892-1. Keys
2
Before Driving
●The keyless entry system operation may vary due to local conditions.
● The keyless entry system is fully operational (door/trunk lid lock/unlock)
when the ignition is switched off. The system does not operate if the ignition
is switched to any position other than off.
● If the key does not operate when pres sing a button or the operational range
becomes too small, the battery may be dead. To install a new battery, refer
to Key Battery Replacement ( →P. 443).
● Additional keys can be obtained at your Toyota dealer. Up to 6 keys can be
used with the keyless functions per vehicle. Bring all keys to your Toyota
dealer when additional keys are required.
Operation indicator light
Operation buttons
The operation indicator light
flashes when the buttons are
pressed.
● Battery life is about one year. Replace
the battery with a new one if the KEY
indicator light (green) flashes in the com-
bination meter. Replacing the battery
about once a year is recommended
because the KEY warning light/indicator
light may not illuminate or flash depend-
ing on the rate of battery depletion.
NOTICE
Radio equipment like this is governed by laws in the United States.
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
Smart Key
1
2
YARIS_SEDAN_OM_OM99M18z_(U).book Page 89 Monday, June 1, 2015 9:22 PM

147
YARIS_SEDAN_OM_OM99M18z_(U)
3-1. Start/Stop Engine
3
When Driving
Tur ning the Engine Off
Stop the vehicle completely.
Manual transaxle:
Shift into neutral and set the parking brake.
Automatic transaxle:
Shift the selector lever to the P position and set the parking brake.
Press the push button start to turn off the engine. The ignition posi-
tion is off.
●The cooling fan in the engine compartment could turn on for a few minutes
after the ignition is switched from ON to OFF, whether or not the A/C is on or
off, to cool the engine compartment quickly.
● When the push button start is pressed from ON to ACC or OFF, the KEY
indicator light (green) may flash for approximately 30 seconds indicating
that the remaining battery power of the key is low.
Replace with a new battery before the key becomes unusable.
Refer to Key Battery Replacement on P. 443.
● Automatic transaxle:
If the engine is turned off while the selector lever is in a position other than
P, the ignition switches to ACC.
Continuously pressing the push button start or quickly pressing it two
or more times while the engine is running or the vehicle is being
driven will turn the engine off immediately. The ignition switches to
ACC.
WARNING
■Do not stop the engine while the vehicle is moving
Stopping the engine while the vehicle is moving for any reason other than in
an emergency is dangerous. Stopping the engine while the vehicle is mov-
ing will result in reduced braking ability due to the loss of power braking,
which could cause an accident and serious injury.
NOTICE
When leaving the vehicle, make sure the push button start is off.
Emergency Engine Stop
1
2
3
YARIS_SEDAN_OM_OM99M18z_(U).book Page 147 Monday, June 1, 2015 9:22 PM

417
YARIS_SEDAN_OM_OM99M18z_(U)
5Maintenance and Care
5-1. Essential InformationIntroduction ....................... 418
5-2. Scheduled Maintenance Maintenance Monitor ........ 420
5-3. Owner Maintenance Owner Maintenance Precautions ..................... 424
Hood ................................. 426
Engine Compartment Overview ......................... 428
Engine Oil ......................... 429
Engine Coolant ................. 431
Brake/Clutch Fluid............. 434
Window Washer Fluid ....... 435
Body Lubrication ............... 436
Wiper Blades..................... 437
Battery............................... 440
Key Battery Replacement ................... 443
Tires .................................. 446
Light Bulbs ........................ 451
Fuses ................................ 460
5-4. Appearance Care Exterior Care ..................... 468
Interior Care ...................... 476
YARIS_SEDAN_OM_OM99M18z_(U).book Page 417 Monday, June 1, 2015 9:22 PM

440
YARIS_SEDAN_OM_OM99M18z_(U)
5-3. Owner Maintenance
Batter y
Before performing battery mainte-
nance, remove the battery cover
by pressing the tab.
To get the best service from a battery:
●Keep it securely mounted.
● Keep the top clean and dry.
● Keep terminals and connec-
tions clean, tight, and coated
with petroleum jelly or terminal
grease.
● Rinse off spilled electrolyte
immediately with a solution of
water and baking soda.
● If the vehicle will not be used for an extended time, disconnect the
battery cables and charge the battery every six weeks.
Contact your Toyota dealer for a battery replacement purchase.Ta b
Battery Maintenance
Battery Replacement
YARIS_SEDAN_OM_OM99M18z_(U).book Page 440 Monday, June 1, 2015 9:22 PM

443
YARIS_SEDAN_OM_OM99M18z_(U)
5-3. Owner Maintenance
5
Maintenance and Care
Key Batter y Replacement
If the buttons on the smart Key are inoperable and the operation indi-
cator light does not flash, the battery may be dead.
Replace with a new battery before the smart Key becomes unusable.
The following conditions indicate that the battery power is low:
●The KEY indicator light (green) flashes in the instrument cluster for
about 30 seconds after the engine is turned off.
● The system does not operate and the operation indicator light on
the smart Key does not flash when the buttons are pressed.
● The system’s operational range is reduced.
Replacing the battery at your Toyota dealer is recommended to pre-
vent damage to the key. If replacing the battery by yourself, follow the
instruction below.
■Replacing the key battery
Press the knob and pull out
the auxiliary key.
Twist a tape-wrapped flat-
head screwdriver in the
direction of the arrow and
open the cover slightly.
Knob1
Cover2
YARIS_SEDAN_OM_OM99M18z_(U).book Page 443 Monday, June 1, 2015 9:22 PM
