38
7,500 miles or 6 months
Check installation of driver’s floor mat
Inspect and adjust all fluid levels1
Inspect wiper blades
Replace engine oil and oil filter2
Rotate tires

Visually inspect brake linings/drums
and brake pads/discs
Dealer Service verification:
D
ate:
Mileage:
15,000 miles or 12 months
Check installation of driver’s floor mat
Inspect and adjust all fluid levels1

Inspect emergency flat tire repair kit
(if equipped)3
Inspect wiper blades
Replace engine oil and oil filter2
Rotate tires
Inspect the following:
Ball joints and dust covers

Brake linings/drums and brake pads/discs4
Cabin air filter
Engine coolant5
Radiator and condenser
Steering gear
NOTE: Driving in heavy traffic, on dirt
roads or in urban, dusty or desert areas
may shorten the life of the cabin air
filter. Replacement may be needed if
you notice reduced air flow from the
air conditioner and heater or if the
windows fog easily when you use
the “Fresh” mode. Consult your dealer
if any of these conditions occur.
Dealer Service verification:
D
ate:
Mileage:
1 inspect sealed transmissions, transfer cases and differentials for signs of leakage. if any leakage from a sealed
component is suspected, it is recommended that you have the sealed component inspected by a toyota dealer. inspect
power steering fluid (if equipped) and brake fluid level/condition. inspect engine and inverter (if equipped) coolant
level/condition/freezing point. Your dealer may recommend services (Dealer-recommended Maintenance) based on
inspection results.
2 reset the scheduled maintenance indicator light. Use 0W-20 genuine toyota Motor oil or equivalent.3 check the tire repair fluid expiration date every year during inspection. replace the tire repair fluid bottle with a new one
before the expiration date.
4 inspect thickness measurement and disc runout.5 refer to

39
22,500 miles or 18 months
Check installation of driver’s floor mat
Inspect and adjust all fluid levels1
Inspect wiper blades
Replace engine oil and oil filter2
Rotate tires

Visually inspect brake linings/drums
and brake pads/discs
Dealer Service verification:
D
ate:
Mileage:
30,000 miles or 24 months
Check installation of driver’s floor mat
Inspect and adjust all fluid levels1

Inspect emergency flat tire repair kit
(if equipped)3
Inspect wiper blades
Replace cabin air filter
Replace engine oil and oil filter2
Rotate tires

Tighten nuts and bolts on body
and chassis
Inspect the following:
Ball joints and dust covers
Brake lines and hoses

Brake linings/drums and brake pads/discs4
Drive shaft boots
Engine coolant5
Fuel lines and connections, fuel tank band
and fuel tank vapor vent system hoses
Fuel tank cap gasket
Radiator and condenser
Steering gear
Steering linkage and boots
Transmission fluid or oil
Dealer Service verification:
D
ate:
Mileage:
1 inspect sealed transmissions, transfer cases and differentials for signs of leakage. if any leakage from a sealed
component is suspected, it is recommended that you have the sealed component inspected by a toyota dealer. inspect
power steering fluid (if equipped) and brake fluid level/condition. inspect engine and inverter (if equipped) coolant
level/condition/freezing point. Your dealer may recommend services (Dealer-recommended Maintenance) based on
inspection results.
2 reset the scheduled maintenance indicator light. Use 0W-20 genuine toyota Motor oil or equivalent.3 check the tire repair fluid expiration date every year during inspection. replace the tire repair fluid bottle with a new one
before the expiration date.
4 inspect thickness measurement and disc runout.5 refer to

40
37,500 miles or 30 months
Check installation of driver’s floor mat
Inspect and adjust all fluid levels1
Inspect drive belts
Inspect wiper blades
Replace engine air filter
Replace engine oil and oil filter2
Rotate tires

Visually inspect brake linings/drums
and brake pads/discs
Dealer Service verification:
D
ate:
Mileage:
45,000 miles or 36 months
Check installation of driver’s floor mat
Inspect and adjust all fluid levels1

Inspect emergency flat tire repair kit
(if equipped)3
Inspect wiper blades
Replace engine oil and oil filter2
Rotate tires
Inspect the following:
Ball joints and dust covers

