Page 460 of 576

4605-3. Owner Maintenance
YARIS iA_OM_OM99N89z_(U)
43EPS60 APower steering system (if equipped)
44DEFOG40 ARear window defogger
45IG230 AFor protection of various circuits
46INJECTOR30 AEngine control system
47HEATER40 AAir conditioner
48P. W I N D O W 130 APower windows
49DCDC DE40 A—
DESCRIPTIONFUSE
RATINGPROTECTED COMPONENT
Page 502 of 576

5026-7. Warning/Indicator Lights and Warning Sounds
YARIS iA_OM_OM99N89z_(U)
Charging System Warning LightIf the warning light illuminates while driving, it indicates a
malfunction of the alternator or of the charging system.
Drive to the side of the road and park off the right-of-way.
Consult your Toyota dealer.
Engine Oil Warning LightThis warning light indicates low engine oil pressure.
If the light illuminates or the warning indication is dis-
played while driving:
Drive to the side of the road and park off the right-of-
way on level ground.
Turn off the engine and wait 5 minutes for the oil to
drain back into the oil pan.
Inspect the engine oil level P. 424. If it’s low, add the
appropriate amount of engine oil while being careful
not to overfill.
Start the engine and check the warning light.
If the light remains illuminated even though the oil level is
normal or after adding oil, stop the engine immediately
and have your vehicle towed to your Toyota dealer.
(Red)
High Engine Coolant Temperature Warning Light The light flashes when the engine coolant temperature is
extremely high, and illuminates when the engine coolant
temperature increases further.
Handling Procedure:
• Flashing lightDrive slowly to reduce engine load until you can find a
safe place to stop the vehicle and wait for the engine to
cool down.
• Illuminated light This indicates the possibility of overheating. Park the
vehicle in a safe place immediately and stop the engine.
Refer to Overheating P. 496.
Power Steering Malfunction Indicator Light
The light illuminates/flashes if the electric power steering
has a malfunction.
If the light illuminates/flashes, stop the vehicle in a safe
place and do not operate the steering wheel. There is no
problem if the light turns off after a while. Contact your
Toyota dealer if the light illuminates/flashes continuously.
SignalWarning
1
2
3
4
Page 503 of 576

YARIS iA_OM_OM99N89z_(U)
5036-7. Warning/Indicator Lights and Warning Sounds
6
If Trouble Arises
■Power Steering Malfunction Indicator Light
●If the indicator light illuminates/flashes, the power steering will not operate
normally. If this happens, the steering wheel can still be operated, however,
the operation may feel heavy compared to normal, or the steering wheel
could vibrate when turning.
● Repeatedly jerking the steering wheel left and right while the vehicle is
stopped or moving extremely slowly will cause the power steering system to
go into protective mode which will make the steering feel heavy, but this
does not indicate a problem. If this occurs, park the vehicle safely and wait
several minutes for the system to return to normal.
WARNING
■Do not drive with the brake system warning light illuminated. Contact
your Toyota dealer to have the brakes inspected as soon as possible
Driving with the brake system warning light illuminated is dangerous. It indi-
cates that your brakes may not work at all or that they could completely fail
at any time. If this light remains illuminated, after checking that the parking
brake is fully released, have the brakes inspected immediately.
In addition, the effectiveness of the braking may diminish so you may need
to depress the brake pedal more strongly than normal to stop the vehicle.
■ Do not drive with both the ABS warning light and brake warning light
illuminated. Have the vehicle towed to your Toyota dealer to have the
brakes inspected as soon as possible
Driving when the brake system warning light and ABS warning light are illu-
minated simultaneously is dangerous.
When both lights are illuminated, the rear wheels could lock more quickly in
an emergency stop than under normal circumstances.
NOTICE
■Charging System Warning Light
Do not continue driving when the charging system warning light is illumi-
nated because the engine could stop unexpectedly.
■ Engine Oil Warning Light
● Do not run the engine if the oil pressure is low. Otherwise, it could result in
extensive engine damage.
● Do not run the engine if the oil level is low. Otherwise, it could result in
extensive engine damage.
■ High Engine Coolant Temperature Warning Light
Do not drive the vehicle with the high engine coolant temperature warning
light illuminated. Otherwise, it could result in damage to the engine.
Page 515 of 576

YARIS iA_OM_OM99N89z_(U)
5156-7. Warning/Indicator Lights and Warning Sounds
6
If Trouble Arises
If the driver’s door is opened while the ignition is switched to ACC, a
continuous beep sound will be heard to notify th e driver that the igni-
tion has not been switched off (STOP). Left in this condition, the key-
less entry system will not operate, the car cannot be locked, and the
battery power will be depleted.
A beep sound will be hear d 6 times and the KEY warning light (red)
will flash continuously if the ignition has not been switched off, all the
doors are closed, and the key is remo ved from the vehicle. This is to
notify the driver that the key has been removed from the vehicle and
the ignition has not been switched off.
Because the key utilizes low-intensity radio waves, the Key Removed From
Vehicle Warning may activate if the key is carried together with a metal object
or it is placed in a poor signal reception area.
The warning beep sound will be heard for about 3 seconds when
there is any abnormality in tire inflation pressures (→P. 218).
If there is the possibility of a collis ion with a vehicle ahead, the beep
sounds continuously and a warning is indicated in the display.
If the power steering system has a malfunction, the power steering
malfunction light turns on or flashes and the buzzer operates at the
same time.
Refer to Warning/Indicator Lights on P. 156.
Ignition Not Switched Off (STOP) Warning Beep
Key Removed from Vehicle Warning Beep
Tire Inflation Pressure Warning Beep (if equipped)
Collision warning (if equipped)
Power Steering Warning Buzzer
Page 572 of 576

