engine VAUXHALL CORSA 2014.5 Owner's Manual

Introduction3Vehicle specific data
Please enter your vehicle's data on
the previous page to keep it easily
accessible. This information is
available in the sections "Service and maintenance" and "Technical data"
as well as on the identification plate.
Introduction
Your vehicle is a designed
combination of advanced technology, safety, environmental friendliness
and economy.
This Owner's Manual provides you
with all the necessary information to
enable you to drive your vehicle
safely and efficiently.
Make sure your passengers are
aware of the possible risk of accident
and injury which may result from
improper use of the vehicle.
You must always comply with the
specific laws and regulations of the
country that you are in. These laws
may differ from the information in this Owner's Manual.When this Owner's Manual refers to aworkshop visit, we recommend your
Vauxhall Authorised Repairer. For
gas vehicles, we recommend a
Vauxhall Authorised Repairer
licensed to service gas vehicles.
All Vauxhall Authorised Repairers
provide first-class service at
reasonable prices. Experienced
mechanics trained by Vauxhall work
according to specific Vauxhall
instructions.
The customer literature pack should
always be kept ready to hand in the
vehicle.
Using this manual ■ This manual describes all options and features available for this
model. Certain descriptions,
including those for display and
menu functions, may not apply to
your vehicle due to model variant,
country specifications, special
equipment or accessories.
■ The "In brief" section will give you an initial overview.■ The table of contents at thebeginning of this manual and withineach section shows where the
information is located.
■ The index will enable you to search
for specific information.
■ This Owner's Manual depicts left- hand drive vehicles. Operation is
similar for right-hand drive vehicles.
■ The Owner's Manual uses the factory engine designations. The
corresponding sales designations
can be found in the section
"Technical data".
■ Directional data, e.g. left or right, or
front or back, always relate to the
direction of travel.
■ The vehicle display screens may not support your specific language.
■ In this manual all display messages
and interior labellings are written in bold type.

16In brief
Manual transmission automatedN=neutral positiono=drive position+=higher gear-=lower gearA =switch between automatic and
manual modeR=reverse gear (with selector
lever lock)
Manual transmission automated
3 124.
Automatic transmissionP=park positionR=reverse gearN=neutral positionD=drive position
The selector lever can only be moved
out of P or N when the ignition is on
and the foot brake is depressed
(selector lever lock). To engage P or
R , press the release button on the
selector lever.
The automatic transmission is
available in two versions 3 120.
Starting off
Check before starting off ■ Tyre pressure and condition 3 173,
3 217.
■ Engine oil level and fluid levels 3 148.
■ All windows, mirrors, exterior lighting and number plates are free
from dirt, snow and ice and are
operational.
■ Proper position of mirrors, seats, and seat belts 3 27, 3 35,
3 39.
■ Brake function at low speed, particularly if the brakes are wet.

In brief17
Starting the engine
■ Turn key to position 1
■ move the steering wheel slightly to release the steering wheel lock
■ operate clutch and brake. If the clutch pedal is not operated, the
engine might not start and the
control indicator - may illuminate
■ automatic transmission in P or N
■ do not operate accelerator pedal
■ diesel engines, turn the key to position 2 for preheating and wait
until control indicator !
extinguishes
■ turn key to position 3 and release
Starting the engine 3 115.Stop-start system
If the vehicle is at a low speed or at a
standstill and certain conditions are
fulfilled, activate an Autostop as
follows:
■ Depress the clutch pedal
■ shift the selector lever to neutral
■ release the clutch pedal
An Autostop is indicated by the
needle at the AUTOSTOP position in
the tachometer.
To restart the engine, depress the
clutch pedal again.
Stop-start system 3 116.

18In briefParking■ Always apply the parking brake without pressing the release button.Apply as firmly as possible on a
downhill slope or uphill slope.
Depress the foot brake at the same
time to reduce operating force.
■ Switch off the engine. Turn the ignition key to position 0 and
remove it. Turn the steering wheel
until the steering wheel lock is felt
to engage.
For vehicles with automatic
transmission, the key can only be
removed when the selector lever is in the P position.
■ If the vehicle is on a level surface or
uphill slope, engage first gear or set the selector lever to P before
switching off the ignition. On an uphill slope, turn the front wheels
away from the kerb.
If the vehicle is on a downhill slope, engage reverse gear or set the
selector lever to P before switching
off the ignition. Turn the front
wheels towards the kerb.■ Lock the vehicle with button p on
the radio remote control.
■ Activate the anti-theft alarm system
3 25.
■ Do not park the vehicle on an easily
ignitable surface. The high
temperature of the exhaust system
could ignite the surface.
■ Close windows and sunroof.
■ The engine cooling fans may run after the engine has been switched
off 3 146.
■ After running at high engine speeds
or with high engine loads, operate the engine briefly at a low load or
run in neutral for approx.
30 seconds before switching off, in
order to protect the turbocharger.
Keys, locks 3 19.
Laying the vehicle up for a long period
of time 3 145.

