display VAUXHALL VIVA 2019 Owner's Manual

Introduction3Vehicle specific dataPlease enter your vehicle's data on
the previous page to keep it easily
accessible. This information is
available in the sections "Service and
maintenance" and "Technical data"
as well as on the identification plate.
Introduction
Your vehicle is a designed
combination of advanced technology, safety, environmental friendliness
and economy.
This Owner's Manual provides you
with all the necessary information to
enable you to drive your vehicle
safely and efficiently.
Make sure your passengers are
aware of the possible risk of accident
and injury which may result from
improper use of the vehicle.
You must always comply with the
specific laws and regulations of the
country that you are in. These laws
may differ from the information in this Owner's Manual.
Disregarding the description given in
this manual may affect your warranty.When this Owner's Manual refers to a
workshop visit, we recommend your
Vauxhall Authorised Repairer.
For gas vehicles, we recommend a
Vauxhall Authorised Repairer
licensed to service gas vehicles.
All Vauxhall Authorised Repairers
provide first-class service at
reasonable prices. Experienced
mechanics trained by Vauxhall work according to specific Vauxhall
instructions.
The customer literature pack should
always be kept ready to hand in the
vehicle.
Using this manual ● This manual describes all options
and features available for this
model. Certain descriptions,
including those for display and
menu functions, may not apply to
your vehicle due to model
variant, country specifications,
special equipment or
accessories.
● The "In brief" section will give you
an initial overview.● The table of contents at the beginning of this manual and
within each section shows where the information is located.
● The index will enable you to search for specific information.
● This Owner's Manual depicts left-
hand drive vehicles. Operation is similar for right-hand drive
vehicles.
● The Owner's Manual uses the engine identifier code. The
corresponding sales designation
can be found in the section
"Technical data".
● Directional data, e.g. left or right, or front or back, always relate to
the direction of travel.
● Displays may not support your specific language.
● Display messages and interior labelling are written in bold
letters.

In brief111Central locking system ..........20
Power windows .....................28
2 Exterior mirrors .....................26
3 Cruise control .....................115
Speed limiter ...................... 116
Heated steering wheel ..........58
4 Turn lights, headlight
flash, low beam and high
beam ..................................... 90
Exit lighting ........................... 92
Parking lights ........................ 91
5 Side air vents ...................... 100
6 Instruments .......................... 62
7 Driver Information Centre ...... 73
8 Steering wheel controls .......58
9 Windscreen wiper,
windscreen washer
system, rear window
wiper, rear window washer
system ................................... 59
10 Centre air vents .................. 100
11 Hazard warning flashers ......89
12 Info Display ........................... 7813Anti-theft alarm system
status LED ........................... 25
14 Infotainment system
15 Glovebox .............................. 50
16 Climate control system .......... 94
17 AUX input, USB input
18 Selector lever .....................109
19 Seat heating .......................... 35
20 Parking brake ......................111
21 Ignition switch with
steering wheel lock ............103
22 Horn ..................................... 59
Driver airbag ........................ 41
23 Bonnet release lever ..........126
24 Steering wheel adjustment ..58
25 Fuse box ............................ 141
26 Traction Control system .....112
City mode ............................ 113
Stop-start system ................105
Lane departure warning .....119
Electronic Stability Control . 11327 Light switch .......................... 88
Headlight range
adjustment ........................... 89
Front fog light ........................ 90
Rear fog light ........................ 90
Brightness of instrument
panel illumination ..................91

20Keys, doors and windows
Batteries do not belong in household
waste. They must be disposed of at
an appropriate recycling collection
point.
Key with foldaway key section
Press button to extend the key.
Open the unit. Replace the battery
(battery type CR 2032), paying
attention to the installation position.
Close the unit and synchronise.
Memorised settings
Whenever the ignition is switched off,
some functions of the following
settings may be automatically
memorised by the remote control unit:
● lighting
● presets for Infotainment system ● central locking system
● comfort settings
The saved settings are automatically
used the next time the memorised key
is inserted into the ignition switch and
turned to position 1 3 103.
A precondition is that Personalization
By Driver is activated in the personal
settings of the Info Display.
This must be set for each key used.
Vehicle personalisation 3 81.
Central locking system
Unlocks and locks doors and load
compartment.
Notice
In the event of an accident in which
airbags or belt pretensioners are
deployed, the vehicle is
automatically unlocked.

