TOYOTA TUNDRA 2008 2.G Owners Manual

351
2008 TUNDRA from Apr. ’08 Prod. (OM 34477U)
Delete Speed Dial
The registered speed dial can be de-
leted.
List names
The registered names can be checked.
Set Speed Dial
Speed dials can be set
Redial (see page 373)
Callback (see page 374)
Making a phone call (see page 376)
Receiving a phone call (see page 378)
Talking on the phone (see page 379)
—Some basics
XS18010a
This system supports Bluetooth, a
wireless system that allows you to
make or receive calls without taking
your hands from the steering wheel and
without using cables to connect the
phone and system.
The phone must be paired to the system
before using the hands −free feature. If
your cellular phone does not support Blue-
tooth
, this system will not function.
CAUTION
While you are driving, do not use a
cellular phone or connect the Blue-
tooth
 phone.
NOTICE
Do not leave your cellular phone in
the car. The temperature indoor may
be high and damage the phone.

352
2008 TUNDRA from Apr. ’08 Prod. (OM 34477U)
The system may not function in the follow-
ing conditions and places:
The cellular phone is turned off.
The current position is outside the
communication area.
The cellular phone is not connected.
The cellular phone has a low battery.
The cellular phone is hiding behind the
seat or in the glove box and console
box.
The cellular phone touches or is cov-
ered with metal materials.
This system supports the following ser-
vice.
HFP (Hands Free Profile) Ver.1.0.
OPP (Object Push Profile) Ver.1.1.
If your cellular phone does not support
HFP, you cannot enter the Bluetooth

phone, and take OPP service individually.
Bluetooth is a registered trademark of
Bluetooth SIG. Inc. When transferring ownership of the ve-
hicle:
A lot of personal data is registered
when you use the handsfree system.
When transferring ownership of the ve-
hicle, initialize the system.
If you initialize it, the former state will
never come back again. Pay much atten-
tion when initializing the data.
You can initialize the following data in the
system.
Phone book data
Dialed numbers and received calls
Speed dial
Bluetooth phone data
Security code
FCC ID: HYQBTAU01A
IC ID: 1551ABTAU01A
MADE IN MEXICO
This device complies with Part 15 of the
FCC Rules and RSS
−210. Operation is
subject to the following two conditions:
(1) This device may not cause harmful
interference, and (2) this device must
accept any interference received, includ-
ing interference that may cause unde-
sired operation.
CAUTION
Changes or modifications not ex-
pressly approved by the party respon-
sible for compliance could void the
user’s authority to operate the equip-
ment.

353
2008 TUNDRA from Apr. ’08 Prod. (OM 34477U)
NOTE: This equipment has been tested
and found to comply with the limits for
a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits
are designed to provide reasonable
protection against harmful interference in
a residential installation. This equipment
generates, uses and can radiate radio
frequency energy and, if not installed
and used in accordance with the instruc-
tions, may cause harmful interference to
radio communications. However, there is
no guarantee that interference will not
occur in a particular installation. If this
equipment does cause harmful interfer-
ence to radio or television reception,
which can be determined by turning the
equipment off and on, the user is en-
couraged to try to correct the interfer-
ence by one or more of the following
measures:
—Reorient or relocate the receiving an-
tenna.
—Increase the separation between the
equipment and receiver.
—Connect the equipment into an outlet
on a circuit different from that to which
the receiver is connected.
—Consult the dealer or an experienced
radio/TV technician for help.CAUTION: Radio Frequency Radiation
Exposure
This equipment complies with FCC radi-
ation exposure limits set forth for uncon-
trolled equipment and meets the FCC
radio frequency (RF) Exposure Guide-
lines in Supplement C to OET65. This
equipment has very low levels of RF
energy that it deemed to comply without
maximum permissive exposure evalua-
tion (MPE). But it is desirable that it
should be installed and operated with at
least 20 cm and more between the ra-
diator and person’s body (excluding ex-
tremities: hands, wrists, feet and legs).
Colocation: This transmitter must not
be co− located or operated in conjunction
with any other antenna or transmitter.
XS18011a
Steering switches
XS18012a
Overhead console (Type A)
—Control and features
 Steering switches and microphone

354
2008 TUNDRA from Apr. ’08 Prod. (OM 34477U)
XS18013a
Overhead console (Type B)
1. Volume control switch
To increase the volume: Push “+”.
To decrease the volume: Push “ −”.
The volume continues increasing or de-
creasing while the switch is being pushed.
When driving at 80 km/h (50 mph) or
more, the volume automatically increases
without switch adjustment. When your
speed falls below 70 km/h (43 mph), the
volume automatically returns to its original
level. 2. Talk switch
Pushing the talk switch turns the hands −
free system on and initiates the speech
command system.
Pushing and holding the talk switch ends
the speech command system.
3. Offhook switch
Pushing the off −hook switch turns the
hands −free system on.
When receiving a call, pushing the off −
hook switch allows you to talk on the
phone.
4. Onhook switch
When the hands −free system is on, push-
ing the on −hook switch turns the hands −
free system off.
5. Microphone
The microphone is used when talking on
the phone or using the speech command
system.

