warning VAUXHALL VIVA 2015.75 Service Manual

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
Climate Controls 131
{Warning
Periodically turn to the outside air
mode for fresh air. The exchange
of fresh air is reduced in air
recirculation mode. In operation
without cooling the air humidity
increases, so the windows may
mist up. The quality of the
passenger compartment air
deteriorates, which may cause
the vehicle occupants to feel
drowsy.
In warm and very humid ambient air
conditions, the windscreen might
mist up from outside, when cold air
is directed to it. If windscreen mists
up from outside, activate
windscreen wiper and
deactivate
0.
Maximum cooling
Briefly open the windows so that hot
air can disperse quickly.
. Switch on cooling A/C.
. Switch on air recirculation
system
W.
. Press air distribution switch
E.
. Set temperature control to
coldest level.
. Set fan speed to highest level.
. Open all vents.
Demisting and defrosting the
windows
.Turn the air distribution knob to
DEFROST
0.
. Set temperature control to
warmest level.
. Adjust the fan control knob to
highest speed for quick
defrosting.
. Switch on heated rear window
R
1. .
Open side air vents as required
and direct them towards the door
windows.
Note: If
1is pressed while the
engine is running, an Autostop will
be inhibited until
1is pressed
again.
If
1is pressed while the engine is
in an Autostop, the engine will
restart automatically.
Note: If mode knob is set on
Defrost mode
1, A/C operates and
Recirculation mode will be fixed to
outside air mode regardless of
indicator status.
Stop-start system
0Automatic
Engine Start/Stop Feature 0141.

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
Climate Controls 133
Basic setting for maximum comfort:
.Press AUTO.
. Open all air vents to allow
optimised air distribution in
automatic mode.
. Press A/C to switch on optimal
cooling and demisting. Activation
is indicated by the LED in the
button.
. Set the desired temperature.
Temperature preselection
Temperatures can be set to the
desired value. If the minimum
temperature Lo is set, the climate
control system runs at maximum
cooling, if cooling A/C is switched
on. If the maximum temperature Hi
is set, the climate control system
runs at maximum heating.
Recommended temperature
is 22 °C.
Note: If A/C is switched on,
reducing the set cabin temperature
can cause the engine to restart from
an Autostop or inhibit an Autostop
0
Automatic Engine Start/Stop
Feature 0141.
Air recirculation system
The air recirculation mode is
operated with
W. An indicator
light comes on to show that the
recirculation is on.
Press
Wagain to deactivate
recirculation mode.
{Warning
Periodically turn to the outside air
mode for fresh air. The exchange
of fresh air is reduced in air
recirculation mode. In operation
without cooling the air humidity
increases, so the windows may
mist up. The quality of the
passenger compartment air
deteriorates, which may cause
the vehicle occupants to feel
drowsy.
Demisting and defrosting the
windows
. Press0. Activation is indicated
by the LED in the button. And
recirculation mode is to be set and to be fixed to outside air
mode, automatically. The air
conditioning system operated
but an indicator light is no
change.
. Temperature and air distribution
are set automatically and the fan
runs at high speed.
. Switch on heated rear window
R
1.
. To return to previous mode :
Press
0, to return to automatic
mode: press AUTO
Note: If
0is pressed while the
engine is running, an Autostop will
be inhibited until
0is pressed
again.
If
0is pressed while the engine is
in an Autostop, the engine will
restart automatically.
Stop-start system
0Automatic
Engine Start/Stop Feature 0141.

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
Climate Controls 135
condensation may form and drip
from under the vehicle. If no cooling
or drying is required, switch off the
cooling system for fuel saving
reasons.
Activated cooling might inhibit
Autostops
0Automatic Engine
Start/Stop Feature 0141.
Air recirculation system
PressWto activate air
recirculation mode. Activation is
indicated by the LED in the button.
Press
Wagain to deactivate
recirculation mode.
{Warning
The exchange of fresh air is
reduced in air recirculation mode.
In operation without cooling the
air humidity increases, so the
windows may mist up from inside.
The quality of the passenger
compartment air deteriorates,
which may cause the vehicle
occupants to feel drowsy. In warm and very humid ambient air
conditions, the windscreen might
mist up from outside, when cold air
is directed to it. If windscreen mists
up from outside, activate
windscreen wiper.
Maximum cooling
Briefly open the windows so that hot
air can disperse quickly.
.
Switch on cooling A/C.
. Switch on air recirculation
system
W.
. Press air distribution switch
E.
. Set temperature control to
coldest level.
. Set fan speed to highest level.
. Open all vents.
Air Vents
Adjustable Air Vents
At least one air vent must be open
while cooling is on in order to
prevent the evaporator from icing up
due to lack of air movement.
Direct the flow of air by tilting and
swivelling the slats. If you do not
want the flow, move the slats to
inside for centre vent and outside
for side vent. The vent has some air
leakages at closed position.

