TOYOTA YARIS iA 2018 Owners Manual (in English)

YARIS iA_OM_OM99Q46z_(U)
1112-3. Fuel and Emission
2
Before Driving
To open, pull the remote fuel-filler
lid release.
To close, press the fuel-filler lid
until it locks securely.Open
To remove the fuel-filler cap, turn it
counterclockwise. Attach the
removed cap to the inner side of
the fuel lid.
Close
To close the fuel-filler cap, turn it
clockwise until a click is heard.
Fuel-Filler Lid
Remote fuel-filler lid release
Fuel-Filler Cap
1
2
NOTICE
If the check fuel cap warning light illuminates, the fuel-filler cap may not be
properly installed. If the warning light illuminates, park your vehicle safely off
the right-of-way, remove the fuel-filler cap and reinstall it correctly. After the
cap has been correctly installed, the fuel cap warning light may continue to
illuminate until a number of driving cycles have been completed. A drive
cycle consists of starting the engine (after four or more hours with the
engine off) and driving the vehicle on city and highway roads.
Continuing to drive with the check fuel cap warning light illuminated could
cause the check engine light to illuminate as well.

112
YARIS iA_OM_OM99Q46z_(U)
2-4. Steering Wheel
Steering Wheel
To change the angle or length of the steering wheel:Stop the vehicle, and then pull
down the lock release lever
under the steering column.
Tilt the steering wheel and/or
adjust the steering column
length to the desired positions,
then push the lever up to lock
the column.
Attempt to push the steering wheel up and down to make sure it’s
locked before driving.
To sound the horn, press the mark on the steering wheel.
Steering Wheel Adjustment
Lock release
lever
1
2
WARNING
■ Make sure that the steering wheel is locked firmly in place
If it is difficult to raise the lever, lightly move the steering wheel forward and
back to pull up the lever.
■ Never adjust the steering wheel while the vehicle is moving
Adjusting the steering wheel while the vehicle is moving is dangerous. Mov-
ing it can very easily cause the driver to abruptly turn to the left or right. This
can lead to loss of control or an accident.
Horn
3

113
YARIS iA_OM_OM99Q46z_(U)
2-5. Mirrors
2
Before Driving
Mirrors
■Mirror type
Flat type (driver’s side)
Flat surface mirror.
Convex type (front passenger side)
The mirror has single curvature on its surface.
■Power mirror adjustment
The ignition must be switched to ACC or ON position.
To adjust:
Rotate the mirror switch to
the left or right to choose
the left or right side mirror.
Press the mirror switch in the
appropriate direction.
After adjusting the mirror,
lock the control by rotating
the switch in the center posi-
tion.
Before driving, adjust the inside and outside mirrors.
Outside Mirrors
Center position
Mirror switch1
2

114
YARIS iA_OM_OM99Q46z_(U)
2-5. Mirrors
■Folding mirror
Fold the outside mirror rear-
ward until it is flush with the
vehicle.
■Rearview mirror adjustment
Before driving, adjust the rear-
view mirror to center on the
scene through the rear window.
WARNING
■Be sure to look over your shoulder before changing lanes
Changing lanes without taking into account the actual distance of the vehi-
cle in the convex mirror is dangerous. You could have a serious accident.
What you see in the convex mirror is closer than it appears.
■ Always return the outside mirrors to the driving position before you
start driving
Driving with the outside mirrors folded in is dangerous. Your rear view will
be restricted, and you could have an accident.
Rearview Mirror

YARIS iA_OM_OM99Q46z_(U)
1152-5. Mirrors
2
Before Driving
■Reducing glare from headlights
Adjust the mirror with the day/night lever in the day position.
Push the day/night lever for-
ward for day driving. Pull it back
to reduce glare of headlights
from vehicles at the rear. Day
Night
Day/Night lever
1
2
WARNING
■Do not stack cargo or object s higher than the seatbacks
Cargo stacked higher than the seatbacks is dangerous. It can block your
view in the rearview mirror, which might cause you to hit another car when
changing lanes.
■ Caution while driving
Do not adjust the position of the mirror while driving.
Doing so may lead to mishandling of the vehicle and cause an accident,
resulting in death or serious injury.

116
YARIS iA_OM_OM99Q46z_(U)
2-6. Windows
Power Windows
The windows can be opened/closed by operating the power window
switches.
When driving with only one of the rear windows open, your ears might experi-
ence a resonating sound. However, this does not indicate a problem. The
sound can be reduced by slightly opening a front window or by changing the
size of the rear window opening.
WARNING
■ Make sure the opening is clear before closing a window
Closing a power window is dangerous . A person’s hands, head, or even
neck could be caught by the window and result in serious injury or even
death. This warning applies especially to children.
■ Never allow children to play with power window switches
Power window switches that are not locked with the power window lock
switch would allow children to operate power windows unintentionally,
which could result in serious injury if a child’s hands, head or neck becomes
caught by the window.
■ Make sure nothing blocks the window just before it reaches the fully
closed position or while holding up the power window switch
Blocking the power window just before it reaches the fully closed position or
while holding up the power window switch is dangerous.
In this case, the jam-safe function cannot prevent the window from closing
all the way. If fingers are caught, serious injuries could occur.

