remove seats TOYOTA xB 2015 Owners Manual (in English)

46 1-3. Adjustable components (seats, mirrors, steering wheel)
Scion_xB_OM_OM12F03U_(U)
■Installing the head restraints
■ Adjusting the height of the head restraints
■ Adjusting the rear cent er seat head restraint
Always raise the head restraint one level from the stowed position when
using.
CAUTION
■ Head restraint precautions
Observe the following precautions regarding the head restraints. Failure to
do so may result in death or serious injury.
●Use the head restraints designed for each respective seat.
● Adjust the head restraints to the correct position at all times.
● After adjusting the head restraints, push down on them and make sure
they are locked in position.
● Do not drive with the head restraints removed.
● Do not drive with the head restraints installed backwards.
Align the head restraint with the installa-
tion holes and push it down to the lock
position.
Press and hold the lock release button
when lowering the head restraint.
Make sure that the head restraints are
adjusted so that the center of the head
restraint is closest to the top of your ears.

52 1-3. Adjustable components (seats, mirrors, steering wheel)
Scion_xB_OM_OM12F03U_(U)
CAUTION
■Adjustable shoulder anchor
Always make sure the shoulder belt is positioned across the center of your
shoulder. The belt should be kept away from your neck, but not falling off
your shoulder. Failure to do so could reduce the amount of protection in an
accident and cause death or serious injuries in the event of a sudden stop,
sudden swerve or accident. ( P. 48)
■ Seat belt damage and wear
●Do not damage the seat belts by allowing the belt, plate, or buckle to be
jammed in the door.
● Inspect the seat belt system periodically. Check for cuts, fraying, and loose
parts. Do not use a damaged seat belt until it is replaced. Damaged seat
belts cannot protect an occupant from death or serious injury.
● Ensure that the belt and plate are locked and the belt is not twisted.
If the seat belt does not function correctly, immediately contact your Scion
dealer.
● Replace the seat assembly, including the belts, if your vehicle has been
involved in a serious accident, even if there’s no obvious damage.
● Do not attempt to install, remove, modify, disassemble or dispose of the
seat belts. Have any necessary repairs carried out by your Scion dealer.
Inappropriate handling of the pretensioner may prevent it from operating
properly, resulting in death or serious injury.

86 1-7. Safety information
Scion_xB_OM_OM12F03U_(U)
CAUTION
■Front passenger occupant cl assification system precautions
● Do not recline the front passenger seatback so far that it touches a rear
seat. This may cause the “AIR BAG OFF” indicator light to be illuminated,
which indicates that the passenger’s airbags will not deploy in the event of
a severe accident. If the seatback touches the rear seat, return the seat-
back to a position where it does not touch the rear seat. Keep the front\
passenger seatback as upright as possible when the vehicle is moving.
Reclining the seatback excessively may lessen the effectiveness of the
seat belt system.
● If an adult sits in the front passenger seat, the “AIR BAG ON” indicator
light is illuminated. If the “AIR BAG OFF” indicator is illuminated, ask the
passenger to sit up straight, well back in the seat, feet on the floor, and
with the seat belt worn correctly. If the “AIR BAG OFF” indicator still
remains illuminated, either ask the passenger to move to the rear seat, or
if that is not possible, move the front passenger seat fully rearward.
● When it is unavoidable to install a forward-facing child restraint system on
the front passenger seat, install the child restraint system on the front pas-
senger seat in the proper order. ( P. 9 2 )
● Do not modify or remove the front seats.
● Do not kick the front passenger seat or subject it to severe impact. Other-
wise, the SRS warning light may come on to indicate a malfunction of the
detection system. In this case, contact your Scion dealer immediately.
● Child restraint systems installed on the rear seat should not contact the
front seatbacks.
● Do not use a seat accessory, such as a cushion and seat cover, that cov-
ers the seat cushion surface.
● Do not modify or replace the upholstery of the front seat.

380 Alphabetical index
Scion_xB_OM_OM12F03U_(U)
CareExterior .................................. 204
Interior ................................... 207
Seat belts .............................. 208
Cargo capacity ......................... 155
Cargo hooks ............................. 201
Chains ....................................... 161
Child restraint system Booster seats, definition ..........87
Booster seats, installation .......92
Convertible seats, definition ...............................87
Convertible seats, installation .............................92
Front passenger occupant
classification system .............81
Infant seats, definition .............87
Infant seats, installation...........92
Installing CRS with lower anchorages ...........................93
Installing CRS with seat belts ..............................95
Installing CRS with top straps ....................................99
Child safety
Airbag precautions ..................76
Battery precautions ....... 235, 321
Child restraint syst em..............87
Child-protectors .......................31
How your child should wear the seat belt ..........................50
Installing child restraints ..........92
Power window lock switch.......58
Power window precautions .....59
Removed key battery precautions ......................... 257
Seat belt extender
precautions ...........................53
Seat belt precautions ..............51 Child-protectors ......................... 31
Cleaning
Exterior.................................. 204
Interior ................................... 207
Seat belts .............................. 208
Clock ......................................... 194
Coat hooks ............................... 197
Condenser ................................ 231
Console box ............................. 187
Cooling system
Engine overheating ............... 323
Cruise control .......................... 146
Cup holders .............................. 188
Curtain shield airbags ............... 69
Customizable features ............ 358
Daytime running light
system .................................... 140
Defogger Rear window ......................... 178
Side mirrors........................... 178
Dimension ................................ 332
Dinghy towing ................... 167,168
Display Multi-information display ....... 135
Do-it-yourself maintenance .... 217
Doors Back door ................................ 36
Door glasses ........................... 58
Door lock ........................... 26, 30
Side doors ............................... 30
Side mirrors............................. 56
Driver’s seat belt reminder
light ......................................... 293
Driving Correct posture ....................... 67
Procedures............................ 104C
D
