TOYOTA TUNDRA 2010 2.G Owners Manual

651
6-1. Specifications
6
Vehicle specifications
*1: The model code is indicated on the Certification Label. (P. 653)*2: Without towing package*3: With towing package
USK56L-CRTSGA
5.7 L V8
(3UR-FBE) engine 4WD
Standard 8300 lb. (3760 kg)
*2
10300 lb. (4670 kg)*3
USK56L-CRTLGA
8300 lb. (3760 kg)
*2
10200 lb. (4625 kg)*3
USK57L-CHTSGA
Long 10100 lb. (4580 kg)
Model code*1EngineDriving
systemBed typeTowing capacity
(Trailer weight + cargo)

652 6-1. Specifications
CrewMax models
*1: The model code is indicated on the Certification Label. (P. 653)*2: Without towing package*3: With towing package
Model code*1EngineDriving
systemBed typeTowing capacity
(Trailer weight + cargo)
UPK51L-PSTSKA
4.6 L V8
(1UR-FE) engine 2WD
Short 7000 lb. (3175 kg)
*2
8500 lb. (3855 kg)*3
UPK51L-PSTLKA
7000 lb. (3175 kg)
*2
8500 lb. (3855 kg)*3
UPK56L-PSTSKA
4WD 6700 lb. (3035 kg)
*2
8200 lb. (3715 kg)*3
UPK56L-PSTLKA
6700 lb. (3035 kg)
*2
8100 lb. (3670 kg)*3
USK51L-PSTSKA
5.7 L V8
(3UR-FE) engine 2WD
8400 lb. (3810 kg)
*2
10400 lb. (4715 kg)*3
USK51L-PSTLKA
8400 lb. (3810 kg)
*2
10400 lb. (4715 kg)*3
USK56L-PSTSKA
4WD 8100 lb. (3670 kg)
*2
10100 lb. (4580 kg)*3
USK56L-PSTLKA
8100 lb. (3670 kg)
*2
10100 lb. (4580 kg)*3
USK56L-PSTSGA
5.7 L V8
(3UR-FBE) engine 4WD 8100 lb. (3670 kg)
*2
10100 lb. (4580 kg)*3
USK56L-PSTLGA
8100 lb. (3670 kg)
*2
10100 lb. (4580 kg)*3

653
6-1. Specifications
6
Vehicle specifications
Vehicle identification
■ Vehicle identification number
The vehicle identificati on number (VIN) is the legal identifier for your
vehicle. This is the primary identification number for your Toyota. It is
used in registering the ownership of your vehicle.
This number is stamped on the
top left of the instrument panel.
This number is also on the
Certification Label.

654 6-1. Specifications
■Engine number
The engine number is stamped on the engine bl ock as shown.
4.0 L V6 (1GR-FE) engine
4.6 L V8 (1UR-FE) engine
5.7 L V8 (3UR-FE, 3UR-FBE) engine

655
6-1. Specifications
6
Vehicle specifications
Engine
4.0 L V6 (1GR-FE) engine
4.6 L V8 (1UR-FE) and 5.7 L V8 (3UR-FE, 3UR-FBE) engines
Model1GR-FE
Type 6-cylinder V-type, 4-cycle, gasoline
Bore and stroke 3.70  3.74 in. (94.0  95.0 mm)
Displacement 241.4 cu.in. (3956 cm3)
Drive belt tension Automatic adjustment
Valve clearance
(engine cold)
Intake
Exhaust 0.006 
0.010 in. (0.15  0.25 mm)
0.011  0.015 in. (0.29  0.39 mm)
Model 1UR-FE, 3UR-FE, 3UR- FBE
Type 8-cylinder V-type, 4-cycle, gasoline
Bore and stroke 4.6 L V8 (1UR-FE) engine
3.70 
3.27 in. (94.0  83.0 mm)
5.7 L V8 (3UR-FE, 3UR-FBE) engine
3.70  4.02 in. (94.0  102.0 mm)
Displacement 4.6 L V8 (1UR-FE) engine
281.2 cu.in. (4608 cm3)
5.7 L V8 (3UR-FE, 3UR-FBE) engine
345.6 cu.in. (5663 cm
3)
Drive belt tension Automatic adjustment
Valve clearance
(engine cold) Intake
Exhaust Automatic adjustment

