TOYOTA TUNDRA 2001 Owners Manual

'01 TUNDRA_U (L/O 0008)
2732001 TUNDRA (OM 34416U)
Engine
Model:
5VZ±FE and 2UZ±FE
Type: 5VZ±FE engine6 cylinder V type, 4 cycle, gasoline
2UZ±FE engine
8 cylinder V type, 4 cycle, gasoline
Bore and stroke, mm (in.): 5VZ±FE engine93.5
82.0 (3.68
3.23)
2UZ±FE engine
94.0
84.0 (3.70
3.31)
Displacement, cm
3 (cu. in.):
5VZ±FE engine 3378 (206.1)
2UZ±FE engine 4664 (284.6)
Fuel
Fuel type: Unleaded gasoline, Octane Rating 87
(Research Octane Number 91) or higher
Fuel tank capacity, L (gal., Imp. gal.): 100 (26.4, 22.0)
Service specifications
ENGINE
Valve clearance (engine cold), mm (in.):
5VZ±FE engineIntake 0.13Ð0.23 (0.006Ð0.009)
Exhaust 0.27Ð0.37 (0.011Ð0.014)
2UZ±FE engine Intake 0.15Ð0.25 (0.006Ð0.010)
Exhaust 0.25Ð0.35 (0.010Ð0.014)
Spark plug type: 5VZ±FE engineDENSO K16TR11
NGK BKR5EKB11
2UZ±FE engine DENSO K20R±U
NGK BKR6EYA
Spark plug gap, mm (in.): 5VZ±FE engine 1.1 (0.043)
2UZ±FE engine 0.8 (0.031)
Drive belt tension measured with Bor-
roughs drive belt tension gauge
No.BT±33±73F (used belt), lbf: 5VZ±FE engineGenerator belt 100 20
Air conditioning compressor belt
100
+20
±10
Power steering pump belt100+20
±15
ProCarManuals.com

'01 TUNDRA_U (L/O 0008)
2742001 TUNDRA (OM 34416U)
ENGINE LUBRICATION
Oil capacity (drain and ref ill), L (qt., Imp.
qt.):
5VZ±FE engineWith filter 5.2 (5.5, 4.6)
Without filter 4.9 (5.2, 4.3)
2UZ±FE engine With filter 6.2 (6.5, 5.5)
Without filter 5.7 (6.0, 5.0)
Oil grade: API grade SJ, ªEnergy±Conservingº or
ILSAC multigrade engine oil is recom-
mended.
Recommended oil viscosity (SAE):
5W-30 Preferred
Temperature range anticipated before
next oil change
COOLING SYSTEM
Total capacity, L (qt., Imp. qt.): With manual transmission 10.0 (10.6, 8.8)
With automatic transmission 5VZ±FE engine 9.9 (10.5, 8.7)
2UZ±FE engine 11.6 (12.3, 10.2)
Coolant type: ªTOYOTA Long Life Coolantº or equiva-
lent
With ethylene±glycol type coolant for a
proper corrosion protection of aluminum
components
Do not use alcohol type antifreeze or
plain water alone.
BATTERY
Open voltage
* at 20
C (68
F):
12.6Ð12.8 V Fully charged
12.2Ð12.4 V Half charged
11.8Ð12.0 V Discharged
*: Voltage that is checked 20 minutes af- ter the key is removed with all the
lights turned off
Charging rates: 5 A max. CLUTCH
Pedal free play, mm (in.):
5Ð15 (0.2Ð0.6)
Fluid type: SAE J1703 or FMVSS No.116 DOT 3
MANUAL TRANSMISSION
Oil capacity, L (qt., Imp. qt.): Two±wheel drive models 2.6 (2.7, 2.3)
Four±wheel drive models
2.2 (2.3, 1.9)
Oil type: Gear oil API GL±4 or GL±5
Recommended oil viscosity: SAE 75W±90
AUTOMATIC TRANSMISSION
Fluid capacity (drain and ref ill), L (qt.,
Imp. qt.): Up to 2.0 (2.1, 1.8)
Fluid type: Automatic transmission fluid D±II or
DEXRON III (DEXRON II)
ProCarManuals.com

