navigation TOYOTA TUNDRA 2008 2.G Navigation Manual

OTHER FUNCTIONS
1672008 TUNDRA Navigation from Oct.07 Prod.(OM34469U) When you search the destination by “POI
Name”, this screen is displayed.
5U5288G
Touch “Enter” or say “Enter destination”.
When you touch “Show List”, you can
search another spot in its category.
INFORMATION
In the following conditions, the system
may not recognize the command proper-
ly.
The command is not correct or clear.
There are some noises such as wind
noise, etc.
Help screen
This system has a function which displays
the voice recognition help screen. You
can see the command list and operating
guide on it.
(a) Command List
1. If the “Operating Guide” screen is dis-
played, touch “Command List” on the up-
per side of the screen.
5U5115G
2. Select the desired category by touch-
ing the buttons on the right side of the
“Command List” screen.
3. You can scroll through the list of the
command list by touching “
” or “”.
Touch “OK” after you check it.(b) Operating Guide
1. If the “Command List” screen is dis-
played, touch “Operating Guide” on the
upper side of the screen.
5U5502G
2. Select the desired category by touch-
ing the buttons on the right side of the
“Operating Guide” screen.
3. You can scroll through the list of the op-
erating guide by touching “
” or “”.
Touch “OK” after you check it.

OTHER FUNCTIONS
1682008 TUNDRA Navigation from Oct.07 Prod.(OM34469U)
Screen adjustment
The brightness or contrast of the screen
can be adjusted depending on the bright-
ness of your surroundings. You can also
turn the display off.
XS00208
1. To display the “Display” screen, push
the “DISP” button.
5U5008bG
Contrast and brightness adjustment
2. Touch the desired button to adjust con-
trast and brightness.
“Contrast” “+”:
Strengthens the contrast of the screen.
“Contrast” “”:
Weakens the contrast of the screen.
“Brightness” “+”:
Brightens the screen.
“Brightness” “”:
Darkens the screen.
3. After adjusting the screen, touch “OK”.
If your vehicle is equipped with the rear seat
entertainment system, the rear screen turns
on or off when “Rear” is touched.
The screen goes off when “Screen Off” is
touched. To turn the display screen back on,
push any button such as “INFO”, etc. The se-
lected screen appears.
INFORMATION
When you do not touch any touch
screen button on the screen for 20 sec-
onds the “Display” screen goes off.
5U5010bG
Color and tone adjustment (with rear seat
entertainment system)
1. Touch the desired button to adjust col-
or and tone.
You can adjust the color and the tone while
the DVD video and video CD are being
played.
“Color” “R”:
Strengthens the red color of the screen.
“Color” “G”:
Strengthens the green color of the screen.
“Tone” “+”: Strengthens the tone of the
screen.
“Tone” “”: Weakens the tone of the screen.
2. After adjusting the screen, touch “OK”.
The rear screen turns on or off when “Rear”
is touched.

OTHER FUNCTIONS
1692008 TUNDRA Navigation from Oct.07 Prod.(OM34469U) The screen turns off when “Screen Off” is
touched. To turn the screen back on, push
any button such as “INFO”, etc. The selected
screen appears.
INFORMATION
When you do not touch any touch
screen button on the screen for 20 sec-
onds the “Display” screen goes off.
5U5009bG
Depending on the position of the headlight
switch, the screen changes to either day
mode or night mode.
To display the screen in the day mode even
with the headlight switch on, touch “Day
Mode” on the adjustment screen for bright-
ness and contrast control.
If the screen is set in the day mode with the
headlight switch turned on, this condition is
memorized in the system even with the en-
gine turned off.
Screen setting
XS00203
1. Push the “INFO” button to display the
“Information” screen.
5U5112G
2. Touch “Screen Setting”.

