Map
Displaying mapsPage
Viewing the map screen10
Displaying the current vehicle position30
Viewing the current position vicinity map31
Changing the scale37
Changing the map orientation39
Displaying POIs∗80
Displaying the estimated travel/arrival time to the destination73
Selecting the dual map screen35
Viewing foot print map38
Deleting map screen touch −screen buttons11 2
Searching destinationPage
Searching the destination (by home, POI∗, phone #, etc.)43
Changing the search area44
Operating the map location of the selected destination63
Route guidance
Before starting route guidancePage
Setting the destination63
Viewing alternative routes63
Starting route guidance63
Before starting or during route guidancePage
Viewing the route63
Adding destinations74
Changing the route76
Displaying the estimated travel/arrival time to the destination73
∗: Point(s) of Interest
Navigation system function index

20
2009 TUNDRA Navigation from Aug.08 Prod.(OM34476U)
During route guidancePage
Suspending route guidance90
Adjusting route guidance volume91
Deleting the destination75
Displaying the entire route map82
Useful functions
Memory pointsPage
Registering your own memory points94
Marking icons on the map94
InformationPage
Displaying vehicle maintenance timing120
Displaying the calendar124
Handsfree system (for cellular phone)Page
Initiating Bluetooth134
Making a call on the Bluetooth phone137
Receiving a call on the Bluetooth phone143
Speech command systemPage
Operating the system with your voice175
Rear view monitor systemPage
Rear view monitor system252

BASIC FUNCTIONS
25

Maintenance information
This system informs about when to replace
certain parts or components and shows
dealer information (if registered) on the
screen.
When the vehicle reaches a previously set
driving distance or date specified for a
scheduled maintenance check, the
“Information” screen will be displayed
when the navigation system is in
operation.
1U5003F
To disable this screen, touch “Do Not
Display This Message Again.”. This
screen goes off if the screen is not op-
erated for several seconds.
To prevent this information screen from be-
ing displayed again, touch “Do Not
Display This Message Again.” .
To register “Maintenance information”, see
“Maintenance information” on page 120.
Memo information
This system notifies about a memo entry.
At the specified date, the memo informa-
tion will be displayed when the navigation
system is in operation. The memo informa-
tion screen will be displayed every time the
system is turned on.
1U5055F
The memo of the current date can be
viewed by touching “Memo”. (See “ —
Editing a memo” on page 127.)
To disable this screen, touch “Do Not
Display This Message Again.”. This
screen goes off if the screen is not op-
erated for several seconds.
To prevent this information screen from be-
ing displayed again, touch “Do Not
Display This Message Again.” .
To register “Memo information”, see
“Calendar with memo” on page 124.

BASIC FUNCTIONS
30
Function help
Explanations for the functions of the
“Destination”, “Setup”, and “Menu”
screens can be viewed.
XS00328
Touch “?”.
1U5014F
:To view the previous page.
:To view the next page.
:To return to the previous screen. When starting the navigation system, the
current position is displayed first.
This screen displays the current vehicle
position
and a map of the surrounding local
area.
1U5015F
The current vehicle position mark (1) ap-
pears in the center or bottom center of the
map screen.
A street name will appear on the bottom of
the screen, depending on the scale of the
map (
2).
You can return to this map screen that
shows your current position at any time
from any screen by pushing the “MAP/
VOICE” button.
While driving, the current vehicle position
mark is fixed on the screen and the map
moves.
The current position is automatically set as
the vehicle receives signals from the GPS
(Global Positioning System). If the current
position is not correct, it is automatically
corrected after the vehicle receives sig-
nals from the GPS.
Map screen operation —
— Current position display

DESTINATION SEARCH
58
1. Push the “DEST” button.
2. Touching “Emergency” on the
“Destination” screen.
The display changes to a screen to select
police stations, dealers, hospitals or fire
stations. While driving, only nearby police
stations, dealers, hospitals, or fire stations
are shown. The current position is shown
with an address, and the latitude and the
longitude at the top of the screen.
2U5045F
3. Touch the desired emergency cate-
gory.
The selected emergency category list is
displayed.
2U5046F
4. Touch the touchscreen button of
the desired destination.
The screen changes and displays the map
location of the selected destination and the
route preference. (See
“Starting route
guidance” on page 63.)
INFORMATION
The navigation system does not
guide in areas where route guidance
is unavailable. (See page 257.)
1. Push the “DEST” button.
2. Touch “Memory” on the “Destina-
tion” screen.
A list of registered memory points is dis-
played. (To register or edit memory points,
see “My places” on page 94.)
2U5047F
3. Touch the touchscreen button of
your desired memory point.
The screen changes and displays the map
location of the selected destination and the
route preference. (See “Starting route
guidance” on page 63.)
— Destination search by
“Emergency”
— Destination search by
“Memory”

