TOYOTA TUNDRA 2009 2.G Navigation Manual

11
2009 TUNDRA Navigation from Aug.08 Prod.(OM34476U)
No.NameFunctionPage
7“Map View”
Touch this touch−screen button to
browse information about guidance
route, to set the Points of Interest to be
displayed on the screen, or to record the
route.
80, 82, 83, 84
8“  OFF”
Touch this touch−screen button to ob-
tain a broader view. Some of the but-
tons on the screen are not displayed.
They are displayed again by touching
“ON ”.
11 2
9
Zoom in
touchscreen
buttonTouch this touch− screen button to mag-
nify the map scale.37
10
Foot print map
touchscreen
buttonTouch this touch−screen button to dis-
play the foot print map and the building
information.
38
11“INFO” buttonPush this button to display the
“Information” screen.120, 124, 134, 181
12“MENU” buttonPush this button to display the “Menu”
screen.88, 90, 268
13
Screen
configuration
touchscreen
button
Touch this touch−screen button to
change the screen mode.35
14“DEST” buttonPush this button to display the
“Destination” screen.42, 43
15“MAP/VOICE”
buttonPush this button to repeat a voice guid-
ance, cancel one touch scroll, start
guidance, and display the current posi-
tion.
30, 31, 71
16Distance and time
to destinationDisplays the distance, the estimated
travel time to the destination, and the
estimated arrival time at the destination.
73

12
2009 TUNDRA Navigation from Aug.08 Prod.(OM34476U)
17
“GPS” mark
(Global
Positioning
System)Whenever your vehicle is receiving sig-
nals from the GPS, this mark is dis-
played.256
18
Speech
command system
indicatorThis indicator is shown by pushing the
talk switch. The speech command sys-
tem can be operated while this indicator
is shown.
175

13
2009 TUNDRA Navigation from Aug.08 Prod.(OM34476U)
XS00401
0U5002F
0U5003F
0U5004F
1Push “MENU” button.
2Touch “My Places”.
3Touch “Register” of the Home.
4There are 13 different methods to
search your home.
See “Destination search” on page 43.
— Registering home

14
2009 TUNDRA Navigation from Aug.08 Prod.(OM34476U)
0U5005F
0U5006F
5Touch “Enter”.
The “Memory Point” screen is displayed.
6Touch “OK”.
Registration of home is complete.
You can change the icon, quick access,
name, location and phone number. (See
“ — Editing memory points” on page 96.)

15
2009 TUNDRA Navigation from Aug.08 Prod.(OM34476U)
XS00401
0U5007F
0U5008F
0U5009F
1Push “MENU” button.
2Touch “My Places”.
3Touch “Register” of the memory
points.
4There are 13 different methods to
search a preset memory point.
See “Destination search” on page 43.
— Registering preset memory point
(Quick access)

16
2009 TUNDRA Navigation from Aug.08 Prod.(OM34476U)
0U5010F
0U5011F
0U5012F
0U5013F
5Touch “Enter”.
The “Memory Point” screen is displayed.
6Touch “Quick Access”.
7Touch one of preset buttons 1 to
5.
8Touch “OK”.
Registration of the preset memory point is
complete.
You can change the icon, quick access,
name, location and phone number. (See
“ — Editing memory points” on page 96.)
The registered points can be used on the
“Destination” screen. (See “ — Destination
search by Quick access” on page 46.)

17
2009 TUNDRA Navigation from Aug.08 Prod.(OM34476U)
XS00402
0U5014F
0U5015F
0U5016F
1Push “DEST” button.
2There are 13 different methods to
search destinations.
See “Destination search” on page 43.
3Touch “Enter”.
The navigation system performs a search
for the route.
4Touch “Guide”, and start driving.
Routes other than the one recommended
can also be selected. (See “Starting route
guidance” on page 63.)
5Guidance to the destination is
given via voice and on the guid-
ance screen.
— Operation flow: guiding the route

18
2009 TUNDRA Navigation from Aug.08 Prod.(OM34476U)
XS00402
0U5017F
0U5018F
0U5019F
1Push “DEST” button.
2Touch .
The can be used if your home has
been registered. (To register “Home”, see
“ — Registering home” on page 102.)
3Touch “Enter”.
The navigation system performs a search
for the route.
4Touch “Guide”, and start driving.
Routes other than the one recommended
can also be selected. (See “Starting route
guidance” on page 63.)
5Guidance to the destination is
given via voice and on the guid-
ance screen.
— Setting home as the destination

19
2009 TUNDRA Navigation from Aug.08 Prod.(OM34476U)
Map
Displaying mapsPage
Viewing the map screen10
Displaying the current vehicle position30
Viewing the current position vicinity map31
Changing the scale37
Changing the map orientation39
Displaying POIs∗80
Displaying the estimated travel/arrival time to the destination73
Selecting the dual map screen35
Viewing foot print map38
Deleting map screen touch −screen buttons11 2
Searching destinationPage
Searching the destination (by home, POI∗, phone #, etc.)43
Changing the search area44
Operating the map location of the selected destination63
Route guidance
Before starting route guidancePage
Setting the destination63
Viewing alternative routes63
Starting route guidance63
Before starting or during route guidancePage
Viewing the route63
Adding destinations74
Changing the route76
Displaying the estimated travel/arrival time to the destination73
∗: Point(s) of Interest
Navigation system function index

20
2009 TUNDRA Navigation from Aug.08 Prod.(OM34476U)
During route guidancePage
Suspending route guidance90
Adjusting route guidance volume91
Deleting the destination75
Displaying the entire route map82
Useful functions
Memory pointsPage
Registering your own memory points94
Marking icons on the map94
InformationPage
Displaying vehicle maintenance timing120
Displaying the calendar124
Handsfree system (for cellular phone)Page
Initiating Bluetooth134
Making a call on the Bluetooth phone137
Receiving a call on the Bluetooth phone143
Speech command systemPage
Operating the system with your voice175
Rear view monitor systemPage
Rear view monitor system252
