VAUXHALL ASTRA K 2020 Owner's Manual

Technical data279Engine identifier codeF15DVCF15DVHSales designation1.51.5Piston displacement [cm3
]14961496Engine power [kW]7790at rpm32503500Torque [Nm]260300 2)
/ 285 3)at rpm1500-25001750-2500 2)
/
1500-2750 3)Fuel typeDieselDiesel2)
MT
3) AT
Performance
5-door Hatchback
EngineF12SHLF12SHRF12SHTF14SHTB14XFTB16SHTMaximum speed [mph]Manual transmission124134130134130146Automatic transmission–––130––

280Technical dataEngineF15DVCF15DVHMaximum speed [mph]Manual transmission124130Automatic transmission–127
Sports Tourer
EngineF12SHLF12SHRF12SHTF14SHTMaximum speed [mph]Manual transmission124134130134Automatic transmission–––130EngineF15DVCF15DVHMaximum speed [mph]Manual transmission124130Automatic transmission–127

Technical data281Vehicle dimensions5-door hatchbackSports TourerLength min.-max. [mm]43704702Width with folded exterior mirrors [mm]18091809Width with unfolded exterior mirrors [mm]20422042Height (without antenna) [mm]1437-15311452-1580Vehicle height - Rear compartment open [mm]20162060Length of load compartment floor [mm]8281065Length of load compartment with folded rear seats [mm]15751872Load compartment width [mm]10011028Load compartment height [mm]600747Wheelbase [mm]26622662Turning circle diameter [m]11.4411.44

282Technical dataCapacities
Engine oilEngineF12SHL,
F12SHR,
F12SHT,
F14SHT,
B14XFTB16SHTDiesel enginesincluding filter [l]4.05.55.0between MIN and MAX [l]1.01.01.0
Fuel tank
Petrol/diesel, refilling quantity [l]48Petrol, refilling quantity [l]14
AdBlue tank
5-door hatchbackSports TourerAdBlue, refilling quantity [l]12.513.5

Technical data283Tyre pressuresComfort with up to
3 peopleECO with up to 3 peopleWith full loadEngineTyresfrontrearfrontrearfrontrear[kPa/bar][kPa/bar][kPa/bar][kPa/bar][kPa/bar][kPa/bar]F12SHL,
F12SHR,
F12SHT,
F14SHT,
F15DVC,
F15DVH195/65 R15,230/2.3210/2.1250/2.5250/2.5280/2.8290/2.9205/55 R16
225/45 R17
225/40 R18230/2.3210/2.1250/2.5230/2.3280/2.8290/2.9B14XFT195/65 R15,
225/45 R17,
215/55 R16,
215/50 R17,
225/40 R18220/2.2 (32)220/2.2 (32)270/2.7 (39)270/2.7 (39)250/2.5
(36)270/2.7
(39)205/55 R16220/2.2 (32)220/2.2 (32)300/3.0 (43)300/3.0 (43)250/2.5
(36)270/2.7
(39)

284Technical dataComfort with up to
3 peopleECO with up to 3 peopleWith full loadEngineTyresfrontrearfrontrearfrontrear[kPa/bar][kPa/bar][kPa/bar][kPa/bar][kPa/bar][kPa/bar]B16SHT225/45 R17240/2.4 (35)220/2.2 (32)270/2.7 (39)270/2.7 (39)250/2.5
(36)270/2.7
(39)225/40 R18260/2.6 (38)240/2.4 (35)270/2.7 (39)270/2.7 (39)270/2.7
(39)290/2.9
(42)205/55 R16240/2.4 (35)220/2.2 (32)300/3.0 (43)300/3.0 (43)250/2.5
(36)270/2.7
(39)AllTemporary spare
wheel
115/70 R16420/4.2420/4.2––420/4.2420/4.2

