3447-3. Do-it-yourself maintenance
Light bulbs
Check the wattage of the light bulb to be replaced. (P. 437)
Front
You may replace the following bulbs by yourself. The difficulty
level of replacement varies depending on the bulb. As there is a
danger that components may be damaged, we recommend that
replacement is carried out by any authorized Toyota dealer or
repairer, or another duly qualified and equipped professional.
For more information about replacing other light bulbs, contact
any authorized Toyota dealer or repairer, or another duly quali-
fied and equipped professional.
Preparing for light bulb replacement
Bulb locations
Front position lights/daytime
running lights (bulb type)
Front turn signal lightsFront fog lights (if equipped)
Halogen headlights
Side turn signal lights1
2
3
4
5

3457-3. Do-it-yourself maintenance
7
Maintenance and care
Rear
*1: Left-hand drive vehicles
*2: Right-hand drive vehicles
Rear fog light*1/
back-up light
*2
License plate lights
Back-up light
*1/
rear fog light
*2
Rear turn signal lights
Stop/tail lights (bulb type)1
2
3
4
5

3477-3. Do-it-yourself maintenance
7
Maintenance and care
Front fog lights (if equipped)
Turn the steering wheel in
the opposite direction of the
light to be replaced.
Turn the steering wheel to a
point that allows your hand to
easily fit between the tire and
fender liner.
Remove the screw.
Partly remove the fender
liner until the bulb is visible.
Unplug the connector while
pressing the lock release.
1
2
3
4

3487-3. Do-it-yourself maintenance
Turn the bulb base counter-
clockwise.
Set the new light bulb.
Align the 3 tabs on the light bulb
with the mounting, and insert.
Turn and secure the bulb.
Install the connector.
Shake the bulb base gently to
check that it is not loose, turn
the front fog light, on once and
visually confirm that no light is
leaking through the mounting.
5
6
7
8

3557-3. Do-it-yourself maintenance
7
Maintenance and care
Back-up light/rear fog light
Remove the clip and partly
remove the cover.
Pull the center section of the clip
and the remove and pull out the
lock.
Turn the bulb base counter-
clockwise.
Remove the light bulb.
After installing the new bulb,
reinstall the clip.
When installing the clip, insert
the clip in and push the center of
the clip.
1
2
3
4

4379-1. Specifications
9
Vehicle specifications
Light bulbs
Light BulbsWTy p e
Exterior
Halogen headlights55A
Front fog lights*19B
Front position light/daytime running lights
(bulb type)21/5C
Front turn signal lights21D
Side turn signal lights5D
Rear turn signal lights21F
Stop/tail lights (bulb type)21/5C
Back-up light21C
Rear fog light21C
License plate lights5C
Interior
Vanity lights*5E
Personal lights/interior light5C
Luggage compartment light5E
A: HIR2 halogen bulbs
C: Wedge base bulbs (clear)
E: Double end bulbsB: H16 halogen bulbs
D: Wedge base bulbs (amber)
F: Single end bulbs (clear)
*: If equipped
