run flat VAUXHALL CROSSLAND X 2019 Owner's Manual

92Instruments and controlsFlashes yellowThe remaining driving range is
between 0 and 370 mph.
AdBlue level is low. Refill AdBlue
soon to avoid prevention of the
engine start. Up to 10 l of AdBlue can
be added.
AdBlue 3 140.
Deflation detection system
w illuminates or flashes yellow.
Illuminates
Tyre pressure loss in one or more
wheels. Stop immediately and check
tyre pressure.
Flashes Fault in system. Consult a workshop.
Deflation detection system 3 208.
Engine oil pressure I illuminates red.
Illuminates when the ignition is
switched on and extinguishes shortly
after the engine starts.Illuminates when the engine is
runningCaution
Engine lubrication may be
interrupted. This may result in
damage to the engine and / or
locking of the drive wheels.
1. Depress clutch.
2. Select neutral gear.
3. Move out of the flow of traffic as quickly as possible without
impeding other vehicles.
4. Switch off ignition.
9 Warning
When the engine is off,
considerably more force is needed
to brake and steer.
During an Autostop, the brake
servo unit will still be operational.
Do not remove key until vehicle is stationary, otherwise the steeringwheel lock could engage
unexpectedly.
Keep engine turned off and let the
vehicle be towed to a workshop
3 189.
Low fuel o illuminates yellow.
Level in fuel tank is too low.
Refuelling 3 178.
Bleeding the diesel fuel system
3 192.
Autostop D illuminates or flashes green.
Illuminates green
Engine is in an Autostop.
Flashes green
Autostop is temporarily unavailable,
or Autostop mode is invoked
automatically.
Stop-start system 3 136.
Exterior light 8 illuminates green.

Vehicle care207Tyre designations
E.g. 195/65 R 15 91 T195:tyre width, mm65:cross-section ratio (tyre height
to tyre width), %R:belt type: RadialRF:type: RunFlat15:wheel diameter, inches91:load index e.g. 95 is equivalent to 615 kgT:speed code letter
Speed code letter:
Q:up to 100 mphS:up to 112 mphT:up to 118 mphH:up to 130 mphV:up to 150 mphW:up to 168 mph
Choose a tyre appropriate for the
maximum speed of your vehicle.
The maximum speed is achievable at
kerb weight with driver (75 kg) plus
125 kg payload. Optional equipment
could reduce the maximum speed of
the vehicle.
Performance 3 238.
Directional tyres
Directional tyres should be mounted
so that they rotate in the correct
direction. The proper rotation
direction is indicated by a symbol (e.g. an arrow) on the sidewall.
Tyre pressure
Check the pressure of cold tyres at
least every 14 days and before any
long journey. Do not forget the spare
wheel. This also applies to vehicles
with tyre pressure monitoring system.
Tyre pressure 3 243.
The tyre pressure information label
on the left door frame indicates the
original equipment tyres and the
correspondent tyre pressures.
The tyre pressure data refers to cold
tyres. It applies to summer and winter tyres.
Always inflate the spare tyre to the
pressure specified for full load.
The ECO tyre pressure serves to
achieve the smallest amount of fuel
consumption possible.
Incorrect tyre pressures will impair
safety, vehicle handling, comfort and
fuel economy and will increase tyre
wear.
Tyre pressures differ depending on
various options. For the correct tyre
pressure value, follow the procedure
below:
1. Identify drive axle and body style.
2. Identify the engine identifier code.
Engine data 3 237.
3. Identify the respective tyre.
The tyre pressure tables show all
possible tyre combinations 3 243.

212Vehicle care4.Screw the compressor air hose to
the connection on the sealant
bottle.
5. Fit the sealant bottle into the bracket on the compressor.
Set the compressor near the tyre
in such a way that the sealant
bottle is upright.
6. Unscrew valve cap from defective
tyre.
7. Screw the filler hose to the tyre valve.
8. The switch on the compressor must be set to J.
9. Connect the compressor plug to
the power outlet or cigarette
lighter socket.
To avoid discharging the battery,
we recommend running the
engine.
10. Set the rocker switch on the compressor to I. The tyre is filled
with sealant.
11. The compressor pressure gauge briefly indicates up to 6 bar whilstthe sealant bottle is emptying
(approx. 30 seconds). Then the
pressure starts to drop.
12. All of the sealant is pumped into the tyre. Then the tyre is being
inflated.
13. The prescribed tyre pressure should be obtained within
10 minutes.
Tyre pressure 3 243.
When the correct pressure is
obtained, switch off the
compressor.
If the prescribed tyre pressure is
not obtained within 10 minutes,
remove the tyre repair kit. Move
the vehicle one tyre rotation.
Reattach the tyre repair kit and
continue the filling procedure for
10 minutes. If the prescribed tyre
pressure is still not obtained, the
tyre is too badly damaged. Seek
the assistance of a workshop.

