luggage cover: 1. Unhook the back of the luggage cov- er.
2. Pull the cover toward the back.
When you remove the luggage cover,
place it somewhere other than the passen-
ger compartment. This will prevent pas-
sengers from being injured in the event of
a sudden stop or an accident.
Floor mat
19T014
Use a floor mat of the correct size.
If the floor carpet and floor mat have 2
holes, then they are designed for use with
locking clips. Fix the floor mat with lock-
ing clips into the holes in the floor carpet.

131
19T015
CAUTION
Make sure the floor mat is properly
placed on the floor carpet. If the floor
mat slips and interferes with the
movement of the pedals during driv-
ing, it may cause an accident.
19T023
The side mudguard is designed to pre-
vent mud from sticking to the vehicle
body while driving.
NOTICE
Do not step on the side mudguard, or
your vehicle may be damaged.
Side mudguard