YARIS iA_OM_OM99Q46z_(U)
1172-6. Windows
2
Before Driving
The window opens while the switch is pressed and it closes while the
switch is pulled up with the ignition switched ON. Do not open or close
three or more windows at the same time.
The front passenger’s side and rear windows can be opened/closed
when the power window lock switch on the driver’s door is in the
unlock position. Keep this switch in the locked position while children
are in the vehicle.
■ Opening/Closing windows
●A power window may no longer open/close if you continue to press the
switch after fully opening/closing the power window. If the power window
does not open/close, wait a moment and then operate the switch again.
● The passenger windows may be opened or closed using the master control
switches on the driver’s door.
● The power window can be operated for about 40 seconds after the ignition
is switched from ON to ACC or off with all doors closed. If any door is
opened, the power window will stop operating.
For engine-off operation of the power window, the switch must be held up
firmly throughout window closure because the auto-closing function will be
inoperable.
Opening/Closing Windows
Driver’s
window Close
Open
Driver’s side Right rear window Locked position
Unlocked position
Front
passenger’s
window
Left rear
window
Open
Close
Front passenger’s side
window/Rear windows

118
YARIS iA_OM_OM99Q46z_(U)
2-6. Windows
To fully open the window automatically, press the switch completely
down, then release. The window will fully open automatically.
To fully close the window automatically , pull the switch completely up,
then release. The window will fully close automatically.
To stop the window partway, pull or press the switch in the opposite
direction and then release it.
This function is only equipped on the driver’s side.
Power window system initialization procedure
If the battery was disconnected during vehicle maintenance, or for other rea-
sons (such as a switch continues to be operated after the window is fully
open/closed), the window will not fully open and close automatically.
The power window auto function will only resume on a power window that has
been reset.
Switch the ignition ON.
Make sure that the power window lock switch located on the driver’s door
is not depressed.
Press the switch and fully open the window.
Pull up the switch to fully close the window and continue holding the
switch for about 2 seconds after the window fully closed.
Make sure that the power windows operate correctly using the door
switches.
If foreign matter is detected between the window and the window
frame while the window is closing automatically, the window stops
closing and automatically opens partway.
■Jam-safe window
●The jam-safe function may operate under the following conditions
• A strong impact is detected while the window is closing automatically.
• Window is closing automatically in very low temperatures.
● In the event the jam-safe function activates and the power window cannot
be closed automatically, pull and hold the switch and the window will close.
● The jam-safe window function does not operate until the system has been
reset.
Auto-opening/closing
Jam-safe window
1
2
3
4
5

119
YARIS iA_OM_OM99Q46z_(U)
2-7. Security System
2
Before Driving
Modification and Add-On Equipment
Toyota cannot guarantee the immo bilizer and the theft deterrent
systems’ operation if the system has been modified or if any
add-on equipment has been installed.
NOTICE
To avoid damage to the vehicle, do not modify the system or install any add-
on equipment to the immobilizer and the theft deterrent systems or the vehi-
cle.

120
YARIS iA_OM_OM99Q46z_(U)
2-7. Security System
Immobilizer System
If someone attempts to start the engine with an unrecognized key, the
engine will not start, thereby helping to prevent vehicle theft.
If you have a problem with the immobilizer system or the key, consult
your Toyota dealer.
● The keys carry a unique electronic code. For this reason, and to assure your
safety, obtaining a replacement key requires some waiting time. They are
only available through your Toyota dealer.
● Always keep a spare key in case one is lost. If a key is lost, consult your
Toyota dealer as soon as possible.
● If you lose a key, your Toyota dealer will reset the electronic codes of your
remaining keys and immobilizer system. Bring all the remaining keys to your
Toyota dealer to reset.
Starting the vehicle with a key that has not been reset is not possible.
The immobilizer system allows th e engine to start only with a
key the system recognizes.
NOTICE
● Radio equipment like this is governed by laws in the United States.
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
● To avoid damage to the key, do not:
• Drop the key.
• Get the key wet.
• Expose the key to any kind of magnetic field.
• Expose the key to high temperatures on places such as the dashboard
or hood, under direct sunlight.
● If the engine does not start with the correct key, and the security indicator
light keeps illuminating or flashing, the system may have a malfunction.
Consult your Toyota dealer.
