VAUXHALL MOVANO_B 2017.5 Owner's Manual

Service and maintenance219Make sure that the Service and
warranty booklet is completed
correctly as continuous proof of
service is essential if any warranty or
goodwill claims are to be met, and is
also a benefit when selling the
vehicle.
Service display
The service interval is based on
several parameters depending on
usage.
The service display, located in the
Driver Information Centre, indicates
when the next service is due. Seek
the assistance of a workshop.
Service display 3 90.
Engine oil lever monitor 3 90.Recommended fluids,
lubricants and parts
Recommended fluids andlubricants
Only use products that meet the
recommended specifications.9 Warning
Operating materials are
hazardous and could be
poisonous. Handle with care. Pay
attention to information given on
the containers.
Engine oil
Engine oil is identified by its quality
and its viscosity. Quality is more
important than viscosity when
selecting which engine oil to use. The oil quality ensures e.g. engine
cleanliness, wear protection and oil
aging control, whereas viscosity
grade gives information on the oil's
thickness over a temperature range.
Dexos is the newest engine oil quality
that provides optimum protection for diesel engines. If it is unavailable,
engine oils of other listed qualities
must be used.
Select the appropriate engine oil based on its quality and on the
minimum ambient temperature
3 223.
Topping up engine oil
Engine oils of different manufacturers
and brands can be mixed as long as
they comply with the required engine
oil quality and viscosity.
Use of engine oil with only
ACEA A1/B1 or only A5/B5 quality is
prohibited, since it can cause long-
term engine damage under certain
operating conditions.
Select the appropriate engine oil
based on its quality and on the
minimum ambient temperature
3 223.
Additional engine oil additives
The use of additional engine oil
additives could cause damage and
invalidate the warranty.

220Service and maintenanceEngine oil viscosity grades
The SAE viscosity grade gives
information of the thickness of the oil.
Multigrade oil is indicated by two
figures, e.g. SAE 5W-30. The first
figure, followed by a W, indicates the
low temperature viscosity and the
second figure the high temperature viscosity.
Select the appropriate viscosity grade
depending on the minimum ambient
temperature 3 223.
All of the recommended viscosity
grades are suitable for high ambient
temperatures.
Coolant and antifreeze
Use only silicate-free long life coolant (LLC) antifreeze approved for the
vehicle. Consult a workshop.
The system is factory filled with
coolant designed for excellent
corrosion protection and frost
protection down to approx. -28 °C.
This concentration should be
maintained all year round. The use of additional coolant additives that
intend to give additional corrosionprotection or seal against minor leaks
can cause function problems. Liability
for consequences resulting from the
use of additional coolant additives will be rejected.
Washer fluid Use only washer fluid approved for
the vehicle to prevent damage of
wiper blades, paintwork, plastic and
rubber parts. Consult a workshop.
Brake fluid Over time, brake fluid absorbs
moisture which will reduce braking
effectiveness. The brake fluid should
therefore be replaced at the specified
interval.
AdBlue Only use AdBlue to reduce the
nitrogen oxides in the exhaust
emission 3 141.

Technical data221Technical dataVehicle identification..................221
Vehicle Identification Number ..221
Identification plate ...................222
Engine identification ................222
Vehicle data ............................... 223
Recommended fluids and lubricants ................................ 223
Engine data ............................. 224
Vehicle weight ......................... 226
Vehicle dimensions .................233
Capacities ................................ 242
Tyre pressures ........................ 243Vehicle identification
Vehicle IdentificationNumber
The Vehicle Identification Number
(VIN) is visible through the
windscreen.
The VIN is also displayed behind a
removable plastic cover on the front
right hand door step.Unclip the
covers using a flat blade screwdriver
to access.