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
136 Climate Controls
{Warning
Do not attach any objects to the
slats of the air vents. Risk of
damage and injury in case of an
accident.
Fixed Air Vents
Additional air vents are located
beneath the windscreen and door
windows and in the foot wells.
These are fixed and cannot be
adjusted.
Maintenance
Air Intake
The air intake in front of the
windscreen in the engine
compartment must be kept clear to
allow air intake. Remove any
leaves, dirt or snow.
Passenger Compartment
Air Filter
Cabin air filtration
The particle filter cleans the cabin
air from solid particulates such as
pollen, dust, soot from the air. The
filter should be replaced as part of
routine scheduled maintenance.
Caution
More frequent maintenance of the
air filter is required if the driving
circumstances are dusty roads,
air pollution areas, and frequent
unpaved roads. It makes the filter
efficiency to be decreased and
the bronchus to be bad effected.

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
138 Driving and Operating
Driving and
Operating
Driving Information
Control of a Vehicle . . . . . . . . . . . 138
Steering . . . . . . . . . . . . . . . . . . . . . . 139
Starting and Operating
New Vehicle Run-In . . . . . . . . . . 139
Ignition Positions . . . . . . . . . . . . . 139
Starting the Engine . . . . . . . . . . . 140
Retained AccessoryPower (RAP) . . . . . . . . . . . . . . . . 141
Automatic Engine Start/Stop Feature . . . . . . . . . . . . . . . . . . . . . 141
Parking . . . . . . . . . . . . . . . . . . . . . . . 143
Engine Exhaust
Engine Exhaust . . . . . . . . . . . . . . 144
Catalytic Converter . . . . . . . . . . . 144
Manual Gearbox
Manual Gearbox . . . . . . . . . . . . . . 145
Brakes
Brakes . . . . . . . . . . . . . . . . . . . . . . . 145
Antilock Brake System (ABS) . . . . . . . . . . . . . . . 146 Parking Brake . . . . . . . . . . . . . . . . 146
Brake Assist . . . . . . . . . . . . . . . . . . 147
Hill Start Assist (HSA) . . . . . . . . 147
Ride Control Systems
Traction Control
System (TCS) . . . . . . . . . . . . . . . 147
Electronic Stability Control (ESC) . . . . . . . . . . . . . . . 148
Object Detection Systems
Parking Assist (Rear parkingassist) . . . . . . . . . . . . . . . . . . . . . . . 150
Driver Assistance Systems
Driver Assistance Systems . . . 152
Cruise Control . . . . . . . . . . . . . . . . 152
Speed Limiter . . . . . . . . . . . . . . . . . 153
Lane DepartureWarning (LDW) . . . . . . . . . . . . . 154
Fuel
Fuel (for Petrol Engines) . . . . . . 156
Filling the Tank . . . . . . . . . . . . . . . 156
Fuel Consumption -CO2-Emissions . . . . . . . . . . . . . 158
Driving Information
Control of a Vehicle
Never coast with engine not
running (except during
Autostop)
Many systems will not function in
this situation (e.g. brake servo unit,
power steering). Driving in this
manner is a danger to yourself and
others.
Idle boost
If charging of the vehicle battery is
required due to vehicle battery
condition, the power output of the
alternator must be increased. This
will be achieved by an idle boost
which may be audible.
Pedals
To ensure the pedal travel is
uninhibited, there must be no mats
in the area of the pedals.

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
Driving and Operating 143
Restart of the engine by the
stop-start system
The selector lever must be in
neutral to enable an automatic
restart.
If one of the following conditions
occurs during an Autostop, the
engine will be restarted
automatically by the stop-start
system.
.The stop-start system is
manually deactivated.
. The bonnet is opened.
. The driver's seat belt is
unfastened and the driver's door
is opened.
. The engine temperature is
too low.
. The vehicle battery is
discharged.
. The brake vacuum is not
sufficient.
. The vehicle starts to move.
. The climate control system
requests an engine start. .
The air conditioning is manually
switched on.
If the bonnet is not fully closed, a
warning message is displayed in the
Driver Information Centre.
If an electrical accessory, e.g. a
portable CD player, is connected to
the power socket, a brief power
drop during restart might be
noticeable.
Parking
{Warning
. Do not park the vehicle on
an easily ignitable surface.
The high temperature of the
exhaust system could ignite
the surface.
. Always apply parking brake.
Apply manual parking brake
without pressing release
button. Apply as firmly as
possible on downhill or
(Continued)
Warning (Continued)
uphill slopes. Depress the
foot brake at the same time
to reduce operating force.
. Switch off the engine and
ignition. Turn the steering
wheel until the steering
wheel lock engages.
. If the vehicle is on a level
surface or uphill slope,
engage first gear before
switching off the ignition.
On an uphill slope, turn the
front wheels away from
the kerb.
If the vehicle is on a
downhill slope, engage
reverse gear before
switching off the ignition.
Turn the front wheels
towards the kerb.
(Continued)

