TOYOTA TUNDRA 2007 2.G Navigation Manual

208
When foreign matter (for example, snow
or mud) is adhering to the camera
When the sun or the beam of headlights is
shining directly into the camera lens
y19112
Check surroundings for safety.
If a bright light (for example, sunlight reflected
off the vehicle body) is picked up by the cam-
era, the smear effect
∗ peculiar to the camera
may occur.
∗: Smear effect—A phenomenon that occurs
when a bright light (for example, sunlight re-
flected off the vehicle body) is picked up by
the camera; when transmitted by the camera,
the light source appears to have a vertical
streak above and below it.

209
APPENDIX
Appendix
Limitations of the navigation system210 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Map database information and updates212 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION VIII

210
Limitations of the navigation
system
This navigation system calculates the cur-
rent vehicle position using satellite sig-
nals, various vehicle signals, map data,
etc. However, the accurate position may
not be shown depending on the satellite
condition, road configuration, vehicle
condition or other circumstances.
The Global Positioning System (GPS) devel-
oped and operated by the U.S. Department of
Defense provides an accurate current vehicle
position, normally using 4 or more satellites,
and in some cases 3 satellites. The GPS sys-
tem has a certain level of inaccuracy. While
the navigation system will compensate for
this most of the time, occasional positioning
errors of up to 300 feet (100 m) can and
should be expected. Generally, position er-
rors will be corrected within a few seconds.
7U5027
When your vehicle is receiving signals from
the satellites, the “GPS” mark appears at the
top left of the screen.
The GPS signal may be physically ob-
structed, leading to inaccurate vehicle posi-
tion on the map display. Tunnels, tall build-
ings, trucks, or even the placement of objects
on the instrument panel may obstruct the
GPS signals.
The GPS satellites may not send signals due
to repairs or improvements being made to
them.
Even when the navigation system is receiving
clear GPS signals, the vehicle position may
not be shown accurately or inappropriate
route guidance may occur in some cases.
NOTICE
The installation of window tinting may
obstruct the GPS signals. Most window
tinting contains some metallic content
that will interfere with GPS signal recep-
tion of the antenna in the instrument
panel. We advise against the use of win-
dow tinting on vehicles equipped with
navigation systems.

211 (a) Accurate current vehicle position
may not be shown in the following cases:
When driving on a small angled Y−shaped
road.
When driving on a winding road.
When driving on a slippery road such as
in sand, gravel, snow, etc.
When driving on a long straight road.
When freeway and surface streets run in
parallel.
After moving by ferry or vehicle carrier.
When a long route is searched during high
speed driving.
When driving without setting the current
position calibration correctly.
After repeating a change of direction by
going forward and backward, or turning on
a turntable in the parking lot.
When leaving a covered parking lot or
parking garage.
When a roof carrier is installed.
When driving with tire chains installed.
When the tires are worn.
After replacing a tire or tires.
When using tires that are smaller or larger
than the factory specifications.
When the tire pressure in any of the four
tires is not correct.
INFORMATION
If your vehicle cannot receive GPS
signals, you can correct the current
position manually. For information on
setting the current position calibration,
see “
 Current position/tire change
calibration” on page 87.
(b) Inappropriate route guidance may oc-
cur in the following cases:
When turning at an intersection off the
designated route guidance.
If you set more than one destination but
skip any of them, auto reroute will display
a route returning to the destination on the
previous route.
When turning at an intersection for which
there is no route guidance.
When passing through an intersection,
there is no route guidance.
During auto reroute, the route guidance
may not be available for the next turn to
the right or left.
It may take a long time to operate auto re-
route during high speed driving. In auto
reroute, a detour route may be shown.
After auto reroute, the route may not be
changed.
An unnecessary U−turn may be shown or
announced.
A location may have multiple names and
the system will announce one or more.
Some routes may not be searched.
If the route to your destination includes
gravel, unpaved roads or alleys, the route
guidance may not be shown.

