TOYOTA VENZA 2011 (in English) User Guide

11
VENZA_U (OM73012U)
Overhead console P. 438
Garage door opener switches  P. 457
Anti-glare inside rear view mirror P. 80
Moon roof switches  P. 89
Vanity mirrors P. 446
SRS curtain shield airbags P. 107
Sun visors P. 445
A
Personal/interior lights P. 431, 432
Personal/interior lights
P. 431, 432
Rear seat entertainment system  P. 356
: If equipped
Compass  P. 464

12
VENZA_U (OM73012U)
B
Door lock switch P. 48
Window lock switch P. 85
Power window switches P. 85
Pictorial indexInterior
Inside lock button P. 48

13
VENZA_U (OM73012U)
Shift lock override
button
P. 590
Seat heater switches  P. 450
C
Shift lever P. 166
: If equipped
Auxiliary box P. 442
Console box
P. 436Cup holders
P. 439
Auxiliary box
P. 442
AUX port/USB port 
AUX port

P. 313, 320
P. 333
Power outlet P. 447

14
VENZA_U (OM73012U)
Pictorial indexInstrument panel
Headlight switch
Turn signal lever
Fog light switch

P. 198
P. 171
P. 209Windshield wipers and washer switch
Rear window wiper and washer switch P. 210
P. 212
Gauges and meters P. 174
Glove box P. 435
Fuel filler door opener P. 93
Hood opener P. 486
SRS knee airbag P. 107
Multi-information display P. 180
Bottle holder P. 441
Parking brake pedal P. 172
Horn P. 173
Engine (ignition) switch (vehicles with smart key system)
P. 159

15
VENZA_U (OM73012U)
: If equipped
*: Refer to “Navigation System Owner’s Manual”.
A
B
Power back door switch  P. 55
Enhanced VSC OFF switch P. 226
Outside rear view mirror
switches
P. 82
Auxiliary box P. 442
Power back door main switch  P. 56
Telephone switch  * P. 394
Talk switch  * P. 394Audio remote control switches P. 334
Engine (ignition) switch (vehicles without smart key system) P. 163
Cruise control switch P. 213

16
VENZA_U (OM73012U)
Pictorial indexInstrument panel
C
With navigation system
Without navi gation system
Multi-information display switches
P. 180, 194
Emergency flasher
switch
P. 550
Audio/
navigation
system
*
Audio
system
P. 280
Emergency flasher
switch
P. 550
Multi-information display switches
P. 180, 194

17
VENZA_U (OM73012U)
D
With automatic air conditioning system
With manual air conditioning system
Air conditioning system P. 272
Rear window defogger switch P. 278
Rear window defogger switch P. 278
Air conditioning system P. 262
*: Refer to “Navigation System Owner’s Manual”.

18
VENZA_U (OM73012U)
Pictorial indexLuggage compartment
Power outlet P. 447
Luggage cover  P. 455
A/V input port  P. 380
Shopping bag
hook
P. 455
Auxiliary box
P. 455
Shopping bag
hook
P. 455
Power outlet 
P. 447
Cargo hooks
P. 455
Luggage
compartment
light
P. 432

19
VENZA_U (OM73012U)
A
: If equipped
Power back door switch  P. 54
Back door handle P. 54

20
VENZA_U (OM73012U)
For your information
Main Owner’s ManualPlease note that this manual applies to all models and explains all
equipment, including options. Therefore, you may find some explana-
tions for equipment not installed on your vehicle.
All specifications provided in this manual are current at the time of
printing. However, because of the Toyota policy of continual product
improvement, we reserve the right to make changes at any time with-
out notice.
Depending on specificati ons, the vehicle shown in the illustration may
differ from your vehicle in terms of equipment.
Accessories, spare parts and modification of your Toyota
A wide variety of non-genuine spare parts and accessories for Toyota
vehicles are currently available in the market. You should know that
Toyota does not warrant these prod ucts and is not responsible for
their performance, repair, or replacement, or for any damage they
may cause to, or adverse effect they may have on, your Toyota vehi-
cle.
This vehicle should not be modi fied with non-genuine Toyota prod-
ucts. Modification with non-genuine Toyota products could affect its
performance, safety or durability , and may even violate governmental
regulations. In addition, damage or performance problems resulting
from the modification may not be covered under warranty.