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
144 Driving and Operating
Warning (Continued)
.Lock the vehicle and
activate the anti-theft alarm
system.
Note: In the event of an accident
with airbag deployment, the engine
is turned off automatically if the
vehicle comes to a standstill within
a certain time.
Engine Exhaust
{Danger
Engine exhaust gases contain
poisonous carbon monoxide,
which is colourless and odourless
and could be fatal if inhaled.
If exhaust gases enter the interior
of the vehicle, open the windows.
Have the cause of the fault
rectified by a workshop.
Avoid driving with an open load
compartment, otherwise exhaust
gases could enter the vehicle.
Catalytic Converter
The catalytic converter reduces the
amount of harmful substances in the
exhaust gases.
Caution
Fuel grades other than those
listed on pages
0Fuel (for Petrol
Engines) 0156,
0Engine Data
0 207 could damage the catalytic
converter or electronic
components.
Unburnt petrol will overheat and
damage the catalytic converter.
Therefore avoid excessive use of
the starter, running the fuel tank
dry and starting the engine by
pushing or towing.
In the event of misfiring, uneven
engine running, a reduction in
engine performance or other
unusual problems, have the cause
of the fault rectified by a workshop
as soon as possible. In an
emergency, driving can be
continued for a short period,
keeping vehicle speed and engine
speed low.

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
Driving and Operating 145
Manual Gearbox
To engage reverse, depress the
clutch pedal and then engage the
reverse gear.If the gear does not engage, set the
lever to neutral, release the clutch
pedal and depress again; then
repeat gear selection.
Do not slip the clutch unnecessarily.
When operating, depress the clutch
pedal completely. Do not use the
pedal as a foot rest.
Caution
It is not advisable to drive with the
hand resting on the selector lever.
Brakes
The brake system comprises two
independent brake circuits.
If a brake circuit fails, the vehicle
can still be braked using the other
brake circuit. However, braking
effect is achieved only when the
brake pedal is depressed firmly.
Considerably more force is needed
for this. The braking distance is
extended. Seek the assistance of a
workshop before continuing your
journey.
When the engine is not running, the
support of the brake servo unit
disappears once the brake pedal
has been depressed once or twice.
Braking effect is not reduced, but
braking requires significantly greater
force. It is especially important to
bear this in mind when being towed.
Control indicator
$
0Brake and
Clutch System Warning Light 071.

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
146 Driving and Operating
Antilock Brake
System (ABS)
Anti-lock brake system (ABS)
prevents the wheels from locking.
ABS starts to regulate brake
pressure as soon as a wheel shows
a tendency to lock. The vehicle
remains steerable, even during hard
braking.
ABS control is made apparent
through a pulse in the brake pedal
and the noise of the regulation
process.
For optimum braking, keep the
brake pedal fully depressed
throughout the braking process,
despite the fact that the pedal is
pulsating. Do not reduce the
pressure on the pedal.
After starting off, the system
performs a self-test which may be
audible.
Control indicator
!0Antilock
Brake System (ABS) Warning
Light 071.
Adaptive brake light
During full braking, all three brake
lights flash for the duration of ABS
control.
Fault
{Warning
If there is a fault in the ABS, the
wheels may be liable to lock due
to braking that is heavier than
normal. The advantages of ABS
are no longer available. During
hard braking, the vehicle can no
longer be steered and may
swerve.
Have the cause of the fault
remedied by a workshop.
Parking Brake
{Warning
Always apply parking brake firmly
without operating the release
button, and apply as firmly as
possible on a downhill or uphill
slope.
To release the parking brake, pull
the lever up slightly, press the
release button and fully lower the
lever. (Continued)

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
Driving and Operating 147
Warning (Continued)
To reduce the operating forces of
the parking brake, depress the
foot brake at the same time.
See Brake and Clutch System
Warning Light 071.
Brake Assist
If the brake pedal is depressed
quickly and forcefully, maximum
brake force is automatically applied
(full braking).
Maintain continuous pressure on the
brake pedal for as long as full
braking is required. Maximum brake
force is automatically reduced when
the brake pedal is released.
Hill Start Assist (HSA)
The system helps prevent
unintended movement when driving
away on inclines.
When releasing the foot brake after
stopping on an incline, the brakes
remain on for a further two seconds.
The brakes release automatically as
soon as the vehicle begins to
accelerate.
The hill start assist is not active
during an Autostop.
Ride Control Systems
Traction Control
System (TCS)
The Traction Control system (TC) is
a component of the Electronic
Stability Control system.
TC improves driving stability when
necessary, regardless of the tyre of
road surface or tyre grip, by
preventing the drive wheels from
spinning.
As soon as the drive wheels starts
to spin, engine output is reduced
and the wheel spinning the most is
braked individually. This
considerably improves the driving
stability of the vehicle on slippery
road surfaces.
TC is operational as soon as the
control indicator
Gextinguishes.
When TC is active
Gflashes.
