cooling VAUXHALL VIVA 2015.75 Owner's Manual

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
16 In Brief
Stop-start system
If the vehicle is at a low speed or at
a standstill and certain conditions
are fulfilled, activate an Autostop as
follows:
.depress the clutch pedal
. set the lever in neutral
. release the clutch pedal
An Autostop is indicated by the
needle at the AUTOSTOP position
in the tachometer.
To restart the engine, depress the
clutch pedal again. Stop-start system
0Automatic
Engine Start/Stop Feature 0141.
Parking
{Warning
.
Do not park the vehicle on
an easily ignitable surface.
The high temperature of the
exhaust system could ignite
the surface.
. Always apply handbrake.
Pull switch
Yfor approx.
one second.
. Switch off the engine.
. surface or uphill slope,
engage first gear or set the
selector lever to position P
before removing the ignition
key. On an uphill slope, turn
the front wheels away from
the kerb.
If the vehicle is on a
downhill slope, engage
reverse gear or set the
(Continued)
Warning (Continued)
selector lever to position P
before removing the ignition
key. Turn the front wheels
towards the kerb.
. Remove the ignition key.
Turn the steering wheel until
the steering wheel lock is
felt to engage.
For vehicles with automatic
transmission, the key can
only be removed when the
selector lever is in
position P.
. Close the windows.
. Lock the vehicle with
Qon the
radio remote control.
. Activate the anti-theft alarm
system
0Anti-theft Alarm
System 024.
. The engine cooling fans may run
after the engine has been
switched off
0End-of-Life
Vehicle Recovery 0161.

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
70 Instruments and Controls
Flashes
After starting off when the seat belt
is unfastened.
Fastening the seat belt
0
Three-Point Seat belt036.
Airbag and Safety Belt
Tensioner Light
9
illuminates red.
When the ignition is switched on,
the control indicator illuminates for a
few seconds. If it does not
illuminate, does not go out after few
seconds or illuminates whilst
driving, there is a fault in the airbag
system. Seek the assistance of a
workshop. The airbags and belt
pretensioners may fail to trigger in
the event of an accident.
Deployment of the belt
pretensioners or airbags is indicated
by continuous illumination of
9.
{Warning
Have the cause of the fault
remedied immediately by a
workshop.
Seat belts, airbag system
0Seat
belts 035, Airbag System 038.
Airbag On-Off Light
/
illuminates yellow.
Illuminates for a few seconds after
the ignition is switched on. The front
passenger airbag is activated.
+illuminates yellow.
The front passenger airbag is
deactivated
0Airbag On-Off
Switch 043.
{Danger
Risk of fatal injury for a child
using a child restraint system
together with activated front
passenger airbag. Risk of fatal
(Continued)
Danger (Continued)
injury for an adult person with
deactivated front passenger
airbag.
Charging System Light
"
illuminates red.
Illuminates when the ignition is
switched on and extinguishes
shortly after the engine starts.
Illuminates when the engine is
running
Stop, switch off engine. Vehicle
battery is not charging. Engine
cooling may be interrupted. The
brake servo unit may cease to be
effective. Seek the assistance of a
workshop.
Malfunction
Indicator Lamp
*
illuminates or flashes yellow.
Illuminates when the ignition is
switched on and extinguishes
shortly after the engine starts.

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
130 Climate Controls
Fan speed
Adjust the air flow by switching the
fan to the desired speed.
Demisting and defrosting
.Turn the air distribution knob to
DEFROST
0.
. Set temperature control to
warmest level.
. Adjust the fan control knob to
highest speed for quick
defrosting.
. Switch on heated rear window
R
1.
. Open side air vents as required
and direct them towards the door
windows.
Note: If the settings for demisting
and defrosting are selected, an
Autostop will be inhibited.
If the settings for demisting and
defrosting are selected while the
engine is in an Autostop, the engine
will restart automatically. Note:
If mode knob is set on
Defrost mode
0, A/C operates and
Recirculation mode will be fixed to
outside air mode regardless of
indicator status.
Stop-start system
0Automatic
Engine Start/Stop Feature 0141.
Air Conditioning System
The air conditioning system has
controls for :
AC : Cooling
W:Air recirculation
Cooling
Press A/Cto switch on cooling.
Activation is indicated by the LED in
the button. Cooling is only functional
when the engine is running and
climate control fan is switched on.
Press A/Cagain to switch off
cooling. The air conditioning system
cools and dehumidifies (dries) as
soon as the outside temperature is
slightly above the freezing point.
Therefore condensation may form
and drip from under the vehicle.
If no cooling or drying is required,
switch off the cooling system for fuel
saving reasons. Activated cooling
might inhibit Autostops.
Air recirculation system
The air recirculation mode is
operated with
W. An indicator
light comes on to show that the
recirculation is on.
Press
Wagain to deactivate
recirculation mode.