572Alphabetical index
YARIS iA_OM_OM99N89z_(U)
Parking Brake .......................... 188
Power Steering ........................ 203
Power Windows ....................... 116
Power steering warning buzzer ..................................... 515
Rear Coat Hooks...................... 409
Rear Door Ch ild Safety
Locks ...................................... 102
Rear Seat .................................... 24
Rear View Monitor ................... 222
Displayable range on the screen................................. 224
Picture quality adjustment..... 231
Rear view monitor operation ............................ 227
Rear view parking camera location ............................... 223
Switching to the rear view
monitor display ................... 223
Variance between actual road conditions and
displayed Image ................. 229
Viewing the display ............... 226
Rear Window Defogger ........... 185
Rearview Mirror ....................... 114
Recommended Oil ................... 422
Recreational Towing ............... 138
Replacement Fuse ...................................... 455
Key battery............................ 436
Light Bulbs ............................ 445
Tires ...................................... 442
Wheel.................................... 443
Wiper .................................... 432
Rocking the Vehicle ................ 130 Safety Defects, Reporting....... 518
Saving Fuel and Protection
of the Environment ............... 127
Seat Belt System ....................... 34 Automatic locking ................... 33
Emergency locking ................. 33
Extender ................................. 39
Pregnant women .................... 32
Seat belt precautions .............. 30
Seat belt warning beep ........... 514
Seats Front seat ............................... 21
Head restraint ......................... 27
Rear seat ................................ 24
Seat warmer ........................... 22
Security System Immobilizer system ............... 121
Theft-deterrent
system .......... ...................... 123
Smart City Brake Support
(SCBS).................................... 205
Smart key ................................... 89
Spare Tire ................................. 479
Specifications .......................... 554
Speedometer............................ 148
SRS Air Bags Front passenger occupant
classification syst em ............ 78
How the SRS air bags work...................................... 70
Limitations to SRS air bag ...... 76
Monitoring ............................... 83
SRS air bag deployment criteria .................................. 74
Supplemental restraint system components ............. 69
P
R
S
Page 573 of 576

573Alphabetical index
YARIS iA_OM_OM99N89z_(U)
Starting the Engine.................. 142
Steering Wheel......................... 112Horn ...................................... 112
Storage Compartments ........... 407 Cargo Sub-Compartment...... 409
Glove compartment .............. 408
Overhead Console ................ 407
Rear coat hooks.................... 409
Sunvisors ................................. 400
Tachometer .............................. 151
Theft-Deterrent System ........... 123
Tiedown Hook ..................................... 499
Tire Information ....................... 530
Tire Pressure Monitoring System ................................... 218
Tire inflation pressure warning beep ......................... 515
Tires .......................................... 439 Flat Tire................................. 477
Replacing a Tire.................... 442
Replacing a Wheel................ 443
Snow tires ............................. 132
Specifications........................ 558
Temporary Spare Tire........... 443
Tire Inflation Pressure........... 439
Tire Rotation ......................... 440
Tire chains ............................ 132
Uniform tire quality grading system (UTQGS) . ............... 527
Towing
Recreational towing .............. 138
Trailer Towing ....................... 137
Towing Description ................. 498
Traction Control System
(TCS)....................................... 194 TCS/DSC Indicator Light ...... 195
Trip Computer .......................... 154
Trip Meter ................................. 149 Trouble
Battery runs out .................... 491
Emergency Starting .............. 494
Emergency Towing ............... 498
Flat Tire ................................ 477
Overheating .......................... 496
Parking in an Emergency ..... 476
When Trunk Lid Cannot be
Opened .............................. 516
Trunk Lid .................................. 103 Inside Trunk Release
Lever .................................. 105
When Trunk Lid Cannot be Opened .............................. 516
Trunk Light............................... 402
Turn Signals............................. 180
Vanity Mirrors .......................... 400
Vehicle Data Recordings ........ 526
Vehicle Information Labels..................................... 552
Warning Lights ........................ 157
Warning Sound is Activated Air Bag/Front Seat Belt
Pretensioner System
Warning Beep .................... 513
Collision warning .................. 515
Ignition not switched off
(STOP) warning beep ........ 515
Key removed from vehicle
warning beep...................... 515
Lights-on reminder................ 513
Power steering warning buzzer ................................ 515
Seat belt warning beep ......... 514
Tire inflation pressure warning beep...................... 515
T
V
W
