Driving and operating99
Rocking the vehicle
Rocking the vehicle is only
permissible if the vehicle is stuck in
sand, mud, snow or a hole. Move the
selector lever between R and A/M (or
between + and -) in a repeat pattern,
while applying light pressure to the
accelerator pedal. Do not race the
engine and avoid sudden
acceleration.
Parking
Apply the parking brake. The most
recently engaged gear (see
transmission display) remains
engaged. With N, no gear is engaged.
When the ignition is switched off, the
transmission no longer responds to
movement of the selector lever.
Manual mode
If a higher gear is selected when the
engine speed is too low, or a lower
gear when the speed is too high, the
shift is not executed. This prevents
the engine from running at too low or too high an engine speed.If engine speed is too low, the
transmission automatically shifts to a
lower gear.
If engine speed is too high, the
transmission only switches to a higher gear via kickdown.
Electronic driving
programmes
Winter mode V
Activate the Winter mode if you have
problems starting off on a slippery
road surface.
Activation
Press the V button. V is shown in the
transmission display. The
transmission switches to automatic
mode and the vehicle starts off in a
suitable gear.
Deactivation
The Winter mode is switched off by:
■ pressing the V button again,
■ turning off the ignition,
■ switching to manual mode.
In order to protect the transmission at extremely high clutch temperatures,
an intermittent audible warning may
sound. In such cases, depress the
foot brake, select "N" and apply the
parking brake to allow the clutch to
cool down.

100Driving and operating
Laden mode kg
It is possible to use the Laden mode
in both manual and automatic modes. In both cases, the gear shifting
patterns are adapted automatically
for carrying an increased payload.
Activation
Press the kg button. kg is shown in the
transmission display. The
transmission will then select
optimized gear shift patterns.
Deactivation
The Laden mode is switched off by:
■ pressing the kg button again,
■ turning off the ignition.
Kickdown If the accelerator pedal is pressed
past the pressure point, the
transmission shifts to a lower gear depending on engine speed. Full
engine power is available for
acceleration.
If engine speed is too high the
transmission switches to a higher
gear, even in manual mode. Without
kickdown this automatic shift is not
effected in manual mode.
Fault
In the event of a fault, W is shown in
the transmission display. Continued driving is possible provided the
vehicle is driven with care and
anticipation.
Have the cause of the fault remedied
by a workshop.Interruption of power
supply
The clutch is not disengaged if there is an interruption of the power supply
when a gear is engaged. The vehicle
cannot move.
If the vehicle battery is discharged,
start the vehicle using jump leads
3 139.
If the cause of the fault is not a
discharged vehicle battery, seek the
assistance of a workshop.
If neutral cannot be selected, the
vehicle must only be towed with the
drive wheels raised off the ground.
Towing the vehicle 3 141.

110Driving and operatingCaution
Use of fuel that does not comply toEN 228 or E DIN 51626-1 or
equivalent can lead to deposits or
engine damage and may affect
your warranty.
Caution
Use of fuel with too low an octane
rating could lead to uncontrolled combustion and engine damage.
Fuel for diesel engines
Only use diesel fuel that complies
with EN 590.
In countries outside the European
Union use Euro-Diesel fuel with a
sulphur concentration below 50 ppm.
Caution
Use of fuel that does not comply to EN 590 or similar can lead to
engine powerloss, increased wear
or engine damage and may affect
your warranty.
Do not use marine diesel oils, heating
oils, Aquazole and similar diesel-
water emulsions. Diesel fuels must
not be diluted with fuels for petrol
engines.
Refuelling
9 Danger
Before refuelling, switch off engine
and any external heaters with
combustion chambers (identified
by sticker on fuel filler flap). Switch off any mobile phones.
Follow the operating and safety
instructions of the filling station
when refuelling.
9 Danger
Fuel is flammable and explosive.
No smoking. No naked flames or
sparks.
If you can smell fuel in your
vehicle, have the cause of this
remedied immediately by a
workshop.
Caution
In case of misfuelling, do not
switch on ignition.
Notice
To ensure the fuel level is displayed
correctly, the ignition must be
switched off before refuelling. Avoid
minor fuel top-ups (e.g. less than
5 litres) to ensure accurate readings.
The fuel tank filler neck with bayonet
cap is located on the left hand side of
the vehicle.
The fuel filler flap can only be opened
if the vehicle is unlocked.