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
Climate Controls 131
{Warning
Periodically turn to the outside air
mode for fresh air. The exchange
of fresh air is reduced in air
recirculation mode. In operation
without cooling the air humidity
increases, so the windows may
mist up. The quality of the
passenger compartment air
deteriorates, which may cause
the vehicle occupants to feel
drowsy.
In warm and very humid ambient air
conditions, the windscreen might
mist up from outside, when cold air
is directed to it. If windscreen mists
up from outside, activate
windscreen wiper and
deactivate
0.
Maximum cooling
Briefly open the windows so that hot
air can disperse quickly.
. Switch on cooling A/C.
. Switch on air recirculation
system
W.
. Press air distribution switch
E.
. Set temperature control to
coldest level.
. Set fan speed to highest level.
. Open all vents.
Demisting and defrosting the
windows
.Turn the air distribution knob to
DEFROST
0.
. Set temperature control to
warmest level.
. Adjust the fan control knob to
highest speed for quick
defrosting.
. Switch on heated rear window
R
1. .
Open side air vents as required
and direct them towards the door
windows.
Note: If
1is pressed while the
engine is running, an Autostop will
be inhibited until
1is pressed
again.
If
1is pressed while the engine is
in an Autostop, the engine will
restart automatically.
Note: If mode knob is set on
Defrost mode
1, A/C operates and
Recirculation mode will be fixed to
outside air mode regardless of
indicator status.
Stop-start system
0Automatic
Engine Start/Stop Feature 0141.

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
Climate Controls 133
Basic setting for maximum comfort:
.Press AUTO.
. Open all air vents to allow
optimised air distribution in
automatic mode.
. Press A/C to switch on optimal
cooling and demisting. Activation
is indicated by the LED in the
button.
. Set the desired temperature.
Temperature preselection
Temperatures can be set to the
desired value. If the minimum
temperature Lo is set, the climate
control system runs at maximum
cooling, if cooling A/C is switched
on. If the maximum temperature Hi
is set, the climate control system
runs at maximum heating.
Recommended temperature
is 22 °C.
Note: If A/C is switched on,
reducing the set cabin temperature
can cause the engine to restart from
an Autostop or inhibit an Autostop
0
Automatic Engine Start/Stop
Feature 0141.
Air recirculation system
The air recirculation mode is
operated with
W. An indicator
light comes on to show that the
recirculation is on.
Press
Wagain to deactivate
recirculation mode.
{Warning
Periodically turn to the outside air
mode for fresh air. The exchange
of fresh air is reduced in air
recirculation mode. In operation
without cooling the air humidity
increases, so the windows may
mist up. The quality of the
passenger compartment air
deteriorates, which may cause
the vehicle occupants to feel
drowsy.
Demisting and defrosting the
windows
. Press0. Activation is indicated
by the LED in the button. And
recirculation mode is to be set and to be fixed to outside air
mode, automatically. The air
conditioning system operated
but an indicator light is no
change.
. Temperature and air distribution
are set automatically and the fan
runs at high speed.
. Switch on heated rear window
R
1.
. To return to previous mode :
Press
0, to return to automatic
mode: press AUTO
Note: If
0is pressed while the
engine is running, an Autostop will
be inhibited until
0is pressed
again.
If
0is pressed while the engine is
in an Autostop, the engine will
restart automatically.
Stop-start system
0Automatic
Engine Start/Stop Feature 0141.

