window VAUXHALL VIVA 2015.75 Owner's Manual

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
ContentsIntroduction . . . . . . . . . . . . . . . . . . . . . . 2
In Brief . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Keys, Doors, and Windows . . . . . 18
Seats and Restraints . . . . . . . . . . . 31
Storage . . . . . . . . . . . . . . . . . . . . . . . . . 52
Instruments and Controls . . . . . . . 59
Lighting . . . . . . . . . . . . . . . . . . . . . . . . . 85
Infotainment System . . . . . . . . . . . . 92
Climate Controls . . . . . . . . . . . . . . 129
Driving and Operating . . . . . . . . . 138
Vehicle Care . . . . . . . . . . . . . . . . . . 159
Service and Maintenance . . . . . 198
Technical Data . . . . . . . . . . . . . . . . 205
Customer Information . . . . . . . . . 210
Index . . . . . . . . . . . . . . . . . . . . 213

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
10 In Brief
1. Infotainment system on pageOperation 099.
2. Info-Display on page Overview 093.
3. Hazard warning lights on page Hazard Warning Flashers 086.
4. Centre air vents on page Adjustable Air Vents 0135.
5. Turn and lane-change signals, headlight flash, dipped beam
and main beam on page
Indicator and Lane-Change
Signals 086.
Exit lighting on page Exit
Lighting 090.
Parking lights on page Parking
Lights 088.
6. Instruments on page Steering
Wheel Adjustment 060.
7. Driver Information Centre on page Driver Information Centre
(DIC) 075. 8. Cruise control, Speed limiter on
page Driver Assistance
Systems 0152.
Heated steering wheel on page
Heated Steering Wheel 060.
9. Windscreen wiper, Windscreen washer system, rear wiper, rear
washer system on page
Windscreen Wiper/
Washer 061.
10. Side air vents on page Fixed
Air Vents 0136.
11. Steering wheel controls on page Steering Wheel
Controls 060.
12. Exterior mirrors on page Convex Mirrors 026
13. Power windows on page Power
Windows 027.
Central locking system on page
Central Locking System 021. 14. Light switch,
Headlight range adjustment,
Front fog lights,
Rear fog light,
Instrument illumination on page
Exterior Lamp Controls 085.
15. Traction control system on page Traction Control System
(TCS) 0147.
Automatic engine start/stop on
page Automatic Engine Start/
Stop Feature 0141.
City mode on page Electronic
Stability Control (ESC) 0148.
Lane departure warning on
page Lane Departure Warning
(LDW) 0154.
16. Ignition switch with steering wheel lock on page Ignition
Positions 0139.
17. Fuse box on page Fuses 0173.
18. Bonnet release lever on page Bonnet 0161.

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
In Brief 13
Windscreen Wiper/
Washer
Windscreen wiper
2 :Fast
1 : Slow
3:Intermittent wiping
O : Off
For a single wipe when the
Windscreen wiper is off, press the
lever down to position 1x.
Windscreen wiper
0Windscreen
Wiper/Washer 061, Wiper blade replacement
0Wiper
Blade Replacement 0166.
Windscreen washer system
Pull lever.
Windscreen wiper
0Windscreen
Wiper/Washer 061,
Washer fluid
0Washer Fluid 0164.
Rear window wiper and
washer systems
Press the rocker switch to activate
the rear window wiper:
Upper position : Short interval
Lower position: Long interval
Middle position: Off

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
14 In Brief
Push lever.
Washer fluid is sprayed on the rear
window and the wiper wipes a few
times.
Rear window wiper/washer
0Rear
Window Wiper/Washer 062.
Climate Controls
Heated rear window, heated
exterior mirrors
The heating is operated by pressing
the
=.
Heated rear window
0Heated
Rear Window 029.
Demisting and defrosting the
windows
Press5.
Set the temperature control to the
highest level.
Heated rear window
=on.
Climate control system
0Heating
and Ventilation System 0129.

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
In Brief 15
Transmission
Manual gearbox
Reverse: with the vehicle stationary,
depress clutch pedal and engage
the gear.
If the gear does not engage, set the
lever to neutral, release the clutch
pedal and depress again; then
repeat gear selection.
Manual gearbox
0Manual
Gearbox 0145.
Starting the Engine
Check before starting off
.
Tyre pressure and condition0
Tyre Pressure 0179.
. Engine oil level and fluid levels
0Engine Oil 0162.
. All windows, mirrors, exterior
lighting and number plates are
free from dirt, snow and ice and
are operational.
. Proper position of mirrors, seats,
and seat belts
0Convex
Mirrors 026, Seat Position 033,
Three-Point Seat belt 036.
. Brake function at low speed,
particularly if the brakes are wet.
Starting the engine
.
Turn key to position 1.
. Move the steering wheel slightly
to release the steering
wheel lock.
. Operate clutch and brake.
. Automatic transmission in P
or N.
. Do not operate accelerator
pedal.
. Turn key to position 3 and
release Starting the engine.
0
Starting the Engine 0140.

