display VAUXHALL VIVARO 2014.5 Owner's Guide

150Vehicle care
Incorrect tyre pressures will impair
safety, vehicle handling, comfort and
fuel economy and will increase tyre
wear.
The tyre pressure tables show all
possible tyre combinations 3 178.
For the tyres approved for your
vehicle, refer to the EEC Certificate of Conformity provided with your vehicle
or other national registration
documents.
The driver is responsible for correct
adjustment of tyre pressure.9 Warning
If the pressure is too low, this can
result in considerable tyre warm-
up and internal damage, leading to tread separation and even to tyre
blow-out at high speeds.
Tyre pressure monitoring
system
The tyre pressure monitoring system
checks the pressure of all four wheels once a minute when vehicle speed
exceeds a certain limit.Caution
Tyre pressure monitoring system
warns only about low tyre pressure
condition and does not replace
regular tyre maintenance by the
driver.
All wheels must be equipped with pressure sensors and the tyres must
have the prescribed pressure.
Notice
In countries where the tyre pressure
monitoring system is legally
required, the use of wheels without
pressure sensors will invalidate the
vehicle type approval.
Tyre pressures in display
The current tyre pressures can be
shown in the Driver Information
Centre 3 86.
With the vehicle stationary, press
button on end of wiper lever
repeatedly until the tyre pressure
menu is displayed.

Vehicle care151
Low tyre pressure condition
A detected low tyre pressure
condition is indicated by illumination
of control indicator w 3 84 and a
corresponding message appears in
the Driver Information Centre.
If w illuminates, stop as soon as
possible and inflate the tyres as
recommended 3 178.
After inflating, driving may be
required to update the tyre pressure
values in the Driver Information
Centre. During this time w may
illuminate.
If w illuminates at lower temperatures
and extinguishes after some driving,
this could be an indicator for getting low pressure. Check tyre pressure.
If the tyre pressure must be reduced
or increased, switch off ignition.
Only mount wheels with pressure
sensors, otherwise the tyre pressure
will not be displayed and w flashes for
several seconds then illuminates continuously together with a
corresponding message in the Driver
Information Centre.
A spare wheel or temporary spare
wheel is not equipped with pressure
sensors. The tyre pressure
monitoring system is not operational
for these wheels. For the further three wheels, the system remains
operational.
Control indicator w and the
corresponding message appears at
each ignition cycle until the tyres are
inflated to the correct tyre pressure.
Driver Information Centre 3 86.
Vehicle messages 3 87.Puncture
A puncture or severely under-inflated
tyre is indicated by illumination of
control indicator w together with F
3 82 and a corresponding message
appears in the Driver Information
Centre.
Tyre pressure 3 178, Tyre repair kit
3 154, Spare wheel 3 158, Wheel
changing 3 157.
Temperature dependency
Tyre pressure depends on the
temperature of the tyre. During
driving, tyre temperature and
pressure increase.
The tyre pressure value displayed in
the Driver Information Centre shows
the actual tyre pressure. Therefore it
is important to check tyre pressure
with cold tyres.

152Vehicle care
Relearn function
After changing wheels, the system
needs to recalculate.
With the vehicle stationary, select the tyre pressure menu in the Driver
Information Centre by pressing button
on end of wiper lever. Press and hold button for approx. 3 seconds to
initialise recalculation. A
corresponding message appears in
the Driver Information Centre.
Several minutes of driving may be
required to complete the relearn
process.
If problems occur during the relearn
process, a warning message is
displayed in the Driver Information
Centre.
Driver Information Centre 3 86.
Vehicle messages 3 87.
General information The use of commercially available
liquid tyre repair kits can impair the
function of the system. Factory-
approved repair kits can be used.
Tyre repair kit 3 154.
External high-power radio equipment
could disrupt the tyre pressure
monitoring system.
Each time the tyres are replaced, tyre
pressure monitoring system sensors
must be dismounted and serviced by a workshop.
Tread depth
Check tread depth at regular
intervals.
Tyres should be replaced for safety
reasons at a tread depth of 2-3 mm
(4 mm for winter tyres).For safety reasons it is recommended
that the tread depth of the tyres on
one axle should not vary by more than
2 mm.
The legally permissible minimum
tread depth (1.6 mm) has been
reached when the tread has worn
down as far as one of the tread wear
indicators (TWI). Their position is
indicated by markings on the
sidewall.
If there is more wear at the front than
the rear, swap round front wheels and
rear wheels. Ensure that the direction
of rotation of the wheels is the same
as before.

