TOYOTA TUNDRA 2010 2.G Owners Manual

641
6-1. Specifications
6
Vehicle specifications
*1: Unladen vehicle
*2: P255/70R18 tires
*3: P275/65R18 tires
*4: P275/55R20 tires
Cab type
CrewMax
Bed type Short
Overall
length229.1 in. (5820 mm)
Overall width
79.9 in. (2030 mm)
Overall
height*1
75.7 in. (1925 mm)*2
75.5 in. (1920 mm)*3,*4
Wheelbase145.6 in. (3700 mm)
Front tread 67.9 in. (1725 mm)
Rear tread67.9 in. (1725 mm)

642 6-1. Specifications
4WD models
*1: Unladen vehicle
*2: P255/70R18 tires
*3: P275/65R18 tires
*4: P275/55R20 tires
Cab typeRegular Cab Double Cab
Bed type Standard Long Standard Long
Overall
length210.2 in.
(5340 mm) 229.1 in. (5820 mm) 248.0 in.
(6300 mm)
Overall width 79.9 in. (2030 mm)
Overall
height*1
76.3 in.
(1940 mm)*276.1 in.
(1935 mm)*276.3 in.
(1940 mm)*276.1 in.
(1935 mm)*2
76.1 in.
(1935 mm)*3,*475.9 in.
(1930 mm)*376.1 in.
(1935 mm)*3,*475.9 in.
(1930 mm)*3
Wheelbase 126.7 in.
(3220 mm) 145.6 in. (3700 mm) 164.5 in.
(4180 mm)
Front tread 67.9 in. (1725 mm)
Rear tread67.9 in. (1725 mm)

643
6-1. Specifications
6
Vehicle specifications
*1: Unladen vehicle
*2: P255/70R18 tires
*3: P275/65R18 tires
*4: P275/55R20 tires
Cab type
CrewMax
Bed type Short
Overall length229.1 in. (5820 mm)
Overall width 79.9 in. (2030 mm)
Overall height*176.1 in. (1935 mm)*2
75.9 in. (1930 mm)*3,*4
Wheelbase145.6 in. (3700 mm)
Front tread 67.9 in. (1725 mm)
Rear tread67.9 in. (1725 mm)

644 6-1. Specifications
Vehicle capacity weightRegular Cab models
*1: The model code is indicated on the Certification Label. (P. 653)*2: With towing package*3: Without option
Model code*1EngineDriving
systemBed typeVehicle capacity weight (Occupants+luggage)
GSK50L-TRADKA 4.0 L V6
(1GR-FE) engine 2WD
Standard 1485 lb. (670 kg)
GSK51L-THADKA Long 1580 lb. (715 kg)
UPK50L-TRTDKA
4.6 L V8
(1UR-FE) engine 2WD
Standard
1710 lb. (775 kg)
1635 lb. (740 kg)
*2
UPK51L-THTDKA Long1835 lb. (830 kg)
1760 lb. (795 kg)*2
UPK55L-TRTDKA 4WDStandard
1665 lb. (755 kg)
1590 lb. (720 kg)*2
UPK56L-THTDKA Long1770 lb. (800 kg)
1695 lb. (765 kg)*2
USK50L-TRTDKA
5.7 L V8
(3UR-FE) engine 2WD
Standard
1650 lb. (745 kg)
1575 lb. (710 kg)*2
USK51L-THTDKA Long1960 lb. (885 kg)
1885 lb. (855 kg)*2
2055 lb. (930 kg)*3
USK55L-TRTDKA 4WDStandard
1595 lb. (720 kg)
1520 lb. (685 kg)*2
USK56L-THTDKA Long1895 lb. (855 kg)
1820 lb. (825 kg)*2
USK55L-TRTDGA 5.7 L V8
(3UR-FBE) engine 4WDStandard
1595 lb. (720 kg)
1520 lb. (685 kg)*2
USK56L-THTDGA Long1895 lb. (855 kg)
1820 lb. (825 kg)*2

