TOYOTA xB 2012 Accessories, Audio & Navigation (in English)

OTHER FUNCTIONS

140
V573_E
z By speed dial
You can call by registered telephone
number which you selected from a
phone book, dialed numbers and re-
ceived calls. (See “(a) Registering
the speed dial” on page 144 for regis-
tering the speed dial.)

1. Touch “Speed Dial” to display the
“Speed Dial” screen.

2. Touch the desired number to call.
You can change the page by touching
“Speed Dial 2” or “Speed Dial 3”.
When you push the teleph one button
while driving, the screen above appears.
Touch the desired name to call. (The
telephone number is not displayed.) z
By POI call

You can call by touching when it
is displayed on the screen from navi-
gation system. (See page 30 for de-
tails.)

OTHER FUNCTIONS
141
V573_E


When a call is received, this screen is
displayed with a sound. Touch

to talk on the phone.
To hang up the phone:
Touch the on-hook button (
) on
the screen.
To refuse to receive the call: Touch
and hold it.
To adjust the volume of received call:
Touch
“–” or “+” or use the vol-
ume switch of the steering wheel.
On the international phone call, the other
party’s name may not be displayed cor-
rectly depending on the cellular phone
which you have.


While you are talking on the phone,
this screen is displayed. You can do
the operation below on the screen.
To adjust the volume of the other party’s
voice:
Touch
“–” or “+” or use the vol-
ume switch of the steering wheel.
To hang up the phone:
Touch the on-hook button (
) on
the screen.
To mute your voice: Touch “Mute” .
To input a Key: Touch “0-9”.
To transfer the call: Touch “Transfer Call” .
You cannot change from Hands −free call
to cellular phone call while driving.
When you change from cellular phone
call to Hands-free call, the Hands-free
screen will be displayed and you can
operate it on the screen.
Transferring method and behavior are
different depending on the cellular phone
which you have.
For the operation of the phone, see the
manual that comes with your cellular
phone.

— Receive on the
Bluetooth
® phone
— Talk on the Bluetooth
®
phone

OTHER FUNCTIONS

142
V573_E

Touch the desired number to input the
key.
To hang up the phone:
Touch the on-hook button (
) on
the screen.
This cannot be operated while driving.

If the continuous tone signal is regis-
tered in a phone book, this screen
appears. (If not registered, “Send”
and “Exit” are not displayed.)
Confirm the number displayed on the
screen and touch “Send”. The num-
ber before marked sign will be sent.
When you touch “Exit”, this function will
be finished and normal tone screen ap-
pears.
To hang up the phone:
Touch the on-hook button (
) on
the screen.
The continuous tone signal is the marked
sign (p or w) and the number following
telephone number.
(ex. 056133w0123p#1 ∗)
You can do this operation when you
want to operate an answering machine
or use a telephone service in bank for
example. You can register the phone
number and the code number in the
phone book.

OTHER FUNCTIONS
143
V573_E

z Sending a tone by the speed tone
You can send a tone by the speed
tone. (For registering the speed tone,
see “(b) Registering the speed tone”
on page 146.)

1. Touch “Speed Tone”.

2. Touch the desired touch screen
button to send a tone.

Touch “Settings” to display the “Set-
tings” screen.

You can change the settings of the
phone.


— Change the settings of
the Bluetooth
®phone

OTHER FUNCTIONS

144
V573_E
(a) Registering the speed dial
You can register the desired tele-
phone number from phone book, di-
aled numbers and received calls. Up
to 17 speed dial numbers can be reg-
istered.
The 6th entry is the speed dial for redial-
ing.

1. Touch “Speed Dial” to display the
“Speed Dial Settings” screen.

2. Touch “Register” of “Speed Dial”.

3. Select the data you want to regis-
ter.

4. Touch the desired telephone
number.

5. Touch the touch screen button
you want to register in.
The latest dialed number is registered in
the 6th item (speed redial).

If you select a touch screen button
you registered before, this screen is
displayed.
6. Touch “Yes” if you want to over-
write it.

OTHER FUNCTIONS
145
V573_E

z Deleting the speed dial individu-
ally
You can delete “01” - “17” of the
speed dial individually.
If you delete them all at once, all of 17
numbers are deleted.

1. Touch “Delete” of “Speed Dial”.

2. Touch the touch screen button
you want to delete.

3. Touch “Yes”. z
Deleting all of the speed dial

1. Touch “Delete All” of “Speed
Dial”.

2. Touch “Yes”.

OTHER FUNCTIONS

146
V573_E
(b) Registering the speed tone
You can register the desired tone
number. Up to 6 speed tone numbers
can be registered.

1. Touch “Register” of “Speed
Tone”.

2. Use the software keyboard to in-
put the name.

3. Input the number and touch “OK”.


4. Touch the desired touch screen
button you want to register in.

If you select a touch screen button
you registered before, this screen is
displayed.
5. Touch “Yes” if you want to over-
write it.

INFORMATION
If you often use a certain set of tone
signals, you can register that set of
code as a speed tone number to al-
low a one-touch operation during
calls.

OTHER FUNCTIONS
147
V573_E

z Editing the speed tone
You can edit the speed tone.

1. Touch “Edit” of “Speed Tone”.

2. Touch the touch screen button
you want to edit.

3. Use the software keyboard to in-
put the name.

4. Input the number and touch “OK”.

OTHER FUNCTIONS

148
V573_E
z Deleting the speed tone individu-
ally
You can delete “1” to “6” of the speed
tone.
If you delete them all at once, all of 6
numbers are deleted.

1. Touch “Delete” of “Speed Tone”.

2. Touch the touch screen button
you want to delete.

3. Touch “Yes”. z
Deleting all the speed tone

1. Touch “Delete All” of “Speed
Tone”.

2. Touch “Yes”.

OTHER FUNCTIONS
149
V573_E

(c) Setting the volume

1. Touch “Volume” to display the
“Volume Settings” screen.

2. Touch “-” or “+” to adjust the
“Voice Volume” or “Ring Volume”.
“Voice Volume” ..... Adjusting the other party’s voice.
“Ring Volume” ....... Adjusting the ring volume. z
Automatic volume settings for
high speed
You can set the volume one step up
when the speed is over 50 mph (80
km/h). (When it is under 43 mph (70
km/h), previous volume is back.)
Each time you touch “Adaptive Volume
Control” , you can switch on or off.