26Keys, doors and windows
Light-emitting diode (LED)
During the first 10 seconds of anti-
theft alarm system activation:
LED illu‐
minates=Test, ignition delay,LED
flashes
quickly=Door, load
compartment or bonnet open, or system fault.
After the first 10 seconds of anti-theft
alarm system activation:
LED flashes
slowly=System active.
Seek the assistance of a workshop in
the event of faults.
Alarm
When triggered, the alarm gives off
an acoustic signal (horn) and a visual signal (hazard warning flashers). The
number and duration of which are
stipulated by legislation.
The alarm siren can be silenced by
pressing any button of the radio
remote control or by switching on the
ignition. The anti-theft alarm system is deactivated at the same time.
If the vehicle's battery is to be
disconnected (e.g. for maintenance
work), the alarm siren must be
deactivated as follows: switch the
ignition on then off, then disconnect
the vehicle's battery within
15 seconds.
Immobiliser
The system checks whether the
vehicle is allowed to start with the key being used. If the transponder in the
key is recognised, the engine can be
started.The immobiliser activates itself
automatically after the key has been removed from the ignition switch.
If control indicator A flashes when
the ignition is on, there is a fault in the
system; the engine cannot be started. Switch off the ignition and then repeat
the start attempt.
If control indicator A continues
flashing, attempt to start the engine
using the spare key and seek the
assistance of a workshop.
If control indicator A illuminates after
the engine has started, there is a fault in the engine electronics or
transmission electronics 3 81,
3 122, 3 127, or there is water in the
diesel fuel filter 3 90.
Notice
The immobiliser does not lock the doors. You should always lock the
vehicle after leaving it and switch on the anti-theft alarm system 3 21,
3 25.

28Keys, doors and windows
Corsa VXR: For pedestrians safety,
the exterior mirrors of the Corsa VXR are released from the holder if they
are struck with sufficient force. Fit mirror housing to holder with latching
lugs and engage by striking gently.
Manual
The exterior mirrors can be folded in
by pressing gently on the outer edge
of the housing.
Heated mirrors
Operated by pressing the Ü button.
Heating works with the engine
running. It is switched off
automatically after a short time.

Keys, doors and windows31
Operating windows from outside
Depending on the equipment level,
the windows can be operated
remotely from outside the vehicle.
Press q or p until all windows have
opened or closed.
Overload
If the windows are repeatedly
operated at short intervals, the
window operation is disabled for
some time.
Fault
If the windows cannot be opened or
closed automatically, activate the window electronics as follows:
1. Close doors.
2. Switch on ignition.
3. Close the window completely and
operate the button for
5 more seconds.
4. Open the window completely and operate the button for
1 more second.
5. Repeat this for each window.Heated rear window
Operated by pressing the Ü button.
Heating functions with the engine running and is switched off
automatically after a short time.
Depending on the engine type, the
heated rear window comes on
automatically when the diesel particle filter is being cleaned.
Sun visors
The sun visors can be folded down or swivelled to the side to prevent
dazzling.

38Seats, restraintsHeating
Activate heating by pressing ß button
for the seat with the ignition on.
LED in button ß on: relevant front
seat heating on.
Seat heating is operational when the engine is running and during an
Autostop.
Seat belts
The belts are locked during heavy
acceleration or deceleration of the
vehicle for the safety of the
occupants.
9 Warning
Fasten seat belt before each trip.
In the event of an accident, people
not wearing seat belts endanger their fellow occupants and
themselves.
Seat belts are designed to be used by only one person at a time. Child
restraint system 3 48.
Periodically check all parts of the belt
system for damage, pollution and
proper functionality.
Have damaged components
replaced. After an accident, have the
belts and triggered belt tensioners
replaced by a workshop.
Notice
Make sure that the belts are not
damaged by shoes or sharp-edged
objects or are trapped. Prevent dirt
from getting into the belt retractors.
Seat belt reminder X 3 80.
Belt force limiters
In the front seats, stress on the body
is reduced by the gradual release of
the belt during a collision.

Seats, restraints479Danger
Risk of fatal injury for a child using
a child restraint system on a seat
with activated front passenger
airbag.
Risk of fatal injury for an adult
person on a seat with deactivated
front passenger airbag.
Deactivation:
■ switch on ignition, control indicator W flashes,
■ press button W within 15 seconds
and hold down,
■ after about 2 seconds, you will hear
a confirmation buzzer. Release
button W after another 4 seconds
at the latest.
Activation: ■ switch on ignition, control indicator W flashes,
■ press button W within 15 seconds
and hold down,
■ after approx. 2 seconds, you will hear a confirmation buzzer.
Release button W after another
4 seconds at the latest.
The airbag systems for front
passenger seat will inflate in the event
of a collision only if control indicator
W does not illuminate.
Change status only when the vehicle is stopped with the ignition off.
Status remains up to the next change.Control indicator for airbag
deactivation 3 80.
Notice
Starting the engine terminates
changing of the setting.
The setting can then only be
changed once the ignition has been
switched off and back on again.

Instruments and controls71Heated steering wheel
Activate heating in combination with
the seat heating by pressing ß*
button once or several times with the ignition on.
LED ß on: driver seat heating on.
LED ß and * on: driver seat heating
and steering wheel heating on.
LED * on: steering wheel heating on.
The steering wheel is heated in the
areas shown in the illustration when
the engine is running and during an
Autostop.
Horn
Press j.
