218Vehicle care
4. Switch on electrical consumers(e.g. headlights, heated rear
window) of the vehicle receiving
the jump start.
5. Reverse above sequence exactly when removing leads.Towing
Towing the vehicle
Insert a screwdriver in the slot at the
lower part of the cap. Release the cap
by carefully moving the screwdriver
downwards.
The towing eye is stowed with the
vehicle tools 3 201.
Screw in the towing eye anticlockwise
as far as it will go until it stops in a
horizontal position.
Attach a tow rope – or better still a tow rod – to the towing eye.
The towing eye must only be used for
towing and not for recovering the
vehicle.
Switch on ignition to release steering
wheel lock and to permit operation of
brake lights, horn and windscreen
wiper.
Transmission in neutral.

Vehicle care221Caution
After washing or cleaning, the softtop must be completely dried
before opening. If a wet soft top
remains opened for a longer time,
it would be damaged by water
spotting and mould growth.
When cleaning with a high-pressure
jet cleaner ensure a minimum
distance of 30 cm to the rear brand
emblem to prevent unintended
unlocking.
Thoroughly rinse and leather-off the
vehicle. Rinse leather frequently. Use
separate leathers for painted and
glass surfaces: remnants of wax on the windows will impair vision.
Have the door hinges of all doors
greased by a workshop.
Exterior lights
Headlight and other light covers are
made of plastic. Do not use any
abrasive or caustic agents, do not use
an ice scraper, and do not clean them dry.
Polishing and waxing
Wax painted parts of the vehicle
regularly (at the latest when water no longer beads). Otherwise, the
paintwork will dry out.
Polishing is necessary only if the paint
has become dull or if solid deposits
have become attached to it.
Paintwork polish with silicone forms a
protective film, making waxing
unnecessary.
Soft top as well as plastic body parts
must not be treated with wax or
polishing agents.
Windows and windscreen wiper blades
Use a soft lint-free cloth or chamois
leather together with window cleaner
and insect remover.
When cleaning the rear window from
inside, always wipe in parallel to the
heating element to prevent damage.For mechanical removal of ice, use a
sharp-edged ice scraper. Press the
scraper firmly against the glass so
that no dirt can get under it and
scratch the glass.
Clean smearing wiper blades with a
soft cloth and window cleaner.
Wheels and tyres
Do not use high-pressure jet
cleaners.
Clean rims with a pH-neutral wheel
cleaner.
Rims are painted and can be treated
with the same agents as the body.
Paintwork damage Rectify minor paintwork damage with
a touch-up pen before rust forms.
Have more extensive damage or rust
areas repaired by a workshop.
UnderbodySome areas of the vehicle underbody
have a PVC undercoating while other
critical areas have a durable
protective wax coating.

222Vehicle care
After the underbody is washed, checkthe underbody and have it waxed if
necessary.
Bitumen/rubber materials could
damage the PVC coating. Have
underbody work carried out by a
workshop.
Before and after winter, wash the
underbody and have the protective
wax coating checked.
Towing equipment Do not clean the coupling ball bar with
a steam-jet or high-pressure jet
cleaner.
Interior care Interior and upholsteryOnly clean the vehicle interior,
including the instrument panel fascia
and panelling, with a dry cloth or
interior cleaner.
Clean the leather upholstery with
clear water and a soft cloth. In case of
heavy soiling, use leather care.The instrument cluster and the
displays should only be cleaned using
a soft damp cloth. If necessary use a
weak soap solution.
Clean fabric upholstery with a
vacuum cleaner and brush. Remove
stains with an upholstery cleaner.
Clothing fabrics may not be
colourfast. This could cause visible
discolourations, especially on light-
coloured upholstery. Removable
stains and discolourations should be
cleaned as soon as possible.
Clean seat belts with lukewarm water or interior cleaner.Caution
Close Velcro fasteners as open
Velcro fasteners on clothing could damage seat upholstery.
The same applies to clothing with
sharp-edged objects, like zips or
belts or studded jeans.
Plastic and rubber parts
Plastic and rubber parts can be
cleaned with the same cleaner as
used to clean the body. Use interior cleaner if necessary. Do not use any
other agent. Avoid solvents and petrol in particular. Do not use high-
pressure jet cleaners.