164Vehicle care
Paintwork damageRectify minor paintwork damage with
a touch-up pen before rust forms.
Have more extensive damage or rust
areas repaired by a workshop.
UnderbodySome areas of the vehicle underbody
have a PVC undercoating while other
critical areas have a durable
protective wax coating.
After the underbody is washed, check
the underbody and have it waxed if
necessary.
Bitumen/rubber materials could
damage the PVC coating. Have
underbody work carried out by a
workshop.
Before and after winter, wash the
underbody and have the protective
wax coating checked.
Towing equipment
Do not clean the coupling ball bar with a steam-jet or high-pressure jet
cleaner.Interior care
Interior and upholstery
Only clean the vehicle interior,
including the instrument panel fascia
and panelling, with a dry cloth or
interior cleaner.
Clean any leather upholstery with
clear water and a soft cloth. In case of heavy soiling, use leather care.
The instrument cluster and the
displays should only be cleaned using
a soft damp cloth. If necessary use a
weak soap solution.
Clean fabric upholstery with a
vacuum cleaner and brush. Remove
stains with an upholstery cleaner.
Clothing fabrics may not be
colourfast. This could cause visible
discolourations, especially on light- coloured upholstery. Removable
stains and discolourations should be
cleaned as soon as possible.
Clean seat belts with lukewarm water or interior cleaner.Caution
Close Velcro fasteners as open
Velcro fasteners on clothing could damage seat upholstery.
The same applies to clothing with
sharp-edged objects, like zips or
belts or studded jeans.
Plastic and rubber parts
Plastic and rubber parts can be
cleaned with the same cleaner as
used to clean the body. Use interior cleaner if necessary. Do not use any
other agent. Avoid solvents and petrol in particular. Do not use high-
pressure jet cleaners.

Service and maintenance165Service and
maintenanceGeneral information ...................165
Recommended fluids, lubricants and parts .................................... 166General information
Service information In order to ensure economical and
safe vehicle operation and to
maintain the value of your vehicle, it
is of vital importance that all
maintenance work is carried out at the proper intervals as specified.
The detailed, up-to-date service
schedule for the vehicle is available at
the workshop.
Service display 3 78.
Engine identification 3 169.
European service intervals
Maintenance of your vehicle is
required every 25,000 miles or after
2 years, whichever occurs first,
unless otherwise indicated by the
service display.
Confirmations
Confirmation of service is recorded in the Service and Warranty Booklet.
The date and mileage is completed
with the stamp and signature of the
servicing workshop.Make sure that the Service and
Warranty Booklet is completed
correctly as continuous proof of
service is essential if any warranty or goodwill claims are to be met, and is
also a benefit when selling the
vehicle.
Service display
The service interval is based on several parameters depending on
usage.
The service display, located in the
Driver Information Centre, indicates
when the next service is due. Seek
the assistance of a workshop.
Service display 3 78.

168Technical dataTechnical dataVehicle identification..................168
Vehicle data ............................... 171Vehicle identification
Vehicle Identification
Number
The Vehicle Identification Number is
visible through the windscreen.
The VIN is also displayed behind a
removable plastic cover on the right-
hand side door step.

