TOYOTA TERCEL 1996 Service Repair Manual

SF0X0-03
MF-16
- MFIINJECTOR
540 Author
: Date
:
1996 TERCEL (RM440U)
INJECTOR
ON-VEHICLE INSPECTION
1. INSPECT INJECTOR OPERATION
Check operation sound from each injector.
(1) With the engine running or cranking, use a sound
scope to check that there is a normal operating
noise in proportion to engine speed.
(2) If you have no sound scope, you can check the
injector transmission operation with your finger.
If no sound or unusual sound is heard, check the wiring connec-
tor, injector or injection signal from the ECM.
2. INSPECT INJECTOR RESISTANCE
(a) Disconnect the injector connector.
(b) Using an ohmmeter, measure the resistance between the
terminals.
Resistance:
13.4 - 14.2 W at 20°C (68°F)
If the resistance is not as specified, replace the injector.
(c) Reconnect the injector connector.

SF0X1-05
- MFIINJECTOR
MF-17
1996 TERCEL (RM440U)
COMPONENTS

SF0X2-03
MF-18
- MFIINJECTOR
1996 TERCEL (RM440U)
REMOVAL
1. DISCONNECT VACUUM SEMSING HOSE FROM FUEL
PRESSURE REGULATOR
2. DISCONNECT FUEL RETURN HOSE FROM FUEL RE-
TURN PIPE
NOTICE:
Catch leaking in a container.
3. DISCONNECT FUEL INLET HOSE FROM DELIVERY
PIPE
(a) Disconnect the engine wire clamp from the No. 2 engine
hanger.
(b) Remove the union bolt, 2 gaskets and inlet hose.
4. DISCONNECT ENGINE WIRE
(a) Disconnect the engine wire from the surge tank stay.
(b) Disconnect the 4 injector connectors.
5. REMOVE DELIVERY PIPE WITH INJECTORS
(a) Remove the 2 bolts and delivery pipe together with the 4
injectors.
NOTICE:
Be careful not to drop the injectors when removing the de-
livery pipe.
(b) Pull out the 4 injectors from the delivery pipe.
(c) Remove the 2 spacers and 4 insulators from the cylinder
head.
(d) Remove the O-ring and grommet from each injector.

SF1PV-02
P20397
Union Bolt
Gasket
SST (Hose)
Fuel Filter
(On Vehicle) SST (Union)
- MFIINJECTOR
MF-19
1996 TERCEL (RM440U)
INSPECTION
1. INSPECT INJECTOR INJECTION
CAUTION:
Keep injector clean of sparks during the test.
(a) Remove the union bolt and 2 gaskets, and disconnect the
fuel inlet hose from the fuel filter outlet.
(b) Connect SST (union and hose) to the fuel filter outlet with
2 gaskets and union bolts.
SST 09268-41046 (90405-09015)
Torque: 29 N´m (290 kgf´cm, 22 ft´lbf)
(c) Remove the pressure regulator from the delivery pipe
(See page MF-14).
(d) Install a O-ring to the fuel inlet of pressure regulator.
(e) Connect SST (hose) to the fuel inlet of the pressure regu-
lator with SST (union) and the 2 bolts.
SST 09268-41046 (09268-41091)
Torque: 8.0 N´m (80 kgf´cm, 69 ft´lbf)
(f) Connect the fuel return hose to the fuel outlet of the pres-
sure regulator.
CAUTION:
Install a suitable vinyl hose onto the injector to prevent
gasoline from splashing out.
(g) Remove the fuse cover on the instrument panel.

Z14695
SST (Hose)
SST (Union)
O-Ring
SST
(Clamp)
Vinyl Tube
P19552
TOYOTA Hand-Held Tester
DLC3
FI3211
SST
(Wire)
Connect
FI1676
MF-20
- MFIINJECTOR
1996 TERCEL (RM440U)
(h) Install the grommet and a O-ring to the injector.
(i) Connect SST (union and hose) to the injector, and hold
the injector and union with SST (clamp).
SST 09368-41046
(j) Put the injector into the graduated cylinder.
CAUTION:
Install a suitable vinyl hose onto the injector to prevent
gasoline from splashing out.
(k) Remove the fuse cover on the instrument panel.
(l) Connect the TOYOTA hand-held tester to the DLC3.
(m) Turn the ignition switch ON and TOYOTA hand-held tes-
ter main switch ON.
NOTICE:
Do not start the engine.
(n) Select the active test mode on the TOYOTA hand-held
tester.
(o) Please refer to the TOYOTA hand-held tester operator's
manual for further details.
(p) If you have no TOYOTA hand-held tester, connect the
positive (+) and negative (-) leads from the battery to the
fuel pump connector (See page MF-5).
(q) Connect SST (wire) to the injector and battery for 15 se-
conds, and measure the injection volume with a gra-
duated cylinder. Test each injector 2 or 3 times.
SST 09842-30070
Volume:
39 - 49 cm
3 (2.4 - 3.0 cu in.) per 15 sec.
Difference between each injector:
5 cm
3 (0.3 cu in.) or less
If the injection volume is not as specified, replace the injector.
2. INSPECT LEAKAGE
(a) In the condition above, disconnect the tester probes of
SST (wire) from the battery and check the fuel leakage
from the injector.
SST 09842-30070
Fuel drop:
1 drop or less per 3 minutes
(b) Disconnect the negative (-) terminal cable from the bat-
tery.
(c) Remove the SST.

