transmission VAUXHALL MOVANO_B 2016 Infotainment system

Introduction33Multimedia favourites
Select an empty slot in the display or
press < (to open a pop-up menu),
then Add Favourite .
Choose from the displayed list to add
a preset FM radio station to the
favourites.Phone favourites
Select an empty slot in the display or
press < (to open a pop-up menu),
then Add Favourite .
Choose from the displayed list to add a phone contact to the favourites.
For further information, refer to
(NAVI 80) "Phonebook" in the
"Phone" section 3 131.Services favourites
Select an empty slot in the display or
press < (to open a pop-up menu),
then Add Favourite .
Choose from the displayed list to add an installed application to the
favourites.Delete favourites
Press < and select Remove all
Favourites or select a favourite from
the displayed list then press Remove
a Favourite . A confirmation message
is displayed. Press Delete to confirm.
Additional features (NAVI 50)
Depending on version, the following
additional features are available:
● Remote engine start-up
● Rear camera view settings
● Driving eco2 function (driving economy)
● AhaⓇ application (for smartphones)Remote engine start-up9Danger
Never leave a child or an animal
inside the vehicle, even for a brief
period, when the remote engine
start-up feature is activated (to
avoid unintended operation of
windows, doors or transmission
etc. in the event the engine starts
automatically).
Risk of fatal injury.
Available depending on vehicle, the
remote engine start-up system
enables an automatic start-up of the
engine to be programmed, to either
heat or ventilate the passenger
compartment before entering the
vehicle. The vehicle can be
programmed to be ready for use at
any time of day and upto 24 hours in
advance.
Notice
Climate control settings
(temperature, fan speed, air
distribution, air conditioning) must be set as required before leaving the vehicle.
From the Home page, press ßSet
Time on the display screen.

140PhoneSelect System followed by System
version to display the software
version.
NAVI 80 - Phone settings
From the Home page, press MENU
then Phone followed by Settings on
the display screen.
Select from the following options on
the display:
● Manage devices :
Refer to (NAVI 80) "Pairing a
mobile phone" in the "Bluetooth
connection" section 3 127.
● Sound levels :
To set the handsfree phone
system call volume and the
ringtone.
● Voice mail :
Refer to (NAVI 80) "Voicemail
box" above.
● Turn Bluetooth on/off :
Refer to (NAVI 80) "Activating Bluetooth" in the "Bluetooth
connection" section 3 127.
● Automatically download phone
data :Press this option to tick the box
☑ alongside it.
When pairing and/or connecting
the mobile phone to the
Infotainment system, the contact
list and call lists in the mobile
phone can now be downloaded
to the handsfree phone system.
Data sharing must also be
authorised on your phone. Refer
to the operating instructions for
your mobile phone or consult
your network provider.
Mobile phones and CB radio
equipment
Installation instructions and
operating guidelines
The vehicle specific installation
instructions and the operating
guidelines of the mobile phone and
handsfree manufacturer must be
observed when installing and
operating a mobile telephone. Failure to do so could invalidate the vehicle
type approval (EU directive 95/54/
EC).Recommendations for fault-free
operation:
● professionally installed exterior antenna to obtain the maximum
range possible
● maximum transmission power 10 watts
● installation of the phone in a suitable spot, consider relevant
Note in the Owner's Manual
section Airbag system
Seek advice on predetermined
installation points for the external
antenna or equipment holder and
ways of using devices with a
transmission power exceeding
10 watts.
Use of a handsfree attachment
without external antenna with mobile
telephone standards GSM
900/1800/1900 and UMTS is only
permitted if the maximum
transmission power of the mobile
telephone is 2 watts for GSM 900 or
1 watt for the other types.
