TOYOTA VENZA 2009 Accessories, Audio & Navigation (in English)

DESTINATION SEARCH
71
1. Push the “DEST” button.
2. Touch “Coordinates” on the second
page of the “Destination” screen.
3. Input the latitude and the longitude.
4. When the input is finished, touch
“OK”.
By touching the button of the desired point,
the screen changes and displays the map
location of the selected destination and the
route preference. (See
“Starting route
guidance” on page 72.)A set destination can be deleted.
1. Push the “DEST” button.
2. Touch “Del. Dest.” on the “Destina-
tion” screen.
When more than one destination is set, a
list will be displayed on the screen.
3. Touch the destination for deletion.
“Select All”: To select all destinations on
the list.
“Unselect All”: To unselect all of the se-
lected destinations.
4. Touch “Delete”.
A message appears to confirm the request
to delete.
5. To delete the destination(s), touch
“Yes”.
If “Yes” is touched, the data cannot be re-
covered.
If “No” is touched, the previous screen will
return.
— Destination search by
“Coordinates”— Deleting set destinations

DESTINATION SEARCH
72
The system searches for the guidance
route again, and displays the entire route.
INFORMATION
Set destinations can also be deleted
by touching “Route”. (See “ — Delet-
ing destinations” on page 85.)
After inputting the destination, the screen
changes and displays the map location of
the selected destination and the route pref-
erence.
1. Scroll the map to the desired point.
“Adjust Location”: To adjust the position
in smaller increments.
When an arrow facing the desired point
is touched, the map scrolls in that di-
rection.
Releasing the finger from the arrow will
stop the scrolling.
2. Touch “Go to
”.
The system starts route search and dis-
plays recommended routes.
If there is already a set destination, “Go to
” and “Add to Route” are displayed.
“Go to
”: To delete the existing destina-
tions and set a new one.
“Add to Route”: To add a destination.
“Info.”: If this button is displayed on the
top of the screen, touch it to view items
such as name, address, and phone num-
ber.
Starting route guidance

DESTINATION SEARCH
73
1Current position
2Destination point
3Type of the route and the distance
4Distance of the entire route
3. To start guidance, touch “OK”.
“Turn List”: The following screen displays
the list of the roads up to the destination.
“3 Routes”: To select the desired route
from 3 possible routes. (See page 74.)
“Edit Route”: To change the route. (See
page 75.)
INFORMATION
Guidance can be paused or re-
sumed. (See “Pausing and resum-
ing guidance” on page 91.)
If “OK” is touched until a beep
sounds, demo mode will start.
Push the “MAP/VOICE” button to
finish Demo mode.
The route for returning may not be
the same as that for going.
The route guidance to the destina-
tion may not be the shortest route
nor a route without traffic conges-
tion.
Route guidance may not be avail-
able if there is no road data for the
specified location.
When setting the destination on a
map with a scale larger than 0.5
miles (800 m), the map scale
changes to 0.5 miles (800 m) auto-
matically. Set the destination
again.
If a destination is entered, the road
nearest to the point you selected is
set as the destination.
CAUTION
Be sure to obey traffic regulations
and keep road conditions in mind
while driving. If a traffic sign on the
road has been changed, the route
guidance may provide incorrect in-
formation.

DESTINATION SEARCH
74
3 ROUTES SELECTION
1. To select the desired route from 3
routes, touch “3 Routes”.
2. Touch “Quick”, “Alt.” or “Short” to
select the desired route.
“Quick”: Recommended route.
This route is indicated by an orange line.
“Alt.”: Alternative route.
This route is indicated by a purple line.
“Short”: A route by which you can reach
the destination in the shortest distance.
This route is indicated by a green line.
“Info.”: To display the following informa-
tion about each of the 3 routes.
1Time necessary for the entire trip
2Distance of the entire trip
3Toll road
4Freeway
5Ferry