355
2008 TUNDRA from Apr. ’08 Prod. (OM 34477U)
1. “AUDIO/CONTROL” knob
Turning the “AUDIO/CONTROL” knob dis-
plays the menu items, names, numbers,
etc. to be selected. To select an item,
push the “AUDIO/CONTROL” knob. Due to
safety concerns, the “AUDIO/CONTROL”
knob does not function while the vehicle
is in motion.
2. Display
Displays such items as the reception lev-
el, a party’s name and phone number. See
“DISPLAY” described on the following
page for further details about the display.
3. “TEXT” button
When the party’s name or phone number
is too long to be displayed, pushing and
holding the “TEXT” button displays the re-
maining characters.
4. Preset buttons
Pushing the preset button displays the
registered speed dial numbers.

Audio unit
XS18014

356
2008 TUNDRA from Apr. ’08 Prod. (OM 34477U)
XS18015a
DISPLAY
1. Bluetooth
 display
Displays when a Bluetooth
 connection is
made. If there is no display, the
Bluetooth
 connection has not been made
and communication between the phone
and system is not possible. When using
the hands −free system, make sure that
“BT” is displayed. The display is updated
in real time. 2. Reception level display
Displays the reception level of the radio
wave signals. This may not match the
display on the cellular phone. The recep-
tion level of some cellular phones may not
be displayed.
The number of bars is greater when the
signal received is stronger.
3. Message display
Displays phone numbers, names, com-
ments, menu items, etc.
—Phone Setup
The phone setup menu includes the fol-
lowing:
Pair Phone
To use the hands −free system, you need
to register your phone in the system.
Once you have registered it, you can
make a hands −free call. Up to 6 phones
can be registered.
Select Phone
When the system connects to Bluetooth
,
the phone previously used is automatically
selected. Select a different phone if nec-
essary. Only the selected phone can be
used with the hands −free system.
Change Name
The registered phone names can be
changed.
List Phones
The registered phone names can be
checked.
The following can be performed during the
name playback:
Select phone
Change name
Delete

357
2008 TUNDRA from Apr. ’08 Prod. (OM 34477U)
Set Passkey
The passkey can be c hanged. A 4 to 8
digit code can be input as a pa sskey.
Delete
The registered phones can be deleted.
To enter the phone setup menu 1. Push the off −hook switch to turn the
hands −free system on.
2. Follow voice guidance instructions, or turn the “AUDIO/CONTROL” knob until
“Setup” is displayed and push the
knob.
“Setup. Please push the talk switch and
say security, or phone setup.” is heard. 3. Follow voice guidance instructions, or turn the “AUDIO/CONTROL” knob until
“Phone Setup” is displayed and push
the knob.
“Phone setup. Push the talk switch and
say pair phone, select phone, change
name, list phones, set pa sskey or delete.”
is heard.
“XXX (phone name) already selected.” is
heard and “XXX (phone name)” is dis-
played.
If no phone has been registered, the sys-
tem may not function properly. To pair phones
1. Push the talk switch and say “Pair phone”, or turn the “AUDIO/CONTROL”
knob until “Pair Phone” is displayed
and push the knob.
“Pair. Push the talk switch and say a
name for the phone.” is heard. 2. Follow voice guidance instructions, or turn the “AUDIO/CONTROL” knob until
“Record Name” is displayed, push the
knob and say “XXX (desired phone
name)”.
“Push the talk switch and say confirm.
Otherwise, say go back.” is heard. 3. Follow voice guidance instructions, or turn the “AUDIO/CONTROL” knob until
“Confirm” is displayed and push the
knob.
“XXX Ready for phone pairing. Please use
the phone to connect it to the hands −free
system. The passkey for the p hone is....”
is heard.
After “HANDS FREE” is displayed, a pass-
key
∗ is displayed and “Searching.” is
heard.
4. Input the passkey displayed on the screen into the phone. “The phone is paired and ready for use.
Returning to the main menu.” is heard and
“Paired” is displayed.
The system may not function in the follow-
ing cases:
If 6 phones have already been regis-
tered.
If the vehicle is moving.
If the system cannot communicate with
the phone.
∗: Passkey is a password r
equired to reg-
ister a phone to the system.
INFORMATION
 To use the handsfree system, you
need to register your phone in the
system. Once you have registered
it, you can make a handsfree call.
Up to 6 phones can be registered.
 For the operation of the phone, see
the manual that comes with your
cellular phone.
 The passkey can be changed. See
page 360 for changing the passkey.

