display VAUXHALL MOKKA 2014 Workshop Manual

Vehicle care171
No.Circuit1Seat, lumbar support, driver2Seat, lumbar support,
passenger3Amplifier4Trailer socket5All-wheel drive6Display7Spare8Trailer9Spare10Spare11Trailer12Navigation13Heated steering wheel14Trailer socket15Steering wheel16Water in fuel sensorNo.Circuit17Interior mirror18Spare
S/B Fuses
No.Circuit01Power seat driver02Power seat passenger03Trailer04Voltage converter05Battery06Headlight washer07Spare08Spare09SpareVehicle tools
Tools
Vehicles with tyre repair kit
The tools and tyre repair kit are in the
right side of the load compartment.
3 177.

174Vehicle care
When the system detects a
malfunction, w will flash for approx.
one minute and then remain
continuously illuminated. This
sequence will continue upon
subsequent vehicle start-ups as long as the malfunction exists.
When w is illuminated, the system
may not be able to detect or signal low tyre pressure as intended.
Tyre Pressure Monitoring Operation The TPMS is designed to warn the
driver when a low tyre pressure
condition exists. TPMS sensors are mounted onto each tyre and wheel
assembly, excluding the spare tyre
and wheel assembly. The TPMS sensors monitor the air pressure in
the tyres and transmit the tyre
pressure readings to a receiver
located in the vehicle.
When a low tyre pressure condition is
detected, w illuminates. Stop as soon
as possible and inflate the tyres to the
recommended tyre pressure 3 172.
Additionally a warning message or a
warning code is displayed in the
Driver Information Centre 3 93.
The low tyre pressure control
indicator and a warning message or
code come on at each ignition cycle
until the tyres are inflated to the
correct tyre pressure.
TPMS Malfunction Indicator and
Message Code
The TPMS will not function properly if
one or more of the TPMS sensors are missing or inoperable. When the
system detects a malfunction, w
flashes for approx. one minute and then illuminates. Additionally a
warning message or code is
displayed.
The indication by the TPMS
malfunction indicator and a warning
message or code will come on at each ignition cycle until the problem iscorrected. Some of the conditions
that can cause these to come on are:
■ One of the tyres has been replaced
with the spare tyre which does not
have a TPMS sensor.
■ The TPMS sensor matching process was not done or not
completed successfully after
rotating the tyres. The malfunction
light and the warning message or
code should go off after
successfully completing the sensor

Vehicle care175
matching process. See "TPMS
Sensor Matching Process" later in
this section.
■ One or more TPMS sensors are missing or damaged. The warning
message or code and the
malfunction light should go off
when the TPMS sensors are
installed and the sensor matching
process is performed successfully.
Consult your workshop for service.
■ Replacement tyres or wheels do not match the original equipment
tyres or wheels. Tyres and wheels other than those recommended
could prevent the TPMS from
functioning properly.
■ Operating electronic devices or being near facilities using radio
wave frequencies similar to the
TPMS could cause the TPMS
sensors to malfunction.
If the TPMS is not functioning
properly, it cannot detect or signal
a low tyre condition. Consult your
workshop for service if the TPMS
malfunction light and a warningmessage or code come on and stay
on.
TPMS Sensor Matching
Process
Each TPMS sensor has a unique
identification code. The identification
code must be matched to a new tyre/
wheel position after rotating the tyres
or replacing one or more of the TPMS
sensors. The TPMS sensor matching process should also be performed
after replacing a spare tyre with a
road tyre containing the TPMS
sensor.
The malfunction light and the warning
message or code should go off at the
next ignition cycle. The sensors are
matched to the tyre/wheel positions,
using a TPMS relearn tool, in the
following order: driver side front tyre,
passenger side front tyre, passenger
side rear tyre, and driver side rear.
Consult your workshop for service or
to purchase a relearn tool. There are
two minutes to match the first tyre/
wheel position, and five minutes
overall to match all four tyre/wheelpositions. If it takes longer, the
matching process stops and must be
restarted.
The TPMS sensor matching process
is:
1. Apply the parking brake.
2. Turn the ignition on.
3. Use the MENU button on the turn
signal lever to select the Vehicle
Information Menu in the Driver
Information Centre (DIC).
4. Use the thumbwheel to scroll to the tyre pressure menu.
5. Press the SET/CLR button to
begin the sensor matching
process. A message requesting
acceptance of the process should display.
6. Press the SET/CLR button again
to confirm the selection. The horn
sounds twice to signal the receiver is in relearn mode.
7. Start with the driver side front tyre.
8. Place the relearn tool against the tyre sidewall, near the valve stem.Then press the button to activate
the TPMS sensor. A horn chirp

