ground clearance VAUXHALL MOVANO_B 2016 Owner's Manual

Driving and operating123Remote control
When increased ground clearance orimproved vehicle access is required,the suspension can be raised or
lowered using the remote control.
Caution
Ensure there is adequate
clearance and that there are no
obstructions when adjusting the
suspension height.
The remote control unit is magnetic
and may be fixed to any metal part of the vehicle or stored in its holder.
With the engine running, press theappropriate button for 2 seconds to
adjust the suspension height.
Indicator light will flash intermittently
while height adjustment is in progress
and illuminates when complete.
If the ignition is switched on with
engine not running, the suspension
height can only be lowered.
Notice
Handle with care, protect from
moisture and high temperatures and
avoid unnecessary operation.
Pre-programmed settings
Adjusts the suspension height to one
of three pre-programmed positions.l:lowered positionk:normal positionj:raised positionCaution
If an obstacle is detected while
raising or lowering, the
suspension height is returned to the normal position after a delay.
This does not guarantee damage-
free operation. Ensuring sufficient
clearance and freedom from
obstacles is the responsibility of the driver.
Manual settings
Manual adjustment can only be
performed when the vehicle is
stationary.
Select by pressing h for 2 seconds,
then R to raise, or S to lower.
To exit, press any of the pre-
programmed buttons.
Notice
Obstacle detection is not available
during manual adjustment.
When a certain low speed is
exceeded or when the ignition is
switched off, height adjustment is deactivated automatically and the
suspension height is returned to the
normal position.
Service mode
When the vehicle is stationary, press
i for 5 seconds to put the vehicle into
service mode. The indicator light will
illuminate.

226Fuel consumption - CO2-
Emissions ............................... 149
Fuel economy rating (ecoScoring) 92
Fuel for diesel engines ..............148
Fuel gauge ................................... 79 Fuel tank ..................................... 218
Fuse box ............................. 171, 172
Fuses ......................................... 170
G Gauges ......................................... 77
General information ...................150
Glass panel .................................. 37
Glovebox ..................................... 65
Glovebox cooler ......................... 114
Ground clearance .......................122
H Hand brake - see Parking brake. 135
Hazard warning flashers ..............98
Headlight flash ............................. 97
Headlight range adjustment ........97
Headlights ...................... 95, 96, 162
Headlights when driving abroad ..97
Head restraint adjustment .............8
Head restraints ............................ 38
Heated exterior mirrors .................15
Heated mirrors ............................. 34
Heated rear window ...............15, 37
Heating ........................................ 44
Heating and ventilation system . 103High beam ............................. 88, 96
High beam assist ....................89, 96
Hill start assist ........................... 136
Horn ....................................... 14, 73
Hub cap hook ............................. 174
I Identification plate .....................199
Idle speed control .......................118
Ignition switch positions .............117
Immobiliser .................................. 32
Indicators ...................................... 77
Information displays...................... 89
Initial drive information.................... 6 Instrument cluster ........................77
Instrument panel fuse box .........171
Instrument panel illumination .....169
Instrument panel overview ........... 10
Instrument panel storage .............64
Interior care ............................... 193
Interior lighting .............................. 99
Interior lights ........................ 99, 168
Interior mirrors .............................. 34
Interruption of power supply ......134
Introduction .................................... 3
ISOFIX child restraint systems ....63
J Jack ............................................ 174
Journey record.............................. 92
Jump starting ............................. 188K
Keys ............................................. 19
Keys, locks ................................... 19
L
Lane departure warning .......86, 146
Lashing eyes ............................... 67
Light covers, misted...................... 99
Lighting ......................................... 95
Lighting features .........................101
Light switch .................................. 95
Load compartment........................ 21
Load compartment fuse box ......172
Load compartment lighting .........100
Loading information .....................71
Low fuel ....................................... 88
M Malfunction indicator light ............84
Manual adjustment ......................33
Manual anti-dazzle ......................34
Manual door locks ........................21
Manual mode ............................. 132
Manual transmission............. 16, 130
Manual transmission automated ......................... 16, 130
Manual windows ..........................35
Messages ..................................... 90
Mirror adjustment ........................... 8
Mirrors .................................... 33, 34
Misted light covers .......................99