Keys, doors and windows21Unlocking
Press c.
Two settings are selectable in the
Info Display:
● To unlock only the driver's door, press c once. To unlock all doors
and load compartment, press c
twice.
● Press c once to unlock all doors
and load compartment.
The setting can be changed in the
menu Settings in the Info Display.
Vehicle personalisation 3 81.
The setting can be saved for the key being used.
Memorised settings 3 20.
Locking
Close doors and load compartment.
Press e.
If the driver's door is not closed
properly, the central locking system will not work.
Central locking buttons Locks or unlocks doors and the load
compartment from inside the
passenger compartment.
Press e to lock.
Press c to unlock.

34Seats, restraints
● Sit with buttocks as far backagainst the backrest as possible.
Adjust the distance between the
seat and the pedals so that legs
are slightly angled when fully
pressing the pedals. Slide the
front passenger seat as far back
as possible.
● Set seat height high enough to have a clear field of vision on all
sides and of all display
instruments. There should be at
least one hand of clearance
between head and the roof
frame. Your thighs should rest
lightly on the seat without
pressing into it.
● Sit with shoulders as far back against the backrest as possible.
Set the backrest rake so that it is possible to easily reach the
steering wheel with arms slightly
bent. Maintain contact between
shoulders and the backrest when
turning the steering wheel. Do
not angle the backrest too far
back. We recommend a
maximum rake of approx. 25°.
● Adjust seat and steering wheel in
a way that the wrist rests on top
of the steering wheel while the
arm is fully extended and
shoulders on the backrest.
● Adjust the steering wheel 3 58.
● Adjust the head restraint 3 32.
● Adjust the seat belt 3 37.
Seat adjustment
Drive only with engaged seats and backrests.Longitudinal adjustment
Pull handle, slide seat, release
handle. Try to move the seat back and forth to ensure that the seat is locked
in place.

Instruments and controls57Instruments and
controlsControls ....................................... 58
Steering wheel adjustment ........58
Steering wheel controls .............58
Heated steering wheel ...............58
Horn ........................................... 59
Windscreen wiper and washer ..59
Rear window wiper and washer ...................................... 60
Outside temperature ..................60
Clock ......................................... 60
Power outlets ............................. 62
Cigarette lighter ......................... 62
Ashtrays .................................... 62
Warning lights, gauges and indi‐ cators ........................................... 62
Instrument cluster ......................62
Speedometer ............................. 62
Odometer .................................. 63
Trip odometer ............................ 63
Tachometer ............................... 63
Fuel gauge ................................ 63
Engine coolant temperature gauge ....................................... 64
Service display .......................... 64Control indicators ......................65
Turn lights .................................. 67
Seat belt reminder .....................68
Airbag and belt tensioners .........68
Airbag deactivation ....................68
Charging system .......................69
Malfunction indicator light ..........69
Service vehicle soon .................69
Brake and clutch system ...........69
Operate pedal ............................ 69
Antilock brake system (ABS) .....70
Gear shifting .............................. 70
Power steering .......................... 70
Lane departure warning ............70
Parking assist ............................ 70
Electronic Stability Control off ...70
Electronic Stability Control and Traction Control system ...........70
Traction Control system off .......71
Engine coolant temperature ......71
Tyre pressure monitoring system ...................................... 71
Engine oil pressure ....................71
Low fuel ..................................... 72
Immobiliser ................................ 72
Reduced engine power .............72
Exterior light .............................. 72
High beam ................................. 72
Front fog lights ........................... 72
Rear fog light ............................. 72Cruise control............................ 72
Speed limiter ............................. 72
Bonnet open .............................. 72
Door open .................................. 73
Displays ....................................... 73
Driver Information Centre ..........73
Info Display ................................ 78
Vehicle messages ........................79
Warning chimes .........................81
Battery voltage .......................... 81
Vehicle personalisation ................81
Telematics service .......................84
OnStar ....................................... 84