240IndexAAccessories and vehicle modifications .......................... 180
Active head restraints ...................45
Adaptive forward lighting ..........
.................................. 93, 114, 190
Adjustable air vents ...................131
Airbag, belt tensioners and anti- roll bars ..................................... 88
Airbag deactivation ................61, 88
Airbag system .............................. 56
Air conditioning regular operation ................................ 132
Air conditioning system .............. 124
Air intake .................................... 131
Air vents...................................... 131
Antilock brake system ................ 144
Antilock brake system (ABS) .......90
Anti-theft alarm system ................25
Anti-theft locking system .............. 25
Appearance care ........................220
Armrest ......................................... 52
Armrest storage ........................... 70
Ashtrays ....................................... 83 Automatic anti-dazzle ..................29
Automatic light control ...............111
Automatic locking ........................22
Automatic transmission .............141
Auxiliary heater ........................... 130B
Battery discharge protection ......122
Battery voltage ........................... 102 Bonnet ....................................... 182
Brake and clutch fluid .................224
Brake and clutch system .............89
Brake assist ............................... 147
Brake fluid .................................. 185
Brakes ............................... 144, 185
Breakdown.................................. 218
Bulb replacement ....................... 188
C
Capacities .................................. 235
Car Pass ...................................... 18
Catalytic converter .....................140
Central locking system ................20
Centre console storage ...............70
Changing tyre and wheel size ...207
Charging system .......................... 89
Child restraint installation locations ................................... 64
Child restraints.............................. 62
Child restraint systems ................62
Cigarette lighter ........................... 83
Climate control ............................. 14
Climate control systems .............123
Clock............................................. 80
Code ........................................... 100

241
Control indicators.......................... 86
Control of the vehicle .................133
Controls ........................................ 76
Convex shape .............................. 28
Coolant and antifreeze ...............224
Cruise control ...................... 93, 151
Cupholders .................................. 69
Curve lighting.............................. 114
D
Danger, Warnings and Cautions ...3
Daytime running lights ...............114
Declaration of conformity ............238
Diesel fuel system bleeding .......187
Diesel particle filter ...............91, 139
Door open .................................... 93
Doors ............................................ 23
Driver assistance systems ..........151
Driver Information Centre .............94
Driving characteristics and towing tips .............................. 174
Driving hints ................................ 133
E Electric adjustment ......................28
Electrical system......................... 196
Electric parking brake ...................90
Electric parking brake fault ...........90
Electronic climate control system 126
Electronic driving programmes ..142Electronic Stability Control.......... 148
Electronic Stability Control and Traction Control system ............91
Electronic Stability Control off....... 91
End-of-life vehicle recovery .......181
Engine compartment fuse box ...197
Engine coolant ........................... 184
Engine coolant temperature gauge ....................................... 85
Engine data ............................... 231
Engine exhaust .......................... 139
Engine identification ...................227
Engine oil ................... 182, 224, 228
Engine oil pressure ......................92
Entry lighting .............................. 121
Event data recorders ..................238
Exit lighting ................................ 121
Exterior care .............................. 220
Exterior light ................................. 93
Exterior lighting ....................12, 110
Exterior mirrors ............................. 28
F
Fault ........................................... 143
First aid ......................................... 74
First aid kit ................................... 74
Fixed air vents ........................... 131
Fog light ....................................... 93
Fog lights ................................... 191
Folding mirrors ............................. 28Following distance indication ......156
Forward collision alert................. 154
Front airbag system .....................60
Front fog lights ........................... 118
Front seats.................................... 46
Front storage ................................ 69
Front turn signal lights ...............191
Fuel............................................. 171
Fuel consumption - CO 2-
Emissions ............................... 173
Fuel for diesel engines ..............172
Fuel for petrol engines ...............171
Fuel gauge ................................... 85
Fuses ......................................... 196
G Gauges ......................................... 83
General information ...................174
Glovebox ..................................... 68
Graphic-Info-Display, Colour- Info-Display .............................. 98
Ground clearance .......................134
H
Halogen headlights ....................188
Hand brake ......................... 144, 145
Hazard warning flashers ............117
Headlight flash ........................... 112
Headlight range adjustment ......113
Headlights................................... 110