Vehicle care119
Remove the caps and ensure funnel
is securely located onto the filler pipe.
Ensure the funnel is replaced
securely together with both end caps
fitted.
A stabilization of the engine oil
consumption will not take place until
the vehicle has been driven several
thousand miles. Only then can the
actual degree of consumption be
established.
If consumption exceeds more than 0.5 litres every 600 miles after this
running-in period, consult a
workshop.
Capacities 3 162, Engine oil level
monitor 3 67.
Fit the cap on straight and tighten it.
Engine air filter Engine air flow indicator
On certain models, an indicator is
located in the engine induction
system and indicates if the air-intake
to the engine is restricted.
Clear=No restrictionRed tell-tale=RestrictedIf the red tell-tale is displayed when
the engine is running, consult a
workshop.
Engine coolant
The coolant provides freeze
protection down to approx. -28 °C.Caution
Only use approved antifreeze.
Coolant level
Caution
Too low a coolant level can cause engine damage.

Vehicle care145
The instrument cluster and the
displays should only be cleaned using
a soft damp cloth. If necessary use a
weak soap solution.
Clean fabric upholstery with a
vacuum cleaner and brush. Remove
stains with an upholstery cleaner.
Clothing fabrics may not be
colourfast. This could cause visible
discolourations, especially on light-
coloured upholstery. Removable
stains and discolourations should be
cleaned as soon as possible.
Clean seat belts with lukewarm water or interior cleaner.Caution
Close Velcro fasteners as open
Velcro fasteners on clothing could damage seat upholstery.
The same applies to clothing with
sharp-edged objects, like zips or
belts or studded jeans.
Plastic and rubber parts
Plastic and rubber parts can be
cleaned with the same cleaner as
used to clean the body. Use interior cleaner if necessary. Do not use any
other agent. Avoid solvents and petrol in particular. Do not use high-
pressure jet cleaners.

146Service and maintenanceService and
maintenanceGeneral information ...................146
Recommended fluids, lubricants and parts .................................... 147General information
Service information In order to ensure economical and
safe vehicle operation and to
maintain the value of your vehicle, it
is of vital importance that all
maintenance work is carried out at the proper intervals as specified.
The detailed, up-to-date service
schedule for the vehicle is available at
the workshop.
Service display 3 67.
Engine identification 3 150.
Service intervals - M9R 630 and
M9R 692 engines only Maintenance of your vehicle is
required every 25,000 miles or after
2 years, whichever occurs first,
unless otherwise indicated by the
service display.Service intervals - except
M9R 630 and M9R 692 engines
Maintenance of your vehicle is
required every 20,000 miles or after
2 years, whichever occurs first,
unless otherwise indicated by the
service display.
Confirmations
Confirmation of service is recorded in the Service and Warranty Booklet.
The date and mileage is completed
with the stamp and signature of the
servicing workshop.
Make sure that the Service and
Warranty Booklet is completed
correctly as continuous proof of
service is essential if any warranty or goodwill claims are to be met, and is
also a benefit when selling the
vehicle.
Service display The service interval is based on
several parameters depending on
usage.

Service and maintenance147
The service display, located in the
Driver Information Centre, indicates
when the next service is due. Seek
the assistance of a workshop.
Service display 3 67.
Engine oil level monitor 3 67.Recommended fluids,
lubricants and parts
Recommended fluids andlubricants Only use products that meet the
recommended specifications.
Damage resulting from the use of
products not in line with these
specifications will not be covered by
the warranty.9 Warning
Operating materials are
hazardous and could be
poisonous. Handle with care. Pay
attention to information given on
the containers.
Engine oil
Engine oil is identified by its quality
and its viscosity. Quality is more
important than viscosity when
selecting which engine oil to use. The oil quality ensures e.g. engine
cleanliness, wear protection and oil
aging control, whereas viscosity
grade gives information on the oil's
thickness over a temperature range.
Dexos is the newest engine oil quality
that provides optimum protection for
petrol and diesel engines. If it is
unavailable, engine oils of other listed qualities have to be used.
Select the appropriate engine oil
based on its quality and on the
minimum ambient temperature
3 152.
Topping up engine oil
Engine oils of different manufacturers
and brands can be mixed as long as
they comply with the required engine oil quality and viscosity.
Use of engine oil with only
ACEA A1/B1 or only A5/B5 quality is
prohibited, since it can cause long-
term engine damage under certain
operating conditions.
Select the appropriate engine oil
based on its quality and on the
minimum ambient temperature
3 152.

Technical data149Technical dataVehicle identification..................149
Vehicle data ............................... 152Vehicle identification
Vehicle Identification
Number
The Vehicle Identification Number is
visible through the windscreen.
The VIN is also displayed behind a
removable plastic cover on the right
hand side door step.

