126 2-1. Driving procedures
CAUTION
■When the vehicle is parked
●Always apply the parking brake, shift the shift lever to P (automatic trans-
mission only), stop the engine and lock the vehicle.
Do not leave the vehicle unattended while the engine is running.
● Do not touch the exhaust pipe while the engine is running or immediately
after turning the engine off.
Doing so may cause burns.
● Do not leave the engine running in an area with snow build-up, or where it
is snowing. If snowbanks build up around the vehicle while the engine is
running, exhaust gases may collect and enter the vehicle. This may lead
to death or a serious health hazard.
■ Exhaust gases
Exhaust gases include harmful carbon monoxide (CO) that is colorless and
odorless. Inhaling exhaust gases may lead to death or a serious health haz-
ard.
●If the vehicle is in a poorly ventilated area, stop the engine. In a closed
area, such as a garage, exhaust gases may collect and enter the vehicle.
This may lead to death or a serious health hazard.
● The exhaust should be checked occasionally. If there is a hole or crack
caused by corrosion, damage to a joint or abnormal exhaust noise, be
sure to have the vehicle inspected and repaired by your Toyota dealer.
Failure to do so may allow exhaust gases to enter the vehicle, resulting in
death or a serious health hazard.
■ When taking a nap in the vehicle
Always turn the engine off. Otherwise, you may accidentally move the shift
lever or depress the accelerator pedal, which could cause an accident or fire
due to engine overheating. Additionally, if the vehicle is parked in a poorly
ventilated area, exhaust gases may collect and enter the vehicle, leadin\
g to
death or a serious health hazard.
■ When braking the vehicle
●When the brakes are wet, drive more cautiously.
Braking distance increases when the brakes are wet, and may cause one
side of the vehicle to brake differently than the other side. Also the parking
brake may not securely hold the vehicle.

137
2-1. Driving procedures
2
When driving
NOTICE
■
Before driving
Fully release the parking brake.
Driving the vehicle with the parking brake set will lead to brake components
overheating, which may affect braking performance and increase brake
wear.
●Parking brake engaged warning buzzer ( →P. 315)

144 2-2. Instrument cluster
NOTICE
■To prevent damage to the engine and its components
●Do not let the indicator needle of the tachometer enter the red zone, which
indicates the maximum engine speed.
● The engine may be overheating if the high engine coolant temperature
warning light comes on. In this case, immediately stop the vehicle in a safe
place, and check the engine after it has cooled completely. (
→P. 345)

163
2-4. Using other
driving systems
2
When driving
■Automatic TRAC reactivation
If only the TRAC system is turned off, the TRAC system will turn on when
vehicle speed increases.
■ Automatic TRAC and VSC reactivation
If the TRAC and VSC systems are turned off, the systems will not turn on
even when vehicle speed increases.
■ If the slip indicator lights up
There is a malfunction in the TRAC and VSC systems. Contact your Toyota
dealer and have your Toyota inspected.
■ If the brake system overheats
TRAC will cease operation and a buzzer will sound to alert the driver. Stop
the vehicle in a safe place. (There is no problem with continuing normal driv-
ing.)
■ EPS operation sound
When the steering wheel operates, a motor sound (whirring sound) may be
heard.
This does not indicate a malfunction.
■ Reduced effectiveness of EPS
The effectiveness of EPS is reduced to prevent the system from overheating
when there is frequent steering input over an extended period of time. The
steering wheel may feel heavy as a result. Should this occur, refrain from
excessive steering input or stop the vehicle and turn the engine off. The sys-
tem should return to normal within 10 minutes.
CAUTION
■The ABS does not opera te effectively when
● Tires with inadequate gripping ability are used (such as excessively worn
tires on a snow covered road).
● The vehicle hydroplanes while driving at high speed on the wet or slick
road.

179
2-5. Driving information
2
When driving
●
In order to maintain engine braking efficiency, do not use the trans-
mission in D (automatic transmiss ion) or 5 (manual transmission).
● Due to the added load of the trailer, your vehicle’s engine may
overheat on hot days (at temperatures over 85°F [30°C]) when
driving up a long or steep grade. If the engine coolant temperature
gauge indicates overheating, immedi ately turn off the air condition-
ing (if in use), pull your vehicle off the road and stop in a safe spot.
( → P. 345)
● Always place wheel blocks under both the vehicle and the trailer
wheels when parking. Apply the parking brake firmly, and put the
transmission in P (automatic transmission) or in 1 or R (manual
transmission). Avoid parking on a slope, but if unavoidable, do so
only after performing the following:
Apply the brakes and keep them applied.
Have someone place wheel blocks under both the vehicle and
trailer wheels.
When the wheel blocks are in pl ace, release the brakes slowly
until the blocks absorb the load.
Apply the parking brake firmly.
Shift into 1 or R (manual transmission) or P (automatic trans-
mission) and turn off the engine.
● When restarting after parking on a slope:
With the transmission in P (automatic transmission) or the
clutch pedal (manual transmission) depressed, start the
engine. On vehicles with an au tomatic transmission, be sure
to keep the brake pedal pressed.
Shift into a forward gear. If reversing, shift into R.
Release the parking brake (also brake pedal on vehicles with
an automatic transmission), and slowly pull or back away from
the wheel blocks. Stop and apply the brakes.
Have someone retrieve the blocks.