656 6-1. Specifications
Fuel
Lubrication system4.0 L V6 (1GR-FE) engine
Engine Gasoline engine Flex-fuel engine
Fuel typeUnleaded gasoline onlyUnleaded gasoline, E85,
or a blend of the two fuels
Octane rating
(Unleaded gasoline) 87 (Research octane number 91) or higher
Ethanol percentage
(E85) 
85% or less
Fuel tank capacity
(Reference) 26.4 gal. (100.0 L, 22.0 lmp.gal.)
Oil capacity
Drain and refill
(Reference)
With filter
Without filter 5.5 qt. (5.2 L, 4.6 Imp.qt.)
5.2 qt. (4.9 L, 4.3 Imp.qt.)

657
6-1. Specifications
6
Vehicle specifications
■
Engine oil selection
“Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use
Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy
the following grade and viscosity.
Oil grade: ILSAC multigrade engine oil
Recommended viscosity: SAE 5W-30
SAE 5W-30 is the best choice for
good fuel economy and good
starting in cold weather.
If SAE 5W-30 is not available,
SAE 10W-30 oil may be used.
However, it should be replaced
with SAE 5W-30 at the next oil
change.
The 5W portion of the oil viscosity rating indicates the characteristic of the
oil which allows cold startability. Oils with a lower value before the W allow
for easier starting of the engine in cold weather.
The 30 in 5W-30 indicates the oil viscosity when the oil is at its operating
temperature. An oil with a higher viscosity may be better suited if the
vehicle is operated at high speeds, or under extreme load conditions.
How to read oil container label:
The ILSAC (International Lubricant Standardization and Approval
Committee) Certification Mark is added to some oil containers to help
you select the oil you should use.
Outside temperature

658 6-1. Specifications
4.6 L V8 (1UR-FE) engine
■Engine oil selection
“Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use
Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy
the following grade and viscosity.
Oil grade: ILSAC multigrade engine oil
Recommended viscosity: SAE 0W-20
SAE 0W-20 is the best choice for
good fuel economy and good
starting in cold weather.
If SAE 0W-20 is not available,
SAE 5W-20 oil may be used.
However, it must be replaced
with SAE 0W-20 at the next oil
change.
The 0W portion of the oil viscosity rating indicates the characteristic of the
oil which allows cold startability. Oils with a lower value before the W allow
for easier starting of the engine in cold weather.
The 20 in 0W-20 indicates the oil viscosity when the oil is at its operating
temperature. An oil with a higher viscosity may be better suited if the
vehicle is operated at high speeds, or under extreme load conditions.
Oil capacity
Drain and refill
(Reference)
With filter
Without filter 7.9 qt. (7.5 L, 6.6 Imp.qt.)
7.4 qt. (7.1 L, 6.2 Imp.qt.)
Outside temperature

659
6-1. Specifications
6
Vehicle specifications
How to read oil container label:
The ILSAC (International Lubric
ant Standardization and Approval
Committee) Certification Mark is added to some oil containers to help
you select the oil you should use.
5.7 L V8 (3UR-FE, 3UR-FBE) engine
Oil capacity
Drain and refill
(Reference)
With filter
Without filter 7.9 qt. (7.5 L, 6.6 Imp.qt.)
7.4 qt. (7.1 L, 6.2 Imp.qt.)

660 6-1. Specifications
■Engine oil selection
“Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use
Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy
the following grade and viscosity.
Oil grade: ILSAC multigrade engine oil
Recommended viscosity: SAE 5W-20 or 0W-20
SAE 5W-20 or 0W-20 engine oil
may be used. However, SAE
0W-20 is the best choice for
good fuel economy and good
starting in cold weather.
The 0W portion of the oil viscosity rating indicates the characteristic of the
oil which allows cold startability. Oils with a lower value before the W allow
for easier starting of the engine in cold weather.
The 20 in 0W-20 indicates the oil viscosity when the oil is at its operating
temperature. An oil with a higher viscosity may be better suited if the
vehicle is operated at high speeds, or under extreme load conditions.
How to read oil container label:
The ILSAC (International Lubricant Standardization and Approval
Committee) Certification Mark is added to some oil containers to help
you select the oil you should use.
Outside temperature