222Technical dataIdentification plate
The identification plate is located on
the right hand door pillar.
Information on identification plate:1:manufacturer's name2:certification number3:vehicle identification number4:permissible gross vehicle
weight rating in kg5:permissible gross train weight
in kg6:maximum permissible front axle load in kg7:maximum permissible rear axle
load in kg8:engine type9:engine identification code10:fabrication number11:vehicle paint code
Notice
The identification plate on your
vehicle may differ from the
illustration shown.
The combined total of front and rear
axle loads must not exceed the
permissible gross vehicle weight. For
example, if the front axle is bearing its
maximum permissible load, the rear
axle can only bear a load that is equal
to the gross vehicle weight minus the front axle load.
The technical data is determined in
accordance with European
Community standards. We reserve
the right to make modifications.
Specifications in the vehicle
documents always have priority over
those given in this manual.
Engine identifier code and enginenumber
Stamped on the engine cylinder block
and on a label attached to the timing
chain cover, depending on variant.
Engine identification
The technical data tables show the
engine identifier code. Engine data
3 224.
To identify the respective engine,
refer to the engine power in the EEC
Certificate of Conformity provided
with your vehicle or other national
registration documents.

Technical data223Vehicle data
Recommended fluids and lubricants
Required engine oil qualityEngine oil quality: Europedexos 2✔
For countries with International
service interval 3 218, you may use
the oil qualities listed below:
Engine oil quality: Internationaldexos 2✔GM-LL-A/B-025✔ACEA C3
diesel engines with DPF✔ACEA A3/B4
diesel engines without DPF✔Engine oil viscosity gradesAmbient temperaturedown to -25 °CSAE 5W-30 or
SAE 5W-40below -25 °CSAE 0W-30 or
SAE 0W-40

224Technical dataEngine data
Sales designation
2.3 CDTI 1252.3 CDTI 110,
2.3 CDTI 110
ecoFLEX2.3 CDTI
BITURBO 1352.3 CDTI 1502.3 BITURBO 163Engine identifier codeM9T (MH) 1)
, (MD) 2)
,
(MJ) 2)M9T (MR) 2)M9T (MN)2)M9T (MF)2)M9T (MP) 3)
, (MU) 4)Number of cylinders44444Piston displacement
[cm 3
]22982298229822982298Engine power [kW]9281100110120at rpm35003500350035003500Torque [Nm]310285340/350 5)3503603)
/380 4)at rpm1250-20001250-20001500-250015001500-2750Fuel typeDieselDieselDieselDieselDiesel1)
Euro 4.
2) Euro 5.
3) Euro 5.
4) Euro VI with AdBlue.
5) Front-wheel drive/Rear-wheel drive.

Technical data225Sales designation2.3 CDTI 1102.3 CDTI 1302.3 BITURBO 1302.3 BITURBO 1452.3 BITURBO 170Engine identifier codeM9T (MW)6)M9T (MY)6)M9T (M1)7)M9T (MS) 6)
, (MT) 7)M9T (ML) 6)Number of cylinders44444Piston displacement [cm 3
]22982298229822982298Engine power [kW] (PS)819696107125at rpm35003500350035003500Torque [Nm]290320330360380at rpm1250150015001500-27501500-2750Fuel typeDieselDieselDieselDieselDiesel6) Euro 6 with AdBlue.
7) Euro VI with AdBlue.
AdBlue 3
141.

226Technical dataVehicle weight
Kerb weight, basic model without any optional equipment Optional equipment and accessories increase the kerb weight.
VanDrive wheelsLengthRoof height
Gross vehicle weight
[kg]Kerb weight
[kg]Front-wheel driveL1H1280018063300181135001816H2280018343300183935001844L2H23300188535001890H33300192135001931L3H235001970H335002010

Technical data227
Drive wheelsLengthRoof height
Gross vehicle weight
[kg]Kerb weight
[kg]Rear-wheel driveL3H23500 8)21593500 9)224645002246H335008)21483500 9)227945002279L4H235008)22703500 9)232445002324H335008)23003500 9)2366450023668)
With Single rear wheels.
9) With Twin rear wheels.

228Technical dataDoublecab
Drive wheelsLengthRoof height
Gross vehicle weight
[kg]Kerb weight
[kg]Front-wheel driveL1H13300197035001975L1H23300199535002000L2H23300209435002102L3H235002177Rear-wheel driveL3H23500 8)232435009)24534500 9)24538)
With Single rear wheels.
9) With Twin rear wheels.
