136 Climate Controls
{Warning
Do not attach any objects to the
slats of the air vents. Risk of
damage and injury in case of an
accident.
Fixed Air Vents
Additional air vents are located
beneath the windscreen and door
windows and in the foot wells.
These are fixed and cannot be
adjusted.
Maintenance
Air Intake
The air intake in front of the
windscreen in the engine
compartment must be kept clear to
allow air intake. Remove any
leaves, dirt or snow.
Passenger Compartment
Air Filter
Cabin air filtration
The particle filter cleans the cabin
air from solid particulates such as
pollen, dust, soot from the air. The
filter should be replaced as part of
routine scheduled maintenance.
Caution
More frequent maintenance of the
air filter is required if the driving
circumstances are dusty roads,
air pollution areas, and frequent
unpaved roads. It makes the filter
efficiency to be decreased and
the bronchus to be bad effected.