212
Your destination point might be shown on
the opposite side of the street.
When a portion of the route has regula-
tions prohibiting the entry of the vehicle
that vary by time or season or other rea-
sons.
The road and map data stored in your nav-
igation system may not be complete or
may not be the latest version.
After replacing the tire, implement the
operation described in the “ Current
position/tire change calibration”. (See
page 87.)
This navigation system uses tire turning data
and is designed to work with factory−speci-
fied tires for your vehicle. Installing tires that
are larger or smaller than the originally
equipped diameter may cause inaccurate
display of the vehicle’s position. The tire pres-
sure also affects the diameter of the tires so
please make sure the tire pressure of all four
tires is correct.
Map database information and
updates
This system uses the maps of DENSO.
© 2006 DENSO CORPORATION
© 2005 NAVTEQ. All rights reserved.
© 2005 Tele Atlas North America, Inc. All
rights reserved. This material is propri-
etary and the subject of copyright protec-
tion and other intellectual property rights
owned by or licensed to Tele Atlas North
America, Inc. The use of this material is
subject to the terms of a license agree-
ment. You will be held liable for any unau-
thorized copying or disclosure of this ma-
terial.
Data by infoUSA Copyright © 2005, All
Rights Reserved.
©2005 VISA Corporation
National Research Bureau ©2005
The Bullseye Design is a registered
trademark of Target Brands, Inc.
END USER TERMS
The data (“Data”) is provided for your
personal, internal use only and not for re-
sale. It is protected by copyright, and is
subject to the following terms and condi-
tions which are agreed to by you, on the
one hand, and DENSO CORPORATION
(“[CLIENT]”) and its licensors (including
their licensors and suppliers) on the other
hand.
© 2005 NAVTEQ. All rights reserved.
The Data for areas of Canada includes
information taken with permission from
Canadian authorities, including: © Her
Majesty the Queen in Right of Canada, ©
Queen’s Printer for Ontario, © Canada
Post Corporation, GeoBase.
NAVTEQ holds a non−exclusive license
from the United States Postal Service
to publish and sell ZIP+4 information.
©United States Postal Service 2005.
Prices are not established, controlled or
approved by the United States Postal
Service. The following trademarks and
registrations are owned by the USPS:
United States Postal Service, USPS, and
ZIP+4.

213 TERMS AND CONDITIONS
Personal Use Only. You agree to use this
Data together with the navigation system
for the solely personal, non−commercial
purposes for which you were licensed,
and not for service bureau, time−sharing
or other similar purposes. Accordingly,
but subject to the restrictions set forth in
the following paragraphs, you may copy
this Data only as necessary for your per-
sonal use to (i) view it, and (ii) save it, pro-
vided that you do not remove any copy-
right notices that appear and do not
modify the Data in any way. You agree
not to otherwise reproduce, copy, modify,
decompile, disassemble or reverse engi-
neer any portion of this Data, and may not
transfer or distribute it in any form, for any
purpose, except to the extent permitted
by mandatory laws. Multi−disc sets may
only be transferred or sold as a complete
set as provided by [CLIENT] and not as
a subset thereof.
Restrictions. Except where you have
been specifically licensed to do so by
[CLIENT], and without limiting the pre-
ceding paragraph, you may not (a) use
this Data with any products, systems, or
applications installed or otherwise con-
nected to or in communication with ve-
hicles, capable of vehicle navigation,
positioning, dispatch, real time route
guidance, fleet management or similar
applications; or (b) with or in communica-
tion with any positioning devices or any
mobile or wireless−connected electronic
or computer devices, including without
limitation cellular phones, palmtop and
handheld computers, pagers, and per-
sonal digital assistants or PDAs.
Warning.
The Data may contain inaccu-
rate or incomplete information due to the
passage of time, changing circum-
stances, sources used and the nature of
collecting comprehensive geographic
data, any of which may lead to incorrect
results.
No Warranty. This Data is provided to you
”as is,” and you agree to use it at your
own risk. [CLIENT] and its licensors (and
their licensors and suppliers) make no
guarantees, representations or warran-
ties of any kind, express or implied, aris-
ing by law or otherwise, including but not
limited to, content, quality, accuracy,
completeness, effectiveness, reliability,
fitness for a particular purpose, useful-
ness, use or results to be obtained from
this Data, or that the Data or server will be
uninterrupted or error−free.
Disclaimer of Warranty:
[CLIENT] AND
ITS LICENSORS (INCLUDING THEIR
LICENSORS AND SUPPLIERS)
DISCLAIM ANY WARRANTIES,
EXPRESS OR IMPLIED, OF QUALITY,
PERFORMANCE,
MERCHANTABILITY, FITNESS FOR A
PARTICULAR PURPOSE OR
NON−INFRINGEMENT. Some States,
Territories and Countries do not allow
certain warranty exclusions, so to that
extent the above exclusion may not apply
to you.