DESTINATION SEARCH
75
Edit route
You can again designate the conditions of
the route to the destination.
Touch “Edit Route”.
“Add”: To add destinations. (See page
84.)
“Delete”: To delete destinations. (See
page 85.)
“Reorder”: To reorder destinations. (See
page 84.)
“Preferences”: A number of choices are
provided on the conditions which the sys-
tem uses to determine the route to the des-
tination. (See page 89)
INFORMATION
Even if the “Freeways” indicator is
dimmed, the route cannot avoid in-
cluding a freeway in some cases.
If the calculated route includes a
trip by ferry, the route guidance
shows a sea route. After you travel
by ferry, the current vehicle posi-
tion may be incorrect. Upon recep-
tion of GPS signals, it is automati-
cally corrected.

DESTINATION SEARCH
76

SECTION 3
ROUTE GUIDANCE
77
ROUTE GUIDANCE
Route guidance
Route guidance screen 78. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Typical voice guidance prompts 81. . . . . . . . . . . . . . . . . . . . . . . . . .
Distance and time to destination 83. . . . . . . . . . . . . . . . . . . . . . . . .
Setting and deleting destinations84 . . . . . . . . . . . . . . . . . . . . . .
Adding destinations 84. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Reordering destinations 84. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Deleting destinations 85. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setting route86 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Detour setting 86. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Route overview 87. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Route preference 89. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pausing and resuming guidance 91. . . . . . . . . . . . . . . . . . . . . . .
Show on map92 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Display POI
∗ icons 92. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Route trace 96. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
XM NavTraffic 98. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
∗: Point of Interest

ROUTE GUIDANCE
78
During route guidance, various types of
guidance screens can be displayed de-
pending on conditions.
Screen layout
1Distance to the next turn and the
arrow indicating turning direction
2Current street name
3Distance and travel/arrival time to
the destination
4Current position
5Guidance route
INFORMATION
If the vehicle goes off the guidance
route, the route is searched again.
For some areas, the roads have not
been completely digitized in our
database. For this reason, the
route guidance may select road
that should not be traveled on.
When you arrive at your destina-
tion, the destination name will be
displayed on the top of the screen.
Touching “Off” clears the dis-
play.
During freeway driving
During freeway driving, the freeway exit in-
formation screen will be displayed.
This screen displays the distance to the
next junction and exit, or POIs in the vicin-
ity of the freeway exit.
1Current position
2Points of Interest that are close to
a freeway exit
3Exit number and junction name
4Distance from the current position
to the exit or junction
5Current street name
“Map”:To display the selected map of the
exit vicinity.
:To scroll for farther junctions or exits.
:To scroll for closer junctions or exits.
:To scroll for the closest 3 junctions or
exits.
Route guidance screen

ROUTE GUIDANCE
79
When approaching a freeway exit or
junction
When the vehicle approaches an exit or
junction, the guidance screen for the free-
way will be displayed.
1Next street name
2Distance from the current position
to the exit or junction
3Current position
“Off”: The guidance screen on freeway
disappears and the map screen appears.
When touching
or push-
ing the “MAP/VOICE” button, the guid-
ance screen on freeway reappears.
When approaching an intersection
When the vehicle approaches an intersec-
tion, the intersection guidance screen will
be displayed.
1Next street name
2Distance to the intersection
3Current position
“Off”: The intersection guidance screen
disappears and the map screen appears.
When touching
or push-
ing the “MAP/VOICE” button, the inter-
section guidance screen reappears.

ROUTE GUIDANCE
80
Other screens
TURN LIST SCREEN
On this screen, the list of turns on the guid-
ance route can be viewed.
Touching
during guid-
ance displays the turn list.
1Next street name or destination
name
2Turn direction
3Distance between turns
4Current street nameARROW SCREEN
On this screen, information about next
turns on the guidance route can be viewed.
Touching
during guid-
ance displays the arrow screen.
1Exit number, street name contain-
ing number or next street name
2Turn direction
3Distance to the next turn
4Current street name
