Introduction
Thank you for your purchase of the Navigation System. Please
read this manual carefully to ensure proper use. Keep this
manual in your vehicle at all times.
The Navigation System is one of the most technologically advanced
vehicle accessories ever developed. The system receives satellite
signals from the Global Positioning System (GPS) operated by the U.S.
Department of Defense. Using these signals and other vehicle sen-
sors, the system indicates your present position and assists in locating
a desired destination.
The navigation system is designed to select efficient routes from your
present starting location to your destination. The system is also de-
signed to direct you to a destination that is unfamiliar to you in an effi-
cient manner. Map database is made based on AISIN AW maps,
whose information source comes from NAVTEQ maps. The calcu-
lated routes may not be the shortest nor the least traffic congested.
Your own personal local knowledge or “short cut” may at times be
faster than the calculated routes.
The navigation system’s database includes about 110 Point of Interest
categories to allow you to easily select destinations such as restau-
rants and hotels. If a destination is not in the database, you can enter
the street address or a major intersection close to it and the system will
guide you there.
The system will provide both a visual map and audio instructions.
The audio instructions will announce the distance remaining and the
direction to turn in approaching a fork or intersection. These voice in-
structions will help you keep your eyes on the road and are timed to
provide enough time to allow you to maneuver, change lanes or slow
down.

2 V573_E
Please be aware that all current vehicle navigation systems have
certain limitations that may affect their ability to perform properly.
The accuracy of the vehicle’s position depends on the satellite
condition, road configuration, vehicle condition or other circum-
stances. For more information on the limitations of the system,
refer to pages 270 through 272.

3
V573_E
For safety reasons, this manual indicates
items requiring particular attention with
the following marks.
CAUTION
This is a warning against anything
which may cause injury to people if
the warning is ignored. You are
informed about what you must or
must not do in order to reduce the
risk of injury to yourself and others.


NOTICE
This is a warning against anything
which may cause damage to the ve-
hicle or its equipment if the warning
is ignored. You are informed about
what you must or must not do in
order to avoid or reduce the risk of
damage to your vehicle and its
equipment.


INFORMATION
This provides additional information.

To use this system in the safest possible
manner, follow all the safety tips shown
below.
This system is intended to assist in
reaching the destination and, if used
properly, can do so. The driver is solely
responsible for the safe operation of your
vehicle and the safety of your passen-
gers.
Do not use any feature of this system to
the extent it becomes a distraction and
prevents safe driving. The first priority
while driving should always be the safe
operation of the vehicle. While driving,
be sure to observe all traffic regulations.
Prior to the actual use of this system,
learn how to use it and become thor-
oughly familiar with it. Read the entire
Navigation System Owner’s Manual to
make sure you understand the system.
Do not allow other people to use this
system until they have read and under-
stood the instructions in this manual.
For your safety, some functions may
become inoperable when driving. Un-
available touch screen buttons are
dimmed. Only when the vehicle is not
moving, can the destination and route
selection be done.

Important information about
this manual

Safet
y Instruction

4
V573_E
CAUTION
z For safety, the driver should not
operate the navigation system
while he/she is driving. Insuffi-
cient attention to the road and
traffic may cause an accident.
z While you are driving, be sure to
obey the traffic regulations and
maintain awareness of the road
conditions. If a traffic sign on
the road has been changed, route
guidance may provide wrong in-
formation such as the direction of
a one way street.

While driving, listen to the voice instruc-
tions as much as possible and glance at
the screen briefly and only when it is
safe. However, do not totally rely on
voice guidance. Use it just for refer-
ence. If the system cannot determine
the current vehicle position correctly,
there is a possibility of incorrect, late, or
non-voice guidance.
The data in the system may occasionally
be incomplete. Road conditions, in-
cluding driving restrictions (no left turns,
street closures, etc.) frequently change.
Therefore, before following any instruc-
tion from the system, look to see whether
the instruction can be done safely and
legally.
This system cannot warn about such
things as the safety of an area, condition
of streets, and availability of emergency
services. If unsure about the safety of
an area, do not drive into it. Under no
circumstances is this system a sub-
stitute for the driver’s personal
judgement.
Use this system only in locations where it
is legal to do so. Some states/provinces
may have laws prohibiting the use of
video and navigation screens next to the
driver.

5
V573_E
Table of Contents