'01 TUNDRA_U (L/O 0008)
2752001 TUNDRA (OM 34416U)
TRANSFER
Oil capacity, L (qt., Imp. qt.):
1.0 (1.1, 0.9)
Oil type: Gear oil API GL±4 or GL±5
Recommended oil viscosity: SAE 75W±90
DIFFERENTIAL
Oil capacity, L (qt., Imp. qt.): Front1.15 (1.2, 1.0)
Rear
Two±wheel drive models3.80 (4.0, 3.3)
Four±wheel drive models 3.50 (3.7, 3.1)
Oil type: Hypoid gear oil API GL±5
Recommended oil viscosity: Front SAE 75W±90
Rear Above ±18
C (0
F)
SAE 90
Below ±18
C (0
F)
SAE 80W or 80W±90 CHASSIS LUBRICATION
Propeller shafts:
Spiders and slide yokesLithium base chassis grease, NLGI
No.2
Double cardan joint Molybdenum±disulfide lithium base
chassis grease, NLGI No.2
BRAKES
Minimum pedal clearance when depressed
with the force of 490 N (50 kgf, 110 lbf)
with the engine running, mm (in.): 95 (3.7)
Pedal free play, mm (in.): 1Ð6 (0.04Ð0.24)
Pad wear limit, mm (in.): 1.0 (0.04)
Lining wear limit, mm (in.): 1.0 (0.04)
Parking brake adjustment: Pedal typeÐwhen depressed with the
force of 294 N (30 kgf, 66.1 lbf)5Ð8 clicks
Lever typeÐwhen pulled with the force
of 196 N (20 kgf, 44 lbf) 4Ð12 clicks
Fluid type: SAE J1703 or FMVSS No.116 DOT 3 STEERING
Wheel free play:
Less than 30 mm (1.2 in.)
Power steering fluid type: Automatic transmission fluid DEXRON II
or III
ProCarManuals.com

'01 TUNDRA_U (L/O 0008)
2762001 TUNDRA (OM 34416U)
Tires
Tire size and pressure:
STANDARD CAB MODELS
Two±wheel drive models
Tire size
Tire pressure
kPa (kgf/cm2 or bar, psi)Wheel sizeTire size
FrontRear
Wheel size
P245/70R16180 (1.8, 26)240 (2.4, 35)16
7JJ
Four±wheel drive models
Tire size
Tire pressure
kPa (kgf/cm2 or bar, psi)Wheel sizeTire size
FrontRear
Wheel size
P245/70R16180 (1.8, 26)240 (2.4, 35)16
7JJ (J)
P265/70R16180 (1.8, 26)200 (2.0, 29)16
7JJ (J)
ProCarManuals.com

'01 TUNDRA_U (L/O 0008)
2772001 TUNDRA (OM 34416U)
ACCESS CAB MODELS
Tire size
Tire pressure
kPa (kgf/cm2 or bar, psi)Wheel sizeTire size
FrontRear
Wheel size
P245/70R16180 (1.8, 26)240 (2.4, 35)16
7JJ (J)
P265/70R16180 (1.8, 26)200 (2.0, 29)16
7JJ (J)
P265/70R16
Off±road package180 (1.8, 26)200 (2.0, 29)16
7JJ
Wheel nut torque, N´m (kgf´m, ft´lbf):
110 (11.5, 83.2)
NOTE: For a complete information on tires (e.g. replacing tires or replacing wheels), see ªChecking tire pressureº through ªAlum inum
wheel precautionsº in Section 7±2.
ProCarManuals.com

'01 TUNDRA_U (L/O 0008)
2782001 TUNDRA (OM 34416U)
Fuses
Engine compartment (2UZ±FE engine)Engine compartment (5VZ±FE engine)
Engine compartment (with towing kit)
Fuses (type A)
1. EFI NO.1 20 A (2UZ±FE engine) or EFI NO.1 15 A (5VZ±FE engine): Mul-
tiport fuel injection system/sequential
multiport fuel injection system, emis-
sion control system, fuel pump and all
components in ªEFI NO.2º fuse
2. ETCS 15 A: Multiport fuel injection
system/s equential multiport fuel injec-
tion system and electronic throttle con-
trol system
3. DOME 15 A: Interior light, personal
lights, vanity light and courtesy lights
ProCarManuals.com