Vehicle care191Interior careInterior and upholsteryOnly clean the vehicle interior,
including the instrument panel fascia
and panelling, with a dry cloth or
interior cleaner.
Clean the leather upholstery with clear water and a soft cloth. In case of
heavy soiling, use leather care.
The instrument cluster and the
displays should only be cleaned using
a soft damp cloth. If necessary use a weak soap solution.
Clean fabric upholstery with a
vacuum cleaner and brush. Remove
stains with an upholstery cleaner.
Clothing fabrics may not be
colourfast. This could cause visible
discolourations, especially on light-
coloured upholstery. Removable
stains and discolourations should be
cleaned as soon as possible.
Clean seat belts with lukewarm water or interior cleaner.Caution
Close Velcro fasteners as open
Velcro fasteners on clothing could damage seat upholstery.
The same applies to clothing with
sharp-edged objects, like zips or
belts or studded jeans.
Plastic and rubber parts
Plastic and rubber parts can be
cleaned with the same cleaner as
used to clean the body. Use interior cleaner if necessary. Do not use any
other agent. Avoid solvents and petrol in particular. Do not use high-
pressure jet cleaners.

192Service and maintenanceService and
maintenanceGeneral information ...................192
Recommended fluids, lubricants and parts .................................... 193General information
Service information In order to ensure economical and
safe vehicle operation and to
maintain the value of your vehicle, it
is of vital importance that all
maintenance work is carried out at the proper intervals as specified.
The detailed, up-to-date service
schedule for your vehicle is available
at the workshop.
Service display 3 80.
European service intervals
Maintenance of your vehicle is
required every 20,000 miles or after
1 year , whichever occurs first, unless
otherwise indicated in the service
display.
The European service intervals are
valid for the following countries:
Andorra, Austria, Belgium, Bosnia-
Herzegovina, Bulgaria, Croatia,
Cyprus, Czech Republic, Denmark,
Estonia, Finland, France, Germany,
Greece, Greenland, Hungary,Iceland, Ireland, Italy, Latvia,
Lithuania, Luxembourg, Macedonia,
Malta, Montenegro, Netherlands,
Norway, Poland, Portugal, Romania,
Slovakia, Slovenia, Spain, Sweden, Switzerland, United Kingdom.
Service display 3 80.
International service intervals Maintenance of your vehicle is
required every 10,000 miles or after
1 year , whichever occurs first, unless
otherwise indicated in the service
display.
The international service intervals are
valid for the countries which are not
listed in the European service
intervals.
Service display 3 80.
Confirmations
Confirmation of service is recorded in the Service and Warranty Booklet.The date and mileage is completed
with the stamp and signature of the
servicing workshop.

Service and maintenance193
Make sure that the Service and
Warranty Booklet is completed
correctly as continuous proof of
service is essential if any warranty or goodwill claims are to be met, and is
also a benefit when selling the
vehicle.
Service interval with remaining
engine oil life duration The service interval is based on
several parameters depending on
usage.
The service display lets you know
when to change the engine oil.
Service display 3 80.Recommended fluids,
lubricants and parts
Recommended fluids and
lubricants
Only use products that meet the
recommended specifications.
Damage resulting from the use of
products not in line with these
specifiations will not be covered by
the warranty.9 Warning
Operating materials are
hazardous and could be
poisonous. Handle with care. Pay
attention to information given on
the containers.
Engine oil
Engine oil is identified by its quality
and its viscosity. Quality is more
important than viscosity when
selecting which engine oil to use. The oil quality ensures e.g. engine
cleanliness, wear protection and oil
aging control, whereas viscosity
grade gives information on the oil's
thickness over a temperature range.
Dexos is the newest engine oil quality
that provides optimum protection for
gasoline and diesel engines. If it is unavailable, engine oils of other listed qualities have to be used.
Recommendations for gasoline
engines are also valid for
Compressed Natural Gas (CNG),
Liquified Petroleum Gas (LPG) and
Ethanol (E85) fuelled engines.
Select the appropriate engine oil
based on its quality and on the
minimum ambient temperature
3 197.
Topping up engine oil
Engine oils of different manufacturers
and brands can be mixed as long as
they comply with the required engine
oil quality and viscosity.
Use of engine oil with only
ACEA A1/B1 or only A5/B5 quality is
prohibited, since it can cause long-
term engine damage under certain
operating conditions.

