VAUXHALL COMBO D 2017 Owner's Guide

Keys, doors and windows29Exterior mirrors
Convex shape
The convex exterior mirror contains
an aspherical area and reduces blind spots. The shape of the mirror makes objects appear smaller, which will
affect the ability to estimate
distances.
Manual adjustment
Adjust mirrors by swivelling lever in
required direction.
The lower mirrors are not adjustable.
Electric adjustment
Select the relevant exterior mirror by
turning the control to left _ or right 6.
Then swivel the control to adjust the
mirror.
In position o no mirror is selected.
Folding mirrors
For pedestrian safety, the exterior
mirrors will swing out of their normal
mounting position if they are struck
with sufficient force. Reposition the mirror by applying slight pressure tothe mirror housing.
Parking position
The exterior mirrors can be folded in
by pressing gently on the outer edge
of the housing, e.g. when in a
confined parking situation.

30Keys, doors and windowsHeated mirrors
Operated by pressing Ü.
Heating works with the engine
running and is switched off
automatically after a short time.
Interior mirrors
Manual anti-dazzle
To reduce dazzle, adjust the lever on the underside of the mirror housing.
Windows
Windscreen
Windscreen stickers Do not attach stickers such as toll
road stickers or similar on the
windscreen in the area of the interior
mirror.
Manual windows
The door windows can be opened or
closed with the window winders.
Power windows9 Warning
Take care when operating the
power windows. Risk of injury,
particularly to children.
If there are children on the rear seats, switch on the child safety
system for the power windows.

Keys, doors and windows31Keep a close watch on the
windows when closing them.
Ensure that nothing becomes
trapped in them as they move.
Switch on ignition to operate power windows.
Operate the switch for the respective
window by pushing to open or pulling to close.
Pushing or pulling briefly: window
moves up or down in stages if the
switch is held.
Pushing or pulling firmly and then
releasing: window moves up or down fully with safety function enabled. To
stop movement, operate the switch
once more in the same direction.
With the ignition key removed or in
position 0, the windows can be
operated for approx. 2 minutes and are deactivated as soon as a door is
opened.
Safety function
If the window glass encounters
resistance during automatic closing, it is immediately stopped and openedagain.
If the safety function is activated five times in less than a minute, the
safety function is deactivated. The
windows will only close in stages and not automatically.
Activate the window electronics by
opening the windows. The safety
function is restored and the windows
will operate normally.Overload
If the windows are repeatedly
operated within short intervals, the
window operation is disabled for
some time.
Initialising the power windows
If the windows cannot be closed
automatically (e.g. after
disconnecting the vehicle battery),
activate the window electronics as
follows:
1. Close doors.
2. Switch on ignition.
3. Pull switch until the window is closed and keep pulling for an
additional five seconds.
4. Repeat for each window.

32Keys, doors and windowsChild safety system for rear
windows
Press , to deactivate rear door
power windows.
To activate, press , again.
Operating windows from outside
The windows can be operated
remotely from outside the vehicle
when locking or unlocking the vehicle.
Central locking system 3 23.
Press and hold Ä to open windows.
Press and hold e to close windows.
Release button to stop window
movement.
Rear windows
Opening rear windows
To open, move lever outwards until
the window is fully open.
To close, pull lever then push until
window is fully closed.

Keys, doors and windows33Heated rear window
Operated by pressing Ü.
Heating works with the engine
running and is switched off
automatically after a short time.
Sun visors The sun visors can be folded down or
swivelled to the side to prevent
dazzling.
If the sun visors have integral mirrors, the mirror covers should be closed
when driving.
A ticket holder is located on the rear
of the sun visor.

34Seats, restraintsSeats, restraintsHead restraints............................ 34
Front seats ................................... 35
Seat position .............................. 35
Seat adjustment ........................36
Seat folding ............................... 37
Armrest ...................................... 38
Heating ...................................... 39
Rear seats ................................... 39
Second row seats ......................39
Third row seats .......................... 41
Seat belts ..................................... 43
Three-point seat belt .................44
Airbag system .............................. 46
Front airbag system ...................50
Side airbag system ....................51
Airbag deactivation ....................51
Child restraints ............................. 53
Child restraint systems ..............53
Child restraint installation locations ................................... 54
ISOFIX child restraint systems ..57
Top-tether fastening eyes ..........57Head restraints
Position9 Warning
Only drive with the head restraint
set to the proper position.
The upper edge of the head restraint
should be at upper head level. If this
is not possible for extremely tall
people, set to highest position, and
set to lowest position for small people.
Adjustment
Front head restraints, height
adjustment
Press the release button, adjust
height and engage.

