10ABOUT THE AUDIO AND NAVIGATION SYSTEM
SCION V398
When visibility is affected by light from out-
side the vehicle, the screen can be ad-
justed to three different angles.
1. Push the “
TILT” button.
2. Touch “TILT”.
The display tilts one step (10_) upwards.
Each time “TILT”is touched, the display
tilts upwards another step.
Touch “TILT” when the display has
reached the third step (30 _) to return it to
its original position (0 _).
CAUTION
Take care not to catch your hand in
the display while it is moving. Other-
wise, you could be injured.
NOTICE
Do not obstruct the display while it is
moving. It could damage your navi-
gation system.
INFORMATION
D The display can still be opened
when tilted. When the display is
closed it returns to its previous
tilted position.
D The display returns to its original
position (0 _) if the engine switch is
turned off when the display is
tilted. The display then returns to
its previous tilted position when
the engine switch is next turned to
the “ACC” or the “IG− ON” posi-
tion.
Adjusting the display angle

101ADVANCED FUNCTIONS
SCION V398
DNotifying traffic restriction
When the “Traffic Restrict. Notification”
feature is turned on, the system notifies
you of traffic or seasonal restrictions.
To turn the “Traffic Restrict. Notification”
on:
1. Touch “Setup” on the “Menu”
screen.
Then touch
to display page 2 of the
“Setup” screen.
2. Touch “ON” of “Traffic Restrict. Noti-
fication”.
The selected button is highlighted.
3. Touch “OK”.
DVoice guidance in all modes
When the “Voice Guidance in All Modes”
feature is turned on, the voice guidance in
all modes can be heard.
When the “Voice Guidance in All Modes”
feature is turned off, voice guidance can-
not be heard when using the audio system.
To turn the “Voice Guidance in All Modes”
on:
1. Touch “Setup” on the “Menu”
screen.
Then touch
to display page 2 of the
“Setup” screen.
2. Touch “ON” of “Voice Guidance in
All Modes”.
The selected button is highlighted.
3. Touch “OK”.

11 5OTHER FUNCTIONS
SCION V398
The brightness or contrast of the screen
can be adjusted depending on the bright-
ness of your surroundings. You can also
turn the display off.
To display the “Display” screen, push
the “DISP” button.
1. Touch the desired button to adjust
brightness and contrast.
“Brightness” “
(brightens)”:Bright-
ens the screen.
“Brightness” “
(darkens)”: Dark-
ens the screen.
“Contrast” “
(strengthens)”:
Strengthens the contrast of the screen.
“Contrast” “
(weakens)”: Weakens
the contrast of the screen.
2. After adjusting the screen, touch
“OK”.
The screen turns off when “Screen Off”is
touched. To turn the screen back on push
the “AUDIO” button.
INFORMATION
When you do not touch any button on
the “Display” screen for 20 seconds,
the previous screen will be displayed.
1. Touch the desired button to adjust
tone and color.
You can adjust the tone and the color while
the DVD video and DVD audio are being
played.
“Tone” “
(strengthens)”: Strength-
ens the tone of the screen.
“Tone” “
(weakens)”: Weakens the
tone of the screen.
“Color” “
(green)”: Strengthens the
green color of the screen.
“Color” “
(red)”: Strengthens the red
color of the screen.
2. After adjusting the screen, touch
“OK”.
The screen turns off when “Screen Off”is
touched. To turn the screen back on push
the “AUDIO” button.
INFORMATION
When you do not touch any button on
the “Display” screen for 20 seconds,
the previous screen will be displayed.
Screen adjustment

11 7OTHER FUNCTIONS
SCION V398
(a) Automatic transition
You can select a function that enables au-
tomatic return to the navigation screen
from the audio screen.
Select “NAVI” or “AUDIO” and then
touch “OK”.
“NAVI”:The navigation screen automati-
cally returns from the audio screen 20 sec-
onds after the end of audio screen opera-
tion.
“AUDIO”: The audio screen remains on. (b) Beep Type
You can select the beep type of the touch
−
screen buttons.Select “1”, “2”, “3” or “OFF”.
“OFF”: The beep is turned off.

SECTIONVII
121
SCION V398
AUDIO/VIDEO SYSTEM
AUDIO/VIDEO SYSTEM
DQuick reference 122 .......................................
D Using your audio/video system 123
........................
Some basics 123 ........................................
Adjusting the volume and the sound quality 126 ..............
Radio operation 134 .....................................
Radio operation (XM satellite radio broadcast) 135 ...........
CD player operation 141 ..................................
DVD player operation 147 ................................
iPod operation 161 ......................................
AUX operation 168 ......................................
D Audio/video remote controls 170
..........................
Steering switches 170 ....................................
D Audio/video system operating hints 171 ......................

