length VAUXHALL VIVA 2015.75 Owner's Manual

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
Vehicle Care 185
Tyre damage exceeding 4 mm or
that is at tyre's side wall near the
rim cannot be repaired with the tyre
repair kit.
{Warning
Do not drive faster than 50 mph.
Do not use for a lengthy period.
Steering and handling may be
affected.
If you have a flat tyre :
Apply the parking brake.
For manual gearbox, engage first
gear or reverse gear.
The tyre repair kit is in the tool box
under the floor cover in the load
compartment. 1. Open the storage.
2. Remove the compressor and the sealant bottle.
3. Remove the electricalconnection cable (1) and air
hose (2) from the stowage
compartments on the
underside of the compressor.

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
208 Technical Data
Vehicle Weight
Kerb weight, Basic model without any optional equipment
Engine4 seater 5 seater
Without/without air
conditioning [kg] L5Q
938/947 939/945
Optional equipment and accessories increase the Kerb weight.
Loading information.
Vehicle Dimensions
Length [mm] 3675
Width without exterior mirrors [mm] 1595
Width with two exterior mirrors [mm] 1876
Height (without aerial) [mm] w/o roof rack 1485
Length of load compartment floor [mm] 486
Length of load compartment with folded rear seats [mm] 1109
Load compartment width [mm] 978
Load compartment height [mm] 522
Height of load compartment opening [mm] 608
Wheelbase [mm] 2385
Turning circle diameter [m] 9.6(14"), 10.4(15")