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
134 Climate Controls
Manual settings
Climate control system settings can
be changed by activating the
buttons and rotary knobs as follows.
Changing a setting will deactivate
the automatic mode.
Fan speed
Adjust the air flow by switching the
fan to the desired speed. The
selected fan speed is indicated by
the number of segments in the
display. If the fan is switched off the
air conditioning is also deactivated.
To return to automatic mode,
pressAUTO.
Air distribution
Press appropriate button for desired
adjustment. Activation is indicated
by the LED in the button.
E:To head area via adjustable air
vents.
): To head area and foot well.
[:To foot well, with a small
amount of the air being directed to
windscreen, front door windows and
side air vents.
-: To windscreen and foot well,
with a small amount of the air being
directed to front door windows and
side air vents.
0: To windscreen and front door
windows, with a small amount of the
air being directed to side air vents.
Return to automatic air distribution :
Press AUTO
Cooling
Press A/C to switch on cooling.
Activation is indicated by the LED in
the button. Cooling is only functional
when the engine is running and
climate control fan is switched on.
Press A/C again to switch off
cooling. The air conditioning system
cools and dehumidifies (dries) when
outside temperature is above a
specific level. Therefore

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
Climate Controls 135
condensation may form and drip
from under the vehicle. If no cooling
or drying is required, switch off the
cooling system for fuel saving
reasons.
Activated cooling might inhibit
Autostops
0Automatic Engine
Start/Stop Feature 0141.
Air recirculation system
PressWto activate air
recirculation mode. Activation is
indicated by the LED in the button.
Press
Wagain to deactivate
recirculation mode.
{Warning
The exchange of fresh air is
reduced in air recirculation mode.
In operation without cooling the
air humidity increases, so the
windows may mist up from inside.
The quality of the passenger
compartment air deteriorates,
which may cause the vehicle
occupants to feel drowsy. In warm and very humid ambient air
conditions, the windscreen might
mist up from outside, when cold air
is directed to it. If windscreen mists
up from outside, activate
windscreen wiper.
Maximum cooling
Briefly open the windows so that hot
air can disperse quickly.
.
Switch on cooling A/C.
. Switch on air recirculation
system
W.
. Press air distribution switch
E.
. Set temperature control to
coldest level.
. Set fan speed to highest level.
. Open all vents.
Air Vents
Adjustable Air Vents
At least one air vent must be open
while cooling is on in order to
prevent the evaporator from icing up
due to lack of air movement.
Direct the flow of air by tilting and
swivelling the slats. If you do not
want the flow, move the slats to
inside for centre vent and outside
for side vent. The vent has some air
leakages at closed position.

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
Climate Controls 137
Air Conditioning Regular
Operation
In order to ensure continuously
efficient performance, cooling must
be operated for a few minutes once
a month, irrespective of the weather
and time of year. Operation with
cooling is not possible when the
outside temperature is too low.
Service
For optimal cooling performance, it
is recommended to annually check
the climate control system.
.functionality and pressure test
. heating functionality
. leakage check
. check of drive belts
. cleaning of condenser and
evaporator drainage
. performance check

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
Vehicle Care 161
End-of-Life Vehicle
Recovery
Information on end-of-life vehicle
recovery centres and the recycling
of end-of-life vehicles is available on
our website. Only entrust this work
to an authorised recycling centre.
Gas vehicles must be recycled by a
service centre authorised for gas
vehicles.
Vehicle Checks
Doing Your Own
Service Work
{Warning
Only perform engine compartment
checks when the ignition is off.
The cooling fan may start
operating even if the ignition
is off.
{Danger
The ignition system uses
extremely high voltage. Do not
touch.
Bonnet
Opening
Pull the release lever and return it to
its original position.

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
Vehicle Care 163
We recommend the use of the same
grade of engine oil that was used at
last change.
The engine oil level must not
exceed theMAXmark on the
dipstick.
Caution
Overfilled engine oil must be
drained or suctioned out.
Capacities
0Capacities and
Specifications 0209.
Fit the cap on straight and tighten it.
Engine Coolant
The coolant provides freeze
protection down to approx. -28 °C.
In northern countries with very low
temperatures the factory filled
coolant provides frost protection
down to approx. -37 °C.
Caution
Only use approved antifreeze.
Coolant level
Caution
Too low a coolant level can cause
engine damage.
If the cooling system is cold, the
coolant level should be above the
filling line mark.
{Warning
Allow the engine to cool before
opening the cap. Carefully open
the cap, relieving the pressure
slowly.
To top up use a 1:1 mixture of
released coolant concentrate mixed
with clean tap water. If no coolant
concentrate is available, use clean
tap water. Install the cap tightly.
Have the coolant concentration