358
2008 TUNDRA from Apr. ’08 Prod. (OM 34477U)
To select a phone
1. Push the talk switch and say “Select phone”, or turn the “AUDIO/CONTROL”
knob until “Select Phone” is displayed
and push the knob.
“Select phone. Push the talk switch and
say the phone name or say list phones.”
is heard. 2. Follow voice guidance instructions, or turn the “AUDIO/CONTROL” knob until
the desired phone name is displayed
and push the knob.
When the phone is selected by a voice
command:
“XXX Push the talk switch and say
confirm. Otherwise, say go back.” is heard
and “XXX” is displayed.
Follow voice guidance instructions, or turn
the “AUDIO/CONTROL” knob until
“Confirm” is displayed and push the knob.
“XXX selected. Returning to the phone
setup.” is heard. When the phone is selected by using
the knob:
“XXX selected. Returning to the phone
setup.” is heard.
The system may not function in the follow-
ing cases:
If the phone is not found.
If the system does not recognize the
voice command.
To change a name
1. Push the talk switch and say “Change name”, or turn the “AUDIO/CONTROL”
knob until “Change Name” is displayed
and push the knob.
“Change name. Push the talk switch and
say the phone name to change.” is heard. 2. Follow voice guidance instructions, or turn the “AUDIO/CONTROL” knob until
the phone name that you want to
change is displayed and push the
knob.

359
2008 TUNDRA from Apr. ’08 Prod. (OM 34477U)
When the phone is selected by a voice
command:
“XXX Push the talk switch and say
confirm. Otherwise, say go back.” is heard
and “XXX” is displayed.
1. Follow voice guidance instructions, or turn the “AUDIO/CONTROL” knob until
“Confirm” is displayed and push the
knob.
“Push the talk switch and say a new
name.” is heard.
2. Follow voice guidance instructions, or turn the “AUDIO/CONTROL” knob until
“Record Name” is displayed, push the
knob and say “XXX (desired phone
name)”.
“XXX Push the talk switch and say
confirm. Otherwise, say go back.” is
heard. 3. Follow voice guidance instructions, or turn the “AUDIO/CONTROL” knob until
“Confirm” is displayed and push the
knob.
“Name changed. Returning to the phone
setup.” is heard and “Changed” is dis-
played. When the phone is selected by using
the knob:
“XXX Push the talk switch and say
confirm. Otherwise, say go back.” is heard
and “XXX” is displayed.
1. Follow voice guidance instructions, or turn the “AUDIO/CONTROL” knob until
“Confirm” is displayed and push the
knob.
“Push the talk switch and say a new
name.” is heard.
2. Follow voice guidance instructions, or turn the “AUDIO/CONTROL” knob until
“Record Name” is displayed, push the
knob and say “XXX (desired phone
name)”.
“XXX Push the talk switch and say
confirm. Otherwise, say go back.” is
heard. 3. Follow voice guidance instructions, or turn the “AUDIO/CONTROL” knob until
“Confirm” is displayed and push the
knob.
“Name changed. Returning to the phone
setup.” is heard and “Changed” is dis-
played. The system may not function in the follow-
ing cases:
If no phone has been registered.
If the system does not recognize the
voice command.
To list phones 1. Push the talk switch and say “List phones”, or turn the
“AUDIO/CONTROL” knob until “List
Phones” is displayed and push the
knob.
“List phones. To select a name, push the
talk switch during the name playback.” is
heard. 2. Follow voice guidance instructions.
“Push the talk switch and say select
phone, change name, or delete.” is heard.
Select one of the following:

360
2008 TUNDRA from Apr. ’08 Prod. (OM 34477U)
Select phone
Push the talk switch and say “Select
phone”, or turn the “AUDIO/CONTROL”
knob until “Select Phone” is displayed and
push the knob.
For further details on selecting a phone,
see page 358.
Change name
Push the talk switch and say “Change
name”, or turn the “AUDIO/CONTROL”
knob until “Change Name” is displayed
and push the knob.
For further details on changing a name,
see page 358.
Delete
Push the talk switch and say “Delete”, or
turn the “AUDIO/CONTROL” knob until
“Delete” is displayed and push the knob.
For further details on deleting a phone,
see page 361.
If no phone has been registered, the sys-
tem may not function properly. To set a passkey
1. Push the talk switch and say “Set passkey”, or turn the
“AUDIO/CONTROL” knob until “Set
Passkey” is displayed and push the
knob.
“Set Passkey. The passkey is r equired for
the phone pairing process. Push the talk
switch and say a new passkey.” is heard
and passkey is displayed.
2. Follow voice guidance instructions, or turn the “AUDIO/CONTROL” knob to
select a number.
When using a voice command:
“XXXX (new pa sskey) Push the talk switch
and say confirm. Otherwise, continue
adding numbers, or say go back or
delete.” is heard and “XXXX (new
passkey)” is displayed.
Follow voice guidance instructions, or turn
the “AUDIO/CONTROL” knob until
“Confirm” is displayed and push the knob.
“Passkey ch anged. Returning to the phone
setup.” is heard. When using the knob:
1. Turn the “AUDIO/CONTROL” knob to select a number. Push the
“AUDIO/CONTROL” knob to set.
2. When the passkey is set, push the “AUDIO/CONTROL” knob.
“Passkey c hanged. Returning to the phone
setup.” is heard.
The system may not function in the follow-
ing cases:
If the passkey has less than 4 digits.
If the passkey has more than 8 digits.