168
I
Identification plate .....................150
Ignition switch positions ...............94
Immobiliser .................................. 27
Indicators ...................................... 65
Information displays...................... 74
Instrument panel fuse box .........129
Instrument panel illumination .....128
Instrument panel overview ........... 10
Instrument panel storage ..............55
Interior care ............................... 144
Interior lights ........................ 82, 127
Interior mirrors .............................. 29
Interruption of power supply ......100
Introduction .................................... 3
Isofix child restraint systems ........ 54
J Jump starting ............................. 139
K Keys ............................................. 18
Keys, locks ................................... 18
L
Lashing eyes ............................... 57
Light covers, misted...................... 82
Lighting ......................................... 79
Light switch .................................. 79
Load compartment ....................... 25Load compartment cover .............56
Load compartment lighting ..........82
Loading information .....................58
Load rails and hooks ...................57
Low fuel ....................................... 73
M Malfunction indicator light ............71
Manual adjustment ......................28
Manual anti-dazzle ......................29
Manual mode ............................... 99
Manual transmission .................... 96
Manual transmission automated . 97
Manual windows ..........................30
Messages ..................................... 75
Mirror adjustment ........................... 8
Mirrors .................................... 28, 29
Misted light covers .......................82
N
New vehicle running-in ................94
Number plate light .....................126
O Object detection systems ...........108
Octane rating .............................. 154
Odometer ..................................... 65
Oil ............................................... 117
Oil, engine .......................... 147, 152
Oil level ......................................... 67Oil pressure.................................. 73
Outside temperature ....................63
Overcab storage ..........................56
Overrun cut-off ............................. 95
P Parking .................................. 17, 95
Parking assist ............................ 108
Parking brake ............................ 102
Particulate filter ............................. 95
Performing work ........................116
Pollen filter ................................... 91
Power outlets ............................... 64
Power steering fluid ...................120
Power windows ............................ 30
Preheating ................................... 72
Puncture ..................................... 136
R Radio Frequency Identification (RFID) ..................................... 165
Radio remote control ...................18
Reading lights .............................. 83
Rear air conditioning system .......86
Rear doors ................................... 24
Rear fog light ............................... 73
Rear fog lights ............................. 82
Rear heating system .................... 86
Rear seats .................................... 36
Rear windows .............................. 30

169
Rear window wiper/washer .......... 62
Recommended fluids and lubricants ........................ 147, 152
Refuelling ................................... 110
Remote control ............................. 18
Reversing light ........................... 126
Reversing lights ........................... 82
Roof rack ..................................... 58
S Safety belts ................................... 39
Safety net .................................... 57
Seat adjustment ....................... 7, 34 Seat belt ........................................ 8
Seat belt reminder .......................70
Seat belts ..................................... 39
Seat heating ................................. 35
Seat position ................................ 33
Second row seats ........................36
Selector lever ............................... 97
Service ................................. 92, 146
Service display ............................ 67
Service information ....................146
Service vehicle soon .................... 71
Side airbag system ......................46
Sidelights ...................................... 79
Side turn signal lights ................126
Sliding door .................................. 24
Spare wheel ............................... 138
Speedometer ............................... 65Starting and operating ..................94
Starting off ................................... 16
Starting the engine ................94, 97
Steering ........................................ 93
Steering column controls .............61
Steering wheel adjustment ......9, 60
Steering wheel controls ...............60
Stop engine ................................. 71
Storage ......................................... 55
Storage compartments .................55
Sun visors .................................... 31
Symbols ......................................... 4
T
Tachograph .................................. 78
Tachometer ................................. 66
Tailgate ......................................... 25
Tail lights ................................... 125
Technical data ............................ 154
Three-point seat belt .................... 40
Tools .......................................... 131
Top-tether fastening eyes ............54
Tow bar....................................... 112
Towing ................................ 112, 141
Towing another vehicle .............142
Towing a trailer ........................... 113
Towing equipment .....................113
Towing eye ................................. 141
Towing the vehicle .....................141
Traction Control system ............. 102Trailer coupling ........................... 112
Trailer towing ............................. 113
Transmission ............................... 16
Transmission display .............68, 97
Tread depth ............................... 132
Trip computer .............................. 76
Triple-Info-Display .......................74
Turn and lane-change signals .....81
Turn signal ................................... 70
Tyre chains ................................ 133
Tyre changing ............................. 136
Tyre designations ......................131
Tyre pressure ............................ 132
Tyre pressures ........................... 163
Tyre repair kit ............................. 133
Tyres .......................................... 131
Tyres and wheel size, changing. 133
U Ultrasonic parking assist............. 108
Upholstery .................................. 144
Upshift .......................................... 72
Using this manual ..........................3
V
Vehicle battery ........................... 121
Vehicle checks............................ 116
Vehicle data ................................ 152
Vehicle data recording and privacy ..................................... 164