645
6-1. Specifications
6
Vehicle specifications
Double Cab models
Model code*1EngineDriving
systemBed typeVehicle capacity weight (Occupants+luggage)
GSK51L-CRASKA 4.0 L V6
(1GR-FE) engine 2WD
Standard1290 lb. (585 kg)
UPK51L-CRTSKA
4.6 L V8
(1UR-FE) engine 2WD
Standard
1410 lb. (635 kg)
1335 lb. (605 kg)
*2
UPK51L-CRTLKA 1440 lb. (650 kg)
1365 lb. (615 kg)*2
UPK52L-CHTSKALong 1325 lb. (600 kg)*2
UPK56L-CRTSKA
4WD
Standard
1330 lb. (600 kg)
1255 lb. (565 kg)
*2
UPK56L-CRTLKA 1360 lb. (615 kg)
1285 lb. (580 kg)*2
UPK57L-CHTSKALong 1235 lb. (560 kg)*2
USK51L-CRTSKA
5.7 L V8
(3UR-FE) engine 2WD
Standard
1540 lb. (695 kg)
1465 lb. (660 kg)
*2
USK51L-CRTLKA 1570 lb. (710 kg)
1495 lb. (675 kg)*2
USK52L-CHTSKALong 1455 lb. (655 kg)*2
USK56L-CRTSKA
4WD
Standard
1455 lb. (655 kg)
1380 lb. (625 kg)
*2
USK56L-CRTLKA 1485 lb. (670 kg)
1410 lb. (635 kg)*2
USK57L-CHTSKALong 1360 lb. (615 kg)*2

646 6-1. Specifications
*1: The model code is indicated on the Certification Label. (P. 653)*2: With towing packageCrewMax models
Model code*1EngineDriving
systemBed typeVehicle capacity weight (Occupants+luggage)
USK56L-CRTSGA 5.7 L V8
(3UR-FBE) engine 4WD
Standard 1455 lb. (655 kg)
1380 lb. (625 kg)
*2
USK56L-CRTLGA 1485 lb. (670 kg)
1410 lb. (635 kg)*2
USK57L-CHTSGA Long 1360 lb. (615 kg)*2
Model code*1EngineDriving
systemBed typeVehicle capacity weight (Occupants+luggage)
UPK51L-PSTSKA
4.6 L V8
(1UR-FE) engine 2WD
Short 1330 lb. (600 kg)
1255 lb. (565 kg)
*2
1220 lb. (550 kg)*3
UPK51L-PSTLKA 1360 lb. (615 kg)
1285 lb. (580 kg)*2
1250 lb. (565 kg)*3
UPK56L-PSTSKA
4WD1250 lb. (565 kg)
1175 lb. (530 kg)*2
1140 lb. (515 kg)*3
UPK56L-PSTLKA 1265 lb. (570 kg)
1190 lb. (535 kg)*2
1155 lb. (520 kg)*3

647
6-1. Specifications
6
Vehicle specifications
*1: The model code is indicated on the Certification Label. (P. 653)*2: With towing package or electric moon roof*3: With towing package and electric moon roof
Model code*1EngineDriving
systemBed typeVehicle capacity weight (Occupants+luggage)
USK51L-PSTSKA
5.7 L V8
(3UR-FE) engine 2WD
Short 1445 lb. (655 kg)
1370 lb. (620 kg)
*2
1335 lb. (605 kg)*3
USK51L-PSTLKA 1495 lb. (675 kg)
1420 lb. (640 kg)*2
1385 lb. (625 kg)*3
USK56L-PSTSKA
4WD1375 lb. (620 kg)
1300 lb. (585 kg)*2
1265 lb. (570 kg)*3
USK56L-PSTLKA 1405 lb. (635 kg)
1330 lb. (600 kg)*2
1295 lb. (585 kg)*3
USK56L-PSTSGA 5.7 L V8
(3UR-FBE) engine 4WD 1375 lb. (620 kg)
1300 lb. (585 kg)*2
1265 lb. (570 kg)*3
USK56L-PSTLGA 1405 lb. (635 kg)
1330 lb. (600 kg)*2
1295 lb. (585 kg)*3