214 Disclaimer of Liability:
[CLIENT] AND
ITS LICENSORS (INCLUDING THEIR
LICENSORS AND SUPPLIERS) SHALL
NOT BE LIABLE TO YOU: IN RESPECT
OF ANY CLAIM, DEMAND OR ACTION,
IRRESPECTIVE OF THE NATURE OF
THE CAUSE OF THE CLAIM, DEMAND
OR ACTION ALLEGING ANY LOSS,
INJURY OR DAMAGES, DIRECT OR
INDIRECT, WHICH MAY RESULT
FROM THE USE OR POSSESSION OF
THE INFORMATION; OR FOR ANY
LOSS OF PROFIT, REVENUE,
CONTRACTS OR SAVINGS, OR ANY
OTHER DIRECT, INDIRECT,
INCIDENTAL, SPECIAL OR
CONSEQUENTIAL DAMAGES
ARISING OUT OF YOUR USE OF OR
INABILITY TO USE THIS
INFORMATION, ANY DEFECT IN THE
INFORMATION, OR THE BREACH OF
THESE TERMS OR CONDITIONS,
WHETHER IN AN ACTION IN
CONTRACT OR TORT OR BASED ON
A WARRANTY, EVEN IF [CLIENT] OR
ITS LICENSORS HAVE BEEN
ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. Some States,
Territories and Countries do not allow
certain liability exclusions or damages
limitations, so to that extent the above
may not apply to you.Export Control. You agree not to export
from anywhere any part of the Data pro-
vided to you or any direct product thereof
except in compliance with, and with all li-
censes and approvals required under,
applicable export laws, rules and regula-
tions.
Entire Agreement.
These terms and con-
ditions constitute the entire agreement
between [CLIENT] (and its licensors, in-
cluding their licensors and suppliers) and
you pertaining to the subject matter here-
of, and supersedes in their entirety any
and all written or oral agreements pre-
viously existing between us with respect
to such subject matter.
Governing Law.
The above terms and
conditions shall be governed by the laws
of the State of Illinois [insert
“Netherlands” where European NAVTEQ
Data is used], without giving effect to (i)
its conflict of laws provisions, or (ii) the
United Nations Convention for Contracts
for the International Sale of Goods, which
is explicitly excluded. You agree to
submit to the jurisdiction of the State of
Illinois [insert “The Netherlands” where
European NAVTEQ Data is used] for any
and all disputes, claims and actions
arising from or in connection with the
Data provided to you hereunder.
Government End Users. If the Data is be-
ing acquired by or on behalf of the United
States government or any other entity
seeking or applying rights similar to those
customarily claimed by the United States
government, this Data is a “commercial
item” as that term is defined at 48 C.F.R.
(“FAR”) 2.101, is licensed in accordance
with these End User Terms, and each
copy of the Data delivered or otherwise
furnished shall be marked and em-
bedded as appropriate with the following
“Notice of Use,” and shall be treated in
accordance with such Notice:

215 NOTICE OF USE
CONTRACTOR (MANUFACTURER/
SUPPLIER) NAME: NAVTEQ
CONTRACTOR (MANUFACTURER/
SUPPLIER) ADDRESS:
222 Merchandise Mart Plaza, Suite
900, Chicago, Illinois 60654
This Data is a commercial item as de-
fined in FAR 2.101 and is subject to the
End User Terms under which this Data
was provided.
© 2005 NAVTEQ − All rights reserved.
If the Contracting Officer, federal gov-
ernment agency, or any federal official
refuses to use the legend provided
herein, the Contracting Officer, federal
government agency, or any federal offi-
cial must notify NAVTEQ prior to seek-
ing additional or alternative rights in the
Data.
END USER LICENSE AGREEMENT
PLEASE READ THIS AGREEMENT
CAREFULLY BEFORE USING THE
NAVIGATION SYSTEM
THIS IS A LICENSE AGREEMENT FOR
YOUR COPY OF THE SPATIAL MAP
DATABASE, INCLUDING LOCATION
CODES AND RELATED PRODUCTS
(COLLECTIVELY, THE ”DATABASE”),
USED IN THE NAVIGATION SYSTEM.
BY USING THE NAVIGATION SYSTEM
AND THE DATABASE, YOU ACCEPT
AND AGREE TO BE BOUND BY ALL
TERMS AND CONDITIONS SET
FORTH BELOW.
LICENSE GRANT
Denso Corporation (“Denso”), as a
licensed distributor of the DATABASE,
grants to you a non−exclusive,
non−perpetual license to use your copy
of the DATABASE for your personal use
or for your use in your business’ internal
operations and not for any other purpose.
This license does not include the right to
grant sub−licenses.OWNERSHIP
The DATABASE and the copyrights and
intellectual property and neighboring
rights therein are owned by Tele Atlas
North America, Inc. (“TANA”) and its
licensors. This Agreement does not
transfer any title or interest in the
DATABASE, except for the license to use
the DATABASE according and subject to
the terms and conditions of this
Agreement. You shall not alter, obscure
or remove any copyright notices,
trademark notices or other restrictive
legends relating to the DATABASE.
The DATABASE comprises confidential
and proprietary information and materi-
als of TANA. Accordingly, you shall hold
the DATABASE in confidence and trust.
You shall take reasonable steps to pro-
tect the DATABASE from misappropri-
ation or misuse. You shall not extract
stand−alone data from or publish any
part of the DATABASE without the prior
written consent of TANA and its licen-
sors.