211
Convex shape .............................. 27
Coolant and antifreeze ...............193
Cruise control ...................... 88, 135
Cupholders .................................. 55
Curtain airbag system .................. 45
D Danger, Warnings and Cautions ...4
Daytime running lights ...............106
Declaration of conformity ............207
Delayed locking ............................ 23
Descent control system .......85, 134
Diesel fuel system bleeding .......159
Diesel particle filter ...............86, 125
Door open .................................... 88
Doors ............................................ 24
Driver assistance systems ..........135
Driver Information Centre .............88
Driving characteristics and towing tips .............................. 150
Driving hints ................................ 120
E Electric adjustment ......................27
Electrical system......................... 166
Electronic climate control system 116
Electronic driving programmes ..128
Electronic Stability Control.......... 133
Electronic Stability Control and Traction Control system ............86Electronic Stability Control off....... 86
End-of-life vehicle recovery .......153
Engine compartment fuse box ...167
Engine coolant ........................... 155
Engine coolant temperature gauge ....................................... 80
Engine data ............................... 200
Engine exhaust .......................... 125
Engine identification ...................196
Engine oil ................... 154, 193, 197
Engine oil pressure ......................87
Entry lighting .............................. 112
Event data recorders ..................207
Exit lighting ................................ 112
Exterior care .............................. 189
Exterior light ................................. 87
Exterior lighting ....................12, 104
Exterior mirrors ............................. 27
F Fault ........................................... 129
First aid kit ................................... 69
Fixed air vents ........................... 119
Flex-Fix system ............................ 57
Fog light ....................................... 88
Fog lights ................................... 163
Folding mirrors ............................. 27
Forward collision alert................. 138
Front airbag system .....................44
Front fog lights ........................... 109Front seats.................................... 34
Front turn signal lights ...............163
Fuel............................................. 148
Fuel consumption - CO 2-
Emissions ............................... 150
Fuel for diesel engines ..............148
Fuel for petrol engines ...............148
Fuel gauge ................................... 80
Fuses ......................................... 166
G Gauges ......................................... 79
General information ...................150
Glovebox ..................................... 55
Glove box lighting .......................111
Graphic-Info-Display, Colour- Info-Display .............................. 91
H
Halogen headlights ....................160
Hand brake ......................... 131, 132
Hazard warning flashers ............109
Headlight flash ........................... 105
Headlight range adjustment ......105
Headlights when driving abroad 105
Head restraint adjustment .............8
Head restraints ............................ 33
Heated mirrors ............................. 28
Heated rear window ..................... 30
Heated steering wheel .................73