ADVANCED FUNCTIONS
88
The “Menu” screen allows effective use of the navigation system. To display the “Menu”
screen, push the “MENU” button.
0U5087X
1“Suspend Guidance” and
“Resume Guidance”
Suspends or resumes guidance 90 . . . .
2“Volume”
Sets the volume for voice guidance. 91
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3“?”
Function help for the “Menu” screen can be
viewed on this screen. 30 . . . . . . . . . . . .
4“Map DVD”
Displays information regarding the disc
version or covered area. 258 . . . . . . . . . .
5“Select User”
Up to 3 different settings for dif ferent users
can be memorized. 92 . . . . . . . . . . . . . . .
6“Setup”
Enables various settings for the navigation
system. 89,108 . . . . . . . . . . . . . . . . . . . . . .
7“My Places”
Enables changes to “Memory points”,
“Home” and “Areas to avoid”. Enables
deletion of the previous point. 94 . . . . . .
Quick reference (“Menu” screen)

ADVANCED FUNCTIONS
11 7

Current position/tire change cal-
ibration
The current vehicle position mark can be
adjusted manually. Miscalculation of the
distance caused by tire replacement can
also be adjusted.
1. Push the “MENU” button.
2. Touch “Setup” on the “Menu”
screen.
Then touch
twice to display page 3 of
the “Setup” screen.
4U5079F
3. Touch “Adjust” of “Calibration”.
4U5080F
4. Touch the desired touchscreen
button.
INFORMATION
For additional information on the ac-
curacy of a current vehicle position,
see “Limitations of the navigation
system” on page 256.
POSITION/DIRECTION CALIBRATION
When driving, the current vehicle position
mark will be automatically corrected by
GPS signals. If GPS reception is poor due
to location, you can manually adjust the
current vehicle position mark.
4U5081F
1. Touch “Position/Direction”.
4U5082F
2. Touch the eight directional touch
screen button to move the cursor
to
the desired point on the map.

OTHER FUNCTIONS
120
When the Navigation System is turned on,
the “Information” screen displays when it is
time to replace a part or certain compo-
nents. (See page 25.)
XS00403
1. Push the “INFO” button.
5U5001aF
2. Touch “Maintenance”.
5U5002F
3. Touch the desired touchscreen
button.
For details of each touch −screen button,
see “INFORMATION ITEMS” on page 121.
“Delete All”: To cancel all conditions
which have been inputted.
“Reset All”: To reset the item which has
satisfied a condition.
“Set Dealer”: To register or edit dealer in-
formation. (See “ — Dealer setting” on
page 122.)
If “ON” is selected, the system gives main-
tenance information with the “Information”
screen when the system is turned on. (See
page 25.)
If “OFF” is selected, the “Information”
screen is disabled.
When the vehicle needs to be serviced, the
touch−screen button color will change to
orange.
Maintenance information —
— Maintenance information
setting

OTHER FUNCTIONS
130
XS00405
Microphone (T ype A)
XS00406
Microphone (Type B)
You can use the microphone above
when talking on the phone.
The other party’s voice outputs from the
driver’s speaker. When the received calls
or received voice outputs, the audio from
the Audio system or voice guidance from
the Navigation system will be muted.
INFORMATION
 Talk alternately with the other party
on the phone. If you talk at the
same time, the voice may not reach
each other. (It is not a malfunction.)
 Keep the volume of receiving voice
down. Otherwise, echo is coming
up. When you talk on the phone,
speak clearly towards the micro-
phone.
 In the following situations, your
voice may not reach the other
party.
Driving on unpaved road. (Mak-
ing a traffic noise.)
Driving at the high speed.
The window is open.
Turning the airconditioning
vents towards the microphone.
The sound of the aircondition-
ing fan is loud.

OTHER FUNCTIONS
167
(f) Setting the security
When you set the security, you can pre-
vent people from using some functions
of the Handsfree system. It is useful
when you leave your car with the hotel
or you don’t want others to see the data
you registered.
When you set or unlock the security, you
have to input the security code. Be sure to
change the default code when you use the
security for the first time.Changing the security code
The security code is 4 digits and the de-
fault is “0000”.
Change a new code that is hard for other
people to know.
When you change the security code, don’t
forget the code. The dealers cannot unlock
the security when you forget it.
If you forget the security code, initialize
your personal data. When you initialize it,
not only the phone book data but also the
memory points in the navigation system,
etc. will be deleted. (See “Delete personal
data” on page 183.)
5U5157F
1. Touch “Phone Book Lock”.
5U5158F
2. Touch “Change”.