216 LIMITATIONS ON USE
The DATABASE is restricted for use in
the specific system for which it was
created. Except to the extent explicitly
permitted by mandatory laws, you may
not extract or reutilize any portion of the
contents of the DATABASE, nor
reproduce, copy, duplicate, modify,
adapt, translate, disassemble,
decompile, or reverse engineer any
portion of the DATABASE.
TRANSFER
You may not transfer the DATABASE to
third parties, except together with the
system for which it was created, provided
that you do not retain any copy of the
DATABASE, and provided that the
transferee agrees to all terms and
conditions of this AGREEMENT.
DISCLAIMER OF WARRANTY
THE DATABASE IS PROVIDED ON AN
“AS IS” AND “WITH ALL FAULTS
BASIS” AND DENSO AND TANA (AND
THEIR LICENSORS AND SUPPLIERS)
EXPRESSLY DISCLAIM ALL OTHER
WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING BUT NOT
LIMITED TO, THE IMPLIED
WARRANTIES OF
NON−INFRINGEMENT,
MERCHANTABILITY, SATISFACTORY
QUALITY, ACCURACY, TITLE AND
FITNESS FOR A PARTICULAR
PURPOSE. NO ORAL OR WRITTEN
ADVICE OR INFORMATION
PROVIDED BY DENSO OR TANA (OR
ANY OF THEIR LICENSORS, AGENTS,
EMPLOYEES OR THIRD PARTY
PROVIDERS) SHALL CREATE A
WARRANTY, AND YOU ARE NOT
ENTITLED TO RELY ON ANY SUCH
ADVICE OR INFORMATION. THIS
DISCLAIMER OF WARRANTIES IS AN
ESSENTIAL CONDITION OF THIS
AGREEMENT.LIMITATION OF LIABILITY
IN NO EVENT SHALL DENSO OR TANA
(OR THEIR LICENSORS OR
SUPPLIERS) BE LIABLE FOR ANY
INCIDENTAL, CONSEQUENTIAL,
SPECIAL, INDIRECT OR EXEMPLARY
DAMAGES ARISING OUT OF THIS
AGREEMENT OR YOUR USE OF THE
DATABASE, INCLUDING, WITHOUT
LIMITATION, LOST PROFITS OR
COSTS OF COVER, LOSS OF USE OR
BUSINESS INTERRUPTION OR THE
LIKE, REGARDLESS OF WHETHER
THE PARTY WAS ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES.
IN NO EVENT WILL THE TOTAL
LIABILITY OF DENSO OR TANA (OR
THEIR LICENSORS OR SUPPLIERS)
EXCEED THE AMOUNTS PAID BY
YOU FOR THE DATABASE.

217 WARNINGS
The DATABASE comprises facts and
information from government and other
sources reflecting circumstances in
existence before you received the
DATABASE, which may contain errors
and omissions. Accordingly, the
DATABASE may contain inaccurate or
incomplete information due to the
passage of time, changing
circumstances, and due to the nature of
the sources used. The DATABASE does
not include or reflect information relating
to, among other things, neighborhood
safety; law enforcement; emergency
assistance; construction work; road or
lane closures; vehicle or speed
restrictions; road slope or grade; bridge
height, weight or other limits; road or
traffic conditions; special events; traffic
congestion; or travel time.
U.S. GOVERNMENT RIGHTS
If you are an agency, department, or
other entity of the United States
Government, or funded in whole or in part
by the United States Government, then
use, duplication, reproduction, release,
modification, disclosure or transfer of this
commercial product and accompanying
documentation, is restricted in
accordance with the LIMITED or
RESTRICTED rights as described in
DFARS 252.227−7014(a)(1) (JUN 1995)
(DOD commercial computer software
definition), DFARS 227.7202−1 (DOD
policy on commercial computer
software), FAR 52.227−19 (JUN 1987)
(commercial computer software clause
for civilian agencies), DFARS
252.227−7015 (NOV 1995) (DOD
technical data – commercial items
clause); FAR 52.227−14 Alternates I, II,
and III (JUN 1987) (civilian agency
technical data and noncommercial
computer software clause); and/or FAR
12.211 and FAR 12.212 (commercial
item acquisitions), as applicable. In case
of conflict between any of the FAR and
DFARS provisions listed herein and this
Agreement, the construction that
provides greater limitations on the
Government’s rights shall control.Contractor/manufacturer is Tele Atlas
North America, Inc., 11 Lafayette Street,
Lebanon, NH 03766−1445. Phone:
603.643. 0330. The DATABASE is
©1984−2005 by Tele Atlas North Ameri-
ca, Inc. ALL RIGHTS RESERVED. For
purpose of any public disclosure provi-
sion under any federal, state or local law,
it is agreed that the DATABASE is a trade
secret and a proprietary commercial
product and not subject to disclosure.
