child lock VAUXHALL CASCADA 2014 Owner's Manual

50Seats, restraints
To restore, lift backrest to upright
position and engage. The seat slides
automatically backwards to the
original position.
In case the head restraint of the
folded backrest is blocked by the
upper windscreen frame, allow the
seat to move backwards or
downwards slightly 3 50, or set
head restraint to lowest position
3 44.
Safety function
If the power seat encounters
resistance while sliding forwards or
rearwards, it is immediately stopped
and moved in the opposite direction.
Notice
Do not sit on the seat while seat is
moving.
Power disconnection
If seat remains in forward position
with opened door for more than
10 minutes, power adjustment is
disconnected. In this event, close and open the door or switch on ignition
and operate power adjustment again.Overload
If the folding function is electrically
overloaded, the power supply is
automatically cut-off for a short time.
Power seat adjustment9 Warning
Care must be taken when
operating the power seats. There
is a risk of injury, particularly for
children. Objects could become
trapped.
Keep a close watch on the seats
when adjusting them. Vehicle
passengers should be informed
accordingly.
Seat lengthwise adjustment
Move switch forwards/backwards.

72Storage9Warning
Take care when operating the
electric foldable rear seats. The seat backrest is folded with
considerable power. Risk of injury, particularly to children.
Ensure that nothing is attached to
the rear seats or located on the
seat cushion.
■ Remove big wind deflector if installed, 3 40.
■ Press the catches and push down the head restraints 3 44.
■ Pull the release switch p on one or
both sides of the load
compartment, to fold down the
backrests onto the seat cushion.
■ To fold up, raise the backrest and guide it into an upright position until
it engages audibly.9 Warning
When folding up, ensure that
backrests are securely locked in
position before driving. Failure to
do so may result in personal injury or damage to the load or vehicle in the event of hard braking or a
collision.
Pass-through flap behind rear seats
For transporting long objects in the
load compartment, a pass-through
flap between load compartment and
vehicle interior can be opened:
■ Remove the installed big wind deflector or the bag with the stowed
wind deflectors behind the rear seats 3 40.
■ Close soft top 3 33.
■ Push the load compartment partition at the loop area upwards
to the inside 3 71.

240IndexAAccessories and vehicle modifications .......................... 180
Active head restraints ...................45
Adaptive forward lighting ..........
.................................. 93, 114, 190
Adjustable air vents ...................131
Airbag, belt tensioners and anti- roll bars ..................................... 88
Airbag deactivation ................61, 88
Airbag system .............................. 56
Air conditioning regular operation ................................ 132
Air conditioning system .............. 124
Air intake .................................... 131
Air vents...................................... 131
Antilock brake system ................ 144
Antilock brake system (ABS) .......90
Anti-theft alarm system ................25
Anti-theft locking system .............. 25
Appearance care ........................220
Armrest ......................................... 52
Armrest storage ........................... 70
Ashtrays ....................................... 83 Automatic anti-dazzle ..................29
Automatic light control ...............111
Automatic locking ........................22
Automatic transmission .............141
Auxiliary heater ........................... 130B
Battery discharge protection ......122
Battery voltage ........................... 102 Bonnet ....................................... 182
Brake and clutch fluid .................224
Brake and clutch system .............89
Brake assist ............................... 147
Brake fluid .................................. 185
Brakes ............................... 144, 185
Breakdown.................................. 218
Bulb replacement ....................... 188
C
Capacities .................................. 235
Car Pass ...................................... 18
Catalytic converter .....................140
Central locking system ................20
Centre console storage ...............70
Changing tyre and wheel size ...207
Charging system .......................... 89
Child restraint installation locations ................................... 64
Child restraints.............................. 62
Child restraint systems ................62
Cigarette lighter ........................... 83
Climate control ............................. 14
Climate control systems .............123
Clock............................................. 80
Code ........................................... 100

242
Headlights when driving abroad 113
Head restraint adjustment .............8
Head restraints ............................ 44
Heated mirrors ............................. 29
Heated rear window ..................... 32
Heated steering wheel .................77
Heating ........................................ 53
Heating and ventilation system . 123
High beam ........................... 93, 111
High beam assist ..................93, 112
Hill start assist ........................... 147
Horn ....................................... 13, 77
I
Identification plate .....................226
Ignition switch positions .............134
Immobiliser ............................ 27, 93
Indicators ...................................... 83
Information displays...................... 94
Instrument cluster ........................83
Instrument panel fuse box .........199
Instrument panel illumination .....195
Instrument panel illumination control .................................... 119
Instrument panel overview ........... 10
Interactive driving system ...........149
Interior care ............................... 222
Interior lighting ............................ 119
Interior lights ...................... 119, 195
Interior mirrors .............................. 29Interruption of power supply ......143
Introduction .................................... 3
ISOFIX child restraint systems ....67
J Jump starting ............................. 216
K Key, memorised settings ..............20
Keys ............................................. 18
Keys, locks ................................... 18
L Lane departure warning .......91, 170
Lashing eyes ............................... 74
Light switch ................................ 110
Load compartment ................23, 71
Load compartment fuse box ......200
Loading information .....................75
Low fuel ....................................... 92
M Malfunction indicator light ............89
Manual anti-dazzle ......................29
Manual mode ............................. 142
Manual transmission .................. 144
Memorised settings ......................20
Mirror adjustment ........................... 9
Misted light covers .....................119N
New vehicle running-in ..............134
Number plate light .....................195
O Object detection systems ...........156
Odometer ..................................... 84
Oil, engine .......................... 224, 228
Outside temperature ....................80
Overrun cut-off ........................... 136
P Parking ................................ 17, 138
Parking assist ............................ 156
Parking brake ............................ 145
Parking lights ............................. 118
Particulate filter ........................... 139
Performance .............................. 232
Performing work ........................181
Pollen filter ................................. 131
Power outlets ............................... 82
Power seat adjustment ................50
Power steering.............................. 91
Power windows ............................ 30
Preheating ................................... 91
Puncture ..................................... 211
Q
Quickheat ................................... 130