Brake linings/drums and brake pads/discs4
Cabin air filter
Engine coolant5
Exhaust pipes and mountings
Radiator and condenser
Steering gear
NOTE: Driving in heavy traffic, on dirt
roads or in urban, dusty or desert areas
may shorten the life of the cabin air
filter. Replacement may be needed if
you notice reduced air flow from the
air conditioner and heater or if the
windows fog easily when you use
the “Fresh” mode. Consult your dealer
if any of these conditions occur.
Dealer Service verification:
D
ate:
Mileage:
1 inspect sealed transmissions, transfer cases and differentials for signs of leakage. if any leakage from a sealed
component is suspected, it is recommended that you have the sealed component inspected by a toyota dealer. inspect
power steering fluid (if equipped) and brake fluid level/condition. inspect engine and inverter (if equipped) coolant
level/condition/freezing point. Your dealer may recommend services (Dealer-recommended Maintenance) based on
inspection results.
2 reset the scheduled maintenance indicator light. Use 0W-20 genuine toyota Motor oil or equivalent.3 check the tire repair fluid expiration date every year during inspection. replace the tire repair fluid bottle with a new one
before the expiration date.
4 inspect thickness measurement and disc runout.5 refer to

41
52,500 miles or 42 months
Check installation of driver’s floor mat
Inspect and adjust all fluid levels1
Inspect wiper blades
Replace engine oil and oil filter2
Rotate tires

Visually inspect brake linings/drums
and brake pads/discs
Dealer Service verification:
D
ate:
Mileage:
60,000 miles or 48 months
Check installation of driver’s floor mat
Inspect and adjust all fluid levels1

Inspect emergency flat tire repair kit
(if equipped)3
Inspect wiper blades
Replace cabin air filter
Replace engine oil and oil filter2
Rotate tires

Tighten nuts and bolts on body
and chassis
Inspect the following:
Ball joints and dust covers
Brake lines and hoses

Brake linings/drums and brake pads/discs4
Drive shaft boots
Emission hoses and tubes
Engine coolant5
Fuel lines and connections, fuel tank band
and fuel tank vapor vent system hoses
Fuel tank cap gasket
Radiator and condenser
Steering gear
Steering linkage and boots
Transmission fluid or oil
Dealer Service verification:
D
ate:
Mileage:
1 inspect sealed transmissions, transfer cases and differentials for signs of leakage. if any leakage from a sealed
component is suspected, it is recommended that you have the sealed component inspected by a toyota dealer. inspect
power steering fluid (if equipped) and brake fluid level/condition. inspect engine and inverter (if equipped) coolant
level/condition/freezing point. Your dealer may recommend services (Dealer-recommended Maintenance) based on
inspection results.
2 reset the scheduled maintenance indicator light. Use 0W-20 genuine toyota Motor oil or equivalent.3 check the tire repair fluid expiration date every year during inspection. replace the tire repair fluid bottle with a new one
before the expiration date.
4 inspect thickness measurement and disc runout.5 refer to

42
67,500 miles or 54 months
Check installation of driver’s floor mat
Inspect and adjust all fluid levels1
Inspect wiper blades
Replace engine oil and oil filter2
Rotate tires

Visually inspect brake linings/drums
and brake pads/discs
Dealer Service verification:
D
ate:
Mileage:
75,000 miles or 60 months
Check installation of driver’s floor mat
Inspect and adjust all fluid levels1

Inspect emergency flat tire repair kit
(if equipped)3
Inspect drive belts
Inspect wiper blades
Replace engine air filter
Replace engine oil and oil filter2
Replace spark plugs4
Rotate tires
Inspect the following:
Ball joints and dust covers

