86Instruments and controls
Warning messagesINJECTION FAULTENGINE OVERHEATINGGEARBOX OVERHEATING
Warning chimesWhen starting the engine or
whilst driving
Only one warning chime will sound at
a time.
The warning chime regarding
unfastened seat belts has priority
over any other warning chime.
■ If seat belt is not fastened 3 45.
■ If a certain speed is exceeded with the parking brake applied 3 122.
■ If the parking assist detects an object 3 130.
■ If the vehicle has manual transmission automated and the
clutch temperature is too high
3 118.
■ If the vehicle speed briefly exceeds
a set limit 3 74.
■ During closing of the power sliding door 3 24.
■ If the sliding door is open and the parking brake is released 3 24.
■ During activation and deactivation of alarm monitoring of vehicle
inclination 3 28.
When the vehicle is parked and/ or the driver's door is opened ■ When the key is in the ignition switch.
■ With exterior lights on.
■ If the vehicle has manual transmission automated 3 118; the
parking brake has not been
applied, neutral is not selected or
the foot brake has not been
depressed. A corresponding
message may also appear in the
Driver Information Centre 3 84.
■ If the engine is in an Autostop but not switched off. Stop-start system
3 111.Trip computer
The trip computer provides
information on driving data, which is
continually recorded and evaluated
electronically.
Depending on vehicle, the following
functions can be selected by pressing button repeatedly on end of wiper
lever:
■ Fuel used
■ Average consumption
■ Instantaneous consumption
■ Range

Instruments and controls87
■ Distance travelled
■ Average speed
■ Distance before service 3 76
■ Clock 3 72
■ Cruise control and speed limiter stored speed 3 126
■ Tyre pressures 3 160
■ Fault and information messages
Fuel used
Displays the amount of fuel
consumed since the last reset.
The measurement can be restarted at
any time by pressing and holding the
button on the end of the wiper lever.
Average consumption
The value is displayed after driving a
distance of 0.25 miles.
Average consumption is displayed,
taking into consideration the distance
travelled and the fuel used since the
last reset.
The measurement can be restarted at
any time.Instantaneous consumption
The value is displayed after reaching
a speed of 20 mph.
Range
The value is displayed after driving a
distance of 0.25 miles.
The range is calculated from the
current contents of the fuel tank and
the average consumption since the
last reset.
The range will not display if control
indicator Y is illuminated in the
instrument cluster 3 83.
The measurement can be restarted at
any time.
Distance travelled Displays the distance driven since the
last reset.
The measurement can be restarted at
any time.
Average speed The value is displayed after driving adistance of 0.25 miles.
The average speed since the last
reset is displayed.The measurement can be restarted at
any time.
Interruptions in the journey with the
ignition off are not included in the
calculations.
Reset trip computer information
To reset the trip computer, select one
of its functions then press and hold
button on end of wiper lever.
The following trip computer
information will be reset:
■ Fuel used
■ Average consumption
■ Range
■ Distance travelled
■ Average speed
The trip computer will reset
automatically when the maximum
value of any of the parameters is
exceeded.

108Driving and operatingDriving and operatingDriving hints............................... 108
Starting and operating ...............109
Engine exhaust .......................... 116
Manual transmission ..................117
Manual transmission automa‐
ted .............................................. 118
Brakes ........................................ 121
Ride control systems .................124
Driver assistance systems .........126
Fuel ............................................ 132
Trailer hitch ................................ 134
Auxiliary features .......................136Driving hints
Driving economically ECO mode
ECO mode is a function that
optimises fuel consumption. It affects engine power and torque,
acceleration, gear shift indication,
heating, air conditioning and electrical consumers.
ActivationPress the ECO button. Control
indicator illuminates when activated
and a corresponding message
appears in the Driver Information
Centre 3 84.
During driving, it is possible to
temporarily disable ECO mode, e.g.
to increase engine performance, by
depressing the accelerator pedal
firmly.
ECO mode is reactivated when
pressure is reduced on the
accelerator pedal.
Deactivation
Press the ECO button again. Control
indicator extinguishes.
Control of the vehicle Never coast with engine not
running (except during
Autostop) Many systems will not function in this
situation (e.g. brake servo unit, power
steering). Driving in this manner is a
danger to yourself and others. All

Driving and operating109
systems function during an Autostop,
but there will be a controlled reduction
in power steering assist and vehicle
speed is reduced.
Stop-start system 3 111.
Pedals
To ensure the pedal travel is
uninhibited, there must be no mats in the area of the pedals.
Steering If power steering assist is lost
because the engine stops or due to a system malfunction, the vehicle can
be steered but may require increased
effort.Caution
Vehicles equipped with hydraulic
power steering:
If the steering wheel is turned until it reaches the end of its travel, and
is held in that position for more
than 15 seconds, damage may
occur to the power steering
system and there may be loss of
power steering assist.Starting and operating
New vehicle running-in Do not brake unnecessarily hard for
the first few journeys and after new
disc brake pads have been fitted.
During the first drive, smoke may
occur because of wax and oil
evaporating off the exhaust system.
Park the vehicle in the open for a
while after the first drive and avoid
inhaling the fumes.
During the running-in period fuel and
engine oil consumption may be
higher and the cleaning process of the diesel particle filter may take
place more often. Autostop may be inhibited to allow for charging the
vehicle battery.
Stop-start system 3 111.
Diesel particle filter 3 116.

