Changing or
disconnecting your
battery
About ASL settingIf the battery is changed or discon-nected, you cannot setup the ASL setup option until the vehicle is mov-ing.
Specifications
GeneralPower source . . . . . . . . . . . . . .13. V DC (10.5 V to 16.0 V allowable)Grounding system. . . . . .Negative typeMaximum current consumption . . .18 ADimensions (W × H × D) . . . . . . . . . . . . . . . 05 × 104 × 171 mm(80 in.3/8 × 41 in. × 67 in.3/8)Weight. . . . . . . . . . . . . . . . . . . . . . .06 kg(4.54155 lbs.)
AudioTone controls(Bass) . . . . . . . . . . . . .Frequency : 80 HzLevel : ±10 dB(Treble) . . . . . . . . . . .Frequency : 10 kHzLevel : ±10 dBMaximum power output. . . . . .50 W × 4Load impedance . . . . . . . . . . . . . . . .4 W
CD PlayerSystem . . .Compact disc audio systemUsable discs. . . . . . . . . . .Compact discSignal formatSampling frequency . . . . . . . . .44.1 kHz
Number of quantization bits . . . . . . . . . . . . . . . . . . . . . . . .16; linear
Number of channels . . . . . . .  (stereo)MP3 decoding format . . . . . . . . . . MPEG1 &  Audio Layer 3WMA decoding format . . . . . .Ver.7, 7.1, 8, 9, 10.11 (ch audio) (Windows Media Player)
USBSpecification. . . . . .USB .0 High speedSupply current . . . . . . . . . . . . . . 500 mAMaximum amount of memory. .50 GBFile system. . . . . . . . . . . . FAT16, FAT3MP3 decoding format . . . . . . . . .MPEG-1 &  Audio Layer 3WMA decoding format . . . . .Ver. 7, 7.1, 8, 9, 10, 11 (ch audio) (Windows Media Player)
AM tunerFrequency range . . . . . . . .530 kHz to 1 710 kHz (10 kHz)
FM tunerFrequency range . . . . . . . . . . . .87.75 MHz to 107.9 MHz
CEA2006 Specifications
Power output. . .16W RMS × 4 Channels (4 W and <= 1% THD+N)S/N ratio . . . . . . . . . . . . . . . . . . . .90 dBA(reference: 1 W into 4 W)
