TOYOTA VENZA 2013 Owners Manual (in English)

511
6-1. Specifications
6
Vehicle specifications
VENZA_OM_OM73010U_(U)
Tire related termMeaning
Snow tire A tire that attains a traction index equal to or
greater than 110, compared to the ASTM E-
1136 Standard Reference Test Tire, when
using the snow traction test as described in
ASTM F-1805-00, Standard Test Method for
Single Wheel Driving Traction in a Straight Line
on Snow-and Ice-Covered Surfaces, and which
is marked with an Alpine Symbol ( ) on at
least one sidewall
Te s t r i m The rim on which a tire is fitted for testing, and
may be any rim listed as appropriate for use
with that tire
Tread That portion of a tire that comes into contact
with the road
Tread rib A tread section running circumferentially
around a tire
Tread separation Pulling away of the tread from the tire carcass
Treadwear indicators
(TWI) The projections within the principal grooves
designed to give a visual indication of the
degrees of wear of the tread
Wheel-holding fixture The fixture used to hold the wheel and tire
assembly securely
during testing

512 6-1. Specifications
VENZA_OM_OM73010U_(U)
*:Table 1  Occupant loading and distribution for vehicle normal load
for various designated seating capacities
Designated seating
capacity, Number of occupantsVehicle normal load,
Number of occupantsOccupant distribution in a normally loaded vehicle
2 through 4 2 2 in front
5 through 10 3 2 in front, 1 in second
seat
11 through 15 5 2 in front, 1 in second
seat, 1 in third seat, 1
in fourth seat
16 through 20 7 2 in front, 2 in second
seat, 2 in third seat, 1
in fourth seat

513
6
Vehicle specifications
VENZA_OM_OM73010U_(U)
6-2. Customization
Customizable features
Customizable featuresVehicles with TFT type multi-info rmation display: Some function
settings can be changed by opera ting the multi-information display.
(  P. 520)
Settings that can be chan ged by your Toyota dealer
Definition of symbols: O = Available,  = Not available
Your vehicle includes a variety of electronic features that can be
personalized to your preferen ces. Programming these preferences
requires specialized equipment and may be performed by your
Toyota dealer.
Some function settings are changed simultaneously with other functions
being customized. Contact your Toyota dealer for further details.

514 6-2. Customization
VENZA_OM_OM73010U_(U)
ItemFunctionDefault settingCustomized setting
Smart key
system
(P. 30) Smart key system ON OFF — O
Select doors to
unlock
Driver’s
door All doors — O
Wireless
remote control
( P. 45) Wireless remote
control
ON OFF — O
Unlocking operation Driver’s
door
unlocked in one step, all doors
unlocked in two step All doors
unlocked in one step OO
Open door warning
function (when
locking the vehicle) ON OFF — O
Panic function ON OFF — O

515
6-2. Customization
6
Vehicle specifications
VENZA_OM_OM73010U_(U)
ItemFunctionDefault
settingCustomized setting
Smart key
system
(P. 30)
and wireless
remote control
( P. 45) Operation signal
(Emergency
flashers)
ON OFF O O
Operation signal
(Buzzer) Level 7Level 1 to 6
—O
OFF
Time elapsed before
automatic door lock
function is activated
if door is not opened
after being unlocked 60 secondsOFF
OO
30 seconds
120
seconds
Power easy
access system
( P. 75) Driver’s seat
movement when
exiting the vehicle
ON OFF — O

516 6-2. Customization
VENZA_OM_OM73010U_(U)
ItemFunctionDefault settingCustomized setting
Door lock
(P. 50) Unlocking using
a key
Driver’s
door
unlocked in
one step, all doors
unlocked in two step All doors
unlocked in one step —O
Speed-detecting
automatic door lock
function OFF ON O O
Shifting the shift
lever to position
other than “P” locks
all doors ON OFF O O
Shifting the shift
lever to “P” unlocks
all doors ON OFF O O
Opening driver’s
door unlocks all
doors OFF ON O O

517
6-2. Customization
6
Vehicle specifications
VENZA_OM_OM73010U_(U)
ItemFunctionDefault
settingCustomized setting
Automatic light
control system
(P. 208) Light sensor
sensitivity
Level 3 Level 1 to 5 — O
Daytime running light
system (U.S.A. only) ON OFF — O
Automatic
High Beam
(if equipped) ON OFF O O
Time elapsed before
headlights
automatically turn off
after doors are
closed 30 seconds0 seconds
OO
60 seconds
90 seconds
Alarm system
( P. 1 1 0 ) Time elapsed before
the alarm is set
14 seconds 30 seconds — O
Multi-
information
display
(TFT type only:
P. 192) Language selection English
French
OO
Spanish

518 6-2. Customization
VENZA_OM_OM73010U_(U)
ItemFunctionDefault settingCustomized setting
Illumination
(P. 299) Time period before
lights turn off
15 seconds7.5 seconds
OO
30 seconds
Vehicles with smart
key system:
Operation after the
“ENGINE START
STOP” switch is
turned off
Vehicles without
smart key system:
Operation after the
engine switch is
turned to the “LOCK”
position ON OFF — O
Operation when the
doors are unlocked ON OFF — O
Operation when you
approach the
vehicle with the
electronic key on
your person (When
the personal/interior
light main switch is
door position.)
(vehicles with smart
key system) ON OFF — O

519
6-2. Customization
6
Vehicle specifications
VENZA_OM_OM73010U_(U)
ItemFunctionDefault
settingCustomized setting
Seat belt
reminder
(P. 435) Vehicle speed linked
seat belt reminder
buzzer
ON OFF — O
Power
window
( P. 95) Rear window Auto
Up/Down
ON OFF — O
Auto Up function ON OFF — O

520 6-2. Customization
VENZA_OM_OM73010U_(U)
Customizing the features by using the multi-information display
(vehicles with TFT type mu lti-information display)
Press the “SETUP” button while
the vehicle is stopped.
The “Custom Settings” screen is
displayed on the multi-information
display.
If left idle for approximately 10
seconds, the display will revert to
the previous screen.
Select the setting you wish to
change by pressing the “INFO”
or “SETUP” button, and press
the “SELECT RESET” button.
If you select “Exit” and press the
“SELECT RESET” button, the
display will revert to the previous
screen.
STEP1
STEP2