'01 TUNDRA_U (L/O 0008)
2792001 TUNDRA (OM 34416U)
Instrument panel
4. OBD 7.5 A: On±board diagnosis sys-
tem
5. PWR OUTLET 1 15 A: Power outlet
6. PWR OUTLET 2 15 A: Power outlet
7. ST2 5 A: Starting system
8. FR FOG 20 A: Front fog lights
9. ALT±S 7.5 A: Charging system
10. HEAD (RH) 10 A (without daytime running light system): Right±hand
headlight
HEAD (HI RH) 10 A (with daytime
running light system): Right±hand
headlight (high beam) 11. HEAD (LH) 10 A (without daytime
running light system): Left±hand
headlight
HEAD (HI LH) 10 A (with daytime
running light system): Left±hand
headlight (high beam)
12. EFI NO.2 10 A: Multiport fuel injection
system/s equential multiport fuel injec-
tion system and emission control sys-
tem
13. A/C 10 A: Air conditioning system
14. DRL 7.5 A (with daytime running light system): Daytime running light
system
15. HEAD (LO RH) 10 A (with daytime running light system): Right±hand
headlight (low beam)
16. HEAD (LO LH) 10 A (with daytime running light system): Left±hand
headlight (low beam)
17. WIP 20 A: Windshield wipers and
washer
18. TURN 5 A: Turn signal lights
19. ECU IG 5 A: Anti±lock brake system
and cruise control system
20. 4WD 20 A: Four±wheel drive control
system and A.D.D. control system 21. ACC 15 A:
Cigarette lighter, audio sys-
tem, SRS airbag system and power
rear view mirrors
22. GAUGE 10 A: Gauges and meters,
back±up lights, starting system, day-
time running light system and air condi-
tioning system
23. IGN 5 A: SRS airbag system, multiport
fuel injection system/sequential multi-
port fuel injection system, discharge
system and ignition system
24. CARGO LP 5 A: Cargo lamp
25. TAIL 15 A: Tail lights, license plate
lights, instrument panel lights, parking
lights and glove box light
26. ECU±B 5 A: SRS warning light
27. HORN±HAZ 20 A: Emergency flashers
and horns
28. STA 5 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system, g auges and meters
29. STOP 15 A: Stoplights and high
mounted stoplight
Fuses (type B)
30. ABS 1 40 A: Anti±lock brake system
31. ABS 2 40 A: Anti±lock brake system
ProCarManuals.com

'01 TUNDRA_U (L/O 0008)
2802001 TUNDRA (OM 34416U)
32. J/B 50 A: All components in ªPWRº,
ªHORN´HAZº, ªTAILº, ªCARGO LPº,
ªSTOPº and ªECU±Bº fuses
33. AM2 40 A: Ignition system
34. AM1 40 A: Starting system
35. HTR 50 A: Air conditioning system
36. POWER 30 A: Power door lock sys-
tem, power windows and power seat
37. FL 30 A: Trailer lights
Fuse (type C)
38. ALT 120 A: All components in ªAM1º,
ªALT±Sº, ªHTRº, ªFR FOGº, ªPWR
OUTLET 1º and ªPWR OUTLET 2º
fuses
ProCarManuals.com

'01 TUNDRA_U (L/O 0008)
2812001 TUNDRA (OM 34416U)
REPORTING SAFETY DEFECTS FOR U.S.
OWNERS, UNIFORM TIRE QUALITY
GRADING AND CAMPER INFORMATION
Reporting safety defects for U.S. owners 282
. . . . . . . . . . . . . . . . . . . . . .
Uniform tire quality grading 282
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Camper information 283
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . .
SECTION 9
ProCarManuals.com

'01 TUNDRA_U (L/O 0008)
2822001 TUNDRA (OM 34416U)
If you believe that your vehicle
has a defect which could cause a
crash or could cause injury or
death, you should immediately in-
form the National Highway Traffic
Safety Administration (NHTSA) in
addition to notifying Toyota Motor
Sales, U.S.A., Inc. (Toll±free:
1±800±331±4331).
If NHTSA receives similar com-
plaints, it may open an investiga-
tion, and if it finds that a safety
defect exists in a group of ve-
hicles, it may order a recall and
remedy campaign. However,
NHTSA cannot become involved
in individual problems between
you, your dealer, or Toyota Motor
Sales, U.S.A., Inc. To contact NHTSA, you may ei-
ther call the Auto Safety Hotline
toll±free at 1±800±424±9393 (or
366±0123 in Washington, D.C.
area) or write to: NHTSA, U.S.
Department of Transportation,
Washington, D.C. 20590. You can
also obtain other information about
motor vehicle safety from the Hot-
line.
Uniform tire quality gradingThis information has been prepared in ac-
cordance with regulations issued by the
National Highway Traffic Safety Adminis-
tration of the U.S. Department of Trans-
portation. It provides the purchasers and/
or prospective purchasers of Toyota
vehicles with information on uniform tire
quality grading.
Your Toyota dealer will help answer any
questions you may have as you read this
information.
DOT quality gradesÐAll passenger car
tires must conform to Federal Safety
Requirements in addition to these
grades. Quality grades can be found
where applicable on the tire sidewall
between tread shoulder and maximum
section width. For example: Treadwear
200 Traction AA Temperature A
Reporting safety defects for
U.S. owners