60Instruments and controlsRear window wiper andwasher
Press the rocker switch to activate the
rear window wiper:
upper position:continuous
operationlower position:intermittent
operationmiddle position:off
Push lever. Washer fluid is sprayed
onto the rear window and the wiper
wipes a few times.
Do not use if the rear window is
frozen.
Switch off in car washes.
The rear window wiper comes on
automatically when the windscreen
wiper is switched on and reverse gear
is engaged.
Activation or deactivation of this
function can be changed in the menu Settings in the Info Display.
Washer fluid 3 129.
Vehicle personalisation 3 81.
Outside temperature
A drop in temperature is indicated
immediately and a rise in temperature
after a time delay.9 Warning
The road surface may already be
icy even though the display
indicates a few degrees above 0
°C.
Clock
Date and time are shown in the
Info Display.
Info Display 3 78.

Instruments and controls61Graphic Info DisplayPress MENU to open the respective
audio menu.
Select Time and Date .
Set Time
Select Set Time to enter the
respective submenu.
Select Auto Set at the bottom of the
screen. Activate either On - RDS or
Off (Manual) .
If Off (Manual) is selected, adjust
hours and minutes.
Repeatedly select 12-24 HR at the
bottom of the screen to choose a time mode.
If the 12-hour mode is selected, a
third column for AM and PM selection
is displayed. Select the desired
option.
Set Date
Select Set Date to enter the
respective submenu.
Select Auto Set at the bottom of the
screen. Activate either On - RDS or
Off (Manual) .
If Off (Manual) is selected, adjust the
date settings.
7'' Colour Info Display
Press ; and then select Settings.
Select Time and Date to display the
respective submenu.Set Time Format
To select the desired time format,
touch the screen buttons 12 h or 24 h .
Set Date Format
To select the desired date format,
select Set Date Format and choose
between the available options in the
submenu.
Auto Set
To choose whether time and date are
to be set automatically or manually,
select Auto Set .
For time and date to be set
automatically, select On - RDS.
For time and date to be set manually, select Off - Manual . If Auto Set is set
to Off - Manual , the submenu items
Set Time and Set Date become
available.
Set time and date
To adjust the time and date settings, select Set Time or Set Date .
Touch + or - to adjust the settings.

Instruments and controls63Odometer
The bottom line displays the recordeddistance in miles.
Trip odometer The recorded distance is displayedsince the last reset.
Trip odometer counts up to
9999.9 miles and then restarts at 0.
To reset, press SET/CLR on the stalk
for a few seconds 3 73.
Tachometer
Displays the engine speed.
Drive in a low engine speed range for each gear as much as possible.
Caution
If the needle is in the red warning
zone, the maximum permitted
engine speed is exceeded. Engine at risk.
Fuel gauge
Number of LEDs displays the level in
the fuel tank.
The arrow indicates the vehicle side
where the fuel filler flap is located.

64Instruments and controls
Control indicator Y illuminates if the
level in the tank is low. Refuel
immediately if it flashes.
Never run the fuel tank dry.
Because of the fuel remaining in the
tank, the top-up quantity may be less
than the specified tank capacity.
Engine coolant temperature
gauge
Number of LEDs displays the coolant temperature.
up to 2 LEDs:engine operating
temperature not
yet reached3 to 6 LEDs:normal operating
temperaturemore than 6
LEDs:temperature too
highCaution
If engine coolant temperature is
too high, stop vehicle, switch off
engine. Danger to engine. Check
coolant level.
Service display
The engine oil life system informs
when to change the engine oil and
filter. Based on driving conditions, the interval at which an engine oil and
filter change will be indicated can vary
considerably.
When the system has calculated that
engine oil life has been diminished, a warning message appears in theDriver Information Centre. Have
engine oil and filter changed by a
workshop within one week or
300 miles, whichever occurs first.
This can be an additional engine oil
and filter change or part of a regular
service.