- MFIINJECTOR
MF-21
1996 TERCEL (RM440U)
SST 09268-41046, 09842-30070, 09843-18020
(d) Reinstall the pressure regulator to the delivery pipe (See
page MF-15).
(e) Reconnect the fuel inlet hose to the fuel filter outlet with
2 new gaskets and the union bolt.
Torque: 29 N´m (290 kgf´cm, 22 ft´lbf)
(f) Turn the ignition switch OFF.
(g) Disconnect the TOYOTA hand- held tester from the
DLC3.
(h) Reinstall the fuse cover on the instrument panel.

SF0X4-05
FI3271
New
O-Ring
New Grommet
P00159
CORRECT
WRONG
InjectorDelivery Pipe GrommetO-Ring
WRONG
P20295
Spacer
Insulator
Connector MF-22
- MFIINJECTOR
1996 TERCEL (RM440U)
INSTALLATION
1. INSTALL INJECTORS AND DELIVERY PIPE
(a) Install a new grommet to the injector.
(b) Apply a light coat of gasoline to an O-ring, and install it
to the injector.
(c) While turning the injector left and right, install it to the de-
livery pipe. Install the 4 injectors.
(d) Place the 2 spacers and 4 insulators in position on the cyl-
inder head.
(e) Place the injectors together with the delivery pipe on the
cylinder head.
(f) Check that the injectors rotate smoothly.
HINT:
If the injectors do not rotate smoothly, the probable cause is in-
correct installation of O-rings. Replace the O-rings.
(g) Position the injector connector upward.
(h) Install the 2 bolts.
Torque: 19 N´m (190 kgf´cm, 14 ft´lbf)
2. CONNECT ENGINE WIRE
(a) Connect the 4 injector connectors.
(b) Connect the engine wire to the surge tank stay.
3. CONNECT FUEL INLET HOSE TO DELIVERY PIPE
(a) Install 2 new gaskets and the inlet hose with the union
bolt.
Torque: 30 N´m (300 kgf´cm, 23 ft´lbf)
(b) Connect the engine wire clamp to the No.2 engine hang-
er.
4. CONNECT FUEL RETURN HOSE TO FUEL RETURN
PIPE
5. CONNECT VACUUM SENSING HOSE TO FUEL PRES-
SURE REGULATOR

- MFIINJECTOR
MF-23
1996 TERCEL (RM440U)
6. CHECK FOR FUEL LEAKS (See page MF-1)

SF0X5-04
MF-24
- MFIFUEL TANK AND LINE
548 Author
: Date
:
1996 TERCEL (RM440U)
FUEL TANK AND LINE
COMPONENTS
CAUTION:

Always use new gaskets when replacing the fuel tank or components parts.

Apply the proper torque to all parts tightened.

SF0X7-03
BO0919
CrackLeakage
Defomation
Z00085
Fulcrum
Length
30 cm
(11.81 in.) Use SST
30 N´m
(310 kgf´cm, 22 ft´lbf)
SST: 09631-22020SST
FU0041
2 - 7 mm (0.08 - 0.28 in.)
Pipe Hose
0 - 3 mm (0 - 0.12 in.)
FI6138
Fuel Inlet Hose
2.5 mm (0.1 in.) or less
- MFIFUEL TANK AND LINE
MF-25
1996 TERCEL (RM440U)
INSPECTION
INSPECT FUEL TANK AND LINE
(a) Check the fuel lines for cracks or leakage, and all connec-
tions for deformation.
(b) Check the fuel tank vapor vent system hoses and connec-
tions for looseness, sharp bends or damage.
(c) Check the fuel tank for deformation, cracks, fuel leakage
or tank band looseness.
(d) Check the filler neck for damage or fuel leakage.
(e) Hose and the tube connections are as shown in the il-
lustration.
(f) Make sure the hose clamps do not interfere with the tank,
tubes, hoses and other parts.
If a problem is found, repair or replace the parts as necessary.