Brake linings/drums and brake pads/discs5
Cabin air filter
Engine coolant6
Radiator and condenser
Steering gear
NOTE: Driving in heavy traffic, on dirt
roads or in urban, dusty or desert areas
may shorten the life of the cabin air
filter. Replacement may be needed if
you notice reduced air flow from the
air conditioner and heater or if the
windows fog easily when you use
the “Fresh” mode. Consult your dealer
if any of these conditions occur.
Dealer Service verification:
D
ate:
Mileage:
1 inspect sealed transmissions, transfer cases, and differentials for signs of leakage. if any leakage from a sealed
component is suspected, it is recommended that you have the sealed component inspected by a toyota dealer. inspect
power steering fluid (if equipped) and brake fluid level/condition. inspect engine and inverter (if equipped) coolant
level/condition/freezing point. Your dealer may recommend services (Dealer-recommended Maintenance) based on
inspection results.
2 reset the scheduled maintenance indicator light. Use 0W-20 genuine toyota Motor oil or equivalent. 3 check the tire repair fluid expiration date every year during inspection. replace the tire repair fluid bottle with a new one
before the expiration date.
4 Maintenance services of spark plugs are required under the terms of the emission control Warranty. 5 inspect thickness measurement and disc runout.6 refer to

43
82,500 miles or 66 months
Check installation of driver’s floor mat
Inspect and adjust all fluid levels1
Inspect wiper blades
Replace engine oil and oil filter2
Rotate tires

Visually inspect brake linings/drums
and brake pads/discs
Dealer Service verification:
D
ate:
Mileage:
90,000 miles or 72 months
Check installation of driver’s floor mat
Inspect and adjust all fluid levels1

Inspect emergency flat tire repair kit
(if equipped)3
Inspect wiper blades
Replace cabin air filter
Replace engine oil and oil filter2
Rotate tires

Tighten nuts and bolts on body
and chassis
Inspect the following:
Ball joints and dust covers
Brake lines and hoses

Brake linings/drums and brake pads/discs4
Drive shaft boots
Engine coolant5
Exhaust pipes and mountings Fuel lines and connections, fuel tank band
and fuel tank vapor vent system hoses
Fuel tank cap gasket
Radiator and condenser
Steering gear
Steering linkage and boots
Transmission fluid or oil
Dealer Service verification:
D
ate:
Mileage:
1 inspect sealed transmissions, transfer cases and differentials for signs of leakage. if any leakage from a sealed
component is suspected, it is recommended that you have the sealed component inspected by a toyota dealer. inspect
power steering fluid (if equipped) and brake fluid level/condition. inspect engine and inverter (if equipped) coolant
level/condition/freezing point. Your dealer may recommend services (Dealer-recommended Maintenance) based on
inspection results.
2 reset the scheduled maintenance indicator light. Use 0W-20 genuine toyota Motor oil or equivalent.3 check the tire repair fluid expiration date every year during inspection. replace the tire repair fluid bottle with a new one
before the expiration date.
4 inspect thickness measurement and disc runout.5 refer to

44
97,500 miles or 78 months
Check installation of driver’s floor mat
Inspect and adjust all fluid levels1
Inspect wiper blades
Replace engine oil and oil filter2
Rotate tires

Visually inspect brake linings/drums
and brake pads/discs
Dealer Service verification:
D
ate:
Mileage:
105,000 miles or 84 months
Check installation of driver’s floor mat
Inspect and adjust all fluid levels1

Inspect emergency flat tire repair kit
(if equipped)3
Inspect wiper blades
Replace engine oil and oil filter2
Rotate tires
Inspect the following:
Ball joints and dust covers

Brake linings/drums and brake pads/discs4
Cabin air filter
Engine coolant5
Radiator and condenser
Steering gear
NOTE: Driving in heavy traffic, on dirt
roads or in urban, dusty or desert areas
may shorten the life of the cabin air
filter. Replacement may be needed if
you notice reduced air flow from the
air conditioner and heater or if the
windows fog easily when you use
the “Fresh” mode. Consult your dealer
if any of these conditions occur.
Dealer Service verification:
D
ate:
Mileage:
1 inspect sealed transmissions, transfer cases and differentials for signs of leakage. if any leakage from a sealed
component is suspected, it is recommended that you have the sealed component inspected by a toyota dealer. inspect
power steering fluid (if equipped) and brake fluid level/condition. inspect engine and inverter (if equipped) coolant
level/condition/freezing point. Your dealer may recommend services (Dealer-recommended Maintenance) based on
inspection results.
2 reset the scheduled maintenance indicator light. Use 0W-20 genuine toyota Motor oil or equivalent.3 check the tire repair fluid expiration date every year during inspection. replace the tire repair fluid bottle with a new one
before the expiration date.
4 inspect thickness measurement and disc runout.5 refer to