184
HHand brake - see Parking brake. 118
Hazard warning flashers ..............93
Headlight flash ............................. 92
Headlight range adjustment ........92
Headlights ...................... 91, 92, 139
Headlights when driving abroad ..92
Head restraint adjustment .............8
Head restraints ............................ 40
Heated mirrors ............................. 36
Heated rear window ..................... 38
Heating ........................................ 44
Heating and ventilation system ...97
High beam ............................. 85, 92
Hill start assist ........................... 118
Horn ....................................... 14, 72
I
Identification plate .....................169
Idle speed control .......................112
Ignition switch positions .............109
Immobiliser .................................. 34
Indicators ...................................... 76
Info-display ................................... 86
Information displays...................... 86
Initial drive information.................... 6 Instrument panel fuse box .........145
Instrument panel illumination .....144Instrument panel illumination
control ...................................... 94
Instrument panel overview ........... 10
Instrument panel storage ..............64
Interior care ............................... 164
Interior lighting .............................. 94
Interior lights ........................ 94, 143
Interior mirrors .............................. 36
Introduction .................................... 3
Isofix child restraint systems ........ 63
J
Jack ............................................ 148
Jump starting ............................. 159
K Keys ............................................. 19
Keys, locks ................................... 19
L
Lashing eyes ............................... 67
Light covers, misted...................... 94
Lighting ......................................... 91
Lighting features ........................... 95
Light switch .................................. 91
Load compartment ....................... 30
Load compartment cover .............66
Load compartment lighting ...........95
Loading information .....................69Load rails and hooks ...................67
Low fuel ....................................... 85
M
Malfunction indicator light ............82
Manual adjustment ......................35
Manual anti-dazzle ......................36
Manual transmission .................. 116
Messages ..................................... 87
Mirror adjustment ........................... 8
Mirrors .................................... 35, 36
Misted light covers .......................94
N New vehicle running-in ..............109
Number plate light .....................142
O
Object detection systems ...........124
Octane rating .............................. 172
Odometer ..................................... 77
Oil ............................................... 133
Oil, engine .......................... 166, 171
Oil pressure .................................. 84
Outside temperature ....................74
Overcab storage ..........................66
Overrun cut-off ........................... 113

185
PParking ................................ 18, 115
Parking assist ............................ 124
Parking brake ............................ 118
Particulate filter ........................... 115
Performing work ........................132
Pollen filter ................................. 107
Power button .............................. 110
Power outlets ............................... 75
Power steering fluid ....................135
Power windows ............................ 37
Preheating ................................... 84
Puncture ..................................... 157
R
Radio Frequency Identification (RFID) ..................................... 180
Radio remote control ...................19
Rear air conditioning system .....101
Rear doors ................................... 29
Rear fog light ............................... 85
Rear fog lights ............................. 93
Rear heating system .................. 101
Rear seats .................................... 44
Rear view camera ...................... 125
Rear windows .............................. 38
Rear window wiper/washer .......... 73
Recommended fluids and lubricants ........................ 166, 171Refuelling ................................... 127
Remote control ............................. 19
Reversing light ........................... 142
Reversing lights ........................... 94
Roof load ...................................... 69
Roof rack ..................................... 69
S Safety belts ................................... 47
Safety net .................................... 68
Seat adjustment ....................... 7, 42
Seat belt ........................................ 8
Seat belt reminder .......................81
Seat belts ..................................... 47 Seat heating ................................. 44
Seat position ................................ 41
Service ............................... 107, 165
Service display ............................ 78
Service information ....................165
Service vehicle soon .................... 82
Side airbag system ......................54
Sidelights ...................................... 91
Side turn signal lights ................141
Sliding door .................................. 29
Spare wheel ............................... 158
Spare wheel security tool ...........148
Speed limiter............................... 123
Speedometer ............................... 76
Starting and operating ................109
Starting off ................................... 16Starting the engine ....................111
Steering ...................................... 109
Steering column controls ..............72
Steering wheel adjustment ......9, 71
Steering wheel controls ...............71
Stop engine .................................. 82
Stop-start system........................ 113
Storage ......................................... 64
Storage compartments .................64
Sun visors .................................... 39
Symbols ......................................... 4
T
Tachograph .................................. 90
Tachometer ................................. 77
Tailgate ......................................... 30
Tail lights ................................... 141
Technical data ............................ 172
Three-point seat belt .................... 48
Tools .......................................... 148
Top-tether fastening eyes ............63
Torx key ...................................... 148
Tow bar....................................... 129
Towing ................................ 129, 161
Towing another vehicle .............162
Towing a trailer ........................... 129
Towing eye ......................... 148, 161
Towing the vehicle .....................161
Traction Control system ............. 118
Trailer coupling ........................... 129
