ADJUSTING AND STORING THE EQ
CURVE
Allows the equalizer curve to be adjusted
to a sound quality other than the cur-
rently set equalizer curve and then
stored in the memory.

1. Touch the band from “A” to “E” to
adjust it.

2. Touch or to adjust the
frequency of the band.
3. Touch
or to adjust the
level of the band.
4. Touch the Q curve switch to ad-
just the Q curve (bandwidth).
The Q curve can be adjusted to three
phases.
: Widens the Q curve (bandwidth)
: Narrows the Q curve (bandwidth)
5. Repeat steps 1 to 4 for each band
from “A” to “E”.
6. Touch the switch to be stored in
the memory from “EQ 1” to “EQ 5”
until a beep sounds.
By touching
“Flat” until a beep sounds,
it is possible to return the stored equal-
izer curve to the originally setting.
Touch
when settings are complete.

Band
Median frequency Q curve (yellow) Q curve
switch

APPENDIX
275
V573_E


Dimensions 26.0 x 30.0 x 12.9 (mm)
Weight 50 (g)
Power supply voltage 4.0 to 5.0 (V)
Power consumption 10 to 30 (mA)
Usage temperature -30 to +90 (°C)
Storage temperature -40 to +110 (°C)

Liquid crystal panel 7” wide (16:9) low −glare panel
Screen dimensions 158.6 mm (width), 84.3 mm (height), 179.6 mm (diagonal)
Pixel count 280,800 dots (400 (width) × 234 (height) × 3 RGB)
Active pixel rate More than 99.99%
Display format Transmissive color filter format
Drive system TFT (thin membrane transistor) active matrix format
Usage temperature range -20 to +65 (°C)
Storage temperature range -40 to +85 (°C)
< Radio tuner >
Reception frequency ● AM 530 to 1,710 kHz
● FM 87.75 to 107.9 MHz
Noise limited sensitivity ● Less than AM 34 dBµ (S/N = 20 dB)
● Less than FM 14 dBµ (S/N = 30 dB)
Stereo separation More than 25 dB
< CD >
Distortion Less than 0.3%
Frequency characteristic 20 to 20,000 Hz
S/N ratio More than 65 dB (1 kHz)
Stereo separation More than 60 dB


S
pecifications

APPENDIX
276
V573_E

Rated output More than 14 W x 4 (test voltage 14.4V)
Maximum output More than 20 W x 4 (test voltage 14.4V)
Suitable load impedance 4 Ω (each channel)
Power consumption ● 1 W x 4 output time about 4.1 A
● About 15 A max
Exterior dimensions 205.5 mm (width), 104 mm (height), 161.5 mm (depth)
Weight About 2.7 kg
z Please note that due to changes in specifications and external appearance, the
content of this manual may not correspond exactly with the actual device.
z The number of parts and circuits may be changed to improve functionality without
prior notice.