45
112,500 miles or 90 months
Check installation of driver’s floor mat
Inspect and adjust all fluid levels1
Inspect drive belts
Inspect wiper blades
Replace engine air filter
Replace engine oil and oil filter2
Rotate tires

Visually inspect brake linings/drums
and brake pads/discs
Dealer Service verification:
D
ate:
Mileage:
120,000 miles or 96 months
Check installation of driver’s floor mat
Inspect and adjust all fluid levels1

Inspect emergency flat tire repair kit
(if equipped)3
Inspect wiper blades
Replace cabin air filter
Replace engine coolant4
Replace engine oil and oil filter2
Rotate tires

Tighten nuts and bolts on body
and chassis
Inspect the following:
Ball joints and dust covers
Brake lines and hoses

Brake linings/drums and brake pads/discs5
Drive shaft boots
Emission hoses and tubes Fuel lines and connections, fuel tank band
and fuel tank vapor vent system hoses
Fuel tank cap gasket
Radiator and condenser
Steering gear
Steering linkage and boots
Transmission fluid or oil
Dealer Service verification:
D
ate:
Mileage:
1 inspect sealed transmissions, transfer cases and differentials for signs of leakage. if any leakage from a sealed
component is suspected, it is recommended that you have the sealed component inspected by a toyota dealer. inspect
power steering fluid (if equipped) and brake fluid level/condition. inspect engine and inverter (if equipped) coolant
level/condition/freezing point. Your dealer may recommend services (Dealer-recommended Maintenance) based on
inspection results.
2 reset the scheduled maintenance indicator light. Use 0W-20 genuine toyota Motor oil or equivalent. 3 check the tire repair fluid expiration date every year during inspection. replace the tire repair fluid bottle with a new one
before the expiration date.
4 NOTE: Initial replacement at 120,000 miles/120 months. Replace every 60,000 miles/60 months thereafter. Refer
to “Engine Coolant” in the “Explanation of Maintenance Items” section in the back of this guide for more information.
5 Inspect thickness measurement and disc runout.
Maintenance Log
MAINTENANCE LOG
MAINTENANCE

48
Fuel Lines and Connections,
Fuel Tank Band and Fuel Tank
Vapor Vent System Hoses
Visually inspect for corrosion, damage,
cracks, and loose or leaking connections.
Tighten connections or replace parts
as necessary.
Fuel Tank Cap Gasket
Visually inspect for cracks, deterioration
and damage and replace if necessary.
Nuts and Bolts on Chassis
and Body
Retighten the seat-mounting bolts and
front /rear suspension member retaining
bolts to specified torque.
Radiator and Condenser
Inspect for debris, corrosion and signs
of damage. Have any problem repaired
immediately by a qualified technician.
Spark Plugs
Replace at specified intervals. Install new
plugs of the same type as originally
equipped. A qualified technician should
perform this operation.
Steering Gear
Inspect for signs of leakage. If you
discover any leakage, have it repaired
immediately by a qualified technician.
Steering Linkage and Boots
With the vehicle stopped, check for
excessive freeplay in the steering wheel.
Inspect the linkage for bending and
damage and the dust boots for
deterioration, cracks and damage. Replace
any damaged parts. A qualified technician
should perform these operations.
Tire Rotation
Tires should be rotated according to the
instructions in the Owner’s Manual. When
rotating tires, check for damage and
uneven wear. Replace if necessary.
Transmission Fluid or Oil
Inspect at specified intervals. When
performing inspections, check each
component for signs of leakage. If you
discover any leakage, have it repaired
by a qualified technician immediately.
Wiper Blades
The wiper blades should not show any
signs of cracking, splitting, wear,
contamination or deformation. The wiper
blades should clear the windshield without
streaking or skipping.
EXPLANATION OF MAINTENANCE ITEMS
Maintenance Log
MAINTENANCE