212
Heating ........................................ 37
Heating and ventilation system . 114
High beam ........................... 87, 105
Hill start assist ........................... 132
Horn ....................................... 13, 73
I
Identification plate .....................195
Ignition switch positions .............121
Immobiliser ............................ 26, 87
Indicators ...................................... 79
Information displays...................... 88
Initial drive information.................... 6 Instrument panel fuse box .........168
Instrument panel illumination control .................................... 110
Instrument panel overview ........... 10
Instrument panel storage ..............54
Interior care ............................... 191
Interior lighting ............................ 110
Interior lights ...................... 111, 166
Interior mirrors .............................. 28
Interruption of power supply ......129
Introduction .................................... 3
ISOFIX child restraint systems ....52
J
Jump starting ............................. 185K
Key, memorised settings ..............21
Keys ............................................. 19
Keys, locks ................................... 19
L
Lane departure warning .......85, 146
Lashing eyes ............................... 69
Lighting features .........................112
Light switch ................................ 104
Load compartment ................24, 66
Load compartment cover .............68
Load compartment fuse box ......170
Loading information .....................70
Low fuel ....................................... 87
M Malfunction indicator light ............84
Manual anti-dazzle ......................28
Manual mode ............................. 128
Manual transmission .................. 130
Manual windows ..........................29
Memorised settings ......................21
Mirror adjustment ........................... 8
Misted light covers .....................110
N
New vehicle running-in ..............121
Number plate light .....................165O
Object detection systems ...........140
Odometer ..................................... 79
Oil, engine .......................... 193, 197
Outside temperature ....................76
Overrun cut-off ........................... 122
P Parking ................................ 17, 124
Parking assist ............................ 140
Parking brake ............................ 132
Particulate filter ........................... 125
Performance .............................. 201
Performing work ........................153
Pollen filter ................................. 119
Power outlets ............................... 78
Power steering.............................. 85
Power windows ............................ 29
Preheating ................................... 86
Puncture ..................................... 180
R Radio Frequency Identification (RFID) ..................................... 208
Radio remote control ...................20
Reading lights ............................ 111
Rear carrier system ......................57
Rear floor storage cover ..............68
Rear fog light ....................... 88, 110
Rear view camera ...................... 141

213
Rear window wiper/washer .......... 75
Recommended fluids and lubricants ........................ 193, 197
Refuelling ................................... 148
Reversing lights .........................110
Ride control systems ..................133
Roof .............................................. 31
Roof load ...................................... 70
Roof rack ..................................... 70
S Seat adjustment ....................... 6, 35
Seat belt ........................................ 8
Seat belt reminder .......................83
Seat belts ..................................... 38
Seat position ................................ 34
Selector lever ............................. 127
Service ....................................... 119
Service display ............................ 80
Service information ....................192
Service vehicle soon .................... 84
Side airbag system ......................44
Side turn signal lights ................165
Spare wheel ............................... 183
Speed limiter............................... 136
Speedometer ............................... 79
Starting and operating ................121
Starting off ................................... 16
Starting the engine ....................121
Steering ...................................... 120Steering wheel adjustment ......9, 72
Steering wheel controls ...............72
Stop-start system........................ 122
Storage compartments .................54
Sunglasses storage .....................56
Sunroof ........................................ 31
Sunvisor lights ........................... 111
Sun visors .................................... 31
Symbols ......................................... 4
T
Tachometer ................................. 79
Tail lights ................................... 163
Three-point seat belt .................... 39
Tools .......................................... 171
Top-tether fastening eyes ............53
Tow bar....................................... 150 Towing ................................ 150, 186
Towing another vehicle .............188
Towing hitch installation dimensions ............................. 206
Towing the vehicle .....................186
Traction Control system ............. 133
Traction Control system off........... 86
Traffic sign assistant ...................143
Trailer towing ............................. 151
Transmission ............................... 16
Transmission display .................127
Tread depth ............................... 176
Trip computer .............................. 96Trip odometer .............................. 79
Turn and lane-change signals ...109
Turn signal ................................... 83
Tyre chains ................................ 177
Tyre designations ......................172
Tyre pressure ............................ 172
Tyre pressure monitoring system ............................... 86, 173
Tyre pressures ........................... 205
Tyre repair kit ............................. 177
Tyres .......................................... 172
U Ultrasonic parking assist ...... 85, 140
Underseat storage .......................56
Upholstery .................................. 191
Upshift .......................................... 85
Using this manual ..........................3
V Vehicle battery ........................... 157
Vehicle checks............................ 153
Vehicle data ................................ 197
Vehicle data recording and privacy ..................................... 207
Vehicle detected ahead ................88
Vehicle dimensions .................... 203
Vehicle Identification Number ....195
Vehicle jack ................................ 171
Vehicle messages .......................93