116Driving and operatingEngine exhaust9Danger
Engine exhaust gases contain
poisonous carbon monoxide,
which is colourless and odourless and could be fatal if inhaled.
If exhaust gases enter the interior
of the vehicle, open the windows.
Have the cause of the fault
rectified by a workshop.
Avoid driving with an open load
compartment, otherwise exhaust
gases could enter the vehicle.
Diesel particle filter
The diesel particle filter system filters
harmful soot particles out of the
exhaust gases. The system includes
a self-cleaning function that runs
automatically during driving without
any notification.
The filter is cleaned by periodically
burning off the soot particles at high
temperature. This process takes
place automatically under set driving
conditions. Autostop is not available
and fuel consumption may be higher
during this period. The emission of
smells and smoke during this process is normal.
Under certain driving conditions, e.g.
short distances, the system cannot
clean itself automatically.
If cleaning of the filter is required and
if previous driving conditions did not
enable automatic cleaning, it will be
indicated by illumination of control
indicator A 3 80. Seek the
assistance of a workshop
immediately.Caution
If the cleaning process is
interrupted, there is a risk of
provoking severe engine damage.
Cleaning takes place quickest at high engine speeds and loads.
Catalytic converter
The catalytic converter reduces the
amount of harmful substances in the
exhaust gases.Caution
Fuel grades other than those listed on page 3 132, 3 185 could
damage the catalytic converter or
electronic components.
Unburnt petrol will overheat and
damage the catalytic converter.
Therefore avoid excessive use of the starter, running the fuel tank
dry and starting the engine by
pushing or towing.
In the event of misfiring, uneven
engine running, a reduction in engine performance or other unusual
problems, have the cause of the fault
rectified by a workshop as soon as
possible. In an emergency, driving
can be continued for a short period,
keeping vehicle speed and engine
speed low.

134Driving and operating
When refuelling is complete, replace
the fuel filler cap and turn it clockwise.
Close the fuel filler flap.
Fuel filler cap
Only use genuine fuel filler caps. Diesel-engined vehicles have special fuel filler caps.
Fuel consumption - CO 2-
Emissions
For the values specific to your
vehicle, refer to the EEC Certificate of Conformity provided with your vehicle
or other national registration
documents.
General information The official fuel consumption and
specific CO 2 emission figures quoted
relate to the EU base model with
standard equipment.
Fuel consumption data and CO 2
emission data are determined
according to regulation
715/2007 692/2008 A, taking intoconsideration the vehicle weight in running order, as specified by the
regulation.
The figures must not be taken as a
guarantee for the actual fuel
consumption of a particular vehicle.
Additional equipment may result in
slightly higher results than the stated
consumption and CO 2 figures.
Furthermore, fuel consumption is dependent on personal driving style
as well as road and traffic conditions.Trailer hitch
General information
Only use towing equipment that has
been approved for your vehicle.
Entrust fitting of towing equipment at
a later date to a workshop. It may be
necessary to make changes that
affect the cooling system, heat
shields or other equipment.
Driving characteristics and
towing tips In the case of trailers with brakes,
attach the breakaway stopping cable.
Before attaching a trailer, lubricate
the coupling ball. However, do not do so if a stabiliser, which acts on thecoupling ball, is being used to reduce
snaking movements. For trailers with
low driving stability the use of a
stabiliser is recommended.
A maximum speed of 50 mph must
not be exceeded, even in countries
where higher speeds are permitted.

207
Cleaning the vehicle...................175
Climate control ............................. 14
Climate control systems ...............96
Clock ............................................ 72
Control indicators.......................... 77
Control of the vehicle .................108
Controls ........................................ 69
Convex shape .............................. 30
Coolant ....................................... 142
Coolant and antifreeze ...............179
Coolant heater ............................ 102
Cornering light ......................91, 150
Coupling ball bar ........................135
Cruise control ...................... 84, 126
Cupholders .................................. 62
D Danger, Warnings and Cautions ...3
Dashboard .................................... 10
Daytime running lights .................90
Declaration of conformity ............203
Demisting and defrosting ..............14
Diesel fuel ................................... 132
Diesel fuel filter .......................... 146
Diesel fuel system bleeding .......146
Diesel particle filter ....................116
Door locks..................................... 19
Door open .................................... 84
Doors ............................................ 24
DPF (diesel particle filter) ...........116Driver assistance systems ..........126
Driver Information Centre .............84
Driving characteristics and towing tips .............................. 134
Driving economically................... 108
Driving hints ................................ 108
E ECO mode .................................. 108
Electric adjustment ......................31
Electrical system......................... 155
Electronic climate control system 98
Electronic driving programmes ..120
Electronic Stability Program .....
.................................. 81, 125, 136
Electronic Stability Program off ...82
Emergency exit ............................. 35
End-of-life vehicle recovery .......139
Engine compartment fuse box ...156
Engine coolant ........................... 142
Engine coolant temperature ........82
Engine coolant temperature gauge ....................................... 75
Engine data ............................... 185
Engine exhaust .......................... 116
Engine identification ...........182, 183
Engine oil ................... 140, 179, 184
Engine oil additives ....................179
Engine oil level monitor ................76
Engine oil pressure ......................82Engine oil viscosity grades .........179
Enhanced Traction function 124, 125
Event data recorders ..................203
Exhaust gases ............................ 116
Exit lighting .................................. 95
Exterior care .............................. 175
Exterior light ................................. 83
Exterior lighting ......................12, 89
Exterior mirrors ............................. 30
F
Fault ........................................... 121
Fire extinguisher ..........................66
First aid ......................................... 66
First aid kit ................................... 66
Fixed air vents ........................... 107
Fog light ....................................... 84
Fog lights .............................. 92, 150
Folding mirrors ............................. 31
Front airbag system .....................50
Front fog lights ........................ 89, 92
Front seats.................................... 37
Front storage ............................... 62
Front turn signal lights ...............150
Fuel consumption - CO 2-
Emissions ............................... 134
Fuel for diesel engines ..............132
Fuel gauge ................................... 75 Fuse box ............................. 156, 157
Fuses ......................................... 155
