TOYOTA tC 2016 (in English) User Guide

11
tC_OM_OM21056U_(U)
Vehicles with an automatic transmission
Power outlet P. 261
Shift lever P. 178
AUX port/USB port P. 247
Shift lock override button
P. 411
C
Cup holders P. 256
Parking brake lever P. 188
VSC OFF switch P. 216
Auxiliary box P. 256
Seat heater switches
P. 262
: If equipped

12
tC_OM_OM21056U_(U)
Vehicles with a manual transmission
C
Power outlet P. 261
Shift lever P. 185
AUX port/USB port P. 247
Cup holders P. 256
Parking brake lever P. 188
VSC OFF switch P. 216
Auxiliary box P. 256
Pictorial indexInterior
Seat heater switches
P. 262

13
tC_OM_OM21056U_(U)
Emergency flasher switch P. 364
Engine (ignition) switch
(vehicles with a smart key system)
P. 169
Clock P. 260
Tilt and telescopic steering lockrelease lever
P. 84
Fuel filler door opener P. 97
Instrument panelPictorial index

: If equipped

14
tC_OM_OM21056U_(U)
Air conditioning system P. 238
Rear window and outside rear view mirror
defogger switch
P. 245
A
Instrument panelPictorial index

15
tC_OM_OM21056U_(U)
Paddle shift switches P. 178
Headlight switch
Turn signal lever P. 199
P. 187
Steering wheel audio switches
P. 248
SRS driver airbag
Horn P. 108
P. 189
Cruise control switch
P. 211
Engine (ignition) switch (vehicleswithout a smart key system)
P. 165
Windshield wipers and washer switch
Rear window wiper and washer switch

P. 204
P. 208
B
: If equipped

16
tC_OM_OM21056U_(U)
Outside rear view mirror
switches
P. 87
Hood release lever P. 294
C
Instrument panelPictorial index

17
tC_OM_OM21056U_(U)
Luggage compartment
Cargo hooks P. 269Cargo hooks P. 269
Auxiliary boxes P. 269
Luggage cover P. 270
Pictorial index
: If equipped
Luggage compartment
light
P. 62

18
tC_OM_OM21056U_(U)
For your information
Main Owner’s Manual
Please note that this manual applies to all models and all equipment, includ-
ing options. Therefore, you may find some explanations for equipment not
installed on your vehicle.
All specifications provided in this manual are current at the time of printing.
However, because of the Scion policy of continual product improvement, we
reserve the right to make changes at any time without notice.
Depending on specifications, the vehicle shown in the illustrations may differ
from your vehicle in terms of equipment.
Noise from under vehicle after turning off the engine
Approximately five hours after the engine is turned off, you may hear sound
coming from under the vehicle for several minutes. This is the sound of a fuel
evaporation leakage check and, it does not indicate a malfunction.
Accessories, spare parts and modification of your Scion
A wide variety of non-genuine spare parts and accessories for Scion vehicles
are currently available on the market. You should know that Scion does not
warrant these products and is not responsible for their performance, repair,
or replacement, or for any damage they may cause to, or adverse effect they
may have on, your Scion vehicle.
This vehicle should not be modified with non-genuine Scion products.
Modification with non-genuine Scion products could affect its performance,
safety or durability, and may even violate governmental regulations. In
addition, damage or performance problems resulting from the modification
may not be covered under warranty.

19
tC_OM_OM21056U_(U)
Installation of a mobile two-way radio system
The installation of a mobile two-way radio system in your vehicle could affect
electronic systems such as:
●Multi-port fuel injection system/sequential multi-port fuel injection system
● Cruise control system
● Anti-lock brake system
● SRS airbag system
● Seat belt pretensioner system
Be sure to check with your Scion dealer for precautionary measures or spe-
cial instructions regarding installation of a mobile two-way radio system.

20
tC_OM_OM21056U_(U)
Vehicle data recordings
Your Scion is equipped with several sophisticated computers that will record
certain data, such as:
• Engine speed
• Accelerator status
• Brake status
• Vehicle speed
• Shift position (except manual transmission)
The recorded data varies according to the vehicle grade level and options
with which it is equipped. Furthermore, these computers do not record con-
versations, sounds or pictures.
●Data usage
Scion may use the data recorded in these computers to diagnose malfunc-
tions, conduct research and development, and improve quality.
Scion will not disclose the recorded data to a third party except:
• With the consent of the vehicle owner or with the consent of the lessee if the vehicle is leased
• In response to an official request by the police, a court of law or a govern- ment agency
• For use by Scion in a lawsuit
• For research purposes where the data is not tied to a specific vehicle or vehicle owner