648 6-1. Specifications
Towing capacityRegular Cab models
Model code*1EngineDriving
systemBed typeTowing capacity
(Trailer weight + cargo)
GSK50L-TRADKA 4.0 L V6
(1GR-FE) engine 2WD
Standard 5200 lb. (2355 kg)
GSK51L-THADKA Long 5100 lb. (2310 kg)
UPK50L-TRTDKA
4.6 L V8
(1UR-FE) engine 2WD
Standard
7500 lb. (3400 kg)
*2
9000 lb. (4080 kg)*3
UPK51L-THTDKA
Long 7400 lb. (3355 kg)
*2
8900 lb. (4035 kg)*3
UPK55L-TRTDKA
4WDStandard
7200 lb. (3265 kg)
*2
8700 lb. (3945 kg)*3
UPK56L-THTDKA
Long 7100 lb. (3220 kg)
*2
8600 lb. (3900 kg)*3
USK50L-TRTDKA
5.7 L V8
(3UR-FE) engine 2WD
Standard 8900 lb. (4035 kg)
*2
10400 lb. (4715 kg)*3
9900 lb. (4490 kg)*3,4
USK51L-THTDKA
Long 8800 lb. (3990 kg)
*2
10800 lb. (4895 kg)*3
USK55L-TRTDKA
4WDStandard 8700 lb. (3945 kg)
*2
10100 lb. (4580 kg)*3
9600 lb. (4355 kg)*3,4
USK56L-THTDKA
Long 8600 lb. (3900 kg)
*2
10500 lb. (4760 kg)*3

649
6-1. Specifications
6
Vehicle specifications
*1: The model code is indicated on the Certification Label. (P. 653)*2: Without towing package*3: With towing package*4: P275/55R20 tires
USK55L-TRTDGA
5.7 L V8
(3UR-FBE) engine 4WDStandard 8700 lb. (3945 kg)
*2
10100 lb. (4580 kg)*3
9600 lb. (4355 kg)*3,4
USK56L-THTDGA
Long8600 lb. (3900 kg)
*2
10500 lb. (4760 kg)*3
Model code*1EngineDriving
systemBed typeTowing capacity
(Trailer weight + cargo)

650 6-1. Specifications
Double Cab models
Model code*1EngineDriving
systemBed typeTowing capacity
(Trailer weight + cargo)
GSK51L-CRASKA 4.0 L V6
(1GR-FE) engine 2WD Standard 4800 lb. (2175 kg)
UPK51L-CRTSKA
4.6 L V8
(1UR-FE) engine 2WD
Standard 7200 lb. (3265 kg)
*2
8600 lb. (3900 kg)*3
UPK51L-CRTLKA
7100 lb. (3220 kg)
*2
8600 lb. (3900 kg)*3
UPK52L-CHTSKA
Long 8500 lb. (3855 kg)
UPK56L-CRTSKA 4WDStandard 6900 lb. (3130 kg)
*2
8300 lb. (3765 kg)*3
UPK56L-CRTLKA
6800 lb. (3085 kg)
*2
8300 lb. (3765 kg)*3
UPK57L-CHTSKA
Long 8200 lb. (3720 kg)
USK51L-CRTSKA
5.7 L V8
(3UR-FE) engine 2WD
Standard 8600 lb. (3900 kg)
*2
10600 lb. (4805 kg)*3
USK51L-CRTLKA
8600 lb. (3900 kg)
*2
10500 lb. (4760 kg)*3
USK52L-CHTSKA
Long 10400 lb. (4715 kg)
USK56L-CRTSKA 4WDStandard 8300 lb. (3760 kg)
*2
10300 lb. (4670 kg)*3
USK56L-CRTLKA
8300 lb. (3760 kg)
*2
10200 lb. (4625 kg)*3
USK57L-CHTSKA
Long 10100 lb. (4580 kg)