OTHER FUNCTIONS
1702008 TUNDRA Navigation from Oct.07 Prod.(OM34469U)
(a) Automatic transition
You can select a function that enables au-
tomatic return to the navigation screen
from the audio screen.
RS02019a
Select “ON” or “OFF” and then touch
“OK”.
“ON”:The navigation screen automatically
returns from the audio screen 20
seconds after the end of audio op-
eration.
“OFF”:The audio screen remains on.
(b) Switch color
You can select a color of touchscreen
buttons.
RS02019a
Select “Green” or “Orange” and then
touch “OK”.
(c) Rear system lock
(with rear seat entertainment
system)
If the vehicle is equipped with the rear seat
entertainment system, the rear seat enter-
tainment system can be locked to prevent
rear passengers from operating the enter-
tainment system.
RS02019a
Select “ON” or “OFF” and then touch
“OK”.
“ON”: The rear passengers cannot operate
the rear seat entertainment system. Only
front passengers can operate the system.
“OFF”: Both the front and rear passengers
can operate the rear seat entertainment sys-
tem.

OTHER FUNCTIONS
1712008 TUNDRA Navigation from Oct.07 Prod.(OM34469U)
Delete personal data
The following personal data can be de-
leted or returned to their default settings:
Information
Maintenance conditions
Maintenance information “off” setting
Navigation system
Memory points
Areas to avoid
Previous points
Route trace
User selection settings
Handsfree system
Phone book data
Dialed numbers and received calls
Speed dial
Bluetooth phone data
Security code
This function is available only when the
vehicle is not moving.
RS02019a
1. Touch “Delete personal data”. The
“Delete personal data” screen appears.
5U5113G
2. Touch “Delete”. The “Confirmation to
delete all personal data” screen appears.
5U5114G
3. Touch “Yes”.

OTHER FUNCTIONS
1722008 TUNDRA Navigation from Oct.07 Prod.(OM34469U)
Beep setting
You can set a beep sound off.
XS00203
1. Push the “INFO” button.
RS02030
2. Touch “Beep Off”.
“Beep Off” is highlighted.
To set the beep sound on, touch “Beep Off”
again.
Select language
The language of the touchscreen but-
tons, popup messages and the voice
guidance can be changed.
XS00203
1. Push the “INFO” button.
RS02031
2. Touch “Language”.

OTHER FUNCTIONS
1732008 TUNDRA Navigation from Oct.07 Prod.(OM34469U)
5U5706G
3. Touch “English”, “Français” or
“Español” to select a language.
4. Touch “OK”.
The language is changed and the screen re-
turns to the map display.

OTHER FUNCTIONS
1742008 TUNDRA Navigation from Oct.07 Prod.(OM34469U)

AUDIO/VIDEO SYSTEM
1752008 TUNDRA Navigation from Oct.07 Prod.(OM34469U)
AUDIO/VIDEO SYSTEM
Quick reference176 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using your audio/video system177 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Some basics177 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Radio operation182 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CD changer operation190 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DVD player operation201 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio remote controls219 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio/video system operating hints221 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 6

AUDIO/VIDEO SYSTEM
1762008 TUNDRA Navigation from Oct.07 Prod.(OM34469U)
1Function menu display screen
To control the radio, CD changer or DVD
player, touch the touch−screen buttons.
For details, see page 179.
2“TUNE·FILE” knob
Turn this knob to move the station band
and files up or down. For details, see
pages 183 and 198.
3“FM 1·2” button
Push this button to choose an FM sta-
tion. For details, see pages 179 and
182.
4“AM·SAT” button
Push this button to choose an AM or SAT
station. For details, see pages 179, 182
and 185.
5“DISC·AUX” button
Push this button to turn the CD changer,
DVD player and AUX on. For details,
see pages 179, 182, 193 and 202.
6“SCAN” button
Push this button to scan radio stations.
For details, see pages 183, 195, 199,
203 and 206.
7“AUDIO” button
Push this button to display the audio
control screen. For details, see page
178.
Quick reference
XS00209