Customer information285Customer
informationCustomer information ................285
Declaration of conformity .........285
REACH .................................... 289
Software acknowledgement ....289
Software update ......................291
Registered trademarks ............292
Vehicle data recording and pri‐ vacy ........................................... 292
Event data recorders ...............292
Radio Frequency Identification (RFID) ..................................... 295Customer information
Declaration of conformity
Radio transmission systems
This vehicle has systems that
transmit and / or receive radio waves
subject to Directive 2014/53/EU. The
manufacturers of the systems listed
below declare conformity with
Directive 2014/53/EU. The full text of
the EU declaration of conformity for each system is available at the
following internet address:
www.opel.com/conformity.
Importer is
Opel / Vauxhall, Bahnhofsplatz,
65423 Ruesselsheim am Main,
Germany.
Antenna
Laird
8100 Industrial Park Drive, Grand
Blanc, MI, 48439, USA
Operation frequency: N/A
Maximum output: N/AAntenna
Kathrein Automotive North America,
Inc.
3967 W. Hamlin Rd., Rochester Hills, MI 48309, USA
Operation frequency: N/A
Maximum output: N/A
Electronic key
Denso Coperation
Waldeckerstraße 11, 64546
Mörfelden-Walldorf, Germany
Operation frequency: 433,92 MHz
Maximum output: -5,88 dBm
Electronic key module
Denso Coperation
Waldeckerstraße 11, 64546
Mörfelden-Walldorf, Germany
Operation frequency: 125 kHz
Maximum output: -0,14 dBm
Front radar unit
Continental Automotive GmbH
ADC Automotive Distance Control
Systems GmbH, Peter-Dornier-
Straße 10, 88131 Lindau, Germany

286Customer informationOperation frequency: 76-77 GHz
Maximum output: 30 EIRP dBm
Immobiliser
Bosch
Robert Bosch GmbH, Robert Bosch
Platz 1, 70839 Gerlingen, Germany
Operation frequency: 125 kHz
Maximum output:
5.1 dBµA/m @ 10 m
Infotainment system Multimedia
LG Electronics
European Shared Service Center B.V., Krijgsman 1, 1186 DM
Amstelveen, The NetherlandsOperation
frequency (MHz)Maximum output
(dBm)2400.0 - 2483.582400.0 - 2483.5165725.0 - 5875.09
Infotainment system Multimedia Navi
LG
Electronics European Shared Service
Center B.V., Krijgsman 1, 1186 DM
Amstelveen, The NetherlandsOperation
frequency (MHz)Maximum output
(dBm)2402.0 - 2480.042400.0 - 2483.5135725.0 - 5850.013
Infotainment system
Multimedia Navi Pro
Harman International Industries
Becker-Goering-Str. 16, 76307
Karlsbad, Germany
Operation
frequency (MHz)Maximum output
(dBm)2400.0 - 2483.592400.0 - 2483.5195725.0 - 5875.013.9
Parking heater remote conrtol
receiver
Webasto Thermo & Comfort SE
Friedrichshafener Straße 9, 82205
Gilching, Germany
Operation frequency: N/A
Maximum output: N/A
Parking heater remote conrtol
transmitter
Webasto Thermo & Comfort SE
Friedrichshafener Straße 9, 82205 Gilching, Germany
Operation frequency: 869,0 MHz
Maximum output: 14 dBm
Radio remote control receiver
Robert Bosch GmbH
Robert Bosch Platz 1, 70839
Gerlingen, Germany
Operation frequency: 433.92 MHz
Maximum output: N/A
Radio remote control transmitter
Robert Bosch GmbH
Robert Bosch Platz 1, 70839
Gerlingen, Germany
Operation frequency: 433.92 MHz
Maximum output: -9 dbm

Customer information287Tyre pressure sensors
Huf Hülsbeck & Fürst GmbH & Co. KG
Gewerbestraße 40, 75015 Bretten-
Gölshausen, Germany
Operation frequency: 433.92 MHz
Maximum output: 83 dBuV/m

288Customer informationJack
