86Instruments and controlsUCruise control speed limiter
3 91&Tachograph 3 91yDoor open 3 91
Turn signal
O flashes green.
Flashes if a turn signal or the hazard
warning flashers are activated.
Rapid flashing: failure of a turn signal
light or associated fuse.
An audible warning can be heard
when the turn signals are on. When
towing a trailer, the pitch of the
audible warning changes.
Bulb replacement 3 167.
Fuses 3 174.
Turn signals 3 100.
Seat belt reminder
X illuminates or flashes red.
If the seat belt is unfastened, control
indicator X will flash when vehicle
speed exceeds approx. 10 mph. A warning chime also sounds for
approx. 90 seconds.
If the seat belt is fastened, the
indicator light extinguishes.9 Warning
Fasten seat belt before each trip.
In the event of an accident, people
not wearing seat belts endanger their fellow occupants and
themselves.
Three-point seat belts 3 49.
Airbag and belt tensioners
v illuminates yellow.
When the ignition is switched on, the control indicator illuminates briefly. If
it does not illuminate or illuminates
whilst driving, there is a fault in the
airbag system. Seek the assistance
of a workshop. The airbags and belt
pretensioners may fail to trigger in the event of an accident.
Deployment of the belt pretensioners
or airbags is indicated by continuous
illumination of v.9 Warning
Have the cause of the fault
remedied immediately by a
workshop.
Belt pretensioners, airbag system
3 48, 3 51.
Airbag deactivation
W illuminates yellow when the
ignition is switched on and remains
illuminated when the front passenger
airbag has been deactivated 3 55.

Vehicle care157Vehicle careGeneral Information...................158
Accessories and vehicle modifications .......................... 158
Vehicle storage ........................158
End-of-life vehicle recovery .....159
Vehicle checks ........................... 159
Performing work ......................159
Bonnet ..................................... 159
Engine oil ................................. 160
Engine coolant ......................... 161
Power steering fluid .................162
Washer fluid ............................ 163
Brakes ..................................... 163
Brake fluid ............................... 163
Vehicle battery ......................... 163
Diesel fuel filter ........................165
Diesel fuel system bleeding .....166
Wiper blade replacement ........166
Bulb replacement .......................167
Headlights ............................... 167
Adaptive forward lighting .........169
Fog lights ................................. 169
Front turn signal lights .............170
Tail lights ................................. 170
Side turn signal lights ..............171Centre high-mounted brake
light ......................................... 172
Number plate light ...................173
Interior lights ............................ 173
Instrument panel illumination ...174
Electrical system ........................174
Fuses ....................................... 174
Engine compartment fuse box . 176
Instrument panel fuse box .......176
Load compartment fuse box ....177
Vehicle tools .............................. 179
Tools ........................................ 179
Wheels and tyres .......................180
Tyres ....................................... 180
Winter tyres ............................. 180
Tyre designations ....................180
Tyre pressure .......................... 181
Tyre pressure monitoring system .................................... 182
Tread depth ............................. 184
Changing tyre and wheel size . 184 Wheel covers ........................... 184
Tyre chains .............................. 185
Tyre repair kit .......................... 185
Wheel changing .......................188
Spare wheel ............................ 190
Jump starting ............................. 193Towing....................................... 195
Towing the vehicle ...................195
Towing another vehicle ...........196
Appearance care .......................197
Exterior care ............................ 197
Interior care ............................. 198

170Vehicle careFront turn signal lights
1. Remove protective cover.
2. Detach wiring connector from bulb.
3. Rotate bulb holder anti-clockwise to disengage.
4. Withdraw bulb holder from reflector housing.
5. Detach bulb from bulb holder andrenew the bulb.
6. Insert the bulb holder, engaging the two lugs in the reflectorhousing and rotate clockwise to
secure.
7. Reattach wiring connector to bulb.
8. Replace protective cover.
Tail lights
Rear brake, tail, turn signal,
reverse and fog tail lights
1. Remove the upper and lower trim panels from the rear pillar.
2. Unscrew the two nuts from the locating pins on the rear of the
lamp assembly.
3. Withdraw the lamp assembly rearwards from the outer side.
4. Detach wiring connector from lamp assembly.

Vehicle care171
5. Remove the three screws fromthe rear of the lamp assembly.
6. Remove bulb holder from the lamp assembly.
7. Push bulb into socket slightly, rotate anti-clockwise, remove and
renew bulb.
Turn signal light ( 1)
Tail and brake light ( 2)
Reverse light ( 3)
Rear fog light, may be on one side only ( 4)
8. Replace bulb holder in lamp assembly.
9. Replace the three screws on the rear of the lamp assembly.
10. Reattach wiring connector to lamp
assembly.
11. Replace lamp assembly from the outer side into original position,
ensuring that it is seated correctly.
12. Replace the two nuts onto the locating pins on the rear of the
lamp assembly.
13. Install the upper and lower trim panels to the rear pillar.Side turn signal lights
1. Push the lamp assembly to the right and pull at the left-hand side
of the lamp assembly to release
from the aperture.
2. Detach wiring connector from lamp assembly.
3. Remove bulb holder from lamp assembly by rotating 90° and
renew bulb.
4. Install bulb holder in lamp assembly.

172Vehicle care5. Reattach wiring connector.
6. Install lamp assembly into aperture and push to the left to
secure.
Mirror turn signal lights 1. Move the lower mirror assembly from the front to access the screw.
2. Remove the screw using a torx screwdriver.
3. Remove bulb holder from the rear
of the lower mirror assembly.
4. Renew bulb.
5. Replace bulb holder.
6. Replace the screw.
Centre high-mounted brake
light
1. Remove cover from the inside of the rear door.
2. Unscrew the nut from the locating
pin at the rear of the lamp
assembly.
3. Remove the lamp assembly from the aperture on the outer side.
4. Detach wiring connector from lamp assembly.
5. Remove bulb holder from lamp assembly and renew bulb.
6. Install bulb holder in lamp assembly and reattach wiring
connector to lamp assembly.
7. Replace lamp assembly into aperture, ensuring that it is seated
correctly.