122AUDIO/VIDEO SYSTEM
SCION V398
1“MODE” button
Push this button to switch between
the audio (radio, CD, MP3/WMA,
AUX, iPod) and DVD modes, as well
as to turn off the audio system. For
details, see page 124.
2“AUDIO” button
Push this button to display the audio
operation screen. For details, see
page 124.
3“SOUND” button
Push this button to adjust and set the
sound quality. For details, see page
127.
4“MUTE” button
Push this button to mute the audio
system. For details, see page 127.
5“TRACK/TUNE” button
Push this button to select the radio
system, CD music tracks, iPod music
file, and DVD chapters. For details,
see pages 134, 137, 142, 144, 151
and 164.
6“TILT” button
Push this button to open and close
the display, adjust the angle of the
display, and eject discs. For details,
see pages 6, 9 and 10.
7CD disc slot
Load audio CDs and MP3/WMA disc
here. For details, see pages 6
, 141and 143.
8DVD disc slot
Load map DVD −ROMs and DVD vid-
eos here. For details, see pages 6
and 148.
Quick reference

123
SCION V398
AUDIO/VIDEO SYSTEM
9“DISP” button
Push this button to display the “Dis-
play” screen. For details, see page
115.
10“VOL” button
Push this button to adjust the volume
of the audio system. For details, see
page 126.
11Function button display screen
Touch the buttons displayed on the
screen to control the radio, CD player,
DVD player or iPod. For details, see
page 124.This section describes some of the basic
features on SCION audio/video systems.
Your audio/video system works when the
engine switch is in “ACC” or “IG
−ON”
mode.
CAUTION
For vehicles sold in U.S.A. and
Canada:
DPart 15 of the FCC Rules
FCC Warning:
Any unauthorized changes or
modifications to this equipment
will void the user’s authority to op-
erate this device.
DLaser products
DDo not take this unit apart or at-
tempt to make any changes
yourself. This is an intricate unit
that uses a laser pickup to re-
trieve information from the sur-
face of compact discs. The laser
is carefully shielded so that its
rays remain inside the cabinet.
Therefore, never try to disas-
semble the player or alter any of
its parts since you may be ex-
posed to laser rays and danger-
ous voltages.
DThis product utilizes a laser. Use
of controls or adjustments or
performance of procedures oth-
er than those specified herein
may result in hazardous radi-
ation exposure.
NOTICE
To prevent the battery from being dis-
charged, do not leave the audio/video
system on longer than necessary
when the engine is not running.
Using your audio/video
system —
— Some basics

124AUDIO/VIDEO SYSTEM
SCION V398
DTurning on the power
1. Push the “MODE” button.
2. Turn on the power by touching any
one of the audio mode touch−screen
buttons.
When the priority screen is set to naviga-
tion, the operation screen will automatical-
ly be exited from if no operations are per-
formed for approximately 20 seconds or
more after displaying the screen. See “(a)
Automatic transition” on page 117 for de-
tails.
DTurning off the power
Push the “MODE” button and touch
“Audio Off” to turn off the power.
DSwitching between functions
1. Push the “MODE” button.
2. Touch any of the audio mode
switches.
It is not possible to change to AUX, iPod,
or Satellite Radio if they are not connected.
If the disc is not set, the CD player or DVD
player does not turn on.
The selected audio mode will display on
the screen.
The indicator for the currently selected au-
dio mode will illuminate.
Push the “AUDIO” button to display the
respective audio mode operation screen.
You can turn off the CD player or DVD play-
er by ejecting the disc. If the audio system
was previously off, then the entire audio
system will be turned off when you eject
the disc. If another function was previously
playing, it will come on again.

125
SCION V398
AUDIO/VIDEO SYSTEM

126AUDIO/VIDEO SYSTEM
SCION V398
The buttons for radio, CD player, DVD
player, iPod and AUX operation are dis-
played on the function button display
screen when the audio control mode is se-
lected.
Touch them lightly and directly on the
screen.
The selected button is highlighted.
INFORMATION
DIf the system does not respond to
a touch of a touch −screen button,
move your finger away from the
screen and then touch it again.
D You cannot operate dimmed
touch− screen buttons.
D Wipe off fingerprints on the sur-
face of the display using a glass
cleaning cloth.
DMain volume adjustment
1. Adjust with the “VOL” button.
The volume changes one step each time
the “Y ” or “B ” button of “VOL”is
pushed. Furthermore, the volume will con-
tinue to change if the switch is pushed con-
tinuously.
INFORMATION
D Adjust to an appropriate volume
that ensures accident −free, safe
driving.
D The volume may alter when the au-
dio mode is changed. Adjust the
volume to suit the audio mode
used.
—Adjusting the volume and
the sound quality