Seats, restraints35Rear head restraints, height
adjustment
Pull the head restraint upwards or
press the release buttons and push
the head restraint downwards.
Removal
Rear head restraints, removal
Press both release buttons, pull the
head restraint upwards and remove.
Secure the removed head restraint in the load compartment.
Notice
Approved accessories may only be
attached if the seat is not in use.
Front seats
Seat position9 Warning
Only drive with the seat correctly
adjusted.
9 Danger
Do not sit nearer than 25 cm from
the steering wheel, to permit safe
airbag deployment.
9 Warning
Never adjust seats while driving as
they could move uncontrollably.
9 Warning
Never store any objects under the
seats except in the underseat
storage compartment 3 60.
● Sit with buttocks as far back
against the backrest as possible.
Adjust the distance between the
seat and the pedals so that legs
are slightly angled when pressing the pedals. Slide the front
passenger seat as far back as
possible.
● Set the seat height high enough to have a clear field of vision on
all sides and on all display
instruments. There should be at
least one hand of clearance
between head and the roof
frame. Your thighs should rest
lightly on the seat without
pressing into it.

36Seats, restraints● Sit with shoulders as far backagainst the backrest as possible.
Set the backrest rake so that it is possible to reach the steering
wheel with arms slightly bent.
Maintain contact between
shoulders and the backrest when turning the steering wheel. Do
not angle the backrest too far
back. We recommend a
maximum rake of approx. 25°.
● Adjust seat and steering wheel in
a way that the wrist rests on top
of the steering wheel while the
arm is fully extended and
shoulders on the backrest.
● Adjust the steering wheel 3 68.
● Adjust the head restraint 3 34.
● Adjust the height of the seat belt 3 44.
● Adjust the lumbar support so that
it supports the natural shape of
the spine.
Seat adjustment
Drive only with seats and backrests properly engaged.Seat positioning
Pull handle, slide seat, release
handle.
Try to move the seat back and forth to ensure that the seat is locked in place.
Seat backrests
Turn handwheel. Do not lean on
backrest when adjusting.

Seats, restraints37Seat height
Lever pumping motion
up:higherdown:lower
Operate lever and adjust body weight
on seat to raise or lower it.
Lumbar support
Adjust lumbar support using
handwheel to suit personal
requirements.
Rotate handwheel to increase and
decrease support.
Seat folding Folding front passenger seatDepending on version, the front
passenger seat can be folded flat to
the table position.
Slide the front passenger seat as far
back as possible, to avoid contact
with the instrument panel during
folding.
Notice
When seat height is in its highest
position, push head restraints down
3 34 before folding backrest.
Ensure that nothing prevents the
seat from folding, e.g. sun visor,
glovebox.
Pull release levers (1), fold backrest
fully forwards then release the levers. Then push the backrest down further
until it is completely flat.

38Seats, restraints
Pull the flap (2) located at the base of
the backrest and simultaneously push
the backrest down as far as possible.
On some versions, there is a single
release lever located on the inboard
side of the front passenger seat. Pull
release lever, fold backrest fully
forwards, release lever then push
backrest down until it is completely
flat. The flap at the base of the
backrest is not present on some
versions.
Notice
Do not operate handwheel for
backrest inclination when backrest is
folded forwards.
9 Warning
When the front passenger seat is
in the folded position, the front
passenger airbag system must be deactivated.
Airbag deactivation 3 51.
9 Warning
Always make sure that the load in
the vehicle is securely stowed.
Otherwise objects can be thrown
around inside the vehicle and
cause personal injury or damage
to the load or vehicle.
Unfolding front passenger seat
To restore the seat to the upright
position, pull the flap located at the
base of the backrest and
simultaneously pull up the backrest
as far as it will go.
Pull release levers and raise backrest
fully then release levers.
Armrest
Raise or lower the front seat armrest
as required.