242
Headlights when driving abroad 113
Head restraint adjustment .............8
Head restraints ............................ 44
Heated mirrors ............................. 29
Heated rear window ..................... 32
Heated steering wheel .................77
Heating ........................................ 53
Heating and ventilation system . 123
High beam ........................... 93, 111
High beam assist ..................93, 112
Hill start assist ........................... 147
Horn ....................................... 13, 77
I
Identification plate .....................226
Ignition switch positions .............134
Immobiliser ............................ 27, 93
Indicators ...................................... 83
Information displays...................... 94
Instrument cluster ........................83
Instrument panel fuse box .........199
Instrument panel illumination .....195
Instrument panel illumination control .................................... 119
Instrument panel overview ........... 10
Interactive driving system ...........149
Interior care ............................... 222
Interior lighting ............................ 119
Interior lights ...................... 119, 195
Interior mirrors .............................. 29Interruption of power supply ......143
Introduction .................................... 3
ISOFIX child restraint systems ....67
J Jump starting ............................. 216
K Key, memorised settings ..............20
Keys ............................................. 18
Keys, locks ................................... 18
L Lane departure warning .......91, 170
Lashing eyes ............................... 74
Light switch ................................ 110
Load compartment ................23, 71
Load compartment fuse box ......200
Loading information .....................75
Low fuel ....................................... 92
M Malfunction indicator light ............89
Manual anti-dazzle ......................29
Manual mode ............................. 142
Manual transmission .................. 144
Memorised settings ......................20
Mirror adjustment ........................... 9
Misted light covers .....................119N
New vehicle running-in ..............134
Number plate light .....................195
O Object detection systems ...........156
Odometer ..................................... 84
Oil, engine .......................... 224, 228
Outside temperature ....................80
Overrun cut-off ........................... 136
P Parking ................................ 17, 138
Parking assist ............................ 156
Parking brake ............................ 145
Parking lights ............................. 118
Particulate filter ........................... 139
Performance .............................. 232
Performing work ........................181
Pollen filter ................................. 131
Power outlets ............................... 82
Power seat adjustment ................50
Power steering.............................. 91
Power windows ............................ 30
Preheating ................................... 91
Puncture ..................................... 211
Q
Quickheat ................................... 130

243
RRadio Frequency Identification (RFID) ..................................... 239
Radio remote control ...................19
Reading lights ............................ 120
Rear floor storage cover ..............73
Rear fog light ............................... 93
Rear fog lights ........................... 118
Rear storage ................................. 73
Rear view camera ...................... 165
Recommended fluids and lubricants ........................ 224, 228
Refuelling ................................... 172 Retained power off .....................134
Reversing lights .........................119
Ride control systems ..................147
Rollover protection system ...........42
S Seat adjustment ....................... 7, 47
Seat belt ........................................ 8
Seat belt reminder .......................88
Seat belts ..................................... 53
Seat folding .................................. 49
Seat position ................................ 46
Selector lever ............................. 141
Service ............................... 132, 223
Service display ............................ 85
Service information ....................223Side airbag system ......................60
Side blind spot alert ....................164
Sidelights .................................... 110
Side turn signal lights ................194
Soft top ........................................ 33
Spare wheel ............................... 213
Speed limiter............................... 153
Speedometer ............................... 83
Starting and operating ................134
Starting off ................................... 16
Starting the engine ....................135
Steering ...................................... 133
Steering wheel adjustment ......9, 76
Steering wheel controls ...............76
Stop-start system........................ 136
Storage ......................................... 68
Storage compartments .................68
Sunvisor lights ........................... 120
Sun visors .................................... 32
Symbols ......................................... 4
T
Tachometer ................................. 84
Tail lights ................................... 192
Three-point seat belt .................... 55 Tools .......................................... 201
Top-tether fastening eyes ............67
Tow bar....................................... 174 Towing ................................ 174, 218
Towing another vehicle .............219Towing equipment .....................175
Towing the vehicle .....................218
Traction Control system ............. 147
Traction Control system off........... 91
Traffic sign assistant ...................167
Trailer coupling ........................... 174
Trailer towing ............................. 175
Transmission ............................... 15
Transmission display .................141
Tread depth ............................... 206
Trip odometer .............................. 84
Turn and lane-change signals ...117
Turn signal ................................... 88
Tyre chains ................................ 207
Tyre designations ......................203
Tyre pressure ............................ 203
Tyre pressure monitoring system ............................... 92, 204
Tyre pressures ........................... 236
Tyre repair kit ............................. 208
U Ultrasonic parking assist............. 156
Upholstery .................................. 222
Upshift .......................................... 91
Using this manual ..........................3
V Vehicle battery ........................... 185
Vehicle checks............................ 181

244
Vehicle data................................ 228
Vehicle data recording and privacy ..................................... 238
Vehicle detected ahead ................93
Vehicle dimensions .................... 234
Vehicle Identification Number ....226
Vehicle jack ................................ 201
Vehicle messages .....................100
Vehicle personalisation .............102
Vehicle security ............................ 25
Vehicle specific data ......................3
Vehicle storage ........................... 180
Vehicle tools ............................... 201
Vehicle unlocking ........................... 6
Vehicle weight ........................... 233
Ventilating ..................................... 53
Ventilation ................................... 123
W Warning chimes .........................101
Warning lights ............................... 83
Warning triangle .......................... 74
Washer and wiper systems .........14
Washer fluid ............................... 184
Wheel changing .........................211
Wheel covers ............................. 207
Wheels and tyres .......................202
Wind deflector............................... 40
Windows ....................................... 30
Windscreen................................... 30Windscreen wiper/washer ...........78
Winter tyres ............................... 202
Wiper blade replacement ..........187