Vehicle care221
Screw in the towing eye as far as it will
go until it stops in a horizontal
position.
Attach a tow rope – or better still a tow
rod – to the towing eye.
The towing eye must only be used for towing and not for recovering the
vehicle.
Switch on ignition to release steering
wheel lock and to permit operation of
brake lights, horn and windscreen
wiper.
Caution
Deactivate the driver assistance
systems like active emergency
braking 3 156, otherwise the
vehicle may automatically brake during towing.
Switch the selector lever to neutral.
Release the parking brake.
Caution
Drive slowly. Do not drive jerkily.
Excessive tractive force can
damage the vehicle.
When the engine is not running,
considerably more force is needed to
brake and steer.
To prevent the entry of exhaust gases from the towing vehicle, switch on the
air recirculation and close the
windows.
Vehicles with automatic transmission: The vehicle must be towed facing
forwards, not faster than 50 mph nor further than 60 miles. In all other
cases and when the transmission is
defective, the front axle must be
raised off the ground.
Seek the assistance of a workshop. After towing, unscrew the towing eye.
Insert cap with the outer flange into
the recess and fix cap by pushing.
Towing another vehicle
Wrap a cloth around the tip of a flat
screwdriver to prevent paint damage.
Insert a screwdriver in the slot at the
bottom of the cap. Release the cap by carefully moving the screwdriver
downwards.

255Clock............................................. 76
Control indicators.......................... 87
Control of the vehicle .................131
Controls ........................................ 72
Convex shape .............................. 33
Coolant and antifreeze ...............230
Cruise control ...................... 93, 150
Cupholders .................................. 62
Curtain airbag system .................. 54
D Danger, Warnings and Cautions ...4
Daytime running lights ...............111
Declaration of conformity ............244
DEF ............................................ 140
Deflation detection system ...........92
Diesel exhaust fluid ....................140
Diesel fuel system bleeding .......192
Door open .................................... 93
Doors ............................................ 29
Driver alert .................................. 175
Driver assistance systems ..........150
Driver Information Centre .............94
Driving characteristics and towing tips .............................. 182
Driving hints ................................ 131
E Electric adjustment ......................33
Electrical system......................... 201
Electronic climate control system 122Electronic driving programmes ..144
Electronic key system ...................22
Electronic Stability Control and Traction Control system ....91, 148
Electronic Stability Control and Traction Control system off .......91
End-of-life vehicle recovery .......187
Engine compartment fuse box ...202
Engine coolant ........................... 190
Engine coolant temperature ........91
Engine coolant temperature gauge ....................................... 85
Engine data ............................... 237
Engine exhaust .......................... 139
Engine identification ...................233
Engine oil ................... 189, 230, 234
Engine oil level monitor ................86
Engine oil pressure ......................92
Entry lighting .............................. 116
Event data recorders ..................250
Exhaust filter ......................... 91, 139
Exit lighting ................................ 116
Exterior care .............................. 222
Exterior light ................................. 92
Exterior lighting ....................12, 109
Exterior mirrors ............................. 33
F Fault ........................................... 145
First aid ......................................... 68First aid kit ................................... 68
Fixed air vents ........................... 128
Folding mirrors ............................. 34
Forward collision alert................. 155
Front airbag system .....................53
Front fog lights .............93, 113, 196
Front pedestrian protection ........159
Front seats.................................... 42
Fuel............................................. 176
Fuel for diesel engines ..............176
Fuel for liquid gas operation .......178
Fuel for petrol engines ...............176
Fuel gauge ................................... 84 Fuel selector ................................ 84
Fuses ......................................... 201
G
Gauges ......................................... 83
Gear shifting ................................. 90
General information ...................181
Glass panel .................................. 39
Glovebox ..................................... 62
H Halogen headlights ....................194
Hand brake ................................. 147
Hazard warning flashers ............112
Headlight flash ........................... 110
Headlight range adjustment ......111
Headlights................................... 109
Headlights when driving abroad 111