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
16 In Brief
Stop-start system
If the vehicle is at a low speed or at
a standstill and certain conditions
are fulfilled, activate an Autostop as
follows:
.depress the clutch pedal
. set the lever in neutral
. release the clutch pedal
An Autostop is indicated by the
needle at the AUTOSTOP position
in the tachometer.
To restart the engine, depress the
clutch pedal again. Stop-start system
0Automatic
Engine Start/Stop Feature 0141.
Parking
{Warning
.
Do not park the vehicle on
an easily ignitable surface.
The high temperature of the
exhaust system could ignite
the surface.
. Always apply handbrake.
Pull switch
Yfor approx.
one second.
. Switch off the engine.
. surface or uphill slope,
engage first gear or set the
selector lever to position P
before removing the ignition
key. On an uphill slope, turn
the front wheels away from
the kerb.
If the vehicle is on a
downhill slope, engage
reverse gear or set the
(Continued)
Warning (Continued)
selector lever to position P
before removing the ignition
key. Turn the front wheels
towards the kerb.
. Remove the ignition key.
Turn the steering wheel until
the steering wheel lock is
felt to engage.
For vehicles with automatic
transmission, the key can
only be removed when the
selector lever is in
position P.
. Close the windows.
. Lock the vehicle with
Qon the
radio remote control.
. Activate the anti-theft alarm
system
0Anti-theft Alarm
System 024.
. The engine cooling fans may run
after the engine has been
switched off
0End-of-Life
Vehicle Recovery 0161.

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
18 Keys, Doors, and Windows
Keys, Doors, and
Windows
Keys and Locks
Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Car Pass . . . . . . . . . . . . . . . . . . . . . . 19
Radio Remote Control . . . . . . . . . 19
Memorised Settings . . . . . . . . . . . . 20
Central Locking System . . . . . . . 21
Automatic Door Locks . . . . . . . . . 23
Safety Locks . . . . . . . . . . . . . . . . . . . 23
Doors
Load Compartment . . . . . . . . . . . . 23
Vehicle Security
Anti-theft Alarm System . . . . . . . . 24
Immobiliser . . . . . . . . . . . . . . . . . . . . 25
Exterior Mirrors
Convex Mirrors . . . . . . . . . . . . . . . . 26
Power Mirrors . . . . . . . . . . . . . . . . . . 26
Folding Mirrors . . . . . . . . . . . . . . . . . 26
Heated Mirrors . . . . . . . . . . . . . . . . . 26
Interior Mirrors
Manual Rearview Mirror . . . . . . . . 27
Windows
Manual Windows . . . . . . . . . . . . . . 27
Power Windows . . . . . . . . . . . . . . . 27
Heated Rear Window . . . . . . . . . . 29
Sun Visors . . . . . . . . . . . . . . . . . . . . . 29
Roof
Sunroof . . . . . . . . . . . . . . . . . . . . . . . . 29
Keys and Locks
Keys
Replacement keys
The key number is specified on a
detachable tag.
The key number must be quoted
when ordering replacement keys as
it is a component of the immobiliser
system.
Locks
0Exterior Care0195.
Lock cylinders
Designed to free-wheel if they are
forcefully rotated without the correct
key or if the correct key is not fully
inserted. To reset, turn cylinder with
the correct key until its slot is
vertical, remove key and then
re-insert it. If the cylinder still
free-wheels, turn the key through
180° and repeat operation.

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
Keys, Doors, and Windows 19
Key with foldaway key section
Press button to extend.
To fold the key, first press the
button.
Car Pass
The Car Pass contains security
related vehicle data and should
therefore be kept in a safe place.
When the vehicle is taken to a
workshop, this data is required in
order to perform certain operations.
Radio Remote Control
Used to operate:
. central locking system
. anti-theft alarm system
The radio remote control has a
range of approx. 20 metres. It can
be restricted by external influences.
The hazard lights confirm operation.
Handle with care, protect from
moisture and high temperatures and
avoid unnecessary operation.
Fault
If the central locking system cannot
be operated with the radio remote
control, it may be due to the
following:
. Range exceeded,
. Battery voltage too low,
. Frequent, repeated operation of
the remote control while not in
range, which will require
resynchronisation,
. Overload of the central locking
system by operating at frequent
intervals, the power supply is
interrupted for a short time,
. Interference from higher-power
radio waves from other sources.
Unlocking
0Central Locking
System 021.
Radio remote control battery
replacement
Replace the battery as soon as the
range is reduced.

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
20 Keys, Doors, and Windows
Batteries do not belong in
household waste. They must be
disposed of at an appropriate
recycling collection point.
Key with foldaway key section
Extend the key and open the unit.
Replace the battery (battery type
CR 2032), paying attention to the
installation position. Close the unit
and synchronise.
Key with fixed key section
Have the battery replaced by a
workshop.
Radio remote control
synchronisation
After replacing the battery, unlock
the door with the key in the driver's
door lock. The radio remote control
will be synchronised when the
ignition is switched on.
Memorised Settings
Whenever the key is removed from
the ignition switch, the following
settings are automatically
memorised by the key:
.lighting
. infotainment system
. central locking system
. comfort settings
The saved settings are
automatically used the next time the
memorised key is inserted into the
ignition switch and turned to position
1
0Ignition Positions 0139.
A precondition is that
Personalisation by driver is
activated in the personal settings of
the Graphic-Info-Display.

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
Keys, Doors, and Windows 21
This must be set for each key used.
On vehicles equipped with
Colour-Info-Display, the
personalisation is permanently
activated.
Vehicle personalisation
0Vehicle
Personalisation 082.
Central Locking System
Unlocks and locks doors, load
compartment.
Note: In the event of an accident in
which airbags or belt pretensioners
are deployed, the vehicle is
automatically unlocked.
Unlocking
PressK.
. To unlock only the driver's door,
press
Konce. To unlock all
doors and the load
compartment, press
Ktwice,
or
. press
Konce to unlock all
doors, load compartment.
The setting can be changed in the
menu Settings in the Info-Display.
Vehicle personalisation
0Vehicle
Personalisation 082. The setting can be saved for the
key being used.
Memorised settings
0Memorised
Settings 020.
Locking
Close doors, load compartment and
fuel filler flap.
PressQ.
If the driver's door is not closed
properly, the central locking system
will not work.