316 5-2. Steps to take in an emergency
Stop the vehicle immediately.The following warnings indicate the possibility of damage to the vehi-
cle that may lead to an accident. Immediately stop the vehicle in a
safe place and contact your Toyota dealer.
*: The light may come on when the oil level is extremely low. It is not designed to indicate low oil level, and the oil level must be checked using the engine
oil level dipstick.
Have the vehicle inspected immediately.
Failing to investigate the cause of the following warnings may lead to
the system operating abnormally and possibly cause an accident.
Have the vehicle inspected by your Toyota dealer immediately.
Warning lightWarning light/Details
Charging system warning light Indicates a malfunction in the vehicle’s charging sys-
tem.
Low engine oil pressure warning light Indicates that the engine oil pressure is too low*.
High engine coolant temperature warning light Indicate a engine is almost overheating.( →P. 345)
Warning lightWarning light/Details
(except Canada)
(Canada) Malfunction indicator lamp
Indicates a malfunction in:
• The electronic engine control system;
• The electronic throttle control system;
• The electronic automatic transmission control sys-tem; or
• Emission control system.

5
When trouble arises
347
5-2. Steps to take in an emergency
■
Overheating
If you observe the following, your vehicle may be overheating.
●The high engine coolant temperature warning light flashes or comes on
or a loss of power is experienced.
● Steam is coming from under the hood.
CAUTION
■To prevent an accident or injury when inspecting under the hood of
your vehicle
●If steam is seen coming from under the hood, do not open the hood until
the steam has subsided. The engine compartment may be very hot, caus-
ing serious injury such as burns.
● Keep hands and clothing away from the fan and other belts while the
engine is running.
● Do not loosen the radiator cap while the engine and radiator are hot.
Serious injury, such as burns, may result from hot coolant and steam
released under pressure.
NOTICE
■When adding engine coolant
Wait until the engine has cooled down before adding engine coolant.
When adding coolant, do so slowly. Adding cool coolant to a hot engine too
quickly can cause damage to the engine.

391
Alphabetical index
If the warning light turns
on ....................................... 315
If you have a flat tire ............ 325
If you lose your keys............. 340
If you think something is wrong ................................. 311
If the vehicle becomes stuck................................... 348
If your vehicle has to be stopped in an emergency... 350
If your vehicle needs to be
towed ................................. 305
If your vehicle overheats ...... 345
Engine
Compartment........................ 253
Engine switch ....................... 129
Hood ..................................... 250
How to start the engine ........ 129
Identification number ............ 353
If the engine will not start...... 337
Ignition switch ....................... 129
Immobilizer system................. 78
Overheating .......................... 345
Specifications ....................... 354
Warning light ........................ 316
Engine coolant
Capacity ............................... 356
Checking .............................. 258
Indicator................................ 145
Preparing and checking before winter ...................... 169
Type ..................................... 356
Warning light ........................ 316
Engine immobilizer system ...... 78
Engine oil Capacity ............................... 355
Checking .............................. 254
Grade ................................... 355
Initializing the maintenance data .................................... 256
Preparing and checking
before winter ...................... 169
Warning light ................ 316, 318 Engine switch ...........................129
Engine oil maintenance
data .........................................256
EPS EPS .......................................160
Warning light .........................316
Event data recorder .................313
Floor mat...................................232
Fluid Automatic transmission .........357
Brake .....................................260
Clutch ....................................358
Warning light .................315, 318
Washer ..................................264
Fog lights
Indicator ................................151
Replacing light bulbs .............294
Switch....................................151
Wattage .................................360
Front fog lights Indicator ................................151
Replacing light bulbs .............294
Switch....................................151
Wattage .................................360
Front passenger's seat belt reminder light.........................318
Front seats
Adjustment ..............................40
Front side marker lights Replacing light bulbs .............294
Switch....................................149
Wattage .................................360
Front turn signal lights
Indicator ................................135
Lever .....................................135
Replacing light bulbs .............294
Switch....................................135
Wattage .................................360
Fuel
Capacity ................................354
Fuel pump shut off system ....312
Gas station information .........400
F

393
Alphabetical index
Luggage compartment features
Auxiliary boxes ..................... 233
Luggage cover...................... 234
Luggage compartment light Wattage ................................ 360
Maintenance Do-it-yourself maintenance ...................... 247
Emission inspection and
maintenance (I/M)
programs ............................ 246
General maintenance ........... 243
Maintenance data ................. 352
Maintenance requirements ... 241
Vehicle exterior..................... 236
Vehicle interior...................... 238
Manual transmission Manual transmission ............ 134
Oil ......................................... 358
Meter Instrument panel light
control ................................ 143
Meters .................................. 139
Mirrors
Inside rear view mirror ............ 67
Side mirror heaters ............... 193
Side mirrors ............................ 68
Vanity mirrors ....................... 228
MP3 disc................................... 208
Noise from under vehicle ......... 20
Odometer ................................. 142
Oil Engine oil.............................. 254
Manual transmission ............ 358
Warning light ................ 316, 318
Opener Fuel door ................................ 74
Fuel filler door......................... 74
Hood ..................................... 250 Outside rear view mirrors
Adjusting .................................68
Folding ....................................69
Overheating, Engine ................345
Parking brake ...........................136
Parking lights Replacing light bulbs .............294
Switch....................................149
Wattage .................................360
Personal lights Switch....................................219
Wattage .................................360
Power outlet .............................231
Power windows ..........................71
Radiator ....................................259
Radio .........................................197
Rear seat Folding down ...........................45
Rear side marker lights
Replacing light bulbs .............294
Switch....................................149
Wattage .................................360
Rear turn signal lights Indicator ................................135
Lever .....................................135
Replacing light bulbs .............294
Switch....................................135
Wattage .................................360
Rear window defogger ............193
Rear window wiper ..................155
Replacing Key battery ............................281
Fuses ....................................283
Light bulbs .............................294
Tires ..............................266, 325
Reporting safety defects for U.S. owners ......................382
M
N
O
P
R
