technical data VAUXHALL CROSSLAND X 2018 Owner's Manual

Introduction.................................... 2
In brief ............................................ 6
Keys, doors and windows ............21
Seats, restraints ........................... 42
Storage ........................................ 64
Instruments and controls .............73
Lighting ...................................... 110
Climate control ........................... 119
Driving and operating .................131
Vehicle care ............................... 184
Service and maintenance ..........223
Technical data ........................... 227
Customer information ................240
Index .......................................... 248Contents

Introduction3Vehicle specific dataPlease enter your vehicle's data on
the previous page to keep it easily
accessible. This information is
available in the sections "Service and
maintenance" and "Technical data"
as well as on the identification plate.
Introduction
Your vehicle is a designed
combination of advanced technology, safety, environmental friendliness
and economy.
This Owner's Manual provides you
with all the necessary information to
enable you to drive your vehicle
safely and efficiently.
Make sure your passengers are
aware of the possible risk of accident
and injury which may result from
improper use of the vehicle.
You must always comply with the
specific laws and regulations of the
country that you are in. These laws
may differ from the information in this Owner's Manual.
Disregarding the description given in
this manual may affect your warranty.When this Owner's Manual refers to a
workshop visit, we recommend your
Vauxhall Authorised Repairer. For
gas vehicles, we recommend a
Vauxhall Authorised Repairer
licensed to service gas vehicles.
All Vauxhall Authorised Repairers
provide first-class service at
reasonable prices. Experienced
mechanics trained by Vauxhall work according to specific Vauxhall
instructions.
The customer literature pack should
always be kept ready to hand in the
vehicle.
Using this manual ● This manual describes all options
and features available for this
model. Certain descriptions,
including those for display and
menu functions, may not apply to
your vehicle due to model
variant, country specifications,
special equipment or
accessories.
● The "In brief" section will give you
an initial overview.● The table of contents at the beginning of this manual and
within each section shows where the information is located.
● The index will enable you to search for specific information.
● This Owner's Manual depicts left-
hand drive vehicles. Operation is similar for right-hand drive
vehicles.
● The Owner's Manual uses the engine identifier code. The
corresponding sales designation
and engineering code can be
found in the section "Technical
data".
● Directional data, e.g. left or right, or front or back, always relate to
the direction of travel.
● Displays may not support your specific language.
● Display messages and interior labelling are written in bold
letters.

Technical data227Technical dataVehicle identification..................227
Vehicle Identification Number ..227
Identification plate ...................227
Engine identification ................228
Vehicle data ............................... 229
Recommended fluids and lubricants ................................ 229
Engine data ............................. 232
Performance ............................ 234
Vehicle weight ......................... 235
Vehicle dimensions .................236
Capacities ................................ 237
Tyre pressures ........................ 238Vehicle identification
Vehicle IdentificationNumber
The Vehicle Identification Number
may be stamped on the identification plate and on the floor pan, under thefloor covering, visible under a cover.
The Vehicle Identification Number
may be embossed on the instrument
panel, visible through the windscreen,
or in the engine compartment on the
right body panel.
Identification plate
The identification plate is located on
the front left or right door frame.

228Technical dataInformation on identification label:1:manufacturer2:type approval number3:vehicle identification number4:permissible gross vehicle weight
rating in kg5:permissible gross train weight
in kg6:maximum permissible front axle
load in kg7:maximum permissible rear axle
load in kg8:vehicle-specific or country-
specific data
The combined total of front and rear
axle loads must not exceed the
permissible gross vehicle weight. For
example, if the front axle is bearing its
maximum permissible load, the rear
axle can only bear a load that is equal
to the gross vehicle weight minus the front axle load.
The technical data is determined in
accordance with European
Community standards. We reserve
the right to make modifications.
Specifications in the vehicle
documents always have priority over
those given in this manual.
Engine identification
The technical data tables show the
engine identifier code. Engine data
3 232.
To identify the respective engine,
refer to the engine power in the EEC
Certificate of Conformity provided
with your vehicle or other national
registration documents.

Technical data229Vehicle dataRecommended fluids and lubricants
European service schedule Required engine oil qualityCountries with European service interval (country groups 1,2,3) 3 223Engine oil qualityPetrol engines
(including CNG, LPG, E85)Diesel enginesdexos1 Gen2✔–dexos2–✔
Diesel engines only: In case dexos quality is unavailable, you may use max. one litre engine oil quality ACEA C3 once
between each oil change.
Engine oil viscosity grades
Countries with European service interval (country groups 1,2,3) 3 223Ambient temperaturePetrol and diesel enginesdown to -25 °CSAE 0W-30 or SAE 0W-40SAE 5W-30 or SAE 5W-40below -25 °CSAE 0W-30 or SAE 0W-40

230Technical dataInternational service schedule
Required engine oil qualityCountries with international service interval (country group 4) 3 223Engine oil qualityPetrol engines
(including CNG, LPG, E85)Diesel enginesdexos1 Gen2✔–dexos2–✔
In case dexos quality is unavailable you may use the oil qualities listed below:
Countries with international service interval (country group 4) 3 223Engine oil qualityPetrol engines
(including CNG, LPG, E85)Diesel enginesACEA A3/B4–✔ACEA C3–✔
Engine oil viscosity grades
Countries with international service interval (country group 4) 3 223Ambient temperaturePetrol and diesel enginesdown to -25 °CSAE 0W-30 or SAE 0W-40SAE 5W-30 or SAE 5W-40

Technical data231Countries with international service interval (country group 4) 3 223below -25 °CSAE 0W-30 or SAE 0W-40down to -20 °CSAE 10W-30 1)
or SAE 10W-40 1)1)
Permitted, but usage of oils with dexos quality is recommended.

232Technical dataEngine dataEngine identifier codeB12xEB12xEB12xHTB12xHTSales designation1.21.2 LPG1.2 Turbo1.2 TurboEngineering codeEB2FEB2FEB2DTEB2DTSPiston displacement [cm3
]1199119911991199Engine power [kW]60558196at rpm5750560055005500Torque [Nm]118115205230at rpm2750280015001750Fuel typePetrolLiquid gas/PetrolPetrolPetrolOctane rating RON 2)recommended95959595possible98989898Additional fuel type–Liquid gas (LPG)––2)
A country-specific label at the fuel filler flap can supersede the engine-specific requirement.

Technical data233Engine identifier codeB16DTB16DTHB16DTHSales designation1.61.61.6Engineering codeDV6FDDV6FCDV6FCPiston displacement [cm3
]156015601560Engine power [kW]738588at rpm375035003500Torque [Nm]254300300at rpm175017501750Fuel typeDieselDieselDieselAdditional fuel type–––

234Technical dataPerformanceEngineB12xE
B12xE
LPG
B12xHTB12xHT
Maximum speed [mph]Manual transmission106106117 3)1284)Automatic transmission––116–3)
5-gear transmission
4) 6-gear transmissionEngineB16DTB16DTHMaximum speed [mph]Manual transmission112116Automatic transmission––
